Installing the Chassis on a Table or Shelf
This section describes how to attach plastic feet to the chassis and how
to install the chassis on a table or a shelf.
WARNING: Safety regulations state that the selected table or shelf
must be able to support at least 115.6 kg (255 lb), which is three times
the weight of a fully loaded chassis.
Attaching the Chassis Feet. To install plastic, molded feet on the
CoreBuilder 9000 7-slot chassis, follow these steps:
1 Using two people, lift the chassis onto the table or shelf.
2 Position the chassis on its side so that you can access the bottom of
the chassis.
3 Remove the four feet and the four 6-32 Phillips-head screws from the
hardware kit.
4 Using a Phillips screwdriver, screw the feet to the bottom of the chassis.
See Figure 9.
Figure 9 Attaching Plastic Feet to the CoreBuilder 9000 Chassis
