Autostart PRG-1000 Quick Installation Manual

S S T T W O - W A Y
A U T O M A T I C / M A N U A L
S T A R T E R W I T H
P R G - 1 0 0 0 C O M P A T I B L E )
Q
UICK
Manual or Automatic Transmission setup ............... 1
Push-To-Start ........................................................... 2
PTS takeover ........................................................... 2
Hybrid Option ........................................................... 2
Transmitter Programming Procedure ...................... 3
Transmitter Programming Procedure Using PRG-
1000 ......................................................................... 3
Entering Programming Mode ................................... 3
Entering Programming Options ............................... 4
Programming Options .............................................. 5
Horn adjustment ....................................................... 6
Setting up the TACH ................................................ 6

MANUAL OR AUTOMATIC TRANSMISSION SETUP

This module may be installed on vehicles with manual or automatic transmissions. It is originally configured for
manual transmissions. If the vehicle you are working on is automatic, it is mandatory to make a few quick and
easy modifications before the unit is connected. In the event that the configuration requires changes afterwards,
a complete reset (page 7) will be necessary before those changes become effective.
To install this unit in a vehicle with a MANUAL transmission:
1. Make sure the Yellow loop on the PC board is connected (default).
2. Connect the Orange handbrake wire located on the 12-pin harness to the vehicle handbrake
circuit.
3. Connect the Blue/White (+) door input OR the Grey (-) door input wire located on the 12-pin
harness to the vehicle door pin wire which monitors all the doors of the vehicle (only use 1 of the
2 door trigger inputs). Make sure the Purple TACH wire is wired to a tach source - the TACH wire
MUST be hooked up when the module is set for a manual transmission.
4. Make all your regular connections.
5. Power up the unit by first inserting the 5-pin connector, then the 6-pin connector and finally the 12-
pin connector. The parking lights will flash 4 times.
6. When programming the transmitter, the parking lights will flash 5 times quickly.
7. Upon the first successful remote start, the system will lock the transmission settings to manual
mode.
To install this unit in a vehicle with an AUTOMATIC transmission:
1. Cut the loop on the pc board (Yellow wire).
2. Make sure the Orange handbrake wire is not connected to any of the vehicle circuits.
3. Make all the regular connections.
4. Power up the unit by first inserting the 5-pin connector, then the 6-pin connector and finally the 12-
pin connector. The parking lights will flash 4 times.
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of the product, be
that either damage to the vehicle itself or to the unit. This unit must be installed by a certified technician using all safety devices
supplied. Please note that this guide has been written for properly trained Autostart technicians: a certain level of skills and
knowledge is therefore assumed. Please review the installation guide carefully before beginning any work.
Warning
Before installing the unit, if installing on a vehicle with a manual transmission, test that the OEM Door Switch contacts of the
vehicle work well, and that the Parking Brake system operates properly. If installing on a vehicle with an automatic
transmission, test that the vehicle does not start when the gearshift lever is in the "Drive" position. If it starts in gear, reset the
remote starter to manual transmission.
D2105 Rev.:1.0
5 - B U T T O N L C D
T R A N S M I S S I O N
V I R T U A L T A C H
I
NSTALLATION

Table of Contents

The wiring diagram is at the middle of this guide.
© 2013
R E M O T E
S Y S T E M
Virtual Tach adjustment ........................................... 6
Multi-speed Tach Programming (if installed) ............ 7
Resetting the Module ............................................... 7
Bypass ...................................................................... 7
SmartStart™ ............................................................ 7
Testing ...................................................................... 7
Troubleshooting ....................................................... 9
Diagnostics - Parking Light Flash Table .................. 9
Diagnostic table for start failure. ............................... 9
Diagnostic table for shutdown. ................................. 9
- 2W-NGRF-LCD-A/M -
( A S
G
UIDE
- PGa- Canada
