iT500 Internet Thermostat
I N S T A L L E R M A N U A L

Advertisement

loading

Related Manuals for Salus IT500

Summary of Contents for Salus IT500

  • Page 1 Internet Thermostat I N S T A L L E R M A N U A L...
  • Page 2 1. Product compliance & safety information These instructions are applicable to the SALUS Controls model stated on the front cover of this manual only, and must not be used with any other make or model.     This accessory must be fitted by a competent person, and installation must comply with the guidance provided in the current IEE Wiring Regulations and current Building Regulations.
  • Page 3 Wire up the receiver using one of the Clip the front of the unit back on by aligning the Securely screw the front of the receiver in place. schematics on pages 4 and 5 fittings and pushing into place. iT500 Installer Manual 03...
  • Page 4 Sensor required for this configuration. 230V 230V 230V BOILER BOILER 230V Combination Boiler 2 x CH Zones - Potential Volt Free Switching OV - 230v OV 230 0V System Boiler 1 x CH Zone and 1 x HW Zone 04 iT500 Installer Manual...
  • Page 5 Sensor required for this configuration. 230V 230V BOILER BOILER One central heating zone 230 V Switching 230 V Switching plus hot water. Permanent Potential Free Switching iT500 Installer Manual 05 230V 230V 230V 230V 230V 230V BOILER BOILER BOILER BOILER...
  • Page 6 After first ensuring that the bracket Once clipped into place, ensure the unit is suitable wall using the fittings supplied is secure, clip the iT500 into place by securely seated on the bracket. and the built in level. aligning the recess on the back of the unit For best results mount the to the bracket and clipping into place.
  • Page 7 6. Connecting the Gateway to your existing router Flashing red light on setup. Constant green light when the iT500 is You require port 80 and 2165 UDP open on the router connected to the SALUS Controls Server. iT500 Installer Manual 07...
  • Page 8 Insert the second battery supplied into the left Ensure the batteries are fitted securely Replace the battery cover to the hand side of the base of the iT500 Thermostat. in the base of the iT500 Thermostat. base of the iT500 Thermostat.
  • Page 9 8. Setting up the iT500 Thermostat After powering up iT500 for the first time the display will go through the following sequence. OTA* Revision number The globe icon will appear when the unit automatically connects to the internet via the SALUS iTG500 Gateway.

  • Page 10: Lcd Overview

    Indicates touch lock is activated Battery status Indicates battery is low Holiday indicator Indicates holiday operation mode is selected Internet indicator Indicates connection to iTG500 and SALUS server Cooling indicator Indicates cooling output is on* ON indicator Hot water continuously on* Once indicator...
  • Page 11 Selecting your system configuration Based on your system wiring on page 4. AUTO If the iT500 is to be used AUTO in the UK for single zone heating then there is no need to enter system AUTO configuration setup, please proceed to page 15.
  • Page 12 Centigrade to Fahrenheit AUTO AUTO AUTO GMT Time setting** GMT Time setting** GMT Time setting** 12 iT500 Installer Manual * Cooling can only be selected if your system supports this. ** Please refer to the following page for your region.
  • Page 13 GERMANY SWEDEN CYPRUS BELARUS* ICELAND* CZECH NORWAY GREECE FINLAND SPAIN MALTA ROMANIA MOLDOVA FRANCE CROATIA RUSSIA LATVIA ITALY SERBIA UKRAINE SWITZERLAND BOSNIA The countries marked with * do not LUXEMBOURG SLOVENIA iT500 Installer Manual 13 observe Daylight Saving Time HOLLAND...
  • Page 14 Now that you have selected your system configuration you can continue with the rest of the installation setup. DST (daylight saving time) ON will automatically change your time from summer to winter. AUTO AUTO AUTO AUTO AUTO 11. Pairing the iT500 with the iT500RX Receiver AUTO AUTO AUTO 14 iT500 Installer Manual...
  • Page 15 Now go to the iT500 Thermostat. screen sequence shown on the next page. When the iT500RX Receiver and the iT500 Thermostat are paired then the light will be green. FAILSAFE MODE: In the event of RF signal loss, your system will be...
  • Page 16 Receiver LED colours The bottom switch will show a constant red When the iT500RX Receiver and the iT500 light when the iT500RX Receiver is ready to Thermostat are powered and paired then the pair. light will be green. Flashing blue light indicates a heat call/Hot...
  • Page 17 Attach the wall mounting bracket to a Align the grooves on the back of the iT300 Once in place, ensure the unit is securely suitable wall using the fittings supplied. unit and slide onto the bracket. seated on the bracket. iT500 Installer Manual 17...
  • Page 18 2 seconds. The iT500 has successfully paired with the iT300 when the antenna stops flashing. Press The iT300 should be installed in the area of the house that to return to home screen.
  • Page 19 Go to the SALUS controls website. www.salus-controls.com and select your relevant country © Salus Controls 2012 Privacy Policy Disclaimer Site Map Click on the register iT500 icon on the left hand side of your country’s website iT500 Installer Manual 19...
  • Page 20 14. Registering and operating your iT500 online Click on REGISTER Fill in the online form and click REGISTER The above screen will show and a confirmation email will be sent to you 20 iT500 Installer Manual...
  • Page 21 Enter the iT500 STA number (Please refer to page 8). Then press REGISTER. Your iT500 will appear as above and is now ready to be controlled or viewed via your PC or Smartphone. Just click on the iT500 icon on your PC.

  • Page 22: Download Smartphone App

    Once you have registered your iT500 online you can also download the smartphone App from the iPhone App Store or the Android App Store depending on which kind of Smartphone you are using. Find the iT500 App on the App Store and click download. The App will automatically download to your Smartphone and once downloaded you can begin controlling your iT500 Thermostat.
  • Page 23 16. Adding or renaming the iT500 in your device list Enter your user ID and password. When you first open the iT500 App If you add more than 1 iT500 to your If you forget your password, follow Press your iT500 will appear in the device device list, you may wish to rename the on screen instructions.

  • Page 24: Troubleshooting

    (Due to internet speed this may take several attempts) Q. Where do I download my Smartphone app to control the iT500? A. If you have an iPhone, please search for iT500 on the app store, if you have an Android; search for iT500 on Google play.
  • Page 25 A. Check that the top slide switch on the receiver unit is in the AUTO position. A. Perform a quick installation check by putting the top slide switch to Manual position, and the bottom slide switch to CH. The boiler should fire, if not the iT500 receiver may be wired incorrectly. Please contact your installer.
  • Page 26 A. Check that you have the power supply turned ON to the gateway and it has a steady green light showing. The green light indicates you are connected to the SALUS server. A. If you have all the above, remove a battery from the iT500 and replace after 10 seconds. This will reboot the iT500 and bring you back online.

  • Page 27: Warranty

    SALUS Controls warrants that this product will be free from any defect in materials or workmanship, and shall perform in accordance with its specification, for a period of two years from the date of installation. SALUS Controls sole liability for breach of this warranty will be (at its option) to repair or replace the defective product.
  • Page 28 TECHNICAL: T: +44 (0) 1226 323961 E: tech@salus-tech.com www.salus-controls.com SALUS Controls is a member of the Computime Group Maintaining a policy of continuous product development SALUS Controls plc reserve the right to change specification, design and materials of products listed in this brochure without prior notice.
