Summary of Contents for Volvo S90

Page 1 O W N E R ' S M A N U A L...
Page 3 VÄLKOMMEN! We hope you will enjoy many years of driving pleasure in your Volvo. The In order to increase your enjoyment of your Volvo, we recommend that car has been designed for the safety and comfort of you and your pas- you read the instructions and maintenance information in this owner's sengers.
Page 4: Table Of Contents
Navigating in the digital owner's manual Whiplash Protection System Folding up the integrated booster cushion* Owner's Manual in mobile devices Pedestrian Protection System Folding down the integrated booster Volvo Cars support site Seatbelt cushion* Reading the owner's manual Seatbelt tensioner Recording data Fastening/unfastening a seatbelt...
Page 5 INSTRUMENTS AND CONTROLS Instruments and controls, left-hand Voice recognition control of climate Activating/deactivating main beam drive car control Active bending lights Instruments and controls, right-hand Voice recognition and map navigation Adapting the beam pattern from the drive car Manual front seat headlamps Driver display Power front seat*...
Page 6 CLIMATE CONTROL ® Climate control Activating/deactivating heating of HomeLink steering wheel* ® Climate control - sensors Programming HomeLink Parking climate* Perceived temperature Trip computer Starting/stopping preconditioning* Air quality Show trip data in the driver display Timer for preconditioning* Passenger compartment filter Show trip statistics in the centre display Setting the timer for preconditioning* Clean Zone Interior Package*...
Page 7 LOADING AND STORAGE LOCKS AND ALARM Passenger compartment interior Remote control key Type approval for the remote control key system Tunnel console Remote control key range Electrical sockets Red Key - Restricted remote control key* Using the cigarette lighter* Antenna locations for the start and lock system Emptying ashtrays* Locking/unlocking from the outside...
Page 8 DRIVER SUPPORT Speed-dependent steering force Limitations of Distance Warning* Pilot Assist-2* Electronic stability control Adaptive cruise control* Activating and starting the Pilot Assist-2* 303 Sport mode for electronic stability control 261 Activating and starting the adaptive Managing the speed for Pilot Assist-2* cruise control* Symbols and messages for elec- Setting the time interval for...
Page 9 STARTING AND DRIVING Rear Collision Warning Park Assist* Alcohol lock* Blind Spot Information* Activating/deactivating Parking Bypass of the alcohol lock* assistance* Activate/deactivate Blind Spot Before starting the engine with the Information* alcohol lock Limitations of Parking assistance* Limitations of Blind Spot Information* Ignition positions Messages for Park Assist* Starting the car...
Page 10 AUDIO AND MEDIA Brake assistance Audio and media Extendable/retractable towing brackets* Auto braking after a collision Apps Towing bracket specifications* Parking brake Audio settings Driving with a trailer Using the parking brake Radio Driving with a trailer under special conditions In the event of a fault in the parking Changing and searching radio stations brake...
Page 11 WHEELS AND TYRES Tyres Dimension designation for tyre Settings for Apple CarPlay* Technical specifications for media Tyres' rotation direction Tread wear indicators on the tyres Phone Connect phone Checking the tyre pressures Connecting/disconnecting the phone Tyre pressure monitoring Check tyre pressure with the tyre Managing phone calls pressure monitoring system Managing text messages...
Page 12 MAINTENANCE AND SERVICE SPECIFICATIONS Volvo service programme Filling washer fluid Type designations Car status Starter battery Dimensions Book service and repair Symbols on the batteries Weights Remote updates Support battery Towing capacity and towball load System updates Fuses Engine specifications...
Page 13 ALPHABETICAL INDEX Alphabetical Index...
Page 15 INTRODUCTION...
Page 16: Introduction
The owner's manual is available in the car's cen- On the Volvo Cars support site gation with exterior and interior tre display, as a mobile app and on the Volvo there are also video tutorials images of the car. The informa- Cars support site.
Page 17: Digital Owner's Manual In The Car
It is gory. The same article may also important that the car is maintained and appear in several catego- handled in accordance with Volvo's recom- ries. mendations in the owner's information. The digital owner's manual is accessed from the top view.
Page 18: Navigating In The Digital Owner's Manual
INTRODUCTION Navigating in the digital owner's Symbols and their meaning in the owner's Symbols and their meaning in the owner's manual manual menu manual menu The digital owner's manual can be accessed Exterior and interior over- Leads to short video tutori- from the centre display in the car.
Page 19 INTRODUCTION Searching using categories Favourites 1. Press and then select Exterior The articles in the owner's Located here are the articles Interior manual are structured into that have been saved as > Exterior/interior images are shown with main categories and subcate- favourites.
Page 20: Owner's Manual In Mobile Devices
Reading the owner's manual (p. 19) app. Alternatively, you can search for "Volvo manual" in • Volvo Cars support site (p. 19) the App Store or Google Play. The app contains a video along with exterior and interior images where different parts of the car are highlighted with so-called hotspots, which lead to articles about the area in question.
Page 21: Volvo Cars Support Site
Create a personal Volvo ID, log in to My Volvo about where and how to seek professional help and functions, Volvo On Call (VOC)*, the naviga- Web and get an overview of service, agreements will be missing.
Page 22 Examples of menu texts and message texts: In the event of uncertainty over what is standard Phone New message or an option/accessory, contact a Volvo dealer. Decals Special texts The car contains different types of decal which are designed to convey important information in a WARNING simple and clear manner.
Page 23 • Volvo Cars support site (p. 19) illustration that describes the item. the car. The information that applies to your particular car is available on the respective Bulleted lists decals for your car.
Page 24: Recording Data
As part of Volvo's safety and quality assurance, graphic location of the accident or near-miss sit- out the vehicle owner's consent. To comply with certain information about the vehicle's operation, uation.
Page 25: Important Information On Accesso- Ries, Extra Equipment And Diagnostic
Volvo ID provides access to a wide range of per- diagnostic socket sonalized Volvo services online. Incorrect connection and installation of accesso- It is possible to create a Volvo ID from the car, My ries, extra equipment or software/diagnostic Volvo or the Volvo On Call mobile app . Certain...
Page 26 Registering your Volvo ID to the car 3. Follow the instructions that are automatically ways. If the Volvo ID is created with My Volvo or sent to the specified email address. If you created your Volvo ID via the web or the...
Page 27: Drive-E - Cleaner Driving Pleasure
Volvo Car Corporation is constantly working on the development of safer and more efficient Environmental care is one of Volvo Cars’ core val- inside a Volvo is, for example, cleaner than the air Fuel consumption ues and influences all operations. The environ- outside thanks to the climate control system.
Page 28 Contributing to a better environment ised Volvo workshop is recommended. An energy-efficient and fuel-efficient car not only The material used in the interior of a Volvo is contributes to a reduced impact on the environ- carefully selected and has been tested in order to...
Page 29 INTRODUCTION Related information • Drive modes* (p. 394) • The owner's manual and the environment (p. 32) • Driving economically (p. 416) • Fuel consumption and CO2 emissions (p. 561) • Air quality (p. 176) * Option/accessory, for more information, see Introduction.
Page 30: Intellisafe-Driver Support
IntelliSafe-driver support ing the driver and giving corrective steering inter- ventions if the car is about to cross a lane side IntelliSafe is the Volvo Cars concept concerning line. car safety. It comprises a number of systems that contribute to making a car journey safe, to...
Page 31: Sensus - Connection And Maintenance
INTRODUCTION Sensus - connection and Information when it is needed, where it maintenance is needed The different displays in the car provide informa- Sensus makes it possible to surf the Internet, tion at the right time. The information is shown in use different types of apps and make the car a different locations based on how it should be pri- Wi-Fi hotspot.
Page 32 INTRODUCTION Different types of information are shown in different displays depending on how the information should be prioritised. speed information and navigation* information. Driver display Head-up display* Road Sign Information and incoming phone calls are also shown in the head-up display. The dis- play is operated via the right-hand steering wheel keypad and via the centre display.
Page 33 INTRODUCTION • Many of the main functions of the car are con- Driver display (p. 89) trolled from the centre display, a touch screen • Voice recognition (p. 111) which reacts to touch. The number of physical • Online car* (p. 456) buttons and controls in the car is therefore mini- •...
Page 34: The Owner's Manual And The Environment
INTRODUCTION • The owner's manual and the Windows, glass and mirrors Using windscreen wipers (p. 143) environment • Windscreen and headlamp washers (p. 145) The car contains controls for windows, glass The Owner's Manual is printed on paper origi- and mirrors. Some of the windows in the car are nating from controlled forests.
Page 35: Overview Of The Centre Display
INTRODUCTION Overview of the centre display Many of the car's functions are controlled from the centre display. Get an overview of the centre display and its features.
Page 36 INTRODUCTION Three of the centre display's basic views. Swipe right or left to access the function or app view respectively Function view - car functions that are acti- tions are also so-called trigger functions, vated/deactivated with a press. Certain func- which means they open a window with set- The views are reversed for right-hand drive cars.
Page 37 INTRODUCTION ting options. Examples of such are Camera Extra subview - recently used apps/car func- and parking functions. tions that do not belong in any of the other subviews. Tap on the subview to expand it. Home view - the first view that is shown when the screen is started.
Page 38: Operating The Centre Display
INTRODUCTION Operating the centre display views, marking objects, scrolling in a list and mov- IMPORTANT ing apps can be performed by touching the Many of the car's functions are controlled and Do not use sharp objects on the screen as screen in different ways.
Page 39 INTRODUCTION Procedure Execution Result Drag Changes between different views, scrolls a list, text or view. Hold depressed and drag in order to move apps or map points on the map*. Drag horizontally or vertically across the screen. Swipe/drag quickly Changes between different views, scrolls a list, text or view. Drag horizontally or vertically across the screen.
Page 40 INTRODUCTION Turn off the screen and reactivate it 2. Reactivate the screen - briefly tap on the NOTE home button. In home view standard mode - briefly press > The view that was displayed before the the home button. An animation that describes screen was switched off will be shown access to the different views is shown on the again.
Page 41 INTRODUCTION • Using the controls in the centre display Downloading, updating and uninstalling apps NOTE (p. 462) Hide the apps that you rarely or never use by • Using the keyboard in the centre display moving them to the bottom, off the visible (p.
Page 42: Navigating In The Centre Display's Views
INTRODUCTION Navigating in the centre display's An app/car function selected from the app/func- NOTE views tion view starts in the respective subview of the The first time the car is used, some of the home view. For example FM radio starts in the There are five different basic views in the centre home view's subviews have no content.
Page 43 INTRODUCTION Expanding a subview from default mode Standard mode and expanded mode of a subview in the centre display.
Page 44 INTRODUCTION Expanding a subview: In expanded mode, open the Status bar app in full screen - press on The activities in the car are shown at the top of – Press anywhere on the subview. When a the symbol. the screen. Network/connection information is subview is expanded, the fourth subview in shown on the left-hand side of the status bar, the home view is temporarily forced away.
Page 45 INTRODUCTION Leave the top view - press outside the top view Press the symbol in the centre of the Application view or press at the bottom of the top view and drag climate row to open the climate view upward. The underlying view is then visible and and gain access to more climate set- available for use again.
Page 46 INTRODUCTION app view, such as the number of unread text Function view Depending on the amount of functions, it is also messages for Messages possible here to scroll downward in the view. Do this by swiping/dragging from the bottom and up. Tap on an app to open it.
Page 47: Symbols In The Centre Display's Status Bar
INTRODUCTION Symbols in the centre display's Change settings for the centre Symbol Specification status bar display Remote diagnostics active. Overview of the symbols that can be shown in The centre display is started automatically when the centre display's status bar. the driver's door is opened.
Page 48 INTRODUCTION the text is light. This alternative is the default for all themes. A light variant can also be selected, in which the background is light and the text is dark. This alternative can be useful in e.g. strong day- light.
Page 49: Function View With Buttons For Car Functions
INTRODUCTION Function view with buttons for car Different types of buttons basic views. Navigate to the function view from functions There are three different types of buttons for car home view by swiping from left to right across functions; see below: the screen All the buttons for car functions are located in the function view, one of the centre display's...
Page 50 INTRODUCTION The buttons' different modes The function is deactivated when the LED indica- tor is extinguished. When the LED indicator illuminates in green on a function or parking button, the function is acti- vated. When a function is activated, extra text with an explanation for certain functions is shown.
Page 51: Using The Keyboard In The Centre Display
INTRODUCTION Using the keyboard in the centre display The centre display keyboard makes it possible make entries using keys. It is also possible to "draw in" letters and characters on the screen by hand. Making entries with the keyboard The keyboard can be used to enter characters, letters and numbers, e.g.
Page 52 INTRODUCTION The image shows an overview of some of the buttons which may be shown in the keyboard. The appearance varies depending on language settings and the context in which the keyboard is being used.
Page 53 INTRODUCTION password, web address or email address Changing the keyboard language Row of suggested words or characters entry, all letters are automatically lower case The suggested words are adjusted as new To make it possible to switch between different unless otherwise set with the button. letters are being entered.
Page 54 INTRODUCTION Variants of a letter or character Writing characters/letters by hand on Switching between different languages in the screen the keyboard When a number of languages have been selected in Settings , the keyboard button (shown in context as number 7 in the illustration above) is used to switch between different lan- guages.
Page 55 INTRODUCTION • – There are several options for deleting/ Managing text messages (p. 454) Writing characters/letters by hand changing characters/letters: 1. Write a character/letter in the area for hand- • Changing system settings in the settings written letters (1). • view (p.
Page 57 SAFETY...
Page 58: Safety
The car is equipped with a number of sensors does not have full functionality. Volvo recom- that react in the event of an accident and activate mends that an authorised Volvo workshop different safety systems, such as different types should be contacted as soon as possible.
Page 59: Whiplash Protection System
If a rear seat backrest is folded down, the cor- Never modify or repair the seat or WHIPS responding front seat must be moved forward yourself. Volvo recommends that an author- so that it does not make contact with the ised Volvo workshop should be contacted.
Page 60: Pedestrian Protection System
Related information WARNING • Safety (p. 56) • An automatic alarm is sent via Volvo On Call*. Volvo recommends contacting an authorised • Volvo workshop in the event of any damage to Manual front seat (p. 116) The sensors are active at a speed of approx.
Page 61: Seatbelt Tensioner
Never modify or repair the seatbelts yourself. if the seatbelts are not used. seatbelt tensioners that can tension the seat- Volvo recommends that an authorised Volvo belts in critical situations and collisions. workshop should be contacted. It is important that the seatbelt lies against the...
Page 62: Fastening/Unfastening A Seatbelt
WARNING > A loud "click" indicates that the belt has locked. Never modify or repair the seatbelts yourself. Volvo recommends that an authorised Volvo workshop should be contacted. WARNING If the seatbelt has been subjected to a major Always insert the tongue of the seatbelt into load, such as in conjunction with a collision, the buckle on the correct side.
Page 63 SAFETY 3. In the front seats the seatbelt can be WARNING adjusted for height. Each seatbelt is designed for only one person. WARNING Remember not to clip or hook the seatbelt to hooks or other interior fittings, as this pre- vents the belt from tightening properly.
Page 64: Door And Seatbelt Reminder
SAFETY Door and seatbelt reminder Seatbelt reminder Rear seat The seatbelt reminder in the rear seat has two The system reminds unbelted occupants to wear subfunctions: a seatbelt, and also warns about an open door, bonnet, boot lid or fuel filler flap. •...
Page 65 If any of the airbags have deployed, the following • Inflatable curtain (p. 69) is recommended: • Recovering the car. Volvo recommends that it is transported to an authorised Volvo work- shop. Do not drive with deployed airbags. • Volvo recommends engaging an authorised Volvo workshop to handle the replacement of components in the car's safety systems.
Page 66: Airbags
WARNING airbag, occurs within tenths of a second. As a supplement to the seatbelts, the vehicle is Volvo recommends that an authorised Volvo equipped with airbags on the driver and passen- workshop should be contacted for repair. NOTE ger sides in the front seat.
Page 67 SAFETY WARNING WARNING Do not put objects in front of or above the Never allow anybody to stand or sit in front of dashboard where the passenger airbag is the front passenger seat. located. Never use a rear-facing child seat on the front passenger seat if the airbag is activated.
Page 68: Activating/Deactivating The Passenger Airbag
SAFETY Activating/deactivating the Activating the passenger airbag WARNING passenger airbag* If the car is not equipped with a switch to acti- The passenger airbag can be deactivated if the vate/deactivate the passenger airbag, the air- car is equipped with a switch, Passenger Airbag bag will always be activated.
Page 69 SAFETY 2. Confirm the message by pressing the right- Deactivating the passenger airbag 2. Confirm the message by pressing the right- hand steering wheel keypad's O button. hand steering wheel keypad's O button. Pull the switch outward and turn from ON (A) to OFF (B).
Page 70: Side Airbag
Volvo recommends the use only of car seat covers approved by Volvo. Other seat covers may impede the operation of the side airbags.
Page 71: Inflatable Curtain
WARNING Volvo recommends that engaging an author- panels are labelled with IC AIRBAG. ised Volvo workshop to check and restore the The inflatable curtain is a supplement to the A sufficiently violent collision trips the sensors car to normal status after Safety mode See seatbelts.
Page 72: Starting/Moving The Car After Safety Mode
2. Do not move the car further than necessary. WARNING If the car is in safety mode it must not be towed. It must be transported from its loca- tion. Volvo recommends that it is transported to an authorised Volvo workshop. Related information •...
Page 73: Child Safety
Child safety Child seats Related information • Safety (p. 56) Volvo has child safety equipment (child seats, The position of a child in the car and the choice • booster cushions and attachment devices) Child seats (p. 71) of equipment are dictated by the child's weight which is designed for fitting in this particular car.
Page 74 Volvo, are universally approved or are senger seat. buckle to open accidentally. semi-universal, and where the car is included on the manufacturer's vehicle list.
Page 75: Upper Mounting Points For Child Seats
SAFETY Upper mounting points for child Label for passenger airbag Related information • seats Child safety (p. 71) • Upper mounting points for child seats The car is equipped with upper mounting points (p. 73) for child seats on the rear seat's outer seats. •...
Page 76: Lower Mounting Points For Child Seats
SAFETY Lower mounting points for child The mounting points in the front seat are only WARNING seats mounted if the vehicle is equipped with a switch The child seat's upper straps must be routed to activate/deactivate the passenger airbag*. The car is equipped with lower mounting points through the hole in the head restraint leg for child seats in the front seat* and the rear before they are tensioned at the mounting...
Page 77: Using The Car's Seatbelts
SAFETY Table for location of child seats NOTE using the car's seatbelts Always read the section "Child seats" before The table gives a recommendation for which fitting a child seat in the car. child seats suit which locations, and for what size of child.
Page 78 Volvo recommends rear-facing child seat for children in this mass group. Volvo recommends: Volvo reversible seat in the front-facing position (type approval E5 04191); booster cushion with and without back (type approval E5 04216); Volvo booster cushion with backrest (type approval E1 04301169);...
Page 79: I-Size/Isofix Mounting Points
SAFETY i-Size/ISOFIX mounting points Related information • Child seats (p. 71) The car is equipped with i-Size/ISOFIX mount- • Upper mounting points for child seats (p. 73) ing points for child seats in the rear seat. • Lower mounting points for child seats (p. 74) i-Size/ISOFIX is a fixture system for car child •...
Page 80: Table For Location Of Isofix Child Seats
SAFETY Table for location of ISOFIX child The child seat must be approved in accordance NOTE seats with UN Reg R44 and the car model must be Always read the section "Child seats" before included in the manufacturer's vehicle list. The table gives a recommendation for which fitting a child seat in the car.
Page 81 Works for the installation of ISOFIX child seats that are semi-universally approved (IL) if the car is equipped with the ISOFIX console accessory (the accessory range varies depending on market). Volvo recommends: Volvo infant seat secured using the ISOFIX fixture system (type approval E1 04301146).
