Technical Specifications

2600-A2-GN20-40
Technical specifications are subject to change without notice.
Table C-1. BitStorm 2600 Technical Specifications (1 of 2)
Specifications Criteria
Alarm Contacts 30 VDC: 1.0 Amp
Maximum Rated
60 VDC: 0.6 Amp
Load
60 VAC: 0.6 Amp
Cooling and Air Each BitStorm 2600 is independently cooled with integral fans and
Handling does not rely on vertical air flow.
DSL Models 2611 and 2614:
Compatibility
ReachDSL 2.2
Models 2621 and 2624:
G.dmt (G.992.1)
G.lite (G.992.2)
ANSI T1.413-1998
ADSL2 (G.992.3)
ADSL2+ (G.992.5)
Model 2631:
G.dmt (G.992.1) Annex B
ADSL2 (G.992.3) Annex B
ADSL2+ (G.992.5) Annex B
Model 2671:
G.SHDSL (G.991.2)
Electromagnetic Meets the following standards:
Compatibility
EN 300 386-2
(EMC)
EN 55024
EN 55022, Class A
FCC Part 15, Class A
VCCI, Class A
