1. Installation

Mounting Configurations

Mounting Brackets

Installing the Brackets for Rack Mounting

1-6
Three basic installation configurations are available:
Rack mount – see Installing the Brackets for Rack Mounting
Installing the BitStorm 2600 Into a Rack
Wall mount – see Installing the BitStorm 2600 on a Wall
Shelf or desktop – see
page 1-12.
Your BitStorm 2600 can be installed in a rack or on the wall using mounting
brackets. Two brackets suitable for a 19-inch (483 mm) rack (marked EIA-19) and
two brackets suitable for a 23-inch (584 mm) Bay Networks or Nortel rack (marked
with Paradyne Part Number 868-6282-0020) are shipped with the unit. Two
brackets suitable for a 21-inch (535 mm) rack (marked ETSI) are available from
Paradyne as a separate feature (see
Rack-mounting brackets may also be used to attach the unit to a wall.
NOTE:
In this guide, the term rack refers to any rack, cabinet, frame, or bay suitable
for mounting telecommunications equipment.
Procedure
To install the mounting brackets for rack mounting:
1. Locate the black screw nearest the front panel on each side of the unit, as
shown.
2. Remove these two black screws (one from each side) before attempting to
install the mounting brackets.
March 2005
on page 1-8.
Installing the BitStorm 2600 on a Shelf or Desktop
Appendix B, Equipment
on page 1-6 and
on page 1-10.
on
List).
03-17445
2600-A2-GN20-40
