A. Connectors and Pin Assignments

Port 3 GigE SFP Connector

A-4
Port 3's GigE interface is a standard SFP socket.
Table A-4. Port 3 GigE Connector
Signal
VeeT
TXFault
TXDisable
MOD-DEF(2) – I2C_DATA
MOD-DEF(1) – I2C_CLK
MOD-DEF(0) – SFP_PRESENT_L
Rate Select
LOS
VeeR
VeeR
VeeR
RD-
RD+
VeeR
VccR
VccT
VeeT
TD+
TD-
VeeT
March 2005
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
2600-A2-GN20-40