Page 82 SAFETY • Table for location of i-Size child seats (p. 81) • Table for location of child seats using the car's seatbelts (p. 75)
Page 83: Table For Location Of I-Size Child Seats
Suitable for i-Size "universal" child seat, front-facing and rear-facing. X: Not suitable for universally approved child seats. Volvo recommends rear-facing child seats for this group. Related information • Child seats (p. 71) •...
Page 84: Integrated Booster Cushion
15 and 36 kg and who are at least 97 Volvo recommends that repair or replacement cm in height. Lower position Upper position is only carried out by an authorised Volvo workshop. Do not make any modifications or Weight 22-36 kg 15-25 kg additions to the booster cushion.
Page 85 SAFETY Related information • Integrated booster cushion* (p. 82) • Folding down the integrated booster cush- ion* (p. 84) Press the booster cushion backwards to lock. Lift the booster cushion up at the front edge and press it back against the backrest to Upper position, start from the lower position: lock.
Page 86: Folding Down The Integrated Booster Cushion
SAFETY Folding down the integrated booster cushion* The integrated booster cushions on the outer seats in the rear seat can be folded down when not in use. NOTE It is not possible to adjust the booster seat from the upper position to the lower position. From the upper position, the booster seat must first be fully lowered into the seat cush- ion, and then folded up to the lower position.
Page 87 INSTRUMENTS AND CONTROLS...
Page 88: Instruments And Controls, Left-Hand
INSTRUMENTS AND CONTROLS Instruments and controls, left-hand Display/function/control Display/function/control drive car Right-hand steering wheel keypad Front reading lamps and interior lighting The overviews show where the displays and controls near the driver are located. Steering wheel adjustment Panorama roof* Horn Display in roof console Left-hand steering wheel keypad Manual dimming of interior rearview mir-...
Page 89: Instruments And Controls, Right-Hand Drive Car
INSTRUMENTS AND CONTROLS Instruments and controls, right- Display/function/control Display/function/control hand drive car Start knob Power windows, door mirrors The overviews show where the displays and controls near the driver are located. Adjusting front seat Drive modes* Parking brake Automatic braking when stationary Display/function/control Position lamps, daytime running lights, dipped beam, main beam, direction indi-...
Page 90 INSTRUMENTS AND CONTROLS Display/function/control Display/function/control Display/function/control Right-hand steering wheel keypad Front reading lamps and interior lighting Start knob Display lighting, unlocking the boot lid, Panorama roof* Drive modes* opening/closing the boot lid* Display in roof console Parking brake Bonnet opening Manual dimming of interior rearview mir- Automatic braking when stationary Horn...
Page 91: Driver Display
Road Sign Information WARNING If the driver display should extinguish, not illu- minate on activation/start or be fully or parti- ally illegible, the car must not be used. You should visit a workshop immediately. Volvo recommends an authorised Volvo workshop.
Page 92 INSTRUMENTS AND CONTROLS • Driver display, 8-inch Speedometer In the middle • Indicator and warning symbols • Cruise control and speed limiter information • Outside temperature gauge • Door and seatbelt information • Clock On the right • • Messages, in some cases with graphics Compass •...
Page 93: Indicator Symbols In The Driver Display
INSTRUMENTS AND CONTROLS Indicator symbols in the driver Driver display settings Related information • display Indicator symbols in the driver display Some settings for what is shown in the driver dis- (p. 91) play can be set in the app menu; see section The indicator symbols alert the driver that a func- •...
Page 94 This symbol illuminates when the emissions system. Drive to a work- front fog lamp is switched on. Active main beam off shop for checking. Volvo recom- Rear fog lamp on mends that an authorised Volvo The symbol lights up white when workshop is contacted.
Page 95: Warning Symbols In The Driver Display
The loss of brake fluid must be investigated Lane assistance and rain sensor by a workshop. Volvo recommends contacting Stability system White symbol: Lane assistance is an authorised Volvo workshop.
Page 96 Read the message If the bonnet, boot lid, fuel filler flap or any door is in the driver display. Volvo recom- not closed properly then the information or warn- mends that an authorised Volvo ing symbol and graphic illuminate in the driver workshop is contacted.
Page 97: Outside Temperature Gauge
INSTRUMENTS AND CONTROLS Outside temperature gauge Clock – Select Settings System Units select the required unit type, Metric The outside temperature gauge is shown in the The clock is shown in both the driver display and Imperial driver display. the centre display. Related information Location A sensor detects the temperature outside of the...
Page 98: License Agreement For The Driver Display
The following text is be set to obtain the right time zone. If Automatic REGENTS AND CONTRIBUTORS ``AS IS'' AND Volvo's agreement with the manufacturer/devel- Time is not selected, time and data are adjusted ANY EXPRESS OR IMPLIED WARRANTIES, oper.
Page 99 INSTRUMENTS AND CONTROLS Redistribution and use in source and binary WHETHER IN CONTRACT, STRICT LIABILITY, EXEMPLARY, OR CONSEQUENTIAL DAMAGES forms, with or without modification, are permitted OR TORT (INCLUDING NEGLIGENCE OR (INCLUDING, BUT NOT LIMITED TO, provided that the following conditions are met: OTHERWISE) ARISING IN ANY WAY OUT OF PROCUREMENT OF SUBSTITUTE GOODS OR THE USE OF THIS SOFTWARE, EVEN IF...
Page 100 INSTRUMENTS AND CONTROLS (Independent JPEG Group) licenses, which license applies to all files distributed in the that you understand and accept all the terms all encourage inclusion and use of free original FreeType archive, including all source of this license. software in commercial and freeware code, binaries and documentation, unless 2.
Page 101 INSTRUMENTS AND CONTROLS `FreeType Project', `FreeType Engine', libpng versions 1.0.7, July 1, 2000, through libpng versions 0.89, June 1996, through 0.96, `FreeType library', or `FreeType Distribution'. 1.0.13, April 15, 2002, are Copyright (c) May 1997, are Copyright (c) 1996, 1997 2000-2002 Glenn Randers-Pehrson and are Andreas Dilger Distributed according to the same 4.
Page 102 INSTRUMENTS AND CONTROLS merchantability and of fitness for any purpose. Also, the PNG logo (in PNG format, of course) is THE AUTHORS OR COPYRIGHT HOLDERS BE The Contributing Authors and Group 42, Inc. supplied in the files "pngbar.png" and LIABLE FOR ANY CLAIM, DAMAGES OR assume no liability for direct, indirect, incidental, "pngbar.jpg (88x31) and "pngnow.png"...
Page 103: Application Menu In The Driver Display
INSTRUMENTS AND CONTROLS Application menu in the driver SGI Free Software B License Version OR THE USE OR OTHER DEALINGS IN THE display SOFTWARE. 2.0. SGI FREE SOFTWARE LICENSE B (Version 2.0, Application menu (app menu) in the driver dis- Except as contained in this notice, the name of Sept.
Page 104: Using The Application Menu In The Driver Display
INSTRUMENTS AND CONTROLS Using the application menu in the Opening/closing the app menu Functions driver display – Press on open/close (1). Trip com- Selection of trip meter, selection The application menu (the app menu) in the (It is not possible to open the app menu puter of what to show in the driver dis- driver display is operated with the steering...
Page 105: Messages In The Driver Display And The Centre Display
INSTRUMENTS AND CONTROLS Messages in the driver display and Related information • the centre display Application menu in the driver display (p. 101) The driver display and centre display can show • Managing messages in the driver display and messages to inform or assist the driver in the the centre display (p.
Page 106 Part of message, shown together with information on where the of a pop-up window. Pop-up messages have problem has arisen. shop higher priority than messages shown in the sta- An authorised Volvo workshop is recommended. tus bar and require acknowledgement/action Service urgent Contact a workshop Centre display before they disappear.
Page 107: Managing Messages In The Driver Display And The Centre Display
INSTRUMENTS AND CONTROLS Managing messages in the driver For messages without buttons: display and the centre display – Close the message by pressing on confirm Messages in the driver display and centre dis- (2), or allow the message to close automati- play are managed with the steering wheel's cally after a while.
Page 108: Managing Messages Saved From The Driver Display And Centre Display
INSTRUMENTS AND CONTROLS Managing messages saved from for e.g. activating/deactivating a function linked Reading a saved message the driver display and centre display to the message. To read a saved message immediately: Whether saved from the driver display or the Managing a new message –...
Page 109 INSTRUMENTS AND CONTROLS Messages saved from the centre – Press the button to perform the action. Managing a saved message In maximised mode, some messages have two display Saved messages in the top view are deleted buttons available to book service or read the automatically when the car is switched off.
Page 110: Head-Up Display
INSTRUMENTS AND CONTROLS Head-up display* If the warning symbol illuminates - read IMPORTANT the warning message in the driver dis- The head-up display shows warnings and infor- The display unit from which the information is play. mation relating to speed, cruise control func- projected is located in the instrument panel.
Page 111 INSTRUMENTS AND CONTROLS Adjusting brightness and vertical Via the function view NOTE Head-up display position Press the The driver's ability to see the information in button. the head-up display is impaired by the follow- ing: • use of polarising sunglasses •...
Page 112 Never use strong stain removers. A special clean- 2. Select My Car Displays Head-Up ing agent available from Volvo dealers can be Display Calibration. used for more difficult cleaning. 3. Calibrate the image's horizontal position with Replacing the windscreen the steering wheel's right keypad.
Page 113: Voice Recognition
Bluetooth-connected phone, the Bluetooth handsfree system and the voice Depress the steering wheel the climate system and Volvo's navigation sys- recognition system's replies come via the car's button for voice recognition tem*.
Page 114: Settings For Voice Recognition
INSTRUMENTS AND CONTROLS system voice is speaking and say the next com- zero three one two two four four three Settings for voice recognition mand. (03122443). Several settings for the voice recognition system • House numbers can be spoken individually can be made.
Page 115: Voice Recognition Control Of The Phone
INSTRUMENTS AND CONTROLS Voice recognition control of the Voice recognition control of radio Related information • Voice recognition (p. 111) phone and media • Using voice recognition (p. 111) Command for voice recognition control of a Command for voice recognition control of radio Bluetooth-connected mobile phone to e.g.
Page 116: Control
INSTRUMENTS AND CONTROLS • • Voice recognition control of climate " Radio " - starts FM radio. " Air condition on "/" Air condition off " - activates/deactivates the air conditioning. control • " Radio FM " - starts FM radio. •...
Page 117 INSTRUMENTS AND CONTROLS • • Voice recognition and map " Turn on seat ventilation "/" Turn off seat " Go to [Post code] " - Specifies a post ventilation code as a destination. Example "Drive to 1 2 " - activates/deactivates the seat navigation 3 4 5".
Page 118: Manual Front Seat
INSTRUMENTS AND CONTROLS • Manual front seat " Pause guidance " - Pauses the guidance WARNING on the map. The car's front seats have different setting Adjust the position of the driver's seat before • " Resume guidance " - Resumes the options for optimum seating comfort.
Page 119: Power Front Seat
INSTRUMENTS AND CONTROLS Power front seat* Adjusting the power front seat* Related information • Power front seat* (p. 117) The car's front seats have different setting Set to desired sitting position using the control • options for optimum seating comfort. The power on the front seat's seating section.
Page 120: Using The Memory Function In The
INSTRUMENTS AND CONTROLS Using the memory function in the 3. Within three seconds, depress the 1 or 2 WARNING power front seat* button. Risk of crushing! Make sure that children do > When the position has been stored in the The memory function stores settings for the seat, not play with the keypad.
Page 121: Adjusting Functions In The Multi-Func
INSTRUMENTS AND CONTROLS Adjusting functions in the multi- Multi-functional front seat* the screen. When it is possible to show setting functional front seat* options for both the front seats, the driver's set- Enhance the seating comfort using the multi- ting options are shown in the upper half and the function control.
Page 122 INSTRUMENTS AND CONTROLS 3. To choose between the different massage Restarting massage functions, select either directly in the touch screen or by moving the cursor up/down using the multi-function control's upper/ lower button. Change the setting in the selected function by selecting directly in the touch screen or by pressing the arrows, or by using the multi-function control's front/rear button.
Page 123 INSTRUMENTS AND CONTROLS 2. Select Side bolsters in the seat settings view. • Press the front seat button in order to increase the side support. • Press the rear seat button in order to reduce the side support. Adjusting the lumbar support* in the front seat The lumbar support can be adjusted upward/ downward/forward/backward.
Page 124: Tional Front Seat
INSTRUMENTS AND CONTROLS 2. Select Lumbar in the seat settings view. Related information • Multi-functional front seat* (p. 119) • Press the seat button up/down to move • the lumbar support up/down. Managing messages saved from the driver display and centre display (p. 106) •...
Page 125: Easy Entry To And Exit From The Driv Er's Seat
INSTRUMENTS AND CONTROLS Easy entry to and exit from the Adjusting the passenger seat from Activating/deactivating easy entry and driver's seat* the driver's seat* exit 1. Press Settings in the top view in the centre Easy Ingress & Egress function can be The front passenger seat can be adjusted from display.
Page 126: Adjusting The Head Restraints In The Rear Seat
INSTRUMENTS AND CONTROLS Rear seat Adjusting the head restraints in the rear seat The car has 5 seats. The second seat row is divided into two parts, with one or two passen- Adjust the centre seat head restraint according ger seats respectively. to the height of the passenger.
Page 127 INSTRUMENTS AND CONTROLS Electrical lowering of the rear seat's 3. Select Fold Headrest On Second Row Seats to lower the rear outer head outer head restraints* restraints. WARNING Do not lower the outer head restraints if there are passengers in any of the outer seats. Move the head restraint back manually until a click is heard.
Page 128: Lowering The Backrests In The Rear Seat
INSTRUMENTS AND CONTROLS Lowering the backrests in the rear 5. Lower the backrest manually to the horizon- NOTE seat* tal position. The front seats may need to be pushed for- The rear seat's backrest is divided into two To facilitate folding of the rear seat, the car must wards, and/or the backrests adjusted parts.
Page 129: Steering Wheel
INSTRUMENTS AND CONTROLS • Steering wheel Horn Head-up display* (p. 108) • Using the application menu in the driver dis- The steering wheel has controls for horn, driver play (p. 102) support systems and voice recognition, amongst other things. • Managing messages in the driver display and the centre display (p.
Page 130: Adjusting The Steering Wheel
INSTRUMENTS AND CONTROLS Adjusting the steering wheel With knee airbag Without knee airbag The steering wheel can be adjusted in different positions. Adjusting the steering wheel. Adjusting the steering wheel. 1. Push the lever forwards to release the steer- 1. Pull the lever backwards to release the steer- ing wheel.
Page 131: Headlamp Control
Main beam flash can be used. Also at stationary when the car is running, provided that the rotating ring is moved to this position from another position. Volvo recommends that mode is used when the vehicle is driven. Applies to vehicles with halogen headlamps.
Page 132: Headlamp Levelling
INSTRUMENTS AND CONTROLS Headlamp levelling Adjusting the interior brightness WARNING The lamps inside the car come on differently Beam alignment is adjusted using one of the The car's audio system is not able to deter- depending on the ignition position used. thumbwheels in the instrument panel.
Page 133: Position Lamps
INSTRUMENTS AND CONTROLS Position lamps approaching from behind. This takes place irre- Load case Thumb- spective of the position of the rotating ring or the The position lamps are switched on with the wheel ignition position of the car's electrical system. rotating ring on the stalk switch.
Page 134: Daytime Running Lights
INSTRUMENTS AND CONTROLS Daytime running lights Dipped beam Changing to dipped beam also takes place if the front fog lamp and/or rear fog lamp are activated. The daytime running lights are switched on When driving with the stalk switch's rotating ring when the rotating ring on the stalk switch is in At stationary when the car is running, the posi- in the...
Page 135: Activating/Deactivating Main Beam
INSTRUMENTS AND CONTROLS Activating/deactivating main beam Dipped beam is always switched on when the Main beam rotating ring on the stalk switch is in position Main beam can be activated when the steering Main beam is activated with the stalk switch. wheel stalk switch's rotating ring is in position when the car's electrical system is in igni- Active main beam is activated with the rotating...
Page 136 INSTRUMENTS AND CONTROLS The lighting returns to full main beam about a When main beam is activated, the symbol shines Car with LED headlamps* second after the camera sensor no longer blue. This also applies for LED headlamps if the If the active main beam has the on/off functional- detects the headlamp beams from oncoming main beam is partially dimmed, i.e.
Page 137 INSTRUMENTS AND CONTROLS Manual operation the message goes out and the symbol illu- IMPORTANT minates. Examples of when manual switching between NOTE main and dipped beam may be required: WARNING Keep the windscreen surface in front of the • In heavy rain or dense fog camera sensor free from ice, snow, mist and Active main beam is an aid for using the opti- •...
Page 138: Active Bending Lights
INSTRUMENTS AND CONTROLS Active bending lights Adapting the beam pattern from the display at the same time as the driver display headlamps shows an explanatory text. Active bending lights are designed to provide maximum illumination in bends and junctions. If the car is equipped with LED headlamps with The function is only active in weak daylight or adaptive functionality, then the headlamp pattern darkness and only when the car is moving and...
Page 139: Front Fog Lamps/Cornering Lights
INSTRUMENTS AND CONTROLS Rear fog lamp Front fog lamps/cornering lights* NOTE The front fog lamps have cornering lights that When visibility is reduced by fog the rear fog Regulations on the use of fog lamps vary shine diagonally to the side. lamp can be used so that other road users can from country to country.
Page 140: Brake Lights
INSTRUMENTS AND CONTROLS Brake lights Hazard warning flashers Press the on/off button. The symbol in the driver display illuminates when the rear fog lamp The brake light automatically comes on during The hazard warning flashers warn other road is switched on. braking.
Page 141: Using Direction Indicators
INSTRUMENTS AND CONTROLS Using direction indicators Related information NOTE • Using direction indicators (p. 139) The car's direction indicators are operated with • This automatic flashing sequence can be • Emergency brake lights (p. 401) the left-hand stalk switch. The direction indicator stopped by moving the stalk switch lamps flash three times or continuously, depend- immediately in the opposite direction.
Page 142: Passenger Compartment Lighting
INSTRUMENTS AND CONTROLS • Passenger compartment lighting Auto function for passenger compartment remains on for two minutes if one of the side lighting doors is open. The passenger compartment lighting is acti- Reading lamp, right-hand side vated/deactivated with the buttons in the over- Rear lighting head controls above the front seats and the rear The rear area of the car has reading lighting,...
Page 143 INSTRUMENTS AND CONTROLS Vanity mirror lighting 3. Under Interior Mood Light Intensity , select High The lighting for the vanity mirror in the sun visor from is switched on and off respectively when the cover is opened or closed. Ground lighting The ground lighting is switched on and off when the corresponding door is opened or closed.
Page 144: Home Safe Light Duration
INSTRUMENTS AND CONTROLS Home safe light duration Lighting in storage compartments in Changing the colour of the light 1. Press Settings doors in the top view in the centre Some of the exterior lighting can be kept display. The lighting in storage compartments in doors is switched on to work as home safe lighting after switched on when the car is running.
Page 145: Approach Light Duration
INSTRUMENTS AND CONTROLS Approach light duration Using windscreen wipers Continuous wiping Raise the stalk switch for the wipers to Approach lighting is switched on when the car is The windscreen wiper cleans the windscreen. sweep at normal speed. unlocked and is used to switch on the car's Different settings for the windscreen wiper are lighting at a distance.
Page 146: Activating/Deactivating The Rain Sensor
INSTRUMENTS AND CONTROLS Activating/deactivating the rain switch must be in position 0 or in the position for Activating/deactivating the memory sensor a single sweep. function The memory function for the rain sensor can be The rain sensor automatically starts the wind- Activate the rain sensor by pressing the rain sen- activated in such a way that the rain sensor but- screen wipers based on how much water it...
Page 147: Windscreen And Headlamp Washers
INSTRUMENTS AND CONTROLS Windscreen and headlamp washers Power windows Heated washer nozzles* The washer nozzles are heated automatically in Windscreen and headlamp washers clean the All power windows can be operated using the cold weather to prevent the washer fluid from windscreen and headlamps.
