VÄLKOMMEN! We trust that you will enjoy many years of safe driving in your Volvo, an We also urge you and your passengers to wear seat belts at all times in automobile designed with your safety and comfort in mind.
General safety information Volvo Roadside Assistance Glass Occupant safety Additional information about your vehicle Technician certification Reporting safety defects Volvo and the environment Recall information IntelliSafe—driver support Safety during pregnancy Whiplash protection system Sensus Owner's manual in mobile devices Seat belts...
Page 5
PRACTICAL INFORMATION Top tether anchors Passenger compartment storage spaces Wheel bolts Engine compartment overview Removing a wheel Using the glove compartment Installing a wheel Tunnel console Tire Pressure Monitoring System (TPMS) Sun visors Checking tire inflation pressure Loading Reinflating tires equipped with the Tire Pressure Monitoring System (TPMS) Grocery bag holder Calibrating the Tire Pressure...
Page 6
FUSES SPECIFICATIONS INDEX Fuses Label information Index Replacing fuses Dimensions Fuses in the engine compartment Weights Fuses in the passenger compartment Air conditioning refrigerant Fuses in the trunk Brake fluid specification and volume Coolant specifications Engine specifications Engine oil specifications and volume Fuel tank volume Tire inflation pressure table Transmission fluid specification and...
Use the following contact information if you Your new Volvo comes with a four year Volvo would like to get in touch with Volvo in the Uni- Roadside Assistance program. Volvo Cars' website and support site provide ted States or Canada.
• See a trained and qualified Volvo service technician as soon as possible for inspection Volvo was the first in the world to introduce into if the check engine (malfunction indicator) production a three-way catalytic converter with a light illuminates, or stays on after the vehicle Lambda sond, now called the heated oxygen sen- has started.
IntelliSafe is Volvo's philosophy regarding vehi- cle safety. It encompasses a number of systems, both standard and optional, that are designed to help make driving and traveling in a Volvo safer. Support Systems that help make driving safer are an inte- gral part of IntelliSafe.
Sensus Sensus provides an intelligent interface and Internet-connected service with an intuitive navi- Sensus is the core of your personal Volvo experi- gation structure that offers access to relevant ence and provides information, entertainment information when it is needed, with minimal dis- and features that make owning your vehicle eas- tractions.
Page 12
INTRODUCTION Information when it's needed, where it's needed Information is presented in different displays depending on how it should be prioritized (generic illustration) Head-up-display* ately, such as traffic warnings, speed information Instrument panel and navigation. Road sign information and incom- ing phone calls are also displayed here.
Page 13
INTRODUCTION Many of the vehicle's main functions are con- trolled from the center display, a touchscreen that reacts to taps or other gestures. The number of physical buttons is thereby minimized. The screen can be operated with or without gloves. The center display is used to control e.g., the cli- mate and infotainment systems and to adjust the power seats*.
These apps also contain videos and interior/ and the contents are searchable. formed only by a trained and qualified Volvo exterior hotspot views of the vehicle that you can service technician. click on for additional information.
Page 15
Volvo. In all cases, please consult a trained safety. try's applicable safety and exhaust emis- and qualified Volvo service technician before sion requirements.
(2) this device must accept any interference WARNING owner's manual is available on the vehicle's cen- received, including interference that may cause ter display, as a mobile app and on Volvo's sup- undesired operation. Volvo Cars takes no responsibility for the con- port website.
Page 17
(or a new owner's manual supplement) Related information Navigation between the various articles in the can be ordered through a Volvo retailer. • Owner's manual in mobile devices (p. 12) owner's manual is designed to provide easy •...
Never program your audio system while or if you allow accessories to be installed by in the driving environment. Your new Volvo is, or the vehicle is moving. Program radio pre- someone unfamiliar with your vehicle.
Due to the above, Volvo Car USA does not sup- port the use of aftermarket, alternative or any- thing other than original Volvo parts for collision repair.
Whether or not the driver and passenger them to diagnose and rectify any faults that have safety belts were buckled/fastened; occurred in the vehicle and to enable Volvo to ful- • fill legal and other regulatory requirements. Infor- How far (if at all) the driver was depressing mation thus registered in the vehicle is registered the accelerator and/or brake pedal;...
2. Start the app and create a Volvo ID on the start page. 3. Register a personal email address and then follow the instructions that will be sent auto- matically to this address. These services vary and may be subject to change. Consult your Volvo retailer.
