1 Connections
1.3 MP3 players (iPod®) and Internal Mixer Setup
1 Connect the outputs of your MP3 players to the RCA inputs of your U-MIX CONTROL PRO plugging the left
MP3 player into the inputs 1/2 and right MP3 player into the inputs 3/4.
2 Set the U-MIX CONTROL PRO's input selectors to 'Line'.
3 Connect outputs 1/2 of your U-MIX CONTROL PRO to your sound system (amplifier, powered speakers, or
home stereo).
4 Connect your headphones to one of the 'headphones' outputs of your U-MIX CONTROL PRO.
5 If necessary, connect your microphone to the 'microphone' input of your U-MIX CONTROL PRO.
6 Connect the supplied USB cable between the USB output of your U-MIX CONTROL PRO and a free USB slot
of your computer.
7 To turn on your U-MIX CONTROL PRO, set the rear panel selector to 'USB'.
8 After installing the software, set the CROSS DJ Audio preferences as described in the Audio Configuration
part of this manual:
MIXVIBES
SOFTWARE
USB
3.1 on page 12.
SPEAKERS
C
LN
M
9V
0.5A POWER
DC IN OFF USB OUTPUT 3/4 OUTPUT 1/2
R L
R L R L
MIN MAX MIN MAX
TOUCH SENSOR
LEVEL C.F. CURVE
Y
CM
MICROPHONE
MY
CY
MP3 players (iPod®) and internal mixer setup
CMY
K
7 /
Mp3 / iPod (1)
Mp3 / iPod (2)
PH LN PH
LINE LINE
PHONO PHONO
INPUT 3/4 INPUT 1/2
LN PH LN PH
R L R L
HEADPHONES
L R