Page 148: Operating Power Windows
INSTRUMENTS AND CONTROLS Operating power windows Operating when closing has been interrupted, e.g. if ice has formed on the window. After two successive clos- All power windows can be operated using the ing interruptions the pinch protection will be over- control panel for the driver's door - the control ridden and the automatic function deactivated for panels for the other doors operate their respec-...
Page 149: Using The Sun Blind
INSTRUMENTS AND CONTROLS Using the sun blind Rear window Operating with the remote control key, door handle or central locking button Sun blinds are built into each rear door. To control the power windows from the outside There is a sun blind built into the rear parcel with the remote control key or door handle, or shelf.
Page 150: Adjusting The Door Mirrors
INSTRUMENTS AND CONTROLS Adjusting the door mirrors Operating WARNING Rear Give a short tap on the The door mirror positions are adjusted with the Both mirrors are the wide-angle type to pro- Sun Curtain button in the joystick in the driver's door controls. vide optimal vision.
Page 151 INSTRUMENTS AND CONTROLS Settings for this function are set via the centre 2. Fold them out again with the L and R but- 3. Under Auto Dim Mirrors , select Normal display: tons. Dark Light 1. Press Settings in the top view. 3.
Page 152: Interior Rearview Mirror
INSTRUMENTS AND CONTROLS Interior rearview mirror Automatic dimming* Settings for this function are set via the centre display: Bright light from behind is automatically dimmed The interior rearview mirror can be dimmed with by the rearview mirror. The control for manual a control in the mirror's lower edge.
Page 153: Compass
INSTRUMENTS AND CONTROLS Compass* Calibrating the compass* Related information • Calibrating the compass* (p. 151) The upper right-hand corner of the rearview mir- The earth is divided into 15 magnetic zones. The • ror has an integrated display that shows the compass should be calibrated if the car is Ignition positions (p.
Page 154: Sunroof
INSTRUMENTS AND CONTROLS Sunroof* 7. Cars with heated windscreen*: If the char- acter is shown in the display when the The sunroof can be opened vertically at the rear heated windscreen is activated, perform the edge (ventilation position) or horizontally (open calibration in accordance with point 6 above position).
Page 155: Operating The Sunroof
INSTRUMENTS AND CONTROLS Operating the sunroof* The sunroof has a wind deflector that is folded WARNING up when the sunroof is in the open position. Children, other passengers or objects may be WARNING trapped by the sunroof's moving parts. Related information •...
Page 156: Automatic Operation
INSTRUMENTS AND CONTROLS The movement of the sunroof stops if the control Ventilation position is released or when it reaches comfort position or the maximum opening or closing position. Close the sunroof by repeating the preceding procedure in reverse order - press the control forward/downward to the manual closing position instead.
Page 157 INSTRUMENTS AND CONTROLS Closing using the remote control key, the driver's door or passenger door* can be used IMPORTANT to close the sunroof. central locking button or door handles Check that the sunroof is properly closed – Give a long press on the central locking but- Remote control key when closing.
Page 158: Homelink
INSTRUMENTS AND CONTROLS • ® ® Remote control key (p. 224) HomeLink HomeLink panel consists of three programma- ble buttons and one indicator lamp in the mirror • Locking/unlocking from the inside (p. 232) ® HomeLink is a programmable remote control glass.
Page 159: Programming Homelink
INSTRUMENTS AND CONTROLS ® deleted when the car is sold; see the section Programming HomeLink 2. Aim the remote control towards the ® ® "Programming HomeLink ". HomeLink button to be programmed and ® Instructions for programming HomeLink hold it 2-8 cm from the button. Do not Related information ®...
Page 160 INSTRUMENTS AND CONTROLS ® 5. Depress the programmed HomeLink Operation button ® and check the indicator lamp. When HomeLink is fully programmed it can be used in place of the separate original remote > Constant green glow: If the indicator controls.
Page 161: Trip Computer
INSTRUMENTS AND CONTROLS Trip computer ® 1. Depress buttons 1 and 3 on HomeLink hold them depressed until the indicator lamp The car's trip computer records and calculates begins flashing green (about 10 seconds). vales such as e.g. distance, fuel consumption and average speed whilst driving.
Page 162: Show Trip Data In The Driver Display
INSTRUMENTS AND CONTROLS • Show trip data in the driver display Mileage An economic driving style generally results in a longer driving distance. • Driving time The trip computer's recorded and calculated val- ues can be shown in the driver display. •...
Page 163 INSTRUMENTS AND CONTROLS 2. Navigate to the trip computer app to left or Resetting the trip meter right with (2). > The top four menu rows show measured values for trip meter TM. The next four menu rows show measured values for trip meter TA.
Page 164: Show Trip Statistics In The Centre Display
In addition to in the trip computer, these units Trip statistics from the trip computer are dis- are also changed in Volvo's navigation sys- played graphically in the centre display and pro- tem*. vide an overview that facilitates more fuel-effi- cient driving.
Page 165: Settings View
INSTRUMENTS AND CONTROLS Settings view 1. Press Settings in the top view. Changing a setting Settings and information for many of the car's 2. Press System Units. functions can be managed in the centre dis- 3. Under Units , select the required unit stand- play's settings view.
Page 166: Categories In The Settings View
INSTRUMENTS AND CONTROLS Categories in the settings view Related information Types of settings • There are several different types of settings: Overview of the centre display (p. 33) The settings view has a number of main catego- • Categories in the settings view (p. 164) ries and subcategories where settings and infor- mation for many of the car's functions are collec- Setting...
Page 167 INSTRUMENTS AND CONTROLS Subcategories Settings Subcategories Settings Subcategories Settings Drive Mode Individual Drive Mixed Traffic Personal Volvo On Call – Mode Volvo Service Networks Global Guidance Personal Lights Mixed Climate control System Personal Mirrors Personal The main category Climate has no subcatego- ries.
Page 168: Changing System Settings In The Set Tings View
INSTRUMENTS AND CONTROLS Changing system settings in the Related information 3. Select from the following unit standards: • settings view Settings view (p. 163) • Metric - kilometres, litres and degrees • System Changing system settings in the settings category in the settings view col- Celsius.
Page 169: Resetting Settings In The Settings View
INSTRUMENTS AND CONTROLS Resetting settings in the settings See the car's vehicle identification 4. Press to confirm the reset. view number Reset Personal Settings , the reset 1. Press Settings in the top view in the centre It is possible to reset all modified settings in the must be confirmed by pressing Reset for display.
Page 170: Driver Profiles
INSTRUMENTS AND CONTROLS Driver profiles Selecting driver profile remain available for use even if driver profile Y is used. The keyboard layout settings are not saved Many of the settings made in the car can be The last used driver profile is the one selected to a specific driver profile - the settings are adapted according to the driver's personal pref- when the car is next started.
Page 171: Editing A Driver Profile
INSTRUMENTS AND CONTROLS Editing a driver profile 2. Press Profile 3. Save the name change by tapping on Back Close > The same list as for Option 1 is shown. The different driver profiles used in the car can > The name has now been changed. be renamed and locked.
Page 172: Profile
INSTRUMENTS AND CONTROLS Linking remote control key to driver 5. Select Connect key to link the profile with NOTE profile the key. It is not possible to link a driver pro- Global Reset is only possible when the car file to a different key than the one currently It is possible to link your key to a driver profile.
Page 173: Importing/Exporting A Driver Profile From/To Usb
INSTRUMENTS AND CONTROLS Importing/exporting a driver profile Related information 4. Select Import Profile From USB Export from/to USB • Profile To USB Driver profiles (p. 168) The personal settings saved in the driver profiles NOTE can be exported/imported to other cars via USB. A number of profiles can be exported to a Follow these steps in order to import/export a USB memory, but only one profile can be...
Page 174: Changing Settings For Apps
• are part of the car's embedded functions. Set- Settings view (p. 163) owner of the Volvo On Call* service. tings for these apps can be changed directly in • Downloading, updating and uninstalling apps the top view in the centre display.
Page 175 CLIMATE CONTROL...
Page 176: Climate Control
CLIMATE CONTROL • Climate control 4-zone climate* Parking climate* (p. 198) • Voice recognition control of climate control The car is equipped with electronic climate con- (p. 114) trol. The climate control system cools or heats as well as dehumidifies the air in the passenger compartment.
Page 177: Climate Control - Sensors
CLIMATE CONTROL Climate control - sensors Perceived temperature With the Interior Air Quality System* there is also an air quality sensor that is fitted into the climate The climate control system has a number of sen- The climate control system regulates the climate control system air intake.
Page 178: Air Quality
The indicator is visible in the climate row when the climate view is not open. Use cleaning agents and car care products rec- ommended by Volvo to clean the interior. If the conditions have not been met then the Clean Zone text is white.
Page 179: Passenger Compartment Filter
• An enhanced fan function that means that ger compartment from contaminants such as par- Follow the Volvo Service Programme for the rec- the fan starts when the car is unlocked with ticles, hydrocarbons, nitrous oxides and ground- ommended replacement intervals. If the car is the remote control key.
Page 180: Climate Controls
CLIMATE CONTROL • Climate controls 1. Press Settings in the top view in the centre Activating/deactivating defrost of windows display. and door mirrors (p. 186) The climate control system's functions are con- trolled from the centre display, physical buttons 2. Press Climate in the centre console and the climate panel at 3.
Page 181: Climate Controls In The Centre Display
CLIMATE CONTROL Climate controls in the centre Climate view display One tap on the centre button in the climate row gives access to the climate view. The climate view All climate functions can be regulated from the Main climate Rear is divided into the tabs climate row and the climate view in the centre * and...
Page 182: Climate Controls At The Rear Of The
CLIMATE CONTROL Climate controls at the rear of the Rear climate control* Parking climate* tunnel console* All climate functions for the rear seat can be The car's parking climate control can be regula- regulated in the Rear climate tab. ted in the Parking climate tab.
Page 183 CLIMATE CONTROL • Auto-regulating the climate Regulating the fan level (p. 185) 2. Give a short or long press on AUTO • > Auto-regulation of the climate is acti- Regulating the temperature (p. 182) With an auto-regulated climate, several climate vated/deactivated and the button illumi- functions are controlled automatically by the cli- nates/extinguishes.
Page 184: Activating/Deactivating Air Conditioning
CLIMATE CONTROL Activating/deactivating air Regulating the temperature NOTE conditioning The temperature can be set separately for the Close all side windows for air conditioning to The air conditioning cools and dehumidifies left and right-hand sides. With 4-zone climate* work optimally. incoming air as required.
Page 185 CLIMATE CONTROL Regulating temperature for rear seat* Synchronising the temperature From the front seat Temperature control. Synchronisation button on the driver's side temperature 2. Regulate the temperature by either of the controls. following: Temperature buttons in the Rear climate tab in the cli- 1.
Page 186 CLIMATE CONTROL Related information From the rear seat • Climate controls (p. 178) • Climate controls in the centre display (p. 179) • Climate controls at the rear of the tunnel console* (p. 180) • Perceived temperature (p. 175) Temperature control. Temperature control on the climate panel at the rear of 4.
Page 187: Regulating The Fan Level
CLIMATE CONTROL Regulating the fan level Regulating fan level for rear seat* From the rear seat The fan can be set to five different automatic fan From the front seat levels as well as . With 4-zone cli- mate* the fan level can be set separately for the front and rear seats.
Page 188: Activating/Deactivating Defrost Of
CLIMATE CONTROL Activating/deactivating defrost of Cars without heated windscreen: NOTE windows and door mirrors – Press the button (1). The climate control system automatically The three functions max defroster, heated wind- > Max defroster is activated/deactivated adjusts the air flow within the selected fan screen*, and heated rear window and door mir- and the button illuminates/extinguishes.
Page 189 CLIMATE CONTROL From the climate view in the centre NOTE NOTE display The heated windscreen may affect the per- Changing the fan level to increases the Activating/deactivating max defroster noise level. formance of transponders and other commu- nication equipment. Activating/deactivating heated windscreen* NOTE If the heated windscreen is activated when the Start/Stop function has auto-stopped the...
Page 190 CLIMATE CONTROL Activating/deactivating air 1. Press Settings in the top view in the centre Activating/deactivating heated rear window recirculation display. and door mirrors The air recirculation shuts out bad air, exhaust 2. Press Climate fumes, etc. from the passenger compartment, by 3.
Page 191: Air Distribution
CLIMATE CONTROL Air distribution NOTE The climate control system distributes the It is not possible to activate air recirculation incoming air via a number of different vents in when max defroster is activated. the passenger compartment. Overview of air distribution Activating/deactivating the timer for air recirculation It is possible set whether the air recirculation...
Page 192: Changing The Air Distribution
CLIMATE CONTROL • Changing the air distribution Table of air distribution options (p. 193) Related information • Air distribution (p. 189) • Auto-regulating the climate (p. 181) The air distribution can be changed manually if • required. Opening/closing and aiming the air vents (p.
Page 193: Opening/Closing And Aiming The Air Vents
CLIMATE CONTROL Opening/closing and aiming the air Opening/closing the air vents Air vents for the rear seat: vents Air vents for the front seat: Some air vents in the passenger compartment can be opened, closed and aimed individually. If the door pillar vents and instrument panel outer vents are aimed toward the side windows, then misting can be removed.
Page 194 CLIMATE CONTROL Aiming the air vents The air vent's lever – Move the lever sideways/vertically in order to aim the air flow from the nozzle. Related information • Air distribution (p. 189) • Changing the air distribution (p. 190) • Table of air distribution options (p.
Page 195: Table Of Air Distribution Options
CLIMATE CONTROL Table of air distribution options The air distribution can be changed manually if required. The following options are available for setting. Air distribution Purpose If all air distribution buttons are deselected in manual mode, the climate control system returns to automatically regulated climate control. Main air flow from the defroster vents.
Page 196 CLIMATE CONTROL Air distribution Purpose Main air from the defroster vents and air vents in the instrument panel. Provides good comfort in hot and dry climates. Some air flows from other air vents. Main air flow from the defroster vents and air vents at the floor. Some air Provides good comfort and good demisting in a cold or flows from other air vents.
Page 197: Activating/Deactivating Heating Of The Seats
CLIMATE CONTROL Activating/deactivating heating of 2. Repeatedly press the button for heated seats From the rear seat the seats* in order to change between the four levels: With 2-zone climate: High Middle The seats can be heated in order to increase >...
Page 198: Activating/Deactivating Ventilation Of The Seats
CLIMATE CONTROL Activating/deactivating ventilation of WARNING the seats* Heated seats must not be used by people The seats can be ventilated, for example, to who find it difficult to perceive an increase in remove moisture from clothes. temperature due to a lack of sensation or who otherwise have problems operating the con- The ventilation system consists of fans in the trols for the heated seats.
Page 199: Activating/Deactivating Heating Of
CLIMATE CONTROL Activating/deactivating heating of Activating/deactivating ventilation of NOTE steering wheel* the front seat The seat ventilation should be used carefully The steering wheel can be heated in order to by people sensitive to draughts. Level increase comfort for the driver when it is cold. recommended for long-term use.
Page 200 CLIMATE CONTROL Parking climate* 2. Repeatedly press the button for heated Preconditioning can use direct start or be set via steering wheel in order to change between the timer. The climate of the car's passenger compartment the four levels: High Middle can be preconditioned or maintained while the The function utilises several systems in different...
Page 201: Starting/Stopping Preconditioning
3. Press Preconditioning Symbols and messages for parking climate mobile phone that has the Volvo On Call* mobile control* (p. 204) > Preconditioning is started/switched off app. The preconditioning warms the passenger •...
Page 202: Timer For Preconditioning
Engine Remote Start - ERS is finished at a predetermined time. The timer for preconditioning can manage up to via Volvo On Call* mobile app. can be used. 8 time settings. The timer can handle up to 8 different settings...
Page 203 CLIMATE CONTROL 3. Press Add timer Deleting a time setting WARNING > A pop-up window is shown. Do not use preconditioning if the car is equip- ped with a heater*: NOTE • In unventilated spaces indoors. Exhaust gases are emitted if the heater starts. It is not possible to add a time setting if there already are 8 settings entered for the timer.
Page 204: Activating/Deactivating The Timer For Preconditioning
CLIMATE CONTROL Activating/deactivating the timer for Starting/switching off climate WARNING preconditioning* comfort retention* Do not use preconditioning if the car is equip- A time setting in the timer for preconditioning Climate comfort retention maintains the climate ped with a heater*: can be activated or deactivated based on need.
Page 205 CLIMATE CONTROL NOTE It is not possible to start climate comfort retention if there is not enough residual heat in the engine to maintain the passenger com- partment climate, or if the outside tempera- ture is above approx. 20 °C. NOTE Climate comfort retention is switched off when the car is locked from the outside to...
Page 206: Symbols And Messages For Parking Climate Control
Parking climate Parking climate control is disengaged. Contact a workshop to check the function as soon as possible. Service required An authorised Volvo workshop is recommended. • Related information Timer for preconditioning* (p. 200) • Parking climate* (p. 198) •...
Page 207: Heater
CLIMATE CONTROL Heater* Battery and charging If the level in the fuel tank is too low then the heater is switched off automatically and the driver The heater is powered by the car's starter battery. The heater helps the engine and passenger display shows a message.
Page 208: Parking Heater
It is then switched off automatically when the heater and, if possible, pull out its fuse. Volvo right temperature, the time of a set timer or the recommends that an authorised Volvo work- heater's maximum running time has been shop should be contacted for repair.
Page 209: Additional Heater
A ticking NOTE sound from the fuel pump may also be heard Volvo recommends that the automatic start from the rear section of the car. This is per- for the additional heater should be switched fectly normal.
Page 211 LOADING AND STORAGE...
Page 212: Passenger Compartment Interior
LOADING AND STORAGE Passenger compartment interior WARNING Overview of the passenger compartment's inte- Keep loose objects such as mobile phones, rior and storage locations. cameras, remote controls for accessories, etc. in the glove compartment or other compart- Front seat ments. Otherwise they may injure people in the car in the event of sudden braking or a collision.
Page 213: Tunnel Console
LOADING AND STORAGE Tunnel console Related information • Passenger compartment interior (p. 210) The tunnel console is located between the front • seats. Electrical sockets (p. 212) • Using the cigarette lighter* (p. 216) • Emptying ashtrays* (p. 216) • Connecting media via AUX/USB input (p.
Page 214: Electrical Sockets
LOADING AND STORAGE Electrical sockets 230 V electrical socket* 3. Disconnect the accessory by pulling out the plug - do not pull on the cable. In the tunnel console there are two 12 V electri- cal sockets and one 230 V electrical socket*, in Pull up the cover when the socket is not the cargo area there is one 12 V electrical being used or the socket is left unattended.
Page 215 LOADING AND STORAGE aged or has come into contact with water or other liquid. Status indication • Do not connect junction sockets, adapt- A diode on the socket indicates its status: ers or extension cables to the socket as these can override the socket's safety features.
Page 216 If the problem persists, contact a workshop - an authorised Volvo workshop is recommended. WARNING Never modify or repair the 230 V electrical socket yourself. Volvo recommends that an authorised Volvo workshop should be contac- ted. 12 V electrical socket 12 V electrical socket in tunnel console, rear seat.
Page 217 LOADING AND STORAGE Using the sockets 1. Remove the blanking plug (tunnel console) or fold down the cover (cargo area) in front of the socket and plug in the accessory's connector. 2. Unplug the accessory's connector and refit the blanking plug (tunnel console) or fold up the cover (cargo area) when the socket is not in use, or if the socket is left unattended.
Page 218: Using The Cigarette Lighter
LOADING AND STORAGE Using the cigarette lighter* Emptying ashtrays* 1. Press in the button on the lighter. > When the lighter is glowing the button The cigarette lighter can be mounted in the 12 V With a cigarette lighter in the car, there are hops up.
Page 219: Using The Glovebox
LOADING AND STORAGE Using the glovebox 3. Refit the ashtray and allow it to slide down in the tracks on the sides. The glovebox is located on the passenger side. The key's designated storage space 4. Carefully press the two short sides of the The printed owner's manual and maps can be ashtray.