INTRODUCTION Center display overview Many of the vehicle's functions are controlled from the center display. Three of the center display's basic views. Swipe to the right/left to access the Function/App view (generic illustration)
Page 23
INTRODUCTION Function view: vehicle functions can be acti- The extra sub-view: the most recently used vated/deactivated by tapping. Certain func- apps/vehicle functions that do not belong in tions are called "trigger functions", which any of the other sub-views are listed here. Camera open settings windows, e.g., Tap the sub-view to expand it.
INTRODUCTION Changing center display settings ground will be light and the text will be dark, which can increase readability in strong ambient The center display activates automatically when lighting. the driver's door is opened. Settings can be made for e.g., sounds, background and themes. These alternatives are always available and do not shift automatically according to changes in Turning off or changing the volume of...
INTRODUCTION Using the center display keyboard A keyboard can be used on the center display to enter characters and search for e.g., destina- tions using the navigation system, adding con- tacts in phone book, etc. It is also possible to use handwriting on the screen.
Page 26
INTRODUCTION Keyboard function buttons (the appearance may vary depending on language settings, context, etc.) Field for possible search hits. The word word to select it. The keyboard may not sup- The characters that can be entered are lan- changes as new letters are added. Scroll in port all language selections, in which case guage-dependent (see point 7).
Page 27
INTRODUCTION Several buttons (depending on the context languages and tap a language to use it. To When more than one language for which the keyboard is being used) will be add keyboard languages, see the heading has been selected, this button displayed here.
Page 28
INTRODUCTION Special characters Entering characters 1. Enter a handwritten character (1) using a fin- gertip or by holding e.g., a pen near the screen. > Several character suggestions will appear (3). The most likely character will be at the top of the list. CAUTION Do not touch the screen with sharp objects because this could cause scratches.
Page 29
INTRODUCTION Erasing/changing handwritten characters New lines Erase a character by swiping over the handwriting area Create a new line by drawing above the characters as shown in the illustration Blank spaces Characters can be erased/changed in several ways: • Tap the desired character in the list (3). •...
INTRODUCTION Function view buttons Different types of buttons on-screen function buttons. From the Home view, swipe from left to right on the screen to There are three different types of vehicle function The Function view, which is one of the center come to the Function view.
Page 31
INTRODUCTION The yellow triangle indicates that the function is not working correctly Related information • Center display overview (p. 20) • Navigating in the center display's views (p. 30)
INTRODUCTION Navigating in the center display's used app/vehicle function is a music app, the NOTE views Media sub-view will be displayed. When the vehicle is moving: There are 5 different basic views in the center The sub-views display brief information about the •...
Page 33
INTRODUCTION Expanding a sub-view from the standard view Standard view and an expanded sub-view in the center display...
Page 34
INTRODUCTION Status bar Expanding a sub-view: In expanded mode, open the app in full-screen mode by tap- Current vehicle activities are shown in the status – To expand sub-view one, two or three: tap ping the symbol. bar at the top of the screen. Network and con- the screen anywhere in the sub-view.
Page 35
INTRODUCTION App view To leave (minimize) Top view, tap the screen out- When applicable, swipe downward to scroll in the side of this view or tap at the bottom of Top view list of apps (depending on the number of apps and swipe upward.
Page 36
INTRODUCTION Swipe the screen from left to right to access Function view from Home view. From Function view, you can activate/deactivate various vehicle Drive Modes Speed Sign functions such as Assist Park Assist When applicable, swipe upward to scroll in the list of functions (depending on the number of func- tions).
A number of apps are standard and are part of Audio source muted. FM Radio Volvo Sensus, such as Symbol Meaning News broadcasts from current radio To change settings in a basic app: station Roaming activated.
INTRODUCTION Using the center display The screen reacts differently depending on CAUTION whether the user taps, drags or swipes on the Many of the vehicle's functions can be con- Do not touch the screen with sharp objects screen. This makes it possible to move between trolled and settings can be made from the because this could cause scratches.
Page 39
INTRODUCTION Procedure Gesture Result Drag Moves between screen views, scrolls in a list, text or a view. Press and hold to drag apps or objects in a list. Swipe Moves between screen views, scrolls in a list, text or a view Stretch Zooms in.
Page 40
INTRODUCTION Turning off and reactivating the center Moving apps and vehicle function 2. Reactivate by pressing the Home button display briefly. buttons Apps and function buttons can be moved and > The view that was displayed when the organized in their respective views. screen was turned off will be displayed again.
Page 41
INTRODUCTION Digital controls are available for many of the vehi- cle's functions. For example, to set the tempera- ture: • Drag the control to the desired temperature • − to raise or lower the temperature incrementally, or • Tap the desired temperature on the control Related information •...
