Page 1: Installation Instructions
GLASS PANELS INSTALLATION INSTRUCTIONS APPLIES TO THE FOLLOWING RANGE HOOD SERIES C700, CC700, CIC700, CIS700, IU600ES, IB700, IC700, IC700ES, IK700 IS700 Venmar Ventilation Inc., 550 Lemire Blvd. Drummondville QC J2C 7W9 1-800-567-3855 www.venmar.ca 09530 Rev. 02... - Page 2 FTER A POWER FAILURE OR DURING THE RANGE HOOD POWER UP SECOND BOOTING SEQUENCE IS EXECUTED AIT FOR THE CONTROL BACKLIGHTING TO TURN OFF BEFORE USE C700 S ERIES F THE RANGE HOOD IS NOT INSTALLED YET REFER TO STEP...
- Page 3 C700 S ’ ERIES CONT Carefully remove the new glass panel from its packaging. Remove new glass panel nuts (factory installed) from both studs and set aside. If need be, remove current glass panel retaining nuts from both studs. Discard...
- Page 4 IU600ES S ’ ERIES CONT If need be, remove current glass panel retaining nuts from both studs. Discard glass panel and nuts. Insert new glass panel studs in hood front holes. While holding glass panel, pre-tighten previously removed nuts by hand. Ensure glass panel is flush with top of hood and centered from side-to-side.
- Page 5 CIC700 IK700 S ’ ERIES CONT If need be, remove current glass panel retaining nuts from both studs. Discard glass panel and nuts. Insert new glass panel studs in appropriate hood holes (some parts not illustrated to ease understanding). NOTE: Install the glass panel with the control pictogram on the front of the hood.
- Page 6 CC700 CIS700 S ’ ERIES CONT Carefully remove the glass panel from its packaging. Remove new glass panel nuts (factory installed) from both studs and set aside. If need be, remove current glass panel retaining nuts from both studs. Discard glass panel and nuts.
- Page 7 IB700, IC700 IC700ES S ’ ERIES CONT Carefully remove the glass panel from its packaging. Remove new glass panel nuts (factory installed) from both studs and set aside. If need be, remove current glass panel retaining nuts from both studs.
- Page 8 IS700 S ’ ERIES CONT RONT GLASS PANEL STUDS LOCATION If need be, remove current glass panel retaining nuts from both studs. Discard HD0568 glass panel and nuts. Insert new glass panel studs in appropriate hood holes. NOTE: Install glass panel with...