Page 220: Sun Visors
LOADING AND STORAGE Sun visors Cargo area Using the glovebox as a cooled area* The glovebox can be used for cooling of e.g. The rear of each sun visor includes a vanity mir- Inside the car's cargo area, it is possible to drinks or food.
Page 221: Loading
Increasing the space in the cargo area To expand the cargo area and simplify loading, the rear seat's backrest can be lowered*. Note Volvo's load carriers are available for purchase at authorised Volvo dealers. * Option/accessory, for more information, see Introduction.
Page 222: Load Retaining Eyelets
LOADING AND STORAGE Load retaining eyelets Bag hooks WARNING The folding load retaining eyelets are used to Bag hooks keep carrier bags in place and pre- The car's centre of gravity and driving charac- fasten straps in order to anchor items in the vent them from overturning and spreading their teristics are altered by roof loads.
Page 223: Through-Load Hatch In The Rear Seat
LOADING AND STORAGE Through-load hatch in the rear seat* The hatch in the rear seat's backrest can be opened to transport long narrow items, e.g. skis. 1. In the cargo area, grip the hatch's handle and fold down the hatch. 2.
Page 225 LOCKS AND ALARM...
Page 226: Remote Control Key
. Press and hold to close all of the win- authorised Volvo workshop. to be able to start the car. See the section "Star- dows and the sunroof* simultaneously. See ting the engine".
Page 227 Volvo On Call*. The deactivated key is reacti- automatically when the button is held interference with each other.
Page 228: Remote Control Key Range
LOCKS AND ALARM • Remote control key range Power operated boot lid* (p. 241) ton-less key Key Tag is used, a remote control key must be within a semi-circular area of radius • Starting the car (p. 382) In order for the remote control key to work prop- approx.
Page 229: Red Key - Restricted Remote Control Key
Driver Alert Control (DAC)* - see section and message One or more Red Keys can be ordered from a "Driver Alert Control" Volvo dealer. A total of eleven keys with restric- Red key Speed limitation cannot • tions can be programmed and used for a single Road Sign Information* - see section "Road...
Page 230: Antenna Locations For The Start And Lock System
LOCKS AND ALARM Antenna locations for the start and Related information WARNING • lock system Remote control key (p. 224) People with pacemaker operations should not • The car is equipped with a keyless start and lock Adaptive cruise control* (p. 278) come closer than 22 cm to the keyless sys- system and therefore has a number of built-in...
Page 231: Locking/Unlocking From The Outside
Unlock All Doors Driver Door Then select Volvo On Call*. The deactivated key is reacti- Only vated when the car is unlocked. In order for the lock sequence to be activated, the driver's door must be closed.
Page 232: Automatic Relocking
NOTE dle. It is possible to remotely unlock the car with the It is important that only one touch-sensitive Volvo On Call* app. – Touch the marked surface towards the rear surface is activated at a time. Gripping the on the outside of a door handle after the...
Page 233: Indication On Locking/Unlocking The Car
LOCKS AND ALARM Indication on locking/unlocking the Indicator in the lock buttons Indication on the instrument panel Lock buttons only in the front doors When the car is locked or unlocked using the remote control key, the direction indicators con- firm that locking/unlocking was correctly per- formed.
Page 234: Locking/Unlocking From The Inside
LOCKS AND ALARM Locking/unlocking from the inside Related information In all doors* • Locking/unlocking from the outside (p. 229) The doors and boot lid can be locked and • Approach light duration (p. 143) unlocked from inside using the central locking controls in the front doors.
Page 235: Automatic Locking
LOCKS AND ALARM Locking Automatic locking A long press on the button opens all the side The doors and boot lid are locked automatically windows simultaneously - also called global – Press the button - both front doors must when the car starts to move. opening be closed.
Page 236: Deadlocks
Note that the The car can only be unlocked with the remote alarm's movement and tilt detectors* are control key, keyless unlocking or Volvo On Call switched off at the same time. (VOC)* mobile app when deadlocks are activated.
Page 237: Locking/Unlocking The Boot Lid
LOCKS AND ALARM Locking/unlocking the boot lid Keyless unlocking of the boot lid* 1. Press the remote control key's button. The boot lid can be locked/unlocked and > The lock and alarm indicator on the instru- opened in different ways depending on the ment panel extinguishes in order to show equipment level of the car.
Page 238 LOCKS AND ALARM 2. Lift by the outside handle in order to fully Unlocking from the inside of the car Related information • open the tailgate. Remote control key (p. 224) • Power operated boot lid* (p. 241) IMPORTANT • Opening/closing the boot lid with foot move- •...
Page 239: Activate/Deactivate Private Locking
LOCKS AND ALARM Activate/deactivate private locking 2. Enter the desired security code 2. Enter the code to be used in order to unlock the boot lid and rear seat after locking and > The security code is saved. The private The boot lid and rear seat can be locked with tap on Confirm...
Page 240: Detachable Key Blade
Is private locking is activated and the car is The key blade's application areas unlocked via Volvo On Call* or the Volvo On Using the remote control key's detachable key Call* mobile app, private locking will be deac-...
Page 241: Locking/Unlocking With The Detachable Key Blade
LOCKS AND ALARM Locking/unlocking with the 5. Pull out the handle. detachable key blade > The door opens. Amongst other things, the detachable key blade Locking will be performed in the same way, but can be used to unlock the car from the outside - with an anticlockwise turn 45 degrees instead of e.g.
Page 242 LOCKS AND ALARM The left-hand front door can be locked with its The doors can also be unlocked with the unlock NOTE lock cylinder and the detachable key blade. button on the remote control key or with the cen- When the door is unlocked using the key tral locking button on the driver's door.
Page 243: Power Operated Boot Lid
LOCKS AND ALARM Power operated boot lid* Choose one of the following options to open the boot lid: The car's boot lid can be opened/closed electri- • cally. Light press on the boot lid handle. • Opening/closing via a foot movement is also Long press on the instrument panel's available as an extended option - see the section button.
Page 244 LOCKS AND ALARM Cancel closing Closing and locking NOTE – There are five ways to cancel closing: – Press the button on the underside of The button is active 24 hours after the hatch the boot lid to close it and simultaneously •...
Page 245: Opening/Closing The Boot Lid With Foot Movement
LOCKS AND ALARM Opening/closing the boot lid with Operation WARNING foot movement* Pay attention to the risk of crushing when To facilitate the operation of the boot lid when closing. Before starting to close, check that your hands are occupied, it can be opened/ no one is near the boot lid, since a crushing injury can have serious consequences.
Page 246 LOCKS AND ALARM If several kicking motions take place without an Opening/closing NOTE approved remote control key being located Pay attention to the possibility that the sys- behind the car, opening/closing will not be possi- NOTE tem may be activated in a car wash or similar ble until after a certain delay.
Page 247: Replacing The Battery In The Remote Control Key
Hold the remote control key with the front visible and the Volvo logo facing the The battery for the remote control key should be right way - slide the button at bottom edge replaced if: by the key ring to the right.
Page 248 LOCKS AND ALARM Install a new battery with the (+) side up. Move the button to the side and slide the The battery (+) side is facing upwards. Avoid touching the remote control key's bat- back shell a few millimetres upwards. Then carefully prize loose the battery as illus- tery contacts with your fingers.
Page 249 LOCKS AND ALARM NOTE Volvo recommends that the batteries to be used in the remote control key fulfil UN Manual of Test and Criteria, Part III, sub- section 38.3. Batteries fitted in the factory or replaced by an authorised Volvo workshop fulfil the above criteria.
Page 250: Immobiliser
1. Start the engine or choose an ignition posi- dealer for more information and assistance with tion higher than 0. activating the system. Only certain markets and in combination with Volvo On Call*. * Option/accessory, for more information, see Introduction.
Page 251 LOCKS AND ALARM 2. Press the button in the driver's door control The door is blocked against opening from Symbol Message Specification panel. the inside. Rear child Child safety > The driver display shows the message The door can be opened from both the out- locks are acti- lock Acti- Rear child lock Activated...
Page 252: Alarm
If any of the doors are opened from the . In which Arming the alarm case, contact a workshop - an authorised Volvo inside then the alarm is triggered. Lock and arm the car alarm as follows: workshop is recommended.
Page 253: Automatic Arming/Rearming Of The Alarm
LOCKS AND ALARM Automatic arming/rearming of the If the cause of alarm activation is not rectified, To avoid accidental triggering of the alarm - e.g. if a dog is left in a locked car or during transport on the alarm cycle is repeated up to 10 times alarm a car train or car ferry - temporarily deactivate the Automatic rearming of the alarm prevents the car...
Page 254 LOCKS AND ALARM • Disarming the alarm without Detachable key blade (p. 238) working remote control key • Starting the car (p. 382) The car can be unlocked and disarmed even if the remote control key does not work, e.g. if the remote control key's battery is dead.
Page 255: Type Approval For The Remote Control Key System
LOCKS AND ALARM Type approval for the remote Lock system keyless start (Passive control key system Start) and keyless locking/unlocking (Passive Entry*) Type approval for the remote control key system can be read in the table. CEM marking for the remote control key system. For supplementary type approval number, see the table below.
Page 256 LOCKS AND ALARM Country/Area Type approval Brazil MT-3245/2015 Indonesia Nomor: 38301/SDPPI/2015 Malaysia RAAT/37A/0315/S(15-0663) Mexico IFETEL: RLVDEVO15-0396 Russia The United Arab Emirates ER37847/15 DA0062437/11 For more information about type approval for the remote control key system, see support.volvocars.com.
Page 257 LOCKS AND ALARM Remote control key Country/Area Type approval Jordan TRC/LPD/2015/104 Morocco AGREE PAR L'ANRT MAROC Numéro d’agrément: MR 10668 ANRT 2015 Date d’agrément: 24/07/2015 Mexico IFETEL Marca: HUF Modelo (s): HUF8423 NOM-121-SCT1-2009 La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
Page 258 LOCKS AND ALARM Country/Area Type approval Serbia The United Arab Emi- rates Key Tag Country/Area Type approval Jordan TRC/LPD/2015/107 Morocco AGREE PAR L'ANRT MAROC Numéro d’agrément: MR 10667 ANRT 2015 Date d’agrément: 24/07/2015...
Page 259 LOCKS AND ALARM Country/Area Type approval Mexico IFETEL Marca: HUF Modelo (s): HUF8432 NOM-121-SCT1-2009 La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
Page 260 LOCKS AND ALARM Country/Area Type approval Serbia The United Arab Emi- rates Related information • Remote control key (p. 224)
Page 261: Driver Support
DRIVER SUPPORT...
Page 262: Speed-Dependent Steering Force
DRIVER SUPPORT Speed-dependent steering force Electronic stability control Active Yaw Control The function checks the driving and brake force Speed related power steering causes the steer- Electronic stability control (Electronic Stability of the wheels individually in order to stabilise the ing wheel force to increase with the speed of the Control —...
Page 263: Sport Mode For Electronic Stability Control
• Adaptive cruise control* (p. 278) Select/deselect Sport mode The Sport mode is activated/ deactivated in the centre dis- play's function view. Trailer stability assist is included when installing the Volvo genuine towbar. * Option/accessory, for more information, see Introduction.
Page 264: Symbols And Messages For Electronic Stability Control
Temporarily off ESC system disengaged. • Service required Stop the car in a safe place, switch off the engine and start it again. • Visit a workshop if the message remains - an authorised Volvo workshop is recommended.
Page 265 DRIVER SUPPORT Related information • Electronic stability control (p. 260) • Sport mode for electronic stability control (p. 261) • Managing messages in the driver display and the centre display (p. 105)
Page 266: Roll Stability Control
DRIVER SUPPORT Roll Stability Control Speed limiter* The car's current speed Roll Stability Control (RSC) is a stabiliser sys- A speed limiter (Speed Limiter — SL) can be Stored maximum speed tem that minimises the risk of overturning, for regarded as a reverse cruise control — the example during sudden evasive manoeuvres or if driver regulates the speed using the accelerator WARNING...
Page 267: Activating And Starting The Speed Limiter
DRIVER SUPPORT Activating and starting the speed Related information – With the symbol/function displayed, • limiter Activating and starting the speed limiter press the steering wheel button (2). (p. 265) The speed limiter function (Speed Limiter - SL) > The speed limiter starts and the current •...
Page 268: Managing Speed For The Speed Limiter
DRIVER SUPPORT Managing speed for the speed Deactivating/reactivating the speed Related information limiter • limiter Speed limiter* (p. 264) • The speed limiter (Speed Limiter - SL) can be The speed limiter (Speed Limiter - SL) can be Activating and starting the speed limiter set to different speeds.
Page 269: Switching Off The Speed Limiter
DRIVER SUPPORT Switching off the speed limiter Reactivating the speed limiter from 2. Fully release the accelerator pedal when the temporary acceleration is finished. standby mode The speed limiter Speed Limiter — SL can be > The car is then braked automatically –...
Page 270: Automatic Speed Limiter
DRIVER SUPPORT Automatic speed limiter* Related information Is SL or ASL active? • Symbols in the driver display show which speed Speed limiter* (p. 264) The automatic speed limiter (Automatic Speed limiter function is active: • Limiter - ASL) function helps the driver to adapt Activating and starting the speed limiter the car's maximum speed to the speed shown (p.
Page 271: Activating/Deactivating The Automatic Speed Limiter
DRIVER SUPPORT Activating/deactivating the The ASL symbol The ASL will be reactivated when the RSI func- automatic speed limiter The sign symbol (displayed alongside tion can once again interpret and provide speed the stored speed, "70", in the centre of information to the ASL.
Page 272: Changing The Tolerance For The Automatic Speed Limiter
DRIVER SUPPORT Changing the tolerance for the Deactivating the automatic speed Automatic speed limiter limiter – Tap on the Speed Sign Assist button in The speed limiter function (Automatic Speed function view. Limiter - ASL) can be set for different tolerance levels.
Page 273: Cruise Control
DRIVER SUPPORT Cruise control The tolerance is adjusted in the same way as the In cars equipped with the adaptive cruise control speed setting is in the speed limiter. option, the driver can change between CC and The cruise control (Cruise Control - CC) helps ACC - see "Change between Cruise control and the driver maintain an even speed, resulting in a adaptive cruise control".
Page 274: Activating And Starting The Cruise Control
DRIVER SUPPORT Activating and starting the Cruise Managing speed for the Cruise – With the symbol/function displayed, control control press the steering wheel button (2). Cruise control function (Cruise Control - CC) The cruise control (Cruise Control - CC) can be >...
Page 275: Deactivating/Reactivating The Cruise Control
DRIVER SUPPORT • Deactivating/reactivating the cruise If the driver increases the car’s speed using the Deactivating/reactivating the cruise control control accelerator pedal before pressing the steering (p. 273) • wheel button , the speed stored will be the Deactivating Cruise Control (p. 274) The cruise control (Cruise Control - CC) can be car’s speed when the button is depressed, provi- temporarily deactivated so that it is set in the...
Page 276: Deactivating Cruise Control
DRIVER SUPPORT Deactivating Cruise Control Reactivating cruise control from Standby mode on driver intervention The cruise control is temporarily deactivated and standby mode Cruise control Cruise Control — CC can be set in standby mode if: – Press the steering wheel button (1).
Page 277: Distance Warning
DRIVER SUPPORT Distance Warning* functions - see the heading "Change between Head-up display* CC and ACC". The Distance Warning function (Distance Alert) warns the driver if the time interval to the vehicle Related information ahead becomes too short. • Cruise control (p. 271) •...
Page 278 DRIVER SUPPORT Activating and setting the time Related information The same symbol is also shown when the adap- • interval for Distance warning* tive cruise control function is activated. Activating and setting the time interval for Distance warning* (p. 276) The Distance warning (Distance Alert) function •...
Page 279: Activating And Setting The Time Interval For Distance Warning
DRIVER SUPPORT Limitations of Distance Warning* Related information NOTE • Distance Warning* (p. 275) The Distance warning (Distance Alert) function The higher the speed the longer the calcula- • may have limitations in certain situations. Activating and setting the time interval for ted distance in metres for a given time inter- Distance warning* (p.
Page 280: Adaptive Cruise Control
DRIVER SUPPORT Adaptive cruise control* is clear again the car returns to the selected ences or if the vehicle in front brakes suddenly. speed. Due to the limitations of the radar unit, braking The adaptive cruise control (Adaptive Cruise may come unexpectedly or not at all. Control - ACC) helps the driver to maintain an WARNING even speed combined with a pre-selected time...
Page 281 Maintenance of adaptive cruise control com- ponents must only be performed at a work- Target vehicle indicator: ACC has detected shop - an authorised Volvo workshop is rec- and is following a target vehicle at the preset ommended. time interval...
Page 282 DRIVER SUPPORT Collision risk warning Related information WARNING • Activating and starting the adaptive cruise The adaptive cruise control only warns of control* (p. 281) vehicles which its radar unit has detected - • Managing the speed of the adaptive cruise hence a warning may not be given, or it may be given with a certain delay.
Page 283: Activating And Starting The Adaptive
DRIVER SUPPORT Activating and starting the adaptive Managing the speed of the adaptive Start Adaptive Cruise Control cruise control* cruise control* In order to start the ACC the following require- ments apply: The adaptive cruise control (Adaptive Cruise The adaptive cruise control (Adaptive Cruise •...
Page 284: Setting The Time Interval For The Adaptive Cruise Control
DRIVER SUPPORT Setting the time interval for the If the driver increases the car’s speed using the adaptive cruise control* accelerator pedal before pressing the steering wheel button , the speed stored will be the The adaptive cruise control (Adaptive Cruise car’s speed when the button is depressed, provi- Control -ACC) can be set to different time inter- ded the driver’s foot is on the accelerator pedal at...
Page 285: Deactivating/Activating The Adaptive
DRIVER SUPPORT Deactivating/activating the adaptive To temporarily switch off Adaptive Cruise Control NOTE cruise control* and set it in standby mode: Only use the time intervals permitted by local The adaptive cruise control (Adaptive Cruise – Press the steering wheel button (2).
Page 286 DRIVER SUPPORT stationary vehicle or an object, such as a Reactivating adaptive cruise control Standby mode on driver intervention speed bump. The adaptive cruise control is temporarily deacti- from standby mode vated and set in standby mode if: • the speed is below 5 km/h (3 mph) and the vehicle ahead turns off so that ACC no •...
Page 287: Overtaking Assistance With The Adaptive Cruise Control* Or Pilot Assist-2
DRIVER SUPPORT Overtaking assistance with the Starting Overtaking Assistance Some situations should be avoided for this rea- adaptive cruise control* or son. Examples of such situations are: The following conditions must exist for Overtak- Pilot Assist-2* ing Assistance to be activated: •...
Page 288: Change Of Target And Automatic
DRIVER SUPPORT Change of target and automatic control is set in standby mode with automatic WARNING braking with the Adaptive Cruise braking. When the adaptive cruise control is following Control The Adaptive Cruise Control is reactivated in another vehicle at speeds in excess of –...
Page 289: Limitations Of The Adaptive Cruise Control
DRIVER SUPPORT Limitations of the adaptive cruise Change between Cruise control and Cessation of automatic braking control* adaptive cruise control* In some situations, automatic braking ceases on reaching 0 km/h and Adaptive Cruise Control is The (Adaptive Cruise Control - ACC) may have In a car with Adaptive Cruise Control (ACC) the set in standby mode.
Page 290 DRIVER SUPPORT Related information 3. Press the steering wheel button • Cruise control (p. 271) > Cruise control starts and stores the cur- • rent speed. Adaptive cruise control* (p. 278) WARNING The car no longer brakes automatically after switching from ACC to CC - it merely follows the set speed.
Page 291 DRIVER SUPPORT Symbols and messages for the The previous illustration shows that the adaptive adaptive cruise control* cruise control is set to maintain 110 km/h and that there is no vehicle ahead to follow. A number of symbols and messages regarding the adaptive cruise control (Adaptive Cruise Control - ACC) can be shown via the driver dis- play and/or the head-up display*.
