INSTALLATION INSTRUCTIONS
HB0078
CPM SERIES
!
INTENDED FOR DOMESTIC COOKING ONLY
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 12 AND 13.
Venmar Ventilation Inc., 550 Lemire Blvd. Drummondville QC J2C 7W9 1-800-567-3855
REGISTER YOUR PRODUCT ONLINE AT: www.bnv.ca
For additional information - visit www.venmar.ca
08576 rev. 12
Advertisement
Table of Contents
Related Manuals for Venmar CPM series
Summary of Contents for Venmar CPM series
- Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 12 AND 13. Venmar Ventilation Inc., 550 Lemire Blvd. Drummondville QC J2C 7W9 1-800-567-3855 REGISTER YOUR PRODUCT ONLINE AT: www.bnv.ca For additional information - visit www.venmar.ca...
-
Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following
10. To reduce the risk of fire and electrical shock, the Venmar Connaisseur CPM1 and CPM2 Series models should only be installed with their own built-in blowers. - Page 3 CPM1 CPM2 POWER PACK SYSTEMS - ODEL ODEL ODEL ODEL (8” R (10’’ R OOF CAP OUND WALL CAP IGH CAPACITY ROOF CAP OUND WALL CAP ODEL 8” R OUND (10” R OUND ADJUSTABLE ELBOW ADJUSTABLE ELBOW ODEL 8” R OUND (10”...
-
Page 4: Prepare Installation
1. PREPARE INSTALLATION WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. NOTE: Before proceeding to the installation, check the contents of the box. If items are missing or damaged, contact the manufacturer. Make sure that the following items are included: - Power Pack - Accessories:... - Page 5 3. CUSTOM HOOD PREPARATION ( ’ CONT To minimize the gap around the power pack, take actual width and depth measurements of power pack and add 1/16” to get D and E measurements. Cut the hole in the bottom of the cabinet according to dimensions. See chart and illustration for details. UTOUT OWER DIMENSIONS...
- Page 6 6. REMOVE GREASE DRIP RAIL A. Lift grease drip rail to disengage it from the bottom panel. B. Slide grease rail all the way to the left or right ( ) and lift the opposite end to disengage the other end from ...
-
Page 7: Connect Wiring
10. INSTALL ADAPTER AND DAMPER (CPM2 MODELS ONLY) Using 2 no. 8 x 3/8” screws from parts bag, assemble the adapter on the top of the power pack. OUNTING SCREW LOCATIONS Seal all joints with metal foil duct tape to eliminate air leaks. HJ0026 Install 10”... - Page 8 12. REMOVE BLOWER(S) In order to ease the power pack alignment with existing ductwork, unplug and disassemble the blower(s) from the power pack before installing the custom hood. Unplug the blower(s) HE0085 CPM1 M ODELS EFT SIDE MOUNTING SCREW LOCATIONS Using a 5/16”...
- Page 9 13. INSTALL POWER PACK CAUTION Take care not to kink ducting when installing the power pack. Using provided no. 8 x 1/2” chrome plated screws, install the power pack inside the custom hood. Start with 2 screws on front corners, then use 4 screws for sides and use the remaining ones to finalize securing the front power pack.
-
Page 10: Reinstall Bottom Panel
14. REINSTALL BLOWER(S) ( ’ CONT LL MODELS Plug the blower(s) in. HE0085 15. REINSTALL BOTTOM PANEL Lift the bottom panel and engage the power pack metal tabs in Secure the bottom panel to the power pack using its screws bottom panel slots, as shown in details A and B below. -
Page 11: Reinstall Baffle Filters
17. REINSTALL BAFFLE FILTERS CAUTION Remove protective plastic film covering filters before installing them. It is recommended to install side filters first and finish with center one(s). Insert one end of the filter into the upper channel of the power pack. ... -
Page 12: Use And Care
19. USE AND CARE Baffle Filters The baffle filters should be cleaned frequently. Use a warm detergent solution. Wash more often if your cooking style generates greater grease — like frying foods or wok cooking. Remove baffle filters by pushing them towards the back of hood and rotating filters downward. Baffle filters are dishwasher safe. Allow filters to dry completely before reinstalling them in the power pack. -
Page 13: Operation
20. OPERATION Always turn your hood on before you begin cooking to establish an air flow in the kitchen. Let the blower run for a few minutes to clear the air after you turn off the range. This will help keep the whole kitchen cleaner and brighter. HC0056 HC0038 1) H... -
Page 14: Wiring Diagram
21. WIRING DIAGRAM WARNING Risk of electrical shock. Electrical wiring must be done by qualified personnel in accordance with all applicable codes and standards. Before connecting wires, switch power off at service panel and lock service disconnecting means to prevent power from being switched on accidentally. -
Page 15: Warranty
To contact Venmar Ventilation Inc. warranty service call 1-800-567-3855 in Canada. In order to qualify for a warranty claim, the owner of a Venmar Connaisseur CPM Series range hood must have the model and serial number along with a proof of the original purchase date. -
Page 16: Service Parts
CPM1 & CPM2 Series EPLACEMENT ARTS AND EPAIRS In order to ensure your unit remains in good working condition, you must use Venmar Ventilation Inc. genuine replacement parts only. Venmar Ventilation Inc. genuine replacement parts are specially designed for each...
