Machine control – Operating elements
Overview of control sections
Item Symbol
13
14
15
3.1.3

Control section C

Item Symbol
1
2 Balance AC balance rotary knob (JOB 0)
3
12
Description 0
Gas pre-flow time signal light
activArc TIG welding process
•
Switch activArc <>
•
Correct the activArc characteristic
Signal light, two colour
Green: AC frequency (TIG)/pulse frequency (MMA)
Red: Pulse frequency (TIG, kHz pulsing)
Description 0
AC frequency rotary knob (JOB 0)
Tungsten electrode diameter rotary knob (JOB 0)
> see 4.1.20 chapter
Figure 3-4