Page 292 Symbol Message Specification Adaptive cruise The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Service required Windscreen sensor Clean the windscreen in front of the camera and radar unit's detectors.
Page 293: Pilot Assist
DRIVER SUPPORT Pilot Assist* Pilot Assist-1* using the camera and radar unit. The preset time interval is maintained with automatic speed Pilot Assist helps the driver to drive the car Pilot Assist helps the driver to drive the car adjustment whilst the steering assistance helps between the road lane whilst at the same time between the road lane whilst at the same time to position the car in the lane.
Page 294 Reduces the distance to vehicles ahead only be performed at a workshop - an author- ing the driver must brake himself/herself. This ised Volvo workshop is recommended. Function symbol applies in case of large speed differences or if NOTE: The illustration is schematic - details may vary depending on car model.
Page 295 DRIVER SUPPORT Symbols for target vehicle and time interval Collision risk warning Head-up display* to vehicles ahead Driver display Warning light A flashing symbol attracts the driver's attention Pilot Assist uses approx. 40% of the foot brake's If the car is fitted with a head-up display the Indication of speeds.
Page 296: Activating And Starting The Pilot Assist-1
DRIVER SUPPORT • Activating and starting the Setting the time interval for Pilot Assist-1 Function availability is indicated Pilot Assist-1* (p. 295) by the colour of the symbol (WHITE = available) when Pilot • Deactivating/activating the Pilot Assist-1* Pilot Assist must first be activated and then Assist is selected.
Page 297: Setting The Time Interval For Pilot Assist-1
DRIVER SUPPORT Setting the time interval for actively steer the car. If this does not take place, Pilot Assist-1 an acoustic warning signal is given. Pilot Assist can be set with different time inter- If the driver still does not place his or her hands vals.
Page 298: Deactivating/Activating The
DRIVER SUPPORT Deactivating/activating the ...or... NOTE Pilot Assist-1* Press ◀ (3). – Only use the time intervals permitted by local Pilot Assist can be temporarily deactivated so > Pilot Assist is switched off and changes traffic regulations. that it is set in the standby mode and can be to the adaptive cruise control in active If Pilot Assist does not appear to react when reactivated later.
Page 299: Automatic Braking With Pilot Assist-1
DRIVER SUPPORT Automatic braking with Reactivating Pilot Assist from the Automatic standby mode Pilot Assist-1 Pilot Assist is dependent on other systems, such standby mode as the Electronic Stability Control system. If any Automatic braking with Pilot Assist works as fol- of these other systems ceases to function then lows.
Page 300: Limitations Of Pilot Assist-1
DRIVER SUPPORT Limitations of Pilot Assist-1 Cessation of automatic braking Related information • In some situations, automatic braking ceases on Pilot Assist* (p. 291) The Pilot Assist function may have limitations in coming to a standstill and Pilot Assist is set in •...
Page 301 DRIVER SUPPORT markings, with a subsequent risk of con- Miscellaneous IMPORTANT • tact between the car and such obstacles. Off Road drive mode cannot be selected In certain situations, Pilot Assist steering The driver must ensure him/herself that when Pilot Assist is activated. assistance may have difficulty helping the the car is at a suitable distance from such driver in the right way or it may be automati-...
Page 302 DRIVER SUPPORT Pilot Assist-2* The driver selects the desired speed and a time The current status of steering interval to the vehicle ahead. Pilot Assist scans assistance is indicated by the Pilot Assist helps the driver to drive the car the distance to the vehicle ahead and the lane's colour of the steering wheel's between the lane's side markings using steering...
Page 303 Maintenance of Pilot Assist components must only be performed at a workshop - an author- The driver always bears responsibility for how ised Volvo workshop is recommended. the car is controlled as well as for maintaining the correct distance and speed, even when Pilot Assist is being used.
Page 304 DRIVER SUPPORT Overview Function symbol Collision risk warning Controls Symbols for target vehicle and time interval to vehicles ahead Symbol for activated/deactivated steering assistance Driver display Audio and symbol for collision warning Acoustic warning signal in the event of a risk Buttons and symbols for functions of collision Increases stored speed or reactivates Pilot...
Page 305: Activating And Starting The Pilot Assist-2
DRIVER SUPPORT Activating and starting the Related information WARNING • Pilot Assist-2* Pilot Assist* (p. 291) Pilot Assist only gives warning about vehicles • Activating and starting the Pilot Assist-2* Pilot Assist must first be activated and then whose camera and radar unit has been (p.
Page 306 DRIVER SUPPORT • With the adaptive cruise control in the standby Hands on the steering wheel Overtaking assistance with the adaptive mode: cruise control* or Pilot Assist-2* (p. 285) In order for Pilot Assist to function, the driver must have his/her hands on the steering wheel. •...
Page 307 DRIVER SUPPORT • Managing the speed for Deactivating/activating the Pilot Assist-2* wheel button , the speed stored will be the Pilot Assist-2* (p. 307) car’s speed when the button is depressed, provi- ded the driver’s foot is on the accelerator pedal at •...
Page 308: Setting The Time Interval For
DRIVER SUPPORT Setting the time interval for NOTE Pilot Assist-2* Only use the time intervals permitted by local Pilot Assist can be set with different time inter- traffic regulations. vals. If Pilot Assist does not appear to react when Different time intervals to the activated, this may be because the time dis- vehicle in front can be selected tance to the vehicle in front is preventing an...
Page 309: Deactivating/Activating The
DRIVER SUPPORT Deactivating/activating the Press ◀ (3). – assistance is automatically reactivated if the Pilot Assist-2* lane's side markings can still be detected. > Pilot Assist is switched off and changes to the adaptive cruise control in active Pilot Assist can be temporarily deactivated so mode.
Page 310 DRIVER SUPPORT • Activating and starting the Pilot Assist-2* Automatic standby mode (p. 303) Pilot Assist is dependent on other systems, e.g. Reactivating Pilot Assist from the stability control/anti-skid ESC. If any of these standby mode • Managing the speed for Pilot Assist-2* other systems stops working, Pilot Assist is (p.
Page 311: Change Of Target And Automatic Braking With Pilot Assist-2
DRIVER SUPPORT Change of target and automatic Pilot Assist is reactivated in the following – WARNING braking with Pilot Assist-2* way: When Pilot Assist is following another vehicle • In combination with automatic gearbox, Pilot at speeds in excess of approx. 30 km/h Press the steering wheel button Assist has functionality for change of target and (20 mph) and the target is changed from a...
Page 312: Limitations Of Pilot Assist-2
DRIVER SUPPORT Limitations of Pilot Assist-2* Related information Cessation of automatic braking • In some situations, automatic braking ceases on Pilot Assist* (p. 291) The Pilot Assist function may have limitations in coming to a standstill and Pilot Assist is set in •...
Page 313 DRIVER SUPPORT markings, with a subsequent risk of con- Miscellaneous IMPORTANT • tact between the car and such obstacles. Off Road drive mode cannot be selected In certain situations, Pilot Assist steering The driver must ensure him/herself that when Pilot Assist is activated. assistance may have difficulty helping the the car is at a suitable distance from such driver in the right way or it may be automati-...
Page 314: Symbols And Messages For
DRIVER SUPPORT • Symbols and messages for Overtaking assistance with the adaptive Pilot Assist-2* cruise control* or Pilot Assist-2* (p. 285) • Symbols and messages for Pilot Assist-2* A number of symbols and messages regarding (p. 312) Pilot Assist can be shown via the driver display and/or the head-up display*.
Page 315 DRIVER SUPPORT • Change of target and automatic braking with Pilot Assist-2* (p. 309) • Deactivating/activating the Pilot Assist-2* (p. 307) • Overtaking assistance with the adaptive cruise control* or Pilot Assist-2* (p. 285) • Limitations of Pilot Assist-2* (p. 310) •...
Page 316: Radar Unit
DRIVER SUPPORT • Radar unit Distance Warning* (p. 275) • The radar unit is used by several driver support Adaptive cruise control* (p. 278) systems and has the task of sensing other vehi- • Pilot Assist* (p. 291) cles. • City Safety (p.
Page 317: Limitations Of The Radar Unit
DRIVER SUPPORT Limitations of the radar unit The radar unit is placed inside the upper section If the driver display shows this symbol of the windscreen together with the car's camera with the message Windscreen The radar unit has certain limitations - which in unit.
Page 318 Dirt has appeared between the inside of the windscreen and the camera Visit a workshop to have the windscreen inside the unit's cover cleaned - an and radar unit. authorised Volvo workshop is recommended. that drives in between your car and the vehi- NOTE cle ahead.
Page 319 DRIVER SUPPORT • High temperature The same type or Volvo-approved wind- IMPORTANT screen wipers must be fitted during At very high temperatures the camera and radar If a crack, scratch or stone chip in the wind- replacement. unit can temporarily be switched off for...
Page 320 DRIVER SUPPORT • Limitations of the adaptive cruise control* (p. 287) • Limitations of City Safety (p. 333) • Pilot Assist* (p. 291) * Option/accessory, for more information, see Introduction.
Page 321: Type Approval For Radar Units
DRIVER SUPPORT Type approval for radar units Type approval for the car's radar units can be seen in the following table. Market Symbol Type approval BLIS Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
Page 322 DRIVER SUPPORT Market Symbol Type approval BLIS 37295/POSTEL/2014 ✓ 4927 Indonesia 38806/SDPPI/2015 ✓ 4927 Type Approval No.: TRC/LPD/2014/255 ✓ Equipment Type: Low Power Device (LPD) Jordan Type Approval No.: TRC/LPD/2015/3 ✓ Equipment Type: Low Power Device (LPD) AGREE PAR L’ANRT MAROC ✓...
Page 323 DRIVER SUPPORT Market Symbol Type approval BLIS TA-2014/1824 ✓ APPROVED South Africa TA-2014/2390 ✓ APPROVED ✓ CCAB15LP0560T3 Taiwan ✓ CCAB15LP0680T0 ACC = Adaptive Cruise Control BLIS = Blind Spot Information Related information • Radar unit (p. 314) • Limitations of the radar unit (p. 315) •...
Page 324: Camera Unit
DRIVER SUPPORT Camera unit Related information • Limitations of the camera unit (p. 323) The camera unit is used by several driver sup- • port systems and has the task of for example Adaptive cruise control* (p. 278) detecting lane lines or traffic signs. •...
Page 325: Limitations Of The Camera Unit
DRIVER SUPPORT Limitations of the camera unit Blocked unit If the driver display shows this symbol The camera unit has certain limitations - which in with the message Windscreen turn also limits those functions that use the unit. sensor Sensor blocked, see Impaired vision Owner's manual , it means that the...
Page 326 At very high temperatures the camera and radar area in front of the camera and radar unit. replaced. An authorised Volvo workshop is unit can temporarily be switched off for Instead, the whole windscreen should be recommended.
Page 327 Related information • and fitted. Camera unit (p. 322) • • The same type or Volvo-approved wind- Limitations of the radar unit (p. 315) screen wipers must be fitted during • Lane Keeping Aid (p. 350) replacement. •...
Page 328: City Safety
DRIVER SUPPORT City Safety The function helps the driver by automatically In the event of a risk of a collision with a large braking the car in the event of an imminent risk animal, City Safety can reduce the car's speed by City Safety uses visual, haptic and acoustic sig- of collision if the driver does not react in time by up to 15 km/h (9 mph).
Page 329 DRIVER SUPPORT Market limitation City Safety carries out three steps in the follow- Brake support reinforces the driver’s braking ing order: action if the system considers that the braking is City Safety is not available in all countries. If City not sufficient to avoid a collision.
Page 330: Setting The Warning Distance For City
DRIVER SUPPORT Setting the warning distance for City When City Safety is activated and brakes the Auto Brake Safety vehicle, the driver display shows a text message The automatic brake function is activated last. to the effect that the function is/has been active. City Safety is always activated, but it is possible If in this situation the driver has not yet started to to select the warning distance for the function.
Page 331: Detection Of Obstacles With City Safety
DRIVER SUPPORT Detection of obstacles with City at a later stage, which reduces the total number NOTE Safety™ of warnings. Warning with the direction indicators for Rear Later warning distance should only be used The obstructions that City Safety can detect are Collision Warning deactivates if the warning in exceptional cases, as in dynamic driving.
Page 332 DRIVER SUPPORT bicycle outline, requiring the ability to identify the Pedestrians City Safety can also detect pedestrians in the bicycle, head, arms, shoulders, legs, upper and dark if they are illuminated by the car's head- lower body plus a normal human pattern of move- lamps.
Page 333: City Safety In Cross Traffic
DRIVER SUPPORT City Safety in cross traffic Large animals WARNING City Safety can help the driver when turning and City Safety is an aid, and cannot detect all crossing the path of another oncoming vehicle at large animals in all situations and, for exam- an intersection.
Page 334: City Safety When Evasive Manoeu
DRIVER SUPPORT • City Safety when evasive The following further criteria must also be fulfil- if the oncoming vehicle is hidden by another manoeuvres are prevented led: vehicle • • if the oncoming vehicle has headlamps City Safety has the facility to assist the driver by your car must be travelling at no less than switched off automatically braking the car earlier when it is...
Page 335: Limitations Of City Safety
• components must only be performed by a Limitations of City Safety (p. 333) light, reflections, when sunglasses are being workshop - an authorised Volvo workshop is worn or if the driver is not looking straight ahead. recommended. Heat In the event of high passenger compartment Driver intervention temperature caused by e.g.
Page 336 DRIVER SUPPORT Objects, snow, ice or dirt in the area of the Low speed WARNING camera sensor may reduce its function, fully City Safety is not activated at very low speeds - Warnings and brake interventions could be deactivate it or give incorrect function below 4 km/h (3 mph) - and the system there- implemented late or not at all if a traffic situa- response.
Page 337: Messages For City Safety
When City Safety brakes or has done an automatic braking, several of the driver display symbols may be illuminated in connection with a text message being shown. Automatic intervention City Safety The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Reduced functionality Service required Related information •...
Page 338: Rear Collision Warning
DRIVER SUPPORT • Rear Collision Warning Blind Spot Information* if the vehicle approaching from the rear has a speed exceeding 80 km/h (50 mph). The Rear Collision Warning (RCW) function can The Blind Spot Information (BLIS) function is help the driver to avoid being hit by a vehicle designed to give a warning of vehicles diago- NOTE approaching from behind.
Page 339 DRIVER SUPPORT from a constant glow to flashing with a more intense light. NOTE The lamp illuminates on the side of the car where the system has detected the vehicle. If the car is overtaken on both sides at the same time then both lamps illuminate.
Page 340: Activate/Deactivate Blind Spot Information
DRIVER SUPPORT Activate/deactivate Blind Spot If BLIS was deactivated when the engine was WARNING Information* switched off, it will continue to be deactivated The system is a supplement to, not a replace- when the engine is next started and no indicator The Blind Spot Information (BLIS) function can ment for, a safe driving style and use of the lights will then be illuminated.
Page 341: Limitations Of Blind Spot Information
• BLIS is deactivated when a trailer is con- be performed by a workshop - an authorised nected to the car’s electrical system. Volvo workshop is recommended. Sensors The sensors for the BLIS function are located Related information inside each corner of the rear wing/bumper. The •...
Page 342: Activate/Deactivate Cross Traffic Alert
DRIVER SUPPORT Activate/deactivate Cross Traffic If CTA has sensed that something is approaching Related information Alert* • from the side, this is also indicated with: Cross Traffic Alert* (p. 339) • • an acoustic signal - the sound is heard in the The Cross Traffic Alert (CTA) function can be Limitations of Cross Traffic Alert (p.
Page 343: Limitations Of Cross Traffic Alert
The car is parked deep inside a parking slot. nected to the car’s electrical system. be performed by a workshop - an authorised Volvo workshop is recommended. Sensors The sensors for the CTA function are located inside each corner of the rear wing/bumper. The...
Page 344 DRIVER SUPPORT Related information • Cross Traffic Alert* (p. 339) • Activate/deactivate Cross Traffic Alert* (p. 340) • Messages for Blind Spot Information* and Cross Traffic Alert* (p. 343) • Limitations of Blind Spot Information* (p. 339) * Option/accessory, for more information, see Introduction.
Page 345: Messages For Blind Spot Information* And Cross Traffic Alert
Message Specification Blind spot sensor The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Service required Blind spot system off BLIS and CTA have been deactivated as a trailer has been connected to the car's electrical system.
Page 346: Road Sign Information
DRIVER SUPPORT Sign display with Road Sign Road sign information* WARNING Information The road sign information function (Road Sign RSI does not work in all situations but is Information – RSI) helps the driver to observe The Road Sign Information function (Road Sign designed merely as a supplementary aid.
Page 347 DRIVER SUPPORT Besides the speed limit symbol End of all restrictions. Sometimes different speed limits are signed for an additional sign may be the same road - an additional sign then indicates shown as well, such as "no the circumstances under which the different overtaking".
Page 348: Speed Camera Information
DRIVER SUPPORT Speed camera information Sensus Navigation section "Activating/deactivating Road sign infor- mation" as well as the section "Limitations for If the car is equipped with Sensus Navigation, A car equipped with Sensus Navigation can pro- Road sign information". speed information is read from the navigation vide information on an upcoming speed camera unit in the following cases: in the driver display.
Page 349: Activating/Deactivating Road Sign Information
DRIVER SUPPORT Activating/deactivating Road sign The speed warning is given by 2. Press My Car IntelliSafe Road Sign information the driver display symbol show- Information. ing the applicable maximum The Road sign information (Road Sign 3. Select Audio Warning to activate/deacti- permitted speed temporarily Information - RSI) function can be activated/ vate the acoustic warning.
Page 350: Limitations For Road Sign Information
DRIVER SUPPORT Limitations for Road Sign Driver Alert Control NOTE Information* The Driver Alert Control function is intended to The function uses the car's camera unit, attract the driver's attention when he/she starts The Road Sign Information Road Sign which has some general limitations, see the to drive less consistently, e.g.
Page 351: Activate/Deactivate Driver Alert Control
DRIVER SUPPORT Activate/deactivate Driver Alert WARNING Control An alarm should be taken very seriously, as a The Driver Alert Control (DAC) function can be sleepy driver is often not aware of his/her activated/deactivated. own condition. In the event of an alarm or a feeling of tired- Activate/deactivate Driver Alert Control ness;...
Page 352: Limitations Of Driver Alert Control
DRIVER SUPPORT Limitations of Driver Alert Control Lane Keeping Aid 2. Press My Car IntelliSafe Driver Alert Control. The Driver Alert Control (DAC) function may The function of lane assistance is to help the have limitations in certain situations. 3. Select Rest Stop Guidance to activate/ driver to reduce the risk of the car accidentally...
Page 353 DRIVER SUPPORT steer the car back into its lane by applying a If the driver does not keep slight torque to the steering wheel. his/her hands on the steering wheel, the driver display shows 2. Warning activated: If the car is about to cross this symbol and the following a lane line, the driver is warned by means of message, to prompt the driver...
Page 354: Activate/Deactivate Lane Keeping Aid
DRIVER SUPPORT • Activate/deactivate Lane Keeping Lane assistance does not intervene poor weather with reduced visibility • sharp edges or lines other than the lane lines • roads with unclear or non-existent line mark- Lane assistance Lane Keeping Aid (LKA) can be ings.
Page 355 DRIVER SUPPORT 3. Under Lane Keeping Aid Warning Feedback , select type of warning: • Sound - the driver is warned by an acoustic signal. • Vibration — the driver is warned with steering wheel vibrations. Assistance options for Lane Keeping It is possible to select how LKA shall react if the driver if the car leaves its lane.
Page 356: Symbols And Messages For Lane
DRIVER SUPPORT Symbols and messages for lane Lane assistance is scanning one or both lane Indication of steering assistance/warning assistance lines. Unavailable A number of symbols and messages regarding lane assistance can be shown on the driver dis- play. Symbol in the driver display Lane assistance is visualised by symbols in the driver display depending on the situation.