There are several displays in the vehicle that mation and how to contact Volvo if help is show messages generated by various systems required. and functions in the vehicle. The appearance of...
Page 43
INTRODUCTION Risk of damage to the vehicle White ISO symbols and white text/image on a Arrows containing letters are used to indi- black background. These decals provide general cate movement. information. If there are no illustrations associated with a step-by-step list, the steps in the procedure are NOTE indicated by ordinary numbers.
INTRODUCTION On-board digital owner's manual Continuation from previous page Symbols and their descriptions This symbol can be found at the upper left When printed owner's information refers to digi- Takes you to the owner's corner to indicate that the current topic is a con- tal owner's information, this is the on-board infor- information start page.
Page 45
INTRODUCTION Navigating in the digital owner's Symbols and their descriptions Symbols and their descriptions manual Exterior/interior views of Leads to short instructional The digital on-board owner's manual is the vehicle in which certain videos for various vehicle accessed from the center display. The contents areas/components are functions.
Page 46
INTRODUCTION Searching using categories Saving/deleting favorites 1. Tap Exterior Interior followed by The articles in the owner's Save an article as a favorite by tapping the star > Exterior/interior views will be displayed manual are structured in main ) at the upper right when an article is open. with hotspots, which lead to relevant arti- and sub-categories.
Page 47
Volvo at peak operating con- Related information Laminated glass symbol • dition.
Our concern for safety dates back to 1927 when sensors in the vehicle that react and trigger the first Volvo rolled off the production line. Related information safety systems such as Roll Stability Control, air- Three-point seat belts (a Volvo invention), safety •...
• If you are taking any medication, consult your lar complaints, it may open an investi- your local retailer or Volvo Car USA, physician about its potential effects on your gation, and if it finds that a safety LLC if your vehicle is covered under driving abilities.
Volvo customers in Canada For any questions regarding open recalls for your vehicle, please contact your authorized Volvo retailer. If your retailer is unable to answer your The diagonal section should wrap over the shoul- questions, please contact Volvo Customer Rela-...
In the event of certain rear-end collisions, the must be inspected by a trained and quali- hinges and brackets of the front seat backrests fied Volvo service technician, even if the are designed to change position slightly to allow seats appear to be undamaged. Certain...
Children should be prop- work done by a trained and qualified erly restrained, using an infant, car, or booster Volvo service technician only. seat determined by age, weight and height. • Any device used to induce slack into the...
IMPORTANT INFORMATION Buckling and unbuckling seat belts 2. Insert the latch plate into the receptacle. The 3. The height of the seat belts in the front seats seat belt retractor is normally "unlocked" and can be adjusted. The height of the shoulder Seat belts should be used by all occupants in you can move freely, provided that the shoul- section of the seat belt must be correctly...
Page 57
IMPORTANT INFORMATION Unbuckling the seat belt 4. Tighten the lap section of the seat belt by pulling the diagonal section upward toward To remove the seat belt, press the red section on the shoulder. the seat belt receptacle. Before exiting the vehi- cle, check that the seat belt retracts fully after being unbuckled.
IMPORTANT INFORMATION Door and seat belt reminders Seat belt reminder Rear seats The rear seat belt reminder has two functions. The door and seat belt reminders are intended to alert all occupants of the vehicle that their • It indicates which seat belts are buckled in seat belts should be buckled before the vehicle the rear seats.
Volvo service technician for while you are driving, have the vehicle repairs. inspected by a trained and qualified Volvo Before attempting to tow the vehicle: service technician as soon as possible. 1. Switch off the ignition for at least •...
Page 60
IMPORTANT INFORMATION The location of the front airbags is indicated by certain non-frontal collisions where rapid WARNING SRS AIRBAG embossed on the steering wheel deceleration occurs. • The airbags in the vehicle are designed to pad and above the glove compartment, and by •...
Page 61
SRS system, please contact a trained and at partial capacity. If the impact is more qualified Volvo service technician or Volvo cus- severe, the airbags are triggered at full tomer support: capacity.
Never try to open the airbag cover on the Passenger's side airbag decal steering wheel or the passenger's side dashboard. This should only be done by a WARNING trained and qualified Volvo service techni- cian. • Children must never be allowed in the •...
Page 63
• out by an a trained and qualified Volvo the front passenger's seat is unoccupied, or service technician. has small/medium objects in the front seat, However, if a fault is detected in the system: •...
Page 64
This condition reflects limitations of the OWS Volvo recommends that children always be properly restrained in appropriate child restraints in the rear seats. Do not assume classification capability. It does not indicate OWS that the passenger's side front airbag is disabled unless the malfunction.
