INFORMATION FOR USE WHEN ORDERING SPARES:
Model:__________________________________
Serial Number: ___________________________
Colour: _________________________________
GUARANTEE
Conditions of Guarantee
Your ESSE cooker is guaranteed against defects arising from faulty manufacture for two years, subject to the following express conditions:
A suitably qualified person must install the cooker, and upon installation the details must be recorded on the warranty card and
registered with ESSE by returning the correctly completed card. The guarantee period commences upon delivery of the cooker.
The cooker has been used for normal domestic purposes only, and in accordance with the manufacturer's instructions.
The cooker has not been serviced, maintained, repaired, taken apart, or tampered with by any person not authorised by us.
An approved dealer or representative must undertake all service work under this guarantee.
Any cooker or defective part replaced shall become the Company's property.
Exclusions
This guarantee does not cover:
Damage or calls resulting from transportation, improper use or neglect.
Parts deemed to be replaceable in the normal usage of the cooker; e.g. thermostats, elements, induction hob elements, fans etc.
Control Panel Markings; these can become damaged if a hard abrasive is used.
Ceramic Glass Hob; any inherent flaw or defect in the ceramic glass will be immediately evident.
Enamel damage; the vitreous coating on your cooker is in effect an extremely thin layer of glass and as such displays all the characteristics
of glass. It can easily be damaged by impact, or by spillage of cold liquids onto a hot surface. Such damage cannot be covered under
this guarantee. (See also intermittent use of your cooker, below).
This guarantee is personal to the original purchaser and is non-transferable.
Intermittent Use of Your Cooker
In the event of intermittent use and prolonged shutdown, it should be noted that in some circumstances enamel may be displaced due to
ingress of damp. Whilst this is rare, it is most likely to occur in situations where the unused cooker remains in an unheated property. There is a
layer (known as the groundcoat) between the vitreous enamel surface and the cast iron. Groundcoat is porous and if exposed (e.g. after a chip
in the vitreous enamel coat), may allow damp to penetrate behind the vitreous enamel and spread through the groundcoat. Surface oxidisation
of the cast iron may thereafter occur, causing the vitreous enamel to fall off. Such damage will not be covered by your warranty. We
recommend that a light coating of petroleum jelly be applied to any damaged areas when the cooker is not in use to help keep out the damp.
Customer Care
In the event you should require spare parts, please order through your ESSE dealer. Alternatively from our online spares store.
Should you have cause for dissatisfaction with your cooker, you should contact your ESSE dealer, who will, in most instances, be able to
offer you immediate assistance. You will be required to give the following details:
Your name, address and postcode.
Your telephone/contact details.
Clear and concise details of the fault.
Model and serial number of the cooker (found on the data plate inside the warming cupboard on the back face).
Purchase date (please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls).
We will then check that we have an accurately completed warranty card, if not then any work carried out may be charged.
Esse Engineering Limited, Long Ing, Barnoldswick, Lancashire BB18 6BN
Tel: 01282 813235 Fax: 01282 816876 e-mail: enquiries@esse.com
Website: http://www.esse.com On-line Store: http://www.esseparts.com
10/10 (PP)
ESSE Electric Cooker
INSTR.CK-EC2i/u
OPERATING & INSTALLATION INSTRUCTIONS
OPERATING & INSTALLATION INSTRUCTIONS
OPERATING & INSTALLATION INSTRUCTIONS
OPERATING & INSTALLATION INSTRUCTIONS
MODEL: INDUCTION EC2i
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INDUCTION EC2i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Esse INDUCTION EC2i

  • Page 1 In the event you should require spare parts, please order through your ESSE dealer. Alternatively from our online spares store. Should you have cause for dissatisfaction with your cooker, you should contact your ESSE dealer, who will, in most instances, be able to offer you immediate assistance.
  • Page 3: Door Hinge Adjustments

    INTRODUCTION DOOR HINGE ADJUSTMENTS We are pleased that you have chosen an ESSE cooker. We would ask you to read the following 1. Remove upper & lower locking grub screws from hinges using " allen key provided. instructions very carefully. Correctly installed and operated, your ESSE cooker will give satisfactory 2.
  • Page 4: Your Cooker

    To Remove the Fan Unit from the Main Oven YOUR COOKER Unscrew the six screws around the unit, pull the unit out with the wires attached, being careful no to allow them to fall back into the oven. Remove the fan guard by unscrewing the fixing screws on the top and two on the bottom of the unit.
  • Page 5: General Cleaning

    General Cleaning SPACING & DIMENSIONS Enamel is simply a coloured glass coating added to the metal to give a durable and hygienic finish. It can All dimensions are shown in mm. be damaged by scratching or by a sudden application of cold liquids onto its surface when hot. Clean with a cloth and soapy water, preferably while the cooker is still warm.
  • Page 6: Connecting The Cooker

    CONNECTING THE COOKER WARMING CUPBOARD For your own safety, we recommend that a competent person, such as a qualified electrician, install your The warming cupboard is not independently heated but picks up heat from the top and bottom cooker. The cooker should be installed in accordance with the latest Edition of the IEE Regulations. oven.
  • Page 7: Child Lock Function

    GRILL Never use utensils with rough bases. • It is important that any spillage is dealt with before the hob is used again, otherwise it may become • baked on. Accessible parts may become hot when the grill is in use. Children should be kept away. Remove any spillage of high sugar content, such as jam, immediately.
  • Page 8: Operation

    OVENS Fig. 4 Operation The large top oven is fan assisted and the smaller bottom oven is conventional, both are controlled thermostatically. To switch one of the ovens 'ON', turn the corresponding knob on the control panel (see Fig. 4) clockwise to the required temperature marking. The temperature markings on the control panel are in degrees Celsius.