Page 357 Specification Driver support system The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Reduced functionality Service required Windscreen sensor The ability of the camera to scan the roadway in front of the car is reduced.
Page 358 DRIVER SUPPORT Run-off Mitigation Run-off Mitigation Brake intervention helps in situations where Run-off Mitigation with steering assistance steering assistance alone is not sufficient. The The function of Run-off Mitigation is to assist the brake force is adapted automatically depending driver to reduce the risk of the car accidentally on the situation at the time of run-off.
Page 359 DRIVER SUPPORT • • narrow roads Limitations of the camera unit (p. 323) • poor road surface • a very “sporty” driving style • poor weather with reduced visibility • roads with unclear or non-existent side mark- ings • sharp edges or lines other than the lane's side markings.
Page 360: Symbols And Messages For Run-Off Mitigation
Automatic intervention Driver support system The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Reduced functionality Service required Windscreen sensor The ability of the camera to scan the roadway in front of the car is reduced.
Page 361: Park Assist
Be aware of e.g. people or animals near The shorter the distance to the obstacle, the the car. rier on the towbar - without Volvo genuine faster the signal sounds. Other sound from the trailer wiring - parking assistance may need to audio system is muted automatically.
Page 362 DRIVER SUPPORT Along the sides Forwards IMPORTANT When auxiliary lamps are fitted: Remember that these must not obscure the sensors - the auxiliary lamps may then be perceived as an obstacle. Related information • Activating/deactivating Parking assistance* (p. 361) • Limitations of Parking assistance* (p.
Page 363: Activating/Deactivating Parking
DRIVER SUPPORT Activating/deactivating Parking Limitations of Parking assistance* IMPORTANT assistance* The Parking assistance function may have limita- In certain conditions the parking assistance tions in certain situations. The Parking assistance function can be acti- system may produce incorrect warning sig- vated/deactivated.
Page 364 DRIVER SUPPORT NOTE Dirt, ice and snow covering the sensors may cause incorrect warning signals, reduced or no function. Related information • Park Assist* (p. 359) • Activating/deactivating Parking assistance* (p. 361) • Messages for Park Assist* (p. 363) * Option/accessory, for more information, see Introduction.
Page 365: Messages For Park Assist
Message Specification Park Assist System The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Unavailable Service required Park Assist System One or more of the system's sensors are blocked - check and correct as soon as possible.
Page 366: Park Assist Camera
DRIVER SUPPORT Park Assist Camera* CTA* - activate/deactivate Cross Traffic Alert 360° view camera* The Park Assist Camera helps the driver when Zoom - zoom in/out manoeuvring in tight spaces by indicating obsta- cles with a camera image and graphics in the WARNING centre display.
Page 367 DRIVER SUPPORT Backwards Forwards The sides The backwards-facing camera is fitted above the regis- The forwards parking camera is located in the grille. The side cameras are positioned in each door mirror. tration plate. The front camera can be helpful on an exit road The side cameras show what is along each side The backward-facing camera shows a wide area with limited visibility to the sides, e.g.
Page 368: Park Assist Lines And Fields For The Park Assist Camera
DRIVER SUPPORT Park assist lines and fields for the These park assist lines include the car's most IMPORTANT Park Assist Camera* protruding parts, e.g. towbar, door mirrors and Remember that when rear camera view is corners. The Park Assist Camera indicates the position of selected, the centre display only shows the the car in relation to its surroundings by display- area behind the car.
Page 369 DRIVER SUPPORT Sensor field from Parking assistance* Park assist lines in 360° view* Towbar assist line If the car is equipped with Parking assistance* then the distance is shown in the 360° view with coloured fields for each sensor that registers an obstacle.
Page 370: Starting The Park Assist Camera
DRIVER SUPPORT Starting the Park Assist Camera* Activating/deactivating automatic start Sensor field to the sides The side fields are only shown in orange. of the Park Assist Camera The Park Assist Camera can be made to start It is possible to activate/deactivate the automatic automatically when reverse gear is selected or starting of the Park Assist Camera when reverse manually via the centre display.
Page 371: Limitations Of The Park Assist Camera
DRIVER SUPPORT Limitations of the Park Assist 2. Press My Car Park Assist. Camera* 3. Select Rear View Instead of 360° to acti- The Park Assist Camera function may have limi- vate/deactivate the rear camera view as tations in certain situations. basic view.
Page 372: Park Assist Pilot
DRIVER SUPPORT Park Assist Pilot* Maintenance Clean camera lenses regularly with lukewarm Active parking assistance (Park Assist Pilot - water and car shampoo - be careful not to PAP) helps the driver to park in or leave a park- scratch the lenses. ing space.
Page 373 DRIVER SUPPORT 3. The car is positioned in the space by means WARNING NOTE of driving forward/backward. PAP does not work in all situations but is A perpendicular-parked car cannot be assis- Using the Park Out function, a parallel-parked designed merely as a supplementary aid. Park Out ted by the PAP function to leave a...
Page 374: Parking With Active Parking Assistance
DRIVER SUPPORT Parking with Active parking Parking assistance* The PAP function parks the car using the follow- ing steps: The Active parking assistance (Park Assist Pilot - PAP) helps the driver park in three steps. The 1. A parking space is identified and measured. function can also help the driver to leave a park- 2.
Page 375 DRIVER SUPPORT NOTE NOTE • PAP searches the area for parking, displays Keep your hands away from the steering instructions and guides the car in on its pas- wheel when the PAP function is acti- senger side. But if required the car can also vated.
Page 376 DRIVER SUPPORT 2. Keep an eye on the centre display - be pre- Park Out function is acti- Positioning the car in the parking space pared to stop the car when the graphics and vated in the centre display's message so request. function view.
Page 377: Limitations Of Park Assist Pilot
DRIVER SUPPORT • Limitations of Park Assist Pilot* Parking spaces on narrow streets are not IMPORTANT always feasible, since the space required for The Active parking assistance (Park Assist Pilot Under certain circumstances, PAP is unable manoeuvring may not be sufficient. –...
Page 378 (p. 372) tyre circumference, which means that the PAP system's parameters may then need to be updated. Consult a workshop - an author- ised Volvo workshop is recommended. Maintenance PAP sensor locations For the PAP function to work correctly, its sen- sors must be cleaned regularly with water and car shampoo.
Page 379: Messages For Park Assist Pilot
One or more of the systems' sensors are blocked - check and correct as soon as possible. Sensors blocked, cleaning needed Park Assist System The system does not function as it should. A workshop should be contacted - an authorised Volvo workshop is recommended. Unavailable Service required Related information •...
Page 381 STARTING AND DRIVING...
Page 382: Alcohol Lock
All bypass activation is logged and saved in hol in the washer fluid may result in an incor- alcohol lock recommended by Volvo. The inter- the memory in the alcohol lock's control unit. rect measurement result.
Page 383: Ignition Positions
STARTING AND DRIVING Ignition positions Level Functions Level Functions The car's electrical system can be set in different • • Odometer, clock and temperature The headlamps come on. levels/positions and in this way make the differ- gauge are illuminated. • Warning/indicator lamps illuminate ent functions available.
Page 384: Starting The Car
STARTING AND DRIVING Starting the car 2. Make sure that gear position P or N is NOTE selected. The car is started using the remote control key To reach level I or II without starting the and the start knob in the tunnel console. 3.
Page 385: Switching Off The Car
STARTING AND DRIVING Switching off the car NOTE NOTE The car is switched off using the ignition dial in When the remote control key is placed in the The idling speed can be noticeably higher the tunnel console. cup holder, make sure that no other car keys, than normal for certain engine types during metal objects or electronic apparatus (e.g.
Page 386: Steering Lock
STARTING AND DRIVING Steering lock Using jump starting with another 4. Connect one of the red jump lead's clamps battery to the donor battery's positive terminal (1). The steering lock makes steering difficult if the car is e.g. taken unlawfully. A mechanical noise If the starter battery is discharged then the car IMPORTANT can be perceived when the steering lock locks...
Page 387: Gearbox
STARTING AND DRIVING Gearbox 11. Start the engine in the car with the dis- Related information • charged battery. Starter battery (p. 524) The gearbox is part of the car's driveline (power • Ignition positions (p. 381) transmission) between engine and drive wheels. IMPORTANT The function of the gearbox is to change the •...
Page 388: Gear Positions For Automatic Gearbox
STARTING AND DRIVING Gear positions for automatic Gear positions Symbol Specification gearbox Park position - P Information or error message for An automatic gearbox unburdens the driver, who Select the P position when the car is parked or gearbox. Follow the recommenda- can instead focus attention on the traffic and the when starting the engine.
Page 389 STARTING AND DRIVING Kick-down is used when maximum acceleration Neutral position - N is needed, such as for overtaking. No gear is engaged and the engine can be started. Apply the parking brake if the car is sta- Safety function tionary with the gear selector in N position.
Page 390: Gear Shift Indicator
STARTING AND DRIVING Gear selector inhibitor Gear shift indicator The gear selector inhibitor prevents accidental The gear shift indicator in the driver display changing between different gear positions in an shows the current gear during manual gearshift- automatic gearbox. ing and when it is appropriate to engage the next gear for optimum fuel economy.
Page 391: Changing Gear With Steering Wheel
STARTING AND DRIVING Changing gear with steering wheel Automatic gear selector inhibitor If the car cannot be driven, e.g. due to a dis- paddles* charged battery, the gear selector must be The automatic gear selector inhibitor has special moved to the N position so that the car can be safety systems.
Page 392 STARTING AND DRIVING This is indicated by means of the figure for the Manual gearshift mode current gear extinguishing. In gear position M the steering wheel paddles are automatically activated. The exception is during engine braking - then the paddles are activated for as long as engine brak- ing is in progress.
Page 393: Using The Start/Stop Function
STARTING AND DRIVING Start/Stop Using the Start/Stop function See the section "Conditions for Start/Stop func- tion". With the Start/Stop function, the engine The Start/Stop function temporarily switches off switches off temporarily when the car has stop- the engine when stationary and then restarts it Autostart ped e.g.
Page 394 STARTING AND DRIVING Symbols in the driver display Related information Symbol Specification • Start/Stop (p. 391) With 12-inch driver display White symbol: The function is avail- • • Conditions for the Start/Stop function The text READY is shown in the tachometer able.
Page 395: Conditions For The Start/Stop Function
STARTING AND DRIVING • Conditions for the Start/Stop The driver makes sweeping steering wheel The engine auto-starts without the function movements. brake pedal having been released • In the following cases, the engine auto-starts The road is very steep. For the Start/Stop function to work requires that even if the driver does not take his/her foot off a number of conditions are met.
Page 396: Drive Modes
STARTING AND DRIVING Drive modes* Related information Selecting drive mode • Start/Stop (p. 391) Selection of drive mode affects the car's driving • Using the Start/Stop function (p. 391) characteristics in order to enhance the driving experience and facilitate driving in special situa- •...
Page 397 STARTING AND DRIVING • Cannot be selected due to limitations Steering response is faster and shock absorption is harder, which means that the body follows the • Cannot be selected because speed is carriageway in order to reduce roll during corner- too high ing.
Page 398: Drive Mode Eco
STARTING AND DRIVING Drive mode ECO 3. Select a drive mode to start from: With drive mode control* Comfort Dynamic Driving mode ECO mode optimises the car's driving characteristics for more fuel efficient and Possible adjustments apply to settings for environmentally-conscious driving.
Page 399 STARTING AND DRIVING • Driving mode ECO is activated. Deactivate the freewheel function as follows: In the centre display's function view Cars without drive mode control • • The gear selector is in D position. Actuate the accelerator or brake pedal. have a function button for •...
Page 400: Level Control* And Shock Absorption
STARTING AND DRIVING Level control* and shock absorption Climate settings Level control and shock absorption are regula- NOTE ted automatically in the car. When the ECO function is activated, several With rear level control, the car maintains the parameters in the climate control system's same height at the rear regardless of load.
Page 401: All-Wheel Drive
STARTING AND DRIVING Brake functions All-wheel drive* During transport During transport of the car on a ferry, train or All-wheel drive, AWD (All Wheel Drive), means The car's brakes are used to reduce the speed truck, the car must be lashed around the tyres that the car is driving all four wheels at the same or prevent the car from rolling.
Page 402: Foot Brake
To keep the car as safe and reliable as possible, brake servo. speed. The test may be experienced as pulses in follow the Volvo service intervals as specified in the brake pedal. the Service and Warranty Booklet. WARNING...
Page 403: Emergency Brake Lights
If the level in the brake fluid reservoir is normal at this stage, drive carefully to the nearest workshop and have the brake system checked - an authorised Volvo workshop is recommended. • If the brake fluid is below the MIN level in the brake fluid reservoir, do not drive fur- ther before topping up the brake fluid.
Page 404: Brake Assistance
STARTING AND DRIVING Brake assistance Auto braking after a collision Parking brake The brake assist system, BAS (Brake Assist In the event of a collision in which the activation The parking brake prevents the car from rolling System), helps to increase brake force during level is reached for the pyrotechnic seatbelt ten- away from stationary by means of mechanically braking, thereby shortening the braking distance.
Page 405: Using The Parking Brake
STARTING AND DRIVING Using the parking brake Related information Automatic application • Brake functions (p. 399) The parking brake is applied automatically: Use the parking brake to prevent the car from • Using the parking brake (p. 403) rolling from stationary. •...
Page 406 STARTING AND DRIVING Releasing the parking brake Parking on a hill Related information • Parking brake (p. 402) WARNING • In the event of a fault in the parking brake (p. 405) Always apply the parking brake when parking on a slope - leaving the car in gear, or in P if it •...
Page 407: In The Event Of A Fault In The Parking
Hill start assist, Hill Start Assist (HSA), prevents Symbol Specification Contact an authorised Volvo workshop if it is not the car from rolling backwards when starting on If the symbol flashes, it indicates a possible to release or apply the parking brake an uphill gradient.
Page 408: Automatic Braking When Stationary
STARTING AND DRIVING Automatic braking when stationary Switch for automatic brake Related information • Brake functions (p. 399) Automatic braking when stationary (Auto Hold) • means that the driver can release the brake Hill start assist (p. 405) pedal while maintaining braking effect when the car has stopped at traffic lights or a junction.
Page 409: Low Speed Control
STARTING AND DRIVING Low speed control* Hill descent control* – Press the button in order to activate the function. The low speed control function Low Speed Hill descent control, Hill Descent Control > An indicator in the button illuminates Control (LSC) facilitates off-road driving and (HDC), is a low speed function with enhanced when the function is activated.
Page 410: Driving In Water
STARTING AND DRIVING Driving in water The driver can brake and reduce crawling speed, NOTE or stop the car at any time by using the foot Driving in water means that the car is driven The function is deactivated when driving at brake.
Page 411: Overheating In The Engine And Drive System
- tow the car from the water to High temperature Stop safely . Stop the a workshop - an authorised Volvo workshop is car in a safe way and allow the engine to run Symbols in the driver display recommended.
Page 412: Overloading The Starter Battery
STARTING AND DRIVING Overloading the starter battery Preparations for a long trip Related information • Driving with a trailer under special conditions The electrical functions in the car load the starter Before a driving holiday or some other type of (p.
Page 413: Winter Driving
Check the following in particular before the cold Slippery driving conditions • Level control* and shock absorption (p. 398) season: To achieve optimum roadholding Volvo recom- • Warning triangle (p. 494) mends using winter tyres on all wheels if there is •...
Page 414: Opening/Closing The Fuel Filler Flap And Refuelling
STARTING AND DRIVING • Opening/closing the fuel filler flap Drive modes* (p. 394) Refuelling at a petrol station and refuelling • Foot brake (p. 400) The fuel tank is fitted with a coverless fuel filler • All-wheel drive* (p. 399) system.
Page 415: Handling Of Fuel
Do not use fuel with a lower quality than that rec- Mixtures of various fuel types or use of fuels located under the floor hatch in the cargo area. ommended by Volvo, as this will negatively affect which are not recommended will invalidate engine power and fuel consumption.
Page 416: Petrol
When refuelling, check that the area around the • Do not use any additives which have not fuel filler pipe is clean. Avoid spilling fuel onto the been recommended by Volvo. paintwork. Wash off any spillage with detergent and water.
Page 417: Empty Tank And Diesel Engine
Before filling with fuel in the event of fuel generate increased wear and engine damage shortage: that is not covered by the Volvo warranty. • Stop the car on as flat/level ground as possible - if the car is tilting there is a risk Related information of air pockets in the fuel supply.
Page 418: Diesel Particulate Filter
STARTING AND DRIVING Diesel particulate filter Driving economically The car should then be driven for approximately 20 minutes more. Diesel-driven cars are equipped with a particu- Drive economically and eco-consciously by driv- late filter, which results in more efficient emis- ing smoothly, thinking ahead, and adjusting your NOTE sion control.
Page 419: Towing Bracket
There may be different towing bracket variants tance to other vehicles and objects to mini- systems such as the power steering and available for the car; contact a Volvo dealer for brake servo. mise braking. more information.
Page 420 STARTING AND DRIVING Extendable/retractable towing NOTE brackets* When a hitch with a vibration damper is used, The extendable/retractable towing hitch is the towball must not be lubricated. always easily accessible and simple to extend or This also applies when fitting a bicycle rack retract as needed.
Page 421 STARTING AND DRIVING Retracting the towing hitch IMPORTANT Make sure that there is no plug or adapter in the electrical socket when retracting the tow- ing bracket. 1. Open the tailgate. Press and release the but- ton on the right-hand side at the rear of the 2.
Page 422 STARTING AND DRIVING Towing bracket specifications* Dimensions, mounting points (mm) Dimensions and mounting points for the towing 1229 bracket. 111.8 437,5 See the image above 2. Lock the towing bracket by moving it back to 310.5 its retracted position, where it is locked. Ball centre >...
Page 423 For more The stated maximum permitted trailer weights affect the car's fuel consumption. information on tyre pressure, see the section are those permitted by Volvo. National vehicle "Approved tyre pressures". regulations can further limit trailer weights Trailer connector and speeds.
Page 424 STARTING AND DRIVING 2. Confirm the message by pressing the right- Level control* Symbol Message hand steering wheel keypad's O button. The car endeavours to maintain a constant height • Trailer turn indicator Right regardless of load (up to the maximum permissi- >...
Page 425 STARTING AND DRIVING Driving with a trailer under special Trailer Stability Assist* 4. Release the brake pedal and start driving off. conditions The function of the trailer stability assist Trailer Related information When driving with a trailer in hilly terrain in a hot Stability Assist (TSA) is to stabilise cars with •...
Page 426 STARTING AND DRIVING If snaking is not eliminated the first time that Related information snaking. The function is included in the stability • trailer stability assist comes into action, the car/ Driving with a trailer (p. 421) system ESC trailer combination is braked with all wheels and •...
Page 427: Towing Eye
STARTING AND DRIVING Towing eye Use the towing eye for towing. The towing eye is screwed into a threaded socket behind a cover on the right-hand side of the bumper, front or rear. NOTE If the car is equipped with a towing bracket, there is no rear mounting for a towing eye.
Page 428 STARTING AND DRIVING Towing The towing eye may be used to pull the car up 6. Keep the towline taut when the towing vehi- onto a recovery vehicle with a flatbed platform. cle reduces speed by holding your foot gen- During towing, one vehicle pulls another vehicle The car's position and ground clearance deter- tly pressed on the brake pedal - thereby...
Page 429 STARTING AND DRIVING Recovering the car Jump starting IMPORTANT Do not tow the car to jump start the engine. Use For recovery, the car is taken away with the help The towing eye is only designed for towing on a donor battery if the starter battery is discharged of another vehicle.
Page 431 AUDIO AND MEDIA...
Page 432: Audio And Media
AUDIO AND MEDIA Audio and media Apps Related information • Media player (p. 438) The audio and media system consists of media Applications (apps) are programs that are used • player, radio and Bluetooth phone connection. Radio (p. 432) to control some of the car's functions. With an online car it is also possible to listen to •...