Page 65
IMPORTANT INFORMATION WARNING WARNING WARNING • • • No objects that add to the total weight on Keep the following points in mind with Do not place any type of object on the the seat should be placed on the front respect to the OWS system.
SIPS airbag system. This should be done only by a trained and The SIPS airbag system is designed to help qualified Volvo service technician. increase occupant protection in the event of cer- • In order for the SIPS airbag to provide its tain side impact collisions.
IC system. This should be and the occupant of the outboard rear seating reduced. done only by a trained and qualified Volvo positions in certain side impact collisions. service technician. If the vehicle has been involved in a collision, the •...
It must be trans- • General safety information (p. 48) ported on a flatbed tow truck to a trained and qualified Volvo service technician for inspec- 2. Turn the start knob clockwise as far as possi- tion/repairs. ble and release it.
A specially designed and tested booster cushion LATCH attachments, which make it more conven- erly restrained. A child restraint system can help and backrest can be obtained from your Volvo ient to install child seats. protect a child in a vehicle. Here's what to look retailer.
Page 70
Volvo rec- ommends that you do not disconnect the air- Why does Volvo believe that no child should sit in bag system in your vehicle. the front seat of a car? It's quite simple really. A front airbag is a very powerful device designed, •...
IMPORTANT INFORMATION Child restraints Suitable child restraints should always be used when children travel in the vehicle. Child restraint systems Convertible seat Booster cushion WARNING WARNING A child seat should never be used in the front Always refer to the child restraint manufactur- passenger seat of any vehicle with a front er's instructions for detailed information on Infant seat...
A small child's head represents a consid- erable part of its total weight and its neck WARNING is still very weak. Volvo recommends that Do not use child safety seats or child booster children up to age 4 travel, properly cushions/backrests in the front passenger's restrained, facing rearward.
Page 73
IMPORTANT INFORMATION WARNING A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the "Passen- ger airbag off" symbol near the rear-view mir- ror is illuminated (on vehicles equipped with Occupant Weight Sensor).
IMPORTANT INFORMATION Convertible seats NOTE WARNING Suitable child restraints should always be used The locking retractor will automatically It should not be possible to move the child when children (depending on their age/size) are restraint (child seat) more than 1 in. (2.5 cm) release when the seat belt is unbuckled and seated in the vehicle.
Page 75
• A small child's head represents a consider- able part of its total weight and its neck is still very weak. Volvo recommends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that children should ride rearward facing, properly restrained, as long as possible.
Page 76
IMPORTANT INFORMATION Related information NOTE WARNING • ISOFIX/LATCH lower anchors (p. 76) The locking retractor will automatically It should not be possible to move the child • Top tether anchors (p. 78) restraint (child seat) more than 1 in. (2.5 cm) release when the seat belt is unbuckled and in any direction along the seat belt path.
IMPORTANT INFORMATION Booster cushions Related information 3. Fasten the seat belt by inserting the latch • plate into the buckle (lock) until a distinct ISOFIX/LATCH lower anchors (p. 76) Securing a booster cushion click is audible. • Top tether anchors (p. 78) •...
4. Firmly tension the lower child seat straps according to the manufacturer's instructions. WARNING Volvo's ISOFIX/LATCH anchors conform to Fasten the attachment correctly to the ISOFIX/LATCH FMVSS/CMVSS standards. Always refer to lower anchors the child restraint system's manual for weight and size ratings.
IMPORTANT INFORMATION Related information Lower child seat attachment points WARNING • Top tether anchors (p. 78) The vehicle is equipped with lower attachment A child seat should never be used in the front points for child seats in the rear seats. passenger seat of any vehicle with a front passenger airbag –...
Page 80
Top tether anchors Related information Refer also to the child seat manufacturer's • Child safety (p. 67) Your Volvo is equipped with child restraint top instructions for information on securing the child • tether anchorages, located on the parcel shelf, seat.
Page 82
PRACTICAL INFORMATION Passenger compartment storage Removing the storage compartments in the door spaces panels for emptying/cleaning The following is an overview of the passenger compartment and its storage spaces. Front seats Storage spaces, cup holders and 12-volt socket/USB socket in the tunnel console and net pocket Rear seats 1.
Page 83
PRACTICAL INFORMATION Engine compartment overview WARNING The engine compartment overview shows some • The cooling fan (located at the front of maintenance points. the engine compartment, behind the radi- ator) may start or continue to operate (for up to 6 minutes) after the engine has been switched off.
