1.3 TECHNICAL FEATURES
Heat output nominal (80-60°C)
Heat output nominal (50-30°C)
Heat output minimum (80-60°C)
Heat output minimum(50-30°C)
Heat input nominal
Heat input minimum
Nominal D.H.W. heat input
Minimum D.H.W. heat input
Efficiency nom./min. output (80-60°C)
Efficiency nom./min. output (50-30°C)
Seasonal efficiency rating (SEDBUK)
Termal efficiency (CEE 92/42 directive)
Class NOx
Smokes temperature maximum (80-60°C)
Smokes temperature minimum(80-60°C)
Smokes temperature maximum (50-30°C)
Smokes temperature minimum (50-30°C)
Smokes flow
CO maximum/minimum G20
2
CO maximum/minimum G31
2
Adsorbed power consumption
Electrical protection grade
CE certification
Category
Type
CENTRAL HEATING
Maximum water head
Maximum temperature
Water content boiler
C.H. setting range
Expansion vessel capacity
Expansion vessel pressure
DOMESTIC HOT WATER
Minimum/maximum pressure
D.H.W. flow rate (EN 625)
Continuous D.H.W. flow rate ∆t 30°C
Continuous D.H.W. flow rate ∆t 35°C
Minimum D.H.W. flow rate
D.H.W. setting range
GAS PRESSURE AND NOZZLES
Gas supply pressure G20
Gas supply pressure G31
Nozzles quantity
Nozzles diameter G20
Nozzles diameter G31
C.H gas consumption nom./min. G20
C.H. gas consumption nom./min. G31
D.H.W. gas consumption nom./min. G20
D.H.W. gas consumption nom./min. G31
WEIGHT
kW (kcal/h)
kW (kcal/h)
kW (kcal/h)
kW (kcal/h)
kW (kcal/h)
kW (kcal/h)
kW (kcal/h)
kW (kcal/h)
%
%
°C
°C
°C
°C
kg/h
%
%
W
IP
n°
bar
°C
l
°C
l
bar
bar
l/min
l/min
l/min
l/min
°C
mbar
mbar
n°
ø
ø
3
m /h
kg/h
3
m /h
kg/h
kg
FORMAT 25 HE
22.7 (19,500)
24.5 (21. 1 60)
8.4 (7,220)
9.3 (8,000)
23.3 (20,040)
8.7 (7,480)
25.0 (21,500)
8.7 (7,480)
97.5/97.0
105.8/107.3
90.0% (A)
5
70
63
54
50
39
9.0/9.0
10.0/9.9
145
X4D
1312BP4098
II
2H3P
B / C
23-53 13-33-43-53-83
3
80
4.9
20/75
8
1
0.5/7.0
11.2
11.5
10.2
2
30/60
20
37
1
6.0
4.4
2.46/0.92
1.81/0.68
2.64/0.92
1.94/0.68
40
FORMAT 30 HE
27.3 (23,480)
29.8 (25,630)
10.2 (8,770)
11.3 (9,720)
27.9 (24,000)
10.5 (9,030)
30.0 (25,800)
10.5 (9,030)
97.9/97.0
106.9/107.4
90.2% (A)
5
63
56
42
41
47
9.0/9.0
10.0/9.9
145
X4D
1312BP4098
II
2H3P
B / C
23-53 13-33-43-53-83
3
80
5.3
20/75
8
1
0.5/7.0
13.4
14.3
12.3
2
30/60
20
37
1
7.0
5.0
2.95/1. 1 1
2. 1 7/0.82
3. 1 7/1. 1 1
2.33/0.82
43
7