Page 433: Audio Settings
AUDIO AND MEDIA Audio settings – Tap on an app in the app view to launch it. The audio system is preset for optimal sound Related information reproduction, but can be adapted according to • Online car* (p. 456) needs. •...
Page 434: Radio
AUDIO AND MEDIA Radio Changing and searching radio The radio can be operated stations using voice recognition, the It is possible to listen to the AM and FM bands steering wheel keypad or the and to digital radio (DAB)*. When the car is The radio automatically compiles a station list of centre display.
Page 435 AUDIO AND MEDIA Changing lists within the frequency Genres — only plays back channels broadcast- Radio Favourites ing the selected genre/programme type, e.g. pop band Radio Favourites shows saved or classical. favourites from all frequency bands. Changing stations within the selected list –...
Page 436 AUDIO AND MEDIA Changing radio band Searching for radio stations 3. Enter the search terms. > Searching takes place with each input of a character and the search results are shown by category. Manual tuning – Tap on the app (such as ) from app view, The parameters you can search on depend on or open the app menu with the right-hand...
Page 437: Rds Radio
AUDIO AND MEDIA RDS radio Related information Related information • • Radio (p. 432) Radio (p. 432) With RDS (Radio Data System) the radio can • • Digital radio (p. 436) automatically change to the strongest transmit- Settings for radio (p. 437) ter.
Page 438: Digital Radio
AUDIO AND MEDIA Digital radio Linking between different radio DAB subchannel bands FM and DAB Secondary components are usually named sub- Digital radio (Digital Audio Broadcasting, DAB) channels. These are temporary and can contain is a digital broadcasting system for radio. The The function enables the digital radio to switch e.g.
Page 439: Settings For Radio
AUDIO AND MEDIA Settings for radio is resumed when the message is finished. Alarm - interrupts the current media play- Local Interruptions function is a geo- back and sends alerts about major accidents Settings for the different radio bands. Traffic and disasters.
Page 440: Media Player
AUDIO AND MEDIA • Media player Apps (p. 430) • Radio (p. 432) The media player can play back audio from CDs* and externally connected audio sources • CD player* (p. 442) via the AUX/USB input or wirelessly stream • Media via Bluetooth (p.
Page 441: Media Playback
AUDIO AND MEDIA Media playback 2. Open the app from the app view. 3. Start playback from the connected media source. The media player is controlled from the centre 3. Select what to play back. display. Several functions can also be controlled 4.
Page 442 AUDIO AND MEDIA tre display or on the steering wheel's right-hand ® Playing back DivX keypad. ® This DivX Certified device must be registered in order to play back purchased DivX Video-on- Fast forward/move in time - tap on the time axis Demand (VOD) films.
Page 443: Gracenote
AUDIO AND MEDIA • ® Apple CarPlay* (p. 446) Gracenote Updating Gracenote The content of the Gracenote database is upda- • Technical specifications for media (p. 449) Gracenote identifies artist, album, song titles ted continuously. Download the latest update for and associated images, which are shown during optimal functionality.
Page 444: Searching Media
AUDIO AND MEDIA Searching media CD player* 3. Press Search > Connected devices are searched and the It is possible to search by artist, composer, song The media player can play back CD discs with search results are listed by category. (titles), album, video, audiobook, playlist and, audio files.
Page 445: Media Via Bluetooth
AUDIO AND MEDIA Media via Bluetooth Connecting media via Bluetooth Media via AUX/USB input The car's media player is equipped with Connect a Bluetooth device with the car in order An external media source, e.g. an iPod or MP3 Bluetooth and can wirelessly play streaming to stream media and use as Internet connection player, can be connected to the audio system.
Page 446: Connecting Media Via Aux/Usb Input
AUDIO AND MEDIA Connecting media via AUX/USB video Audio settings for media input Video from a USB-connected device can be Personalisation of audio settings for media play- An external audio source, e.g. an iPod or MP3 played back with the media player. back.
Page 447 AUDIO AND MEDIA System volumes for media Change the list of visible channels 1. Press Settings 1. Press Library in top view. The TV picture is only shown when the car is stationary. There will be no picture when the car 2.
Page 448: Settings For Tv
(p. 463) • Voice recognition control of radio and media Apple's website: www.apple.com/ios/carplay/. (p. 113) Please note that Volvo is not responsible for the • Media playback (p. 439) content in Apple CarPlay. • Navigating in the centre display's views (p.
Page 449 - the subview with CarPlay, certain information from your car Apple CarPlay is opened and compatible (including its position) is transferred to your apps are shown. iPhone. In relation to Volvo Cars, you are * Option/accessory, for more information, see Introduction.
Page 450: Settings For Apple Carplay
AUDIO AND MEDIA Settings for Apple CarPlay* Related information iPod to Apple CarPlay • 1. Tap on Apple CarPlay in the app view. Apple CarPlay* (p. 446) Settings for phone connected as Apple CarPlay. • Resetting settings in the settings view 2.
Page 451: Technical Specifications For Media
AUDIO AND MEDIA Technical specifications for media Max file size 4 GB Format File extension Compatible file formats, audio specifications .avi Audio codec MP3, AC3 and USB. Subtitles XSUB AVI (DivX) .avi, divx Audio files Special func- Multiple subtitles, multiple .asf, .wmv For- File extension...
Page 452: Phone
AUDIO AND MEDIA Phone Technical specification for USB Overview connector A mobile phone equipped with Bluetooth can be • Type A socket connected wirelessly to the car's built-in hands- • free system. Version 2.0 • Voltage supply 5 V The audio and media system acts as a handsfree, •...
Page 453: Connect Phone
AUDIO AND MEDIA • Connect phone Settings for text messages (p. 456) 3. Open the subview for phone. • • Bluetooth settings (p. 456) Connect a Bluetooth-activated phone to the car If there is no phone connected to the car, to make calls, send/receive messages, stream •...
Page 454: Connecting/Disconnecting The Phone
AUDIO AND MEDIA Connecting/disconnecting the Option 2 - search car from phone NOTE phone 1. Open the subview for phone. • The message function must be activated • Connect, change or disconnect a connected If there is no phone connected to the car, in some phones.
Page 455: Managing Phone Calls
AUDIO AND MEDIA Managing phone calls Changing phones 2. Select call from: call history, enter number using the keypad or via the contact list. It is 1. Open the subview for phone. Call handling in the car for a Bluetooth-con- possible to search or browse in the contact nected phone.
Page 456: Managing Text Messages
AUDIO AND MEDIA • Managing text messages Incoming phone calls Settings for phone (p. 455) Incoming phone calls are shown in the driver dis- Message handling in the car for a Bluetooth- play and the centre display. Manage the call on connected phone.
Page 457: Settings For Phone
AUDIO AND MEDIA Settings for phone • Reply to message — tap on the contact Settings for connected phone. whose message you wish to reply to, then tap on Answer Phone • Create a new message — tap on Create 1.
Page 458: Settings For Text Messages
AUDIO AND MEDIA Settings for text messages Bluetooth settings Online car* Settings for text messages on connected phone. Settings for Bluetooth-connected phone. An online car provides the ability to use e.g. Internet radio and music services via apps as Message Bluetooth well as contact dealers in the car and download 1.
Page 459: Connecting The Car
The mobile phone and network operator must System updates (p. 503) support tethering (sharing the Internet connec- • Volvo ID (p. 23) tion) and the plan must include data. • 1. Activate tethering (portable/personal hot- Symbols in the centre display's status bar spot) on the mobile phone.
Page 460 Car modem Internet When the car is connected to the Internet via the 5. If another connection source has been used car modem, Volvo On Call services will use this in the past - confirm the option to change connection.
Page 461: Sharing Internet Via Wi-Fi Hotspot
AUDIO AND MEDIA Sharing Internet via Wi-Fi hotspot 2. Press Press Connected devices to see a list of the Communication Car Wi-Fi currently connected devices. Hotspot. When the car is connected to the Internet, its Internet connection can be shared to allow other 3.
Page 462: No Or Poor Connection
AUDIO AND MEDIA No or poor connection Remove Wi-Fi network Related information • Online car* (p. 456) Factors affecting the network. Removing a network that is not to be used. • Connecting the car (p. 457) The amount of data transferred is dependent on 1.
Page 463: Wi-Fi Technologies And Security
Check your roaming agreement for data traffic abroad with your network pro- vider in your home country. • SIM card PIN Selection of frequency is not available on all markets. Only cars with Volvo On Call. * Option/accessory, for more information, see Introduction.
Page 464: Downloading, Updating And Uninstalling Apps
AUDIO AND MEDIA Downloading, updating and 4. Select Install in order to start the download Uninstalling an app uninstalling apps and installation of the desired app. An app that is being used must be closed in order for the uninstallation to be completed. >...
Page 465: License Agreement For Audio And Media
About DIVX VIDEO: DivX is a digital video for- person's right under the terms and conditions of mat created by DivX, LLC, a subsidiary of Rovi the agreement. The following texts are Volvo's ® Corporation. This is an official DivX certified agreements with manufacturers/developers.
Page 466 AUDIO AND MEDIA ® You agree to only use Gracenote data, Gracenote The Gracenote software and everything included Gracenote software and Gracenote servers for your own in Gracenote data are licensed to you "as is". personal non-commercial use. You agree not to Gracenote provides no undertakings or warran- assign, copy, transfer or transmit this Gracenote ties, express or implied, as to the accuracy of the...
Page 467 AUDIO AND MEDIA Sensus software ARE DISCLAIMED. IN NO EVENT SHALL THE sublicense, and/or sell copies of the Software, COPYRIGHT OWNER OR CONTRIBUTORS BE and to permit persons to whom the Software is This software uses parts of sources from clib2 LIABLE FOR ANY DIRECT, INDIRECT, furnished to do so, subject to the following and Prex Embedded Real-time OS - Source...
Page 468 AUDIO AND MEDIA Linux software 1. Redistributions of source code must retain Copyright c 1991-2013 Unicode, Inc. All rights the above copyright notice, this list of reserved. Distributed under the Terms of Use in This product contains software licensed under conditions and the following disclaimer as http://www.unicode.org/copyright.html.
Page 469 AUDIO AND MEDIA INCLUDED IN THIS NOTICE BE LIABLE FOR Declaration of Conformity for ANY CLAIM, OR ANY SPECIAL INDIRECT OR ® Bluetooth module CONSEQUENTIAL DAMAGES, OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THE DATA FILES OR...
Page 470 AUDIO AND MEDIA Country/ Area Exporting country: Japan Manufacturer: Mitsubishi Electric Corporation Type of equipment: Audio Navigation Unit Hereby, Mitsubishi Electric Corporation declares that this Audio Navigation Unit is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EG.
Page 471 AUDIO AND MEDIA Country/ Area China: ■ 使用频率 2.4 - 2.4835 GHz ■ 等效全向辐射率(EIRP) 天线增益 10dBi 时 ≤100 mW 或≤20 dBm ① ■ 最大率谱密度天线增益 10dBi 时 ≤20 dBm / MHz(EIRP) ① ■ 载频容限 20 ppm ■ 帯外发射率(在 2.4-2.4835GHz 頻段以外) ≤-80 dBm / Hz (EIRP) ■...
Page 472 AUDIO AND MEDIA Country/ Area B 급 기기 (가정용 방송통신기자재) Korea: 이 기기는 가정용(B 급) 전자파적합기기로서 주로 가정에서 사용하는 것을 적으로 하며, 든 지역에서 사용할 수 있습니다. 해당 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없습니다. 低功率電波輻射性電機管理辦法 Taiwan: 第十二條...
Page 473 AUDIO AND MEDIA Country/ Area Brazil: Este equipamento opera em caráter secundário isto e, náo tem direito a protecão contra interferéncia prejudicial, mesmo tipo, e não pode causar interferéncia a sistemas operando em caráter primário. Para consultas, visite: www.anatel.gov.br Kazakh- stan: Model name: NR 0V Manufacturer: Mitsubishi Electric Corporation...
Page 474 AUDIO AND MEDIA Country/ Area Mexico: The Uni- ted Arab Emirates: Related information • Audio and media (p. 430) • Media player (p. 438) • Online car* (p. 456) • ® Gracenote (p. 441) • Sensus - connection and maintenance (p.
Page 475: Terms And Conditions For Services And Customer Privacy Policy
Volvo. Volvo offers a wide range of services, from assistance in emergency situations to navi- gation in various infotainment services.
Page 477: Wheels And Tyres
WHEELS AND TYRES...
Page 478 Recommended tyres A suitable distance for the first change is approx. On delivery, the car is equipped with Volvo origi- 5000 km and then at 10000 km intervals. nal tyres that have the VOL...
Page 479: Tyres' Rotation Direction
WHEELS AND TYRES Tyres' rotation direction Storage NOTE Wheels with tyres fitted must be stored lying Tyres with a tread pattern which are designed to Make sure that both pairs of wheels have the down or hanging up - never standing up. only turn in one direction have the direction of same type and dimension, and also the same rotation marked with an arrow.
Page 480: Tread Wear Indicators On The Tyres
WHEELS AND TYRES Tread wear indicators on the tyres Checking the tyre pressures pressures the tyres should have at different loads and speed conditions. Tread wear indicators show the status of the Tyres with the correct air pressure increase driv- tyre's tread depth.
Page 481: Tyre Pressure Monitoring
WHEELS AND TYRES Related information Tyre pressure monitoring When the tyre pressure is too low, the indicator • symbol for low tyre pressure is illuminated in the Tyres (p. 476) The tyre pressure monitoring system, Tyre display and a message is shown, see also the •...
Page 482 WHEELS AND TYRES bol for low tyre pressure. When the system To bear in mind General information on the tire pressure • detects a fault, the symbol in the driver display Always calibrate the system after changing a monitoring system will flash for about one minute and then remain wheel in order to ensure that replacement Each tyre, including the spare tyre*, should be...
Page 483: Check Tyre Pressure With The Tyre Pressure Monitoring System
2. Tap on Status to show the status of the system is not working correctly, contact an tyres. authorised Volvo workshop (recommended). Yellow tyre: Status indication • The tyre's pressure is too low. Stop and Related information The graphics show the status for each tyre.
Page 484: Rectifying Low Tyre Pressure With Tyre
WHEELS AND TYRES Rectifying low tyre pressure with 2. Inflate the tyres to the correct pressure as NOTE indicated on the tyre pressure label on the tyre pressure monitoring To avoid incorrect tyre pressure, the pressure door pillar on the driver's side. When the tyre pressure monitoring system, Tyre should be checked on cold tyres.
Page 485 160 km/h (100 mph), the tyre emergency puncture repair kit (p. 489) pressure should be adjusted in accordance with Volvo's recommended tyre pressure values. Fol- lowing which, the system must be recalibrated. 1. Stop the engine. 3. Start the engine.
Page 486: Emergency Puncture Repair Kit
The compressor for temporary emergency If calibration fails, a message is shown: puncture repair has been tested and Calibration unsuccessful. Please try approved by Volvo. again. NOTE Location The puncture repair kit is located in the foam Remember that the TPMS system must be block under the floor in the cargo area.
Page 487: Using The Emergency Puncture Repair Kit
WHEELS AND TYRES Using the emergency puncture WARNING repair kit • In the event of skin contact with the seal- Seal a puncture with the emergency puncture ing fluid, it must be washed off immedi- repair kit, Temporary Mobility Kit (TMK). ately with soap and plenty of water.
Page 488 Bottle removal NOTE must be performed at a workshop, Volvo Do not break the bottle's seal before use. The recommends an authorised Volvo work- seal is broken automatically when the bottle is shop.
Page 489 WHEELS AND TYRES 7. Connect the electrical cable to the closest 9. Inflate the tyre for 7 minutes. 14. As soon as possible, drive at least 3 km at a 12 V socket and start the car. maximum speed of 80 km/h (50 mph) so that the sealing fluid can seal the tyre.
Page 490 Check the tyre pressure regularly. 3. Switch off the compressor. 18. Remove the tyre sealing equipment, fit the Volvo recommends that the car is driven to the protective cap on the air hose and fold the nearest authorised Volvo workshop for the hose in the box.
Page 491: Inflate Tyres With The Compressor
2. Unscrew the wheel's dust cap and screw in Contact an authorised Volvo workshop for updat- the air hose valve connection to the bottom ing the software at each change of tyre dimen- of the thread on the tyre's air valve.
Page 492: Removing A Wheel
WHEELS AND TYRES Removing a wheel 4. Place chocks in front of and behind the WARNING wheels which will remain on the ground to Instructions for removing a wheel when chang- Check that the jack is not damaged, that the prevent them from rolling.
Page 493: Fitting The Wheels
WHEELS AND TYRES Fitting the wheels Crank up the jack* so that it makes contact WARNING with the car's jacking point. Check that the Instructions for fitting a wheel when changing Never position anything between the ground head of the jack is correctly positioned in the wheels.
Page 494: Wheel Bolts
Nm. Overtightening or loose tightening may damage the nuts and the bolts. Only use rims that are tested and approved by Volvo and which are Volvo genuine accessories. Check the tightening torque of the wheel bolts with a torque wrench.
Page 495: Winter Wheels
IMPORTANT NOTE • Never drive faster than 80 km/h Contact a Volvo dealer for advice about which (50 mph) with a spare wheel on the car. wheel rim and type of tyre are most suitable. • The car must never be driven fitted with more than one "Temporary Spare"...
Page 496: Tool Kit
Storage spaces The warning triangle is fitted with two clips on the Snow chains inside of the boot lid. Volvo recommends that snow chains are not used on wheel dimensions greater than Folding up the warning triangle 18 inches. Mounting instructions are supplied with Volvo original snow chains.
Page 497: Jack
WHEELS AND TYRES Jack* Applies to cars with level control* If the car is equipped with air suspension then Use the jack to raise the car when changing a this must be deactivated before the car is raised wheel. with the jack. Only use the original jack when fitting a spare Switch off the function via the centre display: wheel or when changing between summer and...
Page 498: First Aid Kit
WHEELS AND TYRES First aid kit Dimension designation for wheel Dimension designation for tyre The first aid kit contains first aid equipment. Designations for tyre dimension, load index and Wheel and rim dimensions are designated in speed rating. Store the first aid kit in the space on the right- accordance with the examples in the table hand side in the cargo area.
Page 499 WHEELS AND TYRES Speed rating WARNING Each tyre can withstand a certain maximum The lowest permitted load index (LI) and speed. Tyre speed rating, SS (Speed Symbol), speed rating (SS) for the tyres for each must at least correspond with the car's top respective engine variant are shown in the speed.
Page 501 MAINTENANCE AND SERVICE...
Page 502: Volvo Service Programme
Create a Volvo ID, see section "Volvo ID". • Checking and filling with engine oil • Register the Volvo ID for your car, see sec- (p. 511) tion "Volvo ID". If a Volvo ID already exists, • Book service and repair (p. 500) use the same e-mail address that was used when the Volvo ID was created.
Page 503 Selecting a Volvo dealer other important information to your work- Select the Volvo dealer you would like to contact shop. for service and repairs by going to www.volvocars.com and navigating to My Volvo.
Page 504 • meter reading car, e.g. if you book a workshop visit directly via • the car's vehicle identification number (VIN the My Volvo owner's portal, and will help your workshop with better basic information. • the car's software version •...
Page 505: Remote Updates
MAINTENANCE AND SERVICE Remote updates System updates Related information • Volvo ID (p. 23) Several of the car's systems can be updated System updates are intended for the Internet- • from the centre display with an online car. connected and infotainment components of the Online car* (p.
Page 506: Data Transmission Between Car And
Data download may affect other services that not be cancelled. The time required for a booked visit to a Volvo transmit data, e.g. Internet radio. If the effect workshop can be shortened by transmitting trou- Background search for software...
Page 507 MAINTENANCE AND SERVICE 2. Press Without driver confirmation Communication Volvo Service This option provides the most convenient way of Networks. transmitting troubleshooting data. The car con- 3. Select Automatically connect when I nects without the need for the driver to confirm.
Page 508 3. Select Deactivate Suspension & Leveling Control NOTE Volvo recommends only using the jack that belongs to the car model in question. If a jack is selected other than the one recommended by Volvo, follow the instructions supplied with the equipment.