Page 84
PRACTICAL INFORMATION Using the glove compartment Related information Locking/unlocking the glove • compartment* Opening and closing the hood (p. 127) The glove compartment provides storage space • for small items. Refilling the windshield washer fluid reservoir (p. 126) Storage compartment for the key The glove compartment and trunk can be locked The owner's manual and maps can be kept here.
Page 85
PRACTICAL INFORMATION Tunnel console The tunnel console, located between the front seats, contains a 12-volt electrical socket, cup holders and storage spaces, etc. To lock the glove compartment: Cooling activated Insert the key into the lock. Cooling deactivated Turn the key 90 degrees clockwise. Activate/deactivate cooling by moving the –...
Page 86
PRACTICAL INFORMATION Sun visors Loading NOTE There are vanity mirrors with card holders on the The load carrying capacity of your vehicle is One of the alarm sensors, which is sensitive upper sides of the sun visors. determined by factors such as the number of to metallic objects, is located under the tunnel passengers, the amount of cargo, the weight of console cup holders.
Page 87
Objects placed Roof loads found under the floor of the trunk. higher than this level could impede the Load carriers are available as Volvo accessories. function of the Inflatable Curtain. Observe the following points when in use: WARNING •...
Page 88
PRACTICAL INFORMATION • Grocery bag holder Load anchoring eyelets Place heavier cargo at the bottom of the load. The grocery bag holders (hooks) help keep The eyelets in the trunk can be folded out to • Secure the cargo correctly with appropriate shopping bags in place.
Page 89
Sample fuel pump octane label TOP TIER Detergent Gasoline Volvo endorses the use of “TOP TIER Detergent Gasoline” where available to help maintain engine performance and reliability. TOP TIER Detergent Gasoline meets a new standard jointly estab- lished by leading automotive manufactures to meet the needs of today’s advanced engines.
Page 90
If you live in an area partment is ventilated, and immediately return where you must fill your own gas tank, take pre- the vehicle to a trained and qualified Volvo service technician for correction. cautions. These may include: •...
Page 91
3. Avoid overfilling the fuel tank. Do not press four wheels. Otherwise there is a risk of altering Some Volvo models are equipped with an the handle on the filler nozzle after it has the car's roadholding and handling characteris- Ultra High Performance tire and wheel com- stopped pumping.
Page 92
PRACTICAL INFORMATION New tires ble cracks or discoloration should be replaced NOTE immediately. • If the tires are rotated, they should only Tire economy be moved from front to rear or vice versa. • Maintain correct tire pressure. They should never be rotated left to right/right to left.
Page 93
WARNING NOTE The following information can be found on a • The wheel and tire sizes for your Volvo Please be aware that the following tire desig- tire's sidewall. nation is an example only and that this par- are specified to meet stringent stability and handling requirements.
Page 94
A tire's Speed Symbol (SS) indicates the maxi- indicates that the tire meets all federal • The wheel and tire sizes for your Volvo mum speed for which the tire has been certified standards. The next two numbers or letters...
Page 95
• Recommended tire inflation pressure: rying capability. Inflation pressure, established by Volvo, • Extra load: A class of P-metric or Metric which is based on the type of tires that are tires designed to carry a heavier maximum mounted on a vehicle at the factory.
Page 96
RR = right rear • Tires with tread designed to roll in only one direction are marked with an arrow on the sidewall. • Contact a trained and qualified Volvo service technician if you are unsure about the tread depth.
Page 97
PRACTICAL INFORMATION Tread wear indicator Loading specifications Steps for Determining Correct Load Limit The tires have wear indicator strips running Properly loading your vehicle will provide maxi- 1. Locate the statement "the combined weight across or parallel to the tread. mum return of vehicle design performance.
Page 98
TREADWEAR rating. Use only tires with the correct load and C, representing the tire's resistance to the carrying capacity. Consult your Volvo The treadwear grade is a comparative rating generation of heat and its ability to dissipate heat retailer for information.
Page 99
18". life of the tires. • Snow chains can be used on your Volvo with the Always follow the chain manufacturer's following restrictions: installation instructions carefully. Install WARNING chains as tightly as possible and •...
Page 100
PRACTICAL INFORMATION temperature drop causes a corresponding drop of the factory-mounted tires on your vehicle, as 2. Add air to reach the recommended air pres- of 1 psi (7 kPa) in inflation pressure. Check your well as load limits and inflation pressure. sure.
Page 101
If you mount tires with a dimension other than tire inflation pressure table or the inflation the factory-installed tires, contact an authorized pressure placard. Volvo retailer to update the vehicle's software. This may also be necessary when changing from summer to winter tires, or vice versa. Related information •...
