Summary of Contents for DAITEM SH271AX
- Page 2 2. Unclip the base plate cover. the control panel. If you are adding the siren to an existing system, use the guarantee sticker provided with this product. SH271AX SH271AX Pozidriv 2 Power supply The lithium battery pack is clipped into position (see diagram below). An arrow...
- Page 3 • Example: programming of 1st detector allocated to Group 2 with immediate triggering. “detector 1” “group?” “time delay?” “beep, detector 1 group 2, immediate” IMPORTANT: the control panel indicates then an error by emitting 3 short beeps. When this happens programming should 10 s max.
- Page 4 Checking configuration: the contact is checked by selecting the Parameter n° and then checking the number of times the indicator lamp flashes. Start Press 3 times to select Press once to 2 flashes confirm that the roller the external contact accept selection shutter blind contact has been correctly configured...
-
Page 5: Choosing The Best Place
Example 4, connection of a roller shutter blind sensor (mainly used in the continent and not the UK) 1 2 3 To ensure detector radio range: • do not run the roller shutter blind wire along the detector, • change the cable path and/or its length if the radio range is not satisfactory. IMPORTANT: connecting a roller shutter blind sensor does not ensure anti-tamper protection of the loop. -
Page 6: Connecting External Contacts
3. If necessary use the spacer supplied for the magnet holder or position a Cover spacer below the normally closed detector. Fix the magnet holder base, place the magnet inside the cover and clip it to the base. Magnet To unclip the magnet holder cover, insert a small flat-headed screwdriver into the slot provided and turn. - Page 7 Piezo-electric glassbreak sensor • NC loop type. Detection: up to 2.5 m • Suitable for all types of glass with a thickness of up to 6 mm. from the point of impact • Detection: up to 2.5 m from the point of impact. •...
-
Page 8: Maintenance
• The lithium battery pack must be replaced by the same type of pack with the same technical characteristics (BatLi31 3 V - 1 Ah). • We advise you to use the DAITEM BatLi31 pack available in the catalogue in order to guarantee individual safety and equipment reliability.
