Solar Power Connection - Optional - Maximum Controls Max Megatron 1400 Installation And Owner's Manual

solar power connection - optional

Refer to Solar application guide.
NOTE: Cover solar panel from
sunlight BEFORE wiring plug to
solar panel to prevent a shock
from occurring.
Max Solar
Power Kit
(Sold separately)
Wiring operator
Pos + Red
Polarity Matters!
GND Black
P O
W E
R / S
O L
I N A R
Connect to
POWER/SOLAR
IN
MAX BC-7 Battery Module
(Approximately 450 cycles using only battery power)