Page 102
Only use wheels/rims that have been tested and came with your particular model should • approved by Volvo and are included in Volvo's be used to lift the vehicle. If the vehicle Never allow any part of your body to be product range.
Page 103
PRACTICAL INFORMATION Removing a wheel WARNING NOTE Wheel changes should always be carried out • The jack must correctly engage the jack The jack provided with your vehicle is correctly. attachment. intended to be used only in temporary situa- tions such as changing wheels in the event of •...
Page 104
PRACTICAL INFORMATION Installing a wheel 7. When hoisting the vehicle, it is essential that the jack (or garage lift arms) are positioned It is important to install wheels properly. correctly on the underside of the vehicle. 1. Clean the contact surfaces on the wheel and There are two jack attachment points on hub.
Page 105
PRACTICAL INFORMATION Tire Pressure Monitoring System the inflation pressure recommended by the vehi- CAUTION (TPMS) cle manufacturer on the vehicle placard or tire • After inflating the tires, always reinstall inflation pressure label. (If your vehicle has tires TPMS provides a warning if inflation pressure in the valve cap to help avoid damage to the of a different size than the size indicated on the one or more tires is too low.
Page 106
PRACTICAL INFORMATION Checking tire inflation pressure When the system detects a malfunction, the tell- After changing wheels, always calibrate the sys- tale will flash for approximately one minute and tem to avoid false warnings. The Tire Pressure Monitoring System (TPMS) then remain continuously illuminated.
Page 107
1 minute: the system is not functioning correctly. Green: tire pressure is above the threshold for a tion pressure of all four tires. Have it checked by a trained and qualified Volvo low inflation pressure warning. service technician. 2. Re-inflate the tire(s) to the correct pressure.
Page 108
PRACTICAL INFORMATION Calibrating the Tire Pressure 4. Drive the vehicle at a speed of at least WARNING Monitoring System (TPMS) 22 mph (35 km/h). Please be aware that the • Incorrect inflation pressure could lead to TPMS telltale warning will not go out until In order for the Tire Pressure Monitoring System tire failure, resulting in a loss of control of the low tire pressure has been corrected and...
Page 109
PRACTICAL INFORMATION TPMS 2. Re-inflate the tire(s) to the correct pressure. 5. Tap After adjusting inflation pressure, repeat steps to access Tire Pressure Consult the tire pressure placard located on 1-8. Monitoring System. the driver's side B-pillar (the structural mem- ber at the side of the vehicle, at the rear of NOTE the driver's door opening) or the inflation...
Page 110
Models equipped with a spare tire do not have The tire sealing system's compressor has (p. 105) the tire sealing system. been tested and approved by Volvo. Location The tire sealing system is located under the floor The 12-volt sockets are located in the front tun- of the trunk.
Page 111
WARNING tion date has passed, please take it to a the skin, the central nervous system, and Volvo retailer or a recycling station that • the eyes. After using the tire sealing system, the...
Page 112
PRACTICAL INFORMATION • Using the tire sealing system Ingestion: Do NOT induce vomiting Connecting unless directed to do so by medical per- Overview sonnel. Get medical attention. • Disposal: Dispose of this material and its container to a hazardous or special waste collection point.
Page 113
Be sure that none of the other 12-volt sock- vehicle should not be driven if this occurs. ets is being used while the compressor is in Contact a towing service, use the Volvo On 4. Unscrew the orange cover over the bottle operation.
Page 114
• The empty bottle of sealing compound cannot be removed from the bottle holder. Consult a trained and qualified Volvo serv-...
Page 115
Have the vehicle inflate the tire to the correct pressure • After use, the sealing compound bottle, towed to a trained and qualified Volvo service (see the tire pressure decal on the on the technician. the hose, and certain other system com- driver's side B-pillar (the structural mem- ponents must be replaced.
Page 116
Ensure that the on/off switch is in position 0. Have the tire inspected by a trained and Take out the electrical wire and hose. qualified Volvo service technician as soon 5. Inflate the tire to the correct pressure (see as possible to determine if it can be per- the tire pressure decal on the on the driver's 2.
Page 117
PRACTICAL INFORMATION Electrical sockets 6. Turn off the compressor (press the on/off The electrical sockets can be used for 12-volt switch to position 0) when the correct infla- devices such as monitors, MP3 players and cell There are two 12-volt sockets in the tunnel con- tion pressure has been reached.
