- Page 1 (upgraded for e-Nova applications)
-
Page 2: Table Of Contents
The user must not attempt to access the siren’s internal parts, except areas described in this manual. If the user does access these parts, the product guarantee will be considered null and void and DAITEM shall not be held responsible for any problems. Touching the siren’s internal parts and/or electronic components can damage the product. - Page 3 171-21X/175-21X: motion 172-21X: corridor detector (9 173-21X: curtain detector (9 detector (19 beams, 12 m, 90°) is beams, 22 m, 12°) is designed for beams, 12 m, 8°) is designed for designed to protect rooms at risk unavoidable passageways, and the protection of large surfaces (lounge, main bedroom, etc.).
-
Page 4: Preparation
2. Preparation 2.1 Opening the detector 2.2 Power supply Open the detector casing by Connect the lithium battery pack according to the arrow. loosening the screws using a cross-head screwdriver. Test key Alignment arrow Detection lens Removal tab 171-21X 171-21X Test LED indicator Guarantee sticker:... -
Page 5: Programming
3. Programming 2. Programme the device as follows IMPORTANT: during recognition programming, the product to be “beep, detector X, “détecteur X” “group?” “time delay?” programmed for use with the control group Y immediate panel does not need to be placed next (or delayed or combined)”... -
Page 6: Configuration
4. Configuration • Choosing detection sensitivity or alarm level: IMPORTANT: the casing must be open when configuring the detector. Choice Parameter Parameter Technical data of function n° value Detection edge triggering: not recommended sensitivity for detector 171-21X/175-21X edge triggering (factory setting): recommen- ded for interior using detector 171-21X/175-21X Alarm level Intrusion (factory setting) - Page 7 Configuration example: setting the detector for an alarm level when a full prealert is triggered: Parameter n° 4, Parameter value 2. Start Press 4 times Press once Press 2 times to select to select the alarm level to accept the full prealert level selection Checking configuration: check the alarm level by selecting the Parameter N°...
-
Page 8: Installing The Detector
5. Installing the detector IMPORTANT: make sure there is a distance of at least 2 meters between each product, except between two detectors. 5.1 Choosing the best place The motion detector must be placed: • inside the building, • 2.20 m above ground level •... -
Page 9: Fixing Method
Fixing method Order in which to assemble parts The detector can be fixed to a wall in 3 ways: • on a swivel bracket, • flat against the wall, Pin n° 1 • in a corner. There is an anti-tamper pin for each type of fixing method: •... - Page 10 Fixing the detector on a swivel bracket Fixing the detector flat against the wall 1. Hold the back plate against the wall in the desired 1. Drill through the two pre-drilling holes in the base of position and mark where to drill the holes. the motion detector.
-
Page 11: Directing And Testing The Detector
Fixing the detector in a corner 5.3 Directing and testing the detector 1. Drill through the two pre-drilling holes in the base of The infrared detector has a test mode for checking: the detector. • the power supply: the LED indicator lamp lights up 2. - Page 12 171-21X 172-21X 175-21X 173-21X IMPORTANT: at the end of the test period, the detector automatically switches back to normal operating mode: • detector inhibited for 90 sec. after detection, • the test LED indicator lamp is no longer lit when movement is detected.
-
Page 13: Maintenance
(3.6 V - 4 Ah). • We advise you to use the DAITEM BatLi25 pack available in the catalogue in order to guarantee individual safety and equipment reliability. • Dispose of the waste lithium power pack in an appropriate... -
Page 14: Technical Data
Infrared motion detector Infrared detection • 171-21X/175-21X: 12 m, 90°, motion detector • 172-21X: 22 m, 12°, corridor detector • 173-21X: 12 m, 8°, curtain detector Fixing methods • on a swivel bracket • flat against the wall • in a corner... - Page 15 • Low Voltage Directive: 2006/95/CE • ROHS Directive: 2002/95/CE in compliance with the following harmonised European Standards: Références produits 171-21X 172-21X 173-21X 175-21X EN 300 220-2 V2.1.2 EN 300 330-2 V1.3.1 EN 50130-4 (95) + A1 (98) + A2 (2002) EN 55022 &...