Page 509 MAINTENANCE AND SERVICE The triangles in the plastic cover indicate the locations of the lifting points (marked in red). If the car is raised with a workshop jack, it must be positioned under one of the four lifting points. Ensure that the workshop jack is positioned so that the car cannot slide off the jack.
Page 510: Opening And Closing The Bonnet
For more information on graphics, see section "Door and seatbelt reminder". NOTE If the warning symbol is lit or the warning sig- nal is heard despite the bonnet being closed properly, contact an authorised Volvo work- shop.
Page 511: Engine Compartment Overview
Always have the engine cleaned by a work- shop - an authorised Volvo workshop is rec- ommended. There is a risk of fire if the engine is hot.
Page 512: Engine Oil
If the car is driven in adverse conditions, environmental impact. Volvo recommends using an oil of a higher grade. An approved engine oil must be used in order Related information that the recommended service intervals can •...
Page 513: Checking And Filling With Engine Oil
If this symbol is shown together with the message Engine oil level Service required , visit a workshop - an authorised Volvo workshop is recommended. The oil level may be too high. Engines with electronic oil level sensor do not have a dipstick.
Page 514: Topping Up Coolant
MAINTENANCE AND SERVICE Topping up coolant NOTE The coolant cools the internal combustion If the right conditions for measuring the oil engine to the correct operating temperature. The level (time after engine shutdown, the car's heat that is transferred from the engine to the inclination, outside temperature, etc.) are not coolant can be used to heat the passenger com- met, then the message...
Page 515 Coolant expansion tank, right-hand drive car. cooling system. • Always use coolant with anti-corrosion agent as recommended by Volvo. • Ensure that the coolant mixture is 50% water and 50% coolant. • Mix the coolant with approved quality tap water.
Page 516: Servicing The Climate Control System
Ultraviolet light must be used dur- before the bulbs can be replaced. ing leak detection. Volvo recommends that you contact an author- ised Volvo workshop. Cars with R134a refrigerant WARNING The air conditioning system contains pressur- ised refrigerant R134a.
Page 517 Front fog lamps/cornering lights* (LED The car's electrical system must be in ignition position 0 when replacing bulbs. An authorised Volvo workshop is recommended. LED (Light Emitting Diode) * Option/accessory, for more information, see Introduction.
Page 518: Replacing The Dipped Beam Bulb
Position lamps (LED) Reversing lamp Brake light - central, high-level (LED) Left-hand headlamp. 1. Detach the headlamp's rubber cover for the dipped beam bulb. LED (Light Emitting Diode) Contact a workshop for replacement - an authorised Volvo workshop is recommended.
Page 519: Replacing The Main Beam Lamp
MAINTENANCE AND SERVICE Replacing the main beam lamp 2. Unplug the connector from the bulb. 4. Unplug the connector from the bulb. The main beam lamp in halogen headlamps can 3. Detach the bulb by pushing it gently upwards 5. Replace the bulb. be replaced by the driver.
Page 520: Replacing Daytime Running Light
MAINTENANCE AND SERVICE Replacing daytime running light Replacing the front direction NOTE bulb/position lamp bulb, front indicator bulb The bulb for the daytime running light/posi- The bulb for the daytime running light/position The direction indicator bulb in halogen head- tion lamp is easier to access if the main beam lamp in halogen headlamps can be replaced by lamps can be replaced by the driver.
Page 521: Replacing The Rear Fog Lamp Bulb
MAINTENANCE AND SERVICE Replacing the rear fog lamp bulb The bulb for the rear fog lamp is located behind the panel in the boot lid. Left-hand drive cars have the fog lamp bulb on the left-hand side, right-hand drive on the right- hand side.
Page 522: Bulb Specifications
(e.g. for scraping off ice from the windscreen) • Bulb replacement (p. 514) they must be in service position. IMPORTANT Before placing the wiper blades in the service position, make sure that they are not frozen down. An authorised Volvo workshop is recommended.
Page 523: Replacing A Wiper Blade
MAINTENANCE AND SERVICE Replacing a wiper blade Activating service position Via settings Service mode cannot be activated when the car 1. Press Settings in the top view in the centre The wiper blades sweep water away from the is stationary and the windscreen wipers are not display.
Page 524 MAINTENANCE AND SERVICE Replacing the wiper blade, rear window Fold up the wiper arm when it is in service position. Press the button located on the wiper blade mounting and pull straight out The wiper blades are different lengths. parallel with the wiper arm. 1.
Page 525: Filling Washer Fluid
When approx. 1 litre of washer fluid remains in the reservoir the message Washer fluid Level low, refill is shown in the driver display together with the symbol Prescribed grade: Washer fluid recommended by Volvo - with frost protection during cold weather and below freezing point.
Page 526: Starter Battery
MAINTENANCE AND SERVICE Starter battery WARNING The electrical system is single-pole and uses the • The battery can generate oxyhydrogen chassis and engine casing as a conductor. gas, which is highly explosive. A spark can be formed if a jump lead is connected The starter battery is used to start up the electri- incorrectly, and this can be enough for cal system and drive the starter motor as well as...
Page 527 MAINTENANCE AND SERVICE IMPORTANT NOTE If the following instruction is not observed The life of the battery is shortened if it then the energy saving function for infotain- becomes discharged repeatedly. ment may be temporarily disengaged, and/or The life of the battery is affected by several the message in the driver display about the factors, including driving conditions and cli- starter battery's state of charge may be tem-...
Page 528: Symbols On The Batteries
H7 AGM battery. Further information in the owner's manual for the car. Volvo recommends entrusting battery replace- ment to an authorised Volvo workshop. IMPORTANT When replacing the starter battery or support Store the battery out of the battery, a battery of AGM type must be fit- reach of children.
Page 529: Support Battery
MAINTENANCE AND SERVICE Support battery Voltage (V) Cars with Start/Stop function, in addition to the Cold start capacity - CCA Avoid sparks and naked starter battery, are equipped with a support bat- flames. tery. Size , L×W×H (mm) 150×90×130 Cars with the Start/Stop function are equipped with two 12 V batteries - one extra powerful Capacity (Ah) starter battery for starting and one support bat-...
Page 530 Start/Stop function tions or problems - an authorised Volvo workshop will be activated. It will then be possible for is recommended.
Page 531: Fuses
Volvo recommends contacting an authorised Volvo workshop for checking. 3. If this is the case, replace it with a new fuse of the same colour and amperage.
Page 532: Fuses In Engine Compartment
MAINTENANCE AND SERVICE Fuses in engine compartment Fuses in the engine compartment protect engine and brake functions, amongst other things.
Page 533 Horn Right-hand headlamp Siren* USB port in tunnel console, front* Control module for brake system 12 V socket in tunnel console, (valves, parking brake) front An authorised Volvo workshop is recommended. * Option/accessory, for more information, see Introduction.
Page 534 MAINTENANCE AND SERVICE Function Function Function Module for controlling battery Vacuum regulators; Valve; Valve engagement for output pulse (diesel) Airbags Control module spoiler roller cover; Control module radiator Starter motor Shunt Left-hand headlamp roller cover; Relay coils for out- Starter motor put pulse (diesel) Accelerator pedal sensor Ampere...
Page 535: Fuses Under Glovebox
MAINTENANCE AND SERVICE Fuses under glovebox Fuses under the glovebox protect, amongst other things, the 230 V socket, displays and door modules.
Page 536 MAINTENANCE AND SERVICE On the inside of the cover there are tweezers that The fuse box in the engine compartment also facilitate the procedure for the removal and fitting provides space for several spare fuses. of fuses.
Page 537 Centre display Sun sensor Fan module for climate control sys- Humidity sensor tem, front Door module in right-hand rear door Fuses in cargo area Steering wheel module An authorised Volvo workshop is recommended. * Option/accessory, for more information, see Introduction.
Page 538 MAINTENANCE AND SERVICE Function Function Control module for Internet-con- Door module in left-hand front door nected car; Control module for tel- Control module for suspension ematics (active chassis)* Door module in left-hand rear door Audio control module (amplifier) Sensus control module (certain variants) Module for multi-band antenna Modules for seat comfort (mas-...
Page 539: Fuses In Cargo Area
MAINTENANCE AND SERVICE Fuses in cargo area Fuses in the cargo area protect, amongst other things, power seats*, airbags and seatbelt ten- sioners. * Option/accessory, for more information, see Introduction.
Page 540 MAINTENANCE AND SERVICE On the inside of the cover there are tweezers that The fuse box in the engine compartment also facilitate the procedure for the removal and fitting provides space for several spare fuses. of fuses.
Page 541 Electrically operated front passen- • Replacing a fuse (p. 529) ger seat* • Fuses under glovebox (p. 533) Towbar control module* • Fuses in engine compartment (p. 530) An authorised Volvo workshop is recommended. * Option/accessory, for more information, see Introduction.
Page 542: Cleaning The Exterior
(Auto Hold) and sponge soaked in plenty of water. An author- use water and a non-scratching sponge Automatic application of parking brake. If ised Volvo workshop is recommended for the instead. these functions are not deactivated, the brake removal of any discoloration.
Page 543 Testing the brakes components tion and destroy the surface treatment. Lightly depress the brake pedal now and then A special cleaning agent available from Volvo when driving long distances in rain or slush. The dealers is recommended for the cleaning and Rims...
Page 544: Polishing And Waxing
IMPORTANT • Polishing and waxing (p. 542) Polish and wax the car if the paintwork is dull or Only paint treatment recommended by Volvo • Wiper blades in service position (p. 520) to give the paintwork extra protection. The car should be used.
Page 545: Rustproofing
• of the leather shall be preserved. Volvo offers a Certain items of coloured clothing (e.g. shielding plastic components, abrasion protection comprehensive product, Volvo Leather Care Kit/ dark jeans and suede garments) may and supplemental rust inhibitor in exposed areas.
Page 546: Cleaning The Centre Display
A fibrillated fibre or microfibre cloth, lightly mois- Dirt, stains and grease from fingers can affect mats should be cleaned with agents recom- tened with water, available from Volvo dealers, is the centre display's performance and readability. mended by Volvo dealers.
Page 547: Paint Damage
MAINTENANCE AND SERVICE Paint damage Touching up minor paintwork damage IMPORTANT To avoid the onset of rust, damaged paintwork Paint is an important part of the car's rustproof- The microfibre cloth used to clean the centre should be rectified immediately. ing and should therefore be checked regularly.
Page 548: Repairing Paint Damage
For scratches, proceed as described above, but mask around the damaged area to protect the undamaged paintwork. Touch-up pens and spray paints are available from Volvo dealers. NOTE If the stone chip has not penetrated down to the meal and an undamaged layer of paint...
Page 549 SPECIFICATIONS...
Page 550: Type Designations
The illustration is schematic - details may vary depending on market and model. Knowing the car's type designation, vehicle iden- tification and engine numbers can facilitate all contact with an authorised Volvo dealer regarding the car and when ordering spare parts and accessories.
Page 551 SPECIFICATIONS Type designation, vehicle identification num- Decal A/C system for cars with refrigerant Engine code and engine serial number. ber, permissible maximum weights and code des- R134a. ignation for exterior colour and type approval number. The decal is positioned on the door pil- lar, and will be visible when the right-hand rear door is opened.
Page 552 SPECIFICATIONS Car's identification number (VIN Vehicle Iden- tification Number). Further information on the car is presented in the registration document. NOTE It is not intended that the decals illustrated in the owner's manual should be exact replicas of those in the car. They are included to show their approximate appearance and location in the car.
Page 553: Dimensions
SPECIFICATIONS Dimensions Measurement of car length, height, etc. can be read in the table. Dimensions Dimensions Dimensions Wheelbase 2941 Front track Width including door mirrors 2019 1628 Length 4963 1617 Width including folded-in door 1895 mirrors Load length, floor, folded seat 1978 Rear track 1629...
Page 554: Weights
SPECIFICATIONS Weights NOTE Max. gross vehicle weight, etc. can be read on a The documented kerb weight applies to cars label in the car. in the standard version - i.e. a car without extra equipment or accessories. This means Kerb weight includes the driver, the fuel tank that for every accessory added the loading 90% full and all fluids.
Page 555: Towing Capacity And Towball Load
SPECIFICATIONS Towing capacity and towball load Max. weight braked trailer Towing capacity and towball load for driving with NOTE a trailer can be read in the tables. The use of a stabiliser hitch on the towing bracket is recommended for trailers heavier than 1800 kg.
Page 556 SPECIFICATIONS Engine Gearbox Max. weight braked trailer (kg) Max. towball load (kg) Engine code D4204T14 Automatic 1800 1800 D5 AWD D4204T23 Automatic 2200 The engine code, component number and serial number can be found on the engine. Applies to cars that are not equipped for a higher towing weight. Applies to cars that are equipped for a higher towing weight.
Page 557: Engine Specifications
SPECIFICATIONS Engine specifications NOTE Engine specifications (output etc.) for each Not all engines are available in all markets. respective engine alternative can be read in the table. Engine Output Output Torque No. of cylinders Engine code (kW/rpm) (hp/rpm) (Nm/rpm) B4204T20 183/5500 249/5500 350/1500-4500...
Page 558: Engine Oil — Specifications
SPECIFICATIONS Engine oil — specifications Engine oil grade and volume for each respective engine alternative can be read in the table. Volvo recommends: Engine Oil grade Volume, incl. oil filter Engine code (litres) B4204T20 Castrol Edge Professional V 0W-20 or VCC RBS0-2AE 0W-20 approx.
Page 559: Adverse Driving Conditions For Engine Oil
Volvo Car Corporation driving conditions. It provides extra protection for disclaims any liability for any such damage. the engine. Volvo recommends that oil changes are car- Volvo recommends: ried out at an authorised Volvo workshop. Related information •...
Page 560: Coolant — Specifications
Automatic gearbox turn act on a mechanical brake. Prescribed transmission fluid: Prescribed grade: Volvo Original brake fluid or equivalent. NOTE The gearbox oil does not need to be changed NOTE under normal driving conditions.
Page 561: Fuel Tank — Volume
SPECIFICATIONS Fuel tank — volume Air conditioning — specifications Symbol explanation R1234yf Fuel tank volume for each respective engine The car's climate control system uses a refriger- Symbol Meaning alternative can be read in the table. ant, either R1234yf or R134a depending on Caution market.
Page 562 SPECIFICATIONS Refrigerant Evaporator Cars with refrigerant R134a IMPORTANT Weight Prescribed grade The A/C system's evaporator must never be 700 g R134a repaired or replaced with a previously used evaporator. A new evaporator must be certi- fied and labelled in accordance with SAE WARNING J2842.
Page 563: Fuel Consumption And Co2 Emissions
SPECIFICATIONS Fuel consumption and CO2 urban driving NOTE emissions If the consumption and emission data is miss- extra-urban driving ing then it is included in the enclosed supple- Fuel consumption in a vehicle is measured in ment. litres per 100 km and CO2 emissions in grams CO2 per km.
Page 564 SPECIFICATIONS • The driver's driving style. Related information • Type designations (p. 548) • If the customer has specified wheels larger • than those fitted as standard on the model's Weights (p. 552) basic version, then rolling resistance increa- • Driving economically (p.
Page 565: Approved Tyre Pressures
SPECIFICATIONS Approved tyre pressures NOTE Approved tyre pressures for each engine alterna- All engines, tyres or combinations of these tive can be found in the table. are not always available in all markets. Engine Tyre size Speed Load, 1-3 persons Max.
Page 567: Alphabetical Index
ALPHABETICAL INDEX ALPHABETICAL INDEX radar sensor Air recirculation 1, 2, 3 ... setting the time interval Alarm standby mode automatic re-arming temporary deactivation deactivation Additional heater (Auxiliary heater) reduced alarm level Adjusting the steering wheel Alcohol lock Aerial Allergy and asthma inducing substances. A/C (Air conditioning) location All Wheel Drive, (AWD)
Page 568 ALPHABETICAL INDEX Automatic engine stop Bluetooth auto-stop connect connect car to Internet Camera sensor Automatic gearbox phone trailer Car care settings Leather upholstery Automatic relocking Bonnet, opening Car functions Automatic speed limiter Book service and repair in centre display Boot lid Cargo area jack for connecting media Locking/unlocking...
Page 569 ALPHABETICAL INDEX climate control Clean Zone Interior Package Cooling system messages overheating Climate control 174, 178 operation 36, 40 auto-regulation Cornering lights overview centre display Corner Traction Control symbols in status bar experienced temperature Crash, see Collision Checking the engine oil level fan control Cruise control 271, 272...
Page 570 ALPHABETICAL INDEX Diesel particle filter import/export from/to USB Emergency puncture repair 484, 489 select action Digital radio (DAB) inflating the tyres Drivetrain Dimensions rechecking Gearbox Towing bracket Emergency puncture repair kit Driving dipped beam location cooling system Dipstick, electronic overview with a tailer sealing fluid Direction indicator...
Page 571 ALPHABETICAL INDEX Error messages Front seat Adaptive Cruise Control Climate control see Messages and symbols 289, 312 Gearbox heating automatic Error messages in BLIS Temperature Gear positions Ethanol content Ventilation automatic gearbox maximum 10 percent by volume Front seat, manual Gear selector inhibitor External dimensions Front seat, power...
Page 572 ALPHABETICAL INDEX Headlamp pattern adjustment Immobiliser head restraint Indicator symbols Jack Heated washer nozzles Inflatable curtain Journey statistics Heater Inflatable Curtain Jump starting auxiliary heater Information display parking heater Infotainment system (Audio and media) Heating Instrument lighting seats Instrument overview steering wheel Kerb weight left-hand drive car...
Page 573 ALPHABETICAL INDEX Lighting Loading Max. roof load active bending lights cargo area Media player approach lighting General compatible file formats automatic lighting, passenger compart- load retaining eyelets voice control ment long load Messages and symbols Automatic main beam Loading hooks Adaptive Cruise Control bulbs, specifications Load retaining eyelets...
Page 574 ALPHABETICAL INDEX Online car Parking brake 402, 403, 405 PIN code book service and repair Parking climate Pocket park assist - PAP connect car Symbols and messages Polishing no or poor connection Parking heater Position lamp system updates Passenger Airbag Cut Off Switch Power operated boot lid 241, 243 Output...
Page 575 ALPHABETICAL INDEX Recommendations during driving Road sign information Limitations Recovery Radar sensor operation 344, 346, 347 Red Key Limitations Roll Stability Control Refrigerant Radio Roof load, max. weight Refuelling change and search for radio station RSC (Roll Stability Control) Regeneration Run out of fuel settings ®...
Page 576 ALPHABETICAL INDEX Seats slippery driving conditions keypad heating paddle Soot filter manual front seat steering wheel adjustment spare wheel memory function front seat Steering wheel paddles Speed camera power front seat 117, 119 Stone chips and scratches 545, 546 rear seat Speed limiter 264, 268 Stop/start function...
Page 577 ALPHABETICAL INDEX Symbols TPMS - Tyre Pressure Monitoring 479, Type approval indicator symbols 481, 483 radar system remote control key system Symbols and messages Traction control Adaptive Cruise Control Type designations Traffic information centre display status field Tyre dimension 489, 496 Trailer Collision Warning with Auto Brake cable...
Page 578 Unit standard windscreen Voice recognition Trip computer Waxing VOL marking unlock, lock, open boot lid, manual opening Weights Volvo ID of boot lid, electric lock, rubberised pres- kerb weight sure plate Wheel bolts Unlocking lockable from the outside Wheel change...
Page 579 ALPHABETICAL INDEX Window sun blind Windows and glass Windscreen heating projected image Windscreen washing Windscreen wiper rain sensor Winter driving Winter tyres Winter wheels Wiper blades changing Service position Wipers and washing...
Page 580 ALPHABETICAL INDEX...
Page 582 TP 21106 (English), AT 1617, MY17, Printed in Sweden, Göteborg 2016, Copyright © 2000-2016 Volvo Car Corporation...

Save PDF