Page 118
Volvo workshop. • Consult your Volvo retailer if you are uncertain Condensation may form temporarily on about the type of headlights in your vehicle. the inside of the lenses of exterior lights 12-volt socket in the trunk such as headlights, fog lights, or taillights.
Page 119
PRACTICAL INFORMATION Front bulbs (vehicles with halogen CAUTION headlights) Never touch the glass of bulbs with your fin- gers. Grease and oils from your fingers vapor- ize in the heat and will leave a deposit on the reflector, which will damage it. WARNING •...
Page 120
Taillight (LED) Turn signal Side marker light (LED) Brake light (LED) Taillight (LED) Backup light High-mounted brake light (LED) Not available in all markets. Must be replaced by a trained and qualified Volvo service technician.
Page 121
PRACTICAL INFORMATION Replacing High Beam headlight 2. Remove the bulb by turning the bulb holder bulbs upward and then pulling it straight out. On models with halogen headlights, the High 3. Carefully pry the plastic sleeve by the con- Beam headlight bulb can be replaced by the nector's locking lug to release it.
Page 122
PRACTICAL INFORMATION Replacing front parking light bulbs Replacing front turn signal bulbs 5. Insert the bulb holder in the socket and press it into place. On models with halogen headlights, the front On models with halogen headlights, the front parking light/Daytime Running Light bulb can be turn signal bulb can be replaced by the owner.
Page 123
Bulb specifications (p. 123) side of the vehicle. NOTE Rear fog light bulbs should preferably be replaced by a trained and qualified Volvo serv- ice technician. Replace the rear fog light as follows: Buttons in the trunk 2. Remove the buttons in the trunk by inserting a flat object (kitchen knife, screwdriver, etc.)
Page 124
PRACTICAL INFORMATION clip so that both catches are pressed in at the same time. Pry or pull out the clip. Trunk closing handle Clips on the panel The closing handle on the inside of the trunk 4. Remove the three outermost clips on the lid on the driver's side has to be removed.
Page 125
If other bulbs need to be replaced, con- • The pin in the clip must be pressed back tact a trained and qualified Volvo service techni- 5. Insert the bulb holder by turning it a quarter far enough so that it sticks out of the clip cian.
Page 126
PRACTICAL INFORMATION Replacing wiper blades The wiper blades should be replaced regularly for best effect. The windshield wiper blades must be in the verti- cal (service) position for replacement, washing or to lift them away from the windshield when e.g., removing ice or snow. Replacing the windshield wiper blades With the wipers in the service position, fold out the wiper arm from the windshield.
Page 127
PRACTICAL INFORMATION Windshield wipers in the service Related information The service position can be activated in two ways • position from the center display: Windshield wipers in the service position (p. 125) The windshield wiper blades must be in the verti- Via Function view •...
Page 128
The windshield washers are activated. with windshield washer solvent containing anti- • The rain sensor is activated. freeze. Use Volvo Original Washer Fluid or the equivalent with a recommended pH value CAUTION between 6 and 8 in a 1:1 solution.
Page 129
If the vehicle begins to roll, the audible sig- nal will be repeated several times. NOTE If the warning symbol remains on or if the audible signal is given even if the hood is completely closed and locked, consult a trained and qualified Volvo service technician.
Page 130
PRACTICAL INFORMATION Closing 1. Press down the hood until it begins to close due to its own weight. 2. When the handle under the front edge of the hood is in the lock, press down on the hood to close it completely. WARNING •...
Page 132
WARNING trained and qualified Volvo service technician. Never use metal objects or fuses with higher Location of the fuseboxes amperage than those stated on the following pages.
Page 133
FUSES Fuses in the engine compartment The fuses in the engine compartment help pro- tect electrical components such as engine and brake functions.
Page 134
FUSES Positions There is a fuse removal tool on the inside of the fuse box cover. There are also positions in the There is a decal on the inside of the cover with a fuse box for several extra fuses. list of fuses.
Page 135
– – • Fuses 31–34 and 38–45 are called "MCase" and should only be replaced by a trained and Starter motor – – qualified Volvo service technician. Starter motor Shunt Heated windshield*, driver side Shunt Function – – Heated windshield*, driver side –...
Page 136
FUSES Function Heated windshield*, passenger Shunt side Feed when ignition is switched on to: engine control module, transmission components, elec- trical power steering, central electrical module; Brake system control module – – Passenger side headlight – – – – Battery connection module Air bags;...
Page 137
FUSES Fuses in the passenger tect electrical components such as the 120-volt There is a fuse removal tool on the inside of the compartment socket, displays and door modules. fuse box covers. There are also positions in the fuse box for several extra fuses. The fuses in the passenger compartment (located under the glove compartment) help pro-...
