3Com CoreBuilder 9000 Quick Installation Manual page 2

2 7-S C Q
LOT HASSIS UICK
I G
NSTALLATION UIDE
Figure 1 illustrates the procedures to perform in this document.
Figure 1 CoreBuilder 9000 Enterprise Switch 7-slot Chassis Setup Tasks
Unpack the
CoreBuilder 9000
7-slot Chassis
R
9
8
7
6
5
4
3
2
1
™
CoreBuilder 9000 7-slot Chassis
Install the
Cable Management
Device (optional)
You can order the following optional items through 3Com:
Cable management device (Model Number 3CB9EC7)
Alternate position rack-mount flange kit (Model Number 3CBEK)
1
Read the
Preinstallation
Guidelines (later in
this guide)
™
CoreBuilder 9000
Install the
Alternate Rack-mount
Flanges (optional)
Install the Chassis
• In a rack
• On a table or shelf
5
2
3
4
