Telnet Console

8.1

Introduce

8.1.1 Basic structure
User may use telnet command to access and manage IP phone.
IP100 adopts tree structure for telnet. Every node contains its sub-nodes or local command.
User can type "help" or "?" whenever to see sub-nodes and all local command under current
node.
Besides local command, there are some global commands can be used in each node.
8.1.2 Basic command
Logout: exit telnet mode.
Write: save current settings.
Type sub-nodes name in current node to switch to sub-node.
Type "!" or "exit" in current node to return to parent-node.
Type "help" or "?" can see all sub-nodes and all local command under current node, every
help item has comments such as <command> or <node> to distinguish sub-nodes and local
command. Type "help" or "?" in command can see all parameters using in this command.
When typing node name or command, user no need to key the full name, use TAB button will
make it more efficient.
There are two types in command parameters: optional and required. "required" parameter
use "-" as prefix and "optional" use "_" as prefix. User may type "-" or "_" then press TAB
button for complementarily.
Topcom IP100
Reg Status Public Reg
Private Reg
Detect-server
Dtmf-mode
Interval-time
Swap-server
RFC-version
Signal-Port
Stun Switch
Addr
Port
Expire Time
Code
Handdown-time
Dtmf-Volume
Input-volume
Output-Volume
Syslog Switch
Server-IP
Server-Port
1. Save
2. Reboot
3. Set Default