Page 139
Head-up display* are called "Micro". • Fuses 2, 22, 37–38 and 54 are called – – Courtesy lighting "MCase" and should only be replaced by a trained and qualified Volvo service technician. – – – – Function – – Ceiling console display (seat belt reminder, front passenger side air- –...
Page 140
FUSES Function Function Rear door sun curtains – – Fuel pump control module Circuit breaker for fuses 53 and 58 – – Certain markets only Related information – – • Fuses (p. 130) Driver side front seat heating* • Replacing fuses (p. 130) •...
Page 141
FUSES Fuses in the trunk The fuses in the trunk help protect electrical components such as power seats*, airbags and seat belt tensioners. * Option/accessory.
Page 142
FUSES There is a fuse removal tool on the inside of the fuse box cover. There are also positions in the fuse box in the engine compartment for several extra fuses.
Page 143
Fuses 1–12, 18–20 and 37 are called "MCase" and should only be replaced by a – – – – trained and qualified Volvo service technician. Foot movement detection module Blind Spot Information (BLIS)*, Function for opening the power trunk Control module for exterior audible...
Page 146
SPECIFICATIONS Label information The labels in your vehicle provide information such as the chassis number, paint code, tire inflation pressure, etc.
Page 147
SPECIFICATIONS Location of labels Generic illustration - details may vary slightly depending on model/market...
Page 148
Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Minis- try of Transport (CMVSS) standards (Canada). Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the driver's side B- pillar (the structural member at the side of the vehicle, at the rear of the driver's door opening).
Page 149
SPECIFICATIONS Dimensions The following table lists your vehicle's most important dimensions.
Page 151
SPECIFICATIONS Weights The following table lists important weight data for your vehicle. Category Canada Gross vehicle weight 4-cyl. AWD (All Wheel Drive): B4204T27 5,290 lbs 2,400 kg 4-cyl. AWD (All Wheel Drive): B4204T23 5,245 lbs 2,380 kg 4-cyl. FWD (Front Wheel Drive): B4204T23 5,070 lbs 2,300 kg Capacity weight...
Page 152
SPECIFICATIONS Category Canada Max. trailer weights Without brakes: 1,650 lbs Without brakes: 750 kg With brakes: 2,000 lbs With brakes: 900 kg Max. tongue weight 200 lbs 90 kg CAUTION • When loading the vehicle, the maximum gross vehicle weight and permissible axle weights may not be exceeded.
Page 153
A/C decal marked according to SAE J2842. Topping up or replacing brake fluid should only be done by a trained and qualified Volvo service technician. Specification: Volvo Original Dot 4 class 6 or equivalent...
Page 154
SPECIFICATIONS Coolant specifications Coolant specifications. Specification: Coolant with corrosion inhibitor mixed with water (50/50 mix), see packaging. Consult a Volvo retailer if you are uncertain. Different types of coolant should not be mixed to help avoid health risks.
Page 155
SPECIFICATIONS Engine specifications Not all engines listed here are available in all markets. The following table provides technical data for the respective engines. Engine specifications for Special Edition vehicles may vary. Specification T6 AWD Engine designation B4204T27 Output (kW/rps) 235/95 Output (hp/rpm) 316/5700 Torque (Nm/rps)
Page 156
SPECIFICATIONS Related information • Engine oil specifications and volume (p. 155) • Coolant specifications (p. 152)
Page 157
All Wheel Drive: 15.9 US gallons (60 liters) Volvo recommends: Viscosity chart Extreme engine operation Volvo oil VCC RBS0-2AE/SAE 0W20 is recom- Refer to the warranty and Service Records infor- mended for extreme driving conditions. mation booklet for information on oil change Oil volume intervals and oil type requirements.
Page 158
The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire infla- Tire sizes: S90 Cold tire pressure for up to five persons...
Page 159
SPECIFICATIONS Transmission fluid specification and volume Under normal driving conditions the transmission fluid does not need to be changed during its service life. However, it may be necessary under adverse driving conditions. Transmission: TG-81SC Specification: Transmission fluid AW-1...
Page 161
INDEX INDEX Climate system refrigerant Accessory installation warning 12, 16 Capacity weight 95, 149 Convertible seats Airbags Cargo space Coolant disconnecting the front passenger’s Center display Crash event data side changing settings Crash mode 65, 66 front keyboard inflatable curtain Curb weight 95, 149 navigating in...
Need help?
Do you have a question about the S90 and is the answer not in the manual?
Questions and answers
