- Page 1 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:03 Page Dial Thermostat Models: VS05 I N S TA L L E R / U S E R M A N U A L...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:03 Page Contents Contents System option 1. Icons used in this manual: Introduction. All programmable Product Compliance. thermostats. Safety Safety information. Parameter settings. Installer Parameters. User interface. -
Page 3: Product Compliance
Installation SALUS recommends that you use your VS05 with the SALUS KL10 and VS10. The VS10 can be This product must be fitted by a competent used as a group master and connected using person, and installation must comply with the the data cable see page xx. -
Page 4: Installer Parameters
Product Compliance & Safety Information Sources of danger Installer parameter settings The thermostat must be disconnected from mains The SALUS VS05 is equipped with installer paramter section supply before removing the cover. this must only be entered by the installer or comptent 230V AC Person. -
Page 5: Mounting Position And Installation
All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:03 Page Installation – Thermostat Mounting Mounting position and installation To ensure trouble free operation and efficient control, the unit is best positioned in a draft free area and at 130cm from the floor. -
Page 6: System Grouping And Communication
While the thermostats can function as standalone , Installing this Optional inexpensive Communication cable allows the thermostats to communicate with the SALUS VS10 configured as a group master through the SALUS KL06 WC( both sold separately). The VS05 will follow instructions of the VS10 Bringing central control of features such as Time control, Holiday &... - Page 7 The group selection communication cable must correspond to the group terminals on the KL10 WC. Please refer to note xx and the KL10 installation guide. Group 1 – For Example Down stairs Group 2 – For Example upstairs SALUS KL10 VS05 Installer Manual...
- Page 8 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page Installation – Thermostat Mounting Gently remove front housing. Wall Mounting For wall mounting, mark and mount the rear case to the wall. The VS05 is suitable for wall boxes with a centre hole distance of : 60mm VS05 Installer Manual...
- Page 9 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page Installation – Terminal Connections Understanding your terminal connections Power Terminals 230 Vac Used for supplying power to the Rear of VS05 unit and switched output. Sensor Terminals Can be used for external AIR, Floor sensor when configured...
- Page 10 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page Installation – Thermostat Connections Optional communication connection 12VBC xxxxxxxxxxxxx LABEL & TEXT xxxxxxxxxxx VS05 Installer Manual...
- Page 11 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page Installation – Terminal Connections Check that the wiring is completed for: Power Terminals Sensor Terminals (if applicable) Communication Terminals You are ready to secure the rear housing to the wall box Please use the screws provided Ensure the orientation arrow is pointing upwards.
- Page 12 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page Installation – parameter setting VS05 Installer Manual...
-
Page 13: Parameter Settings
All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page Installation – parameter setting Floor sensor temp (optional) If you are fitting an external Parameter setting sensor for air/floor sensing please select temp here. It can be set from 0-45 and as preset at 27. -
Page 14: User Interface
All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page User Interface Slide switch must be in “A” position to follow group master VS10 LED Indication Temperature Adjustment 5-30 Mode Selection VS05 Installer Manual... -
Page 15: Led Indication When Following Group Master
All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page LED indication when following Group Master Slide switch must be in “A” position to follow group master VS10 RED Led indicates that power is going to the unit in normal operation. - Page 16 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page LED indication when following Group Master Slide switch must be in “A” position to follow group master VS10 To reduce annoyance factor ,no Led is shown when the Group master is in reduced temperature/night time mode.
- Page 17 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page LED indication when following Group Master Slide switch must be in “A” position to follow group master VS10 Blue LED indicates the units is in frost protection mode.
- Page 18 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page LED indication in Manual mode Slide switch “HAND” position to will not follow Group master VS10 and will longer be part of the group. The VS05 will work as a standalone thermostat RED Led indicates that power is going to the unit in normal operation.
- Page 19 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page LED indication when following group master Slide switch “*” position to will not follow group master VS10 and will longer be part of the group. The VS05 will be in permanent frost protection.
-
Page 20: Vs05
All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page Spec MODEL VS05 TYPE Wired dial thermostat designed for 230v ac heating/cooling applications TEMPERATURE Scale Celsius Tolerance 0.5 oc Display Range 5.0-30.0 oc Set Temperature range 5.0-30.0 oc Frost Protection... - Page 21 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page VS05 Installer Manual...
- Page 22 All manuals and user guides at all-guides.com iT600 VS05 Installer - User Manual_Layout 1 06/06/2014 10:04 Page VS05 Installer Manual...
- Page 23 SALUS Controls warrants that this product will be free from any defect in materials or workmanship, and shall perform in accordance with its specification, for a period of two years from the date of installation. SALUS Controls sole liability for breach of this warranty will be (at its option) to repair or replace the defective product.
- Page 24 SALUS Controls is a member of the Computime Group Maintaining a policy of continuous product development SALUS Controls plc reserve the right to change specification, design and materials of products listed in this brochure without prior notice. Issue Date: April 2014...
