IBM Ethernet Switch s-series
Installation and User Guide
Service information: 4003-S08, -S16
GC27-2243-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the s-series and is the answer not in the manual?

Questions and answers

Related Manuals for IBM s-series

Summary of Contents for IBM s-series

  • Page 1 IBM Ethernet Switch s-series Installation and User Guide Service information: 4003-S08, -S16 GC27-2243-00...
  • Page 3 IBM Ethernet Switch s-series Installation and User Guide Service information: 4003-S08, -S16 GC27-2243-00...
  • Page 4 Order publications through your IBM representative or the IBM branch office serving your locality. © Copyright International Business Machines Corporation 2009.

  • Page 5: Table Of Contents

    ......14 24-port 100/1000 Mbps Ethernet hybrid fiber (SFP) interface module ..15 © Copyright IBM Corp. 2009...
  • Page 6 Cleaning fiber optic modules ....53 Automatic MDI/MDIX detection ....53 Ethernet Switch s-series Installation and User Guide...
  • Page 7 Using a CX4 transceiver ..... 53 Testing network connectivity ....54 Pinging an IP address .
  • Page 8 Physical dimensions ..... . 121 Environmental considerations ....121 Ethernet Switch s-series Installation and User Guide...
  • Page 9 Cooling ......122 Fan tray for the B08S ..... 122 Cooling system on the B16S .
  • Page 10 Ethernet Switch s-series Installation and User Guide...

  • Page 11: Figures

    52. Location of AC power connection on B08S ..... 113 53. Attaching AC power cords to a B16S ..... . . 114 © Copyright IBM Corp. 2009...
  • Page 12 ....... . . 131 63. AC power cable plug and input connector - male and female ....132 Ethernet Switch s-series Installation and User Guide...
  • Page 13 Tables 1. Comparable IBM and Brocade products..... . . xxii 2. Maximum number of POE class 3 (15.4W) ports per power supply ... . . 4 3.
  • Page 14 Ethernet Switch s-series Installation and User Guide...

  • Page 15: Preface

    CD that accompanies this product. The following notices and statements are used in IBM documents. They are listed below in order of increasing severity of potential hazards. Follow the links for more detailed descriptions and examples of the notes, attention notices, caution, and danger notices in the sections that follow.

  • Page 16: Notes

    55 kg ( 121.2 lbs) >55kg (121.2 lb) A potential hazard of pinching the hand or other body parts between parts. P/N 18P5850-B SJ000752 A hazardous condition due to moving parts nearby. Ethernet Switch s-series Installation and User Guide...

  • Page 17: Danger Notices

    If the symbol is... It means..A hazardous condition due to the use of a laser in the product. Laser symbols are always accompanied by the classification of the laser as defined by the U.S. Department of Health and Human Services (for example, Class I, Class II, and so forth).
  • Page 18 (D004) The following general electrical danger notice provides instructions on how to avoid shock hazards when servicing equipment. Unless instructed otherwise, follow the procedures in this danger notice. Ethernet Switch s-series Installation and User Guide...
  • Page 19 Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the IBM provided power cord. Do not use the IBM provided power cord for any other product.

  • Page 20: Safety Labels

    IBM Installation Planning Representative (IPR) or IBM authorized service provider. In anticipation of the equipment delivery, the final installation site should be prepared in advance such that professional movers/riggers can transport the equipment to the final installation site within the computer room.
  • Page 21 DANGER Hazardous voltage present. Voltages present constitute a shock hazard, which can cause severe injury or death. (L004) CAUTION: Hazardous energy present. Voltages with hazardous energy might cause heating when shorted with metal, which might result in splattered metal, burns, or both. (L005) CAUTION: Hazardous moving parts nearby (L008) CAUTION:...

  • Page 22: Rack Safety

    Attempting to move the drawer partially or completely out of the rack might cause the rack to become unstable or cause the drawer to fall out of the rack. (R001 part 2 of 2) Ethernet Switch s-series Installation and User Guide...

  • Page 23: Rack Relocation (19" Rack)

    (R002) Product recycling and disposal Refer to the IBM Systems Environmental Notices and User Guide (Z125-5823) on the product documentation CD for translated environmental statements and information regarding product recycling and disposal. Preface...

  • Page 24: Product Documents

    Table 1 to assist you when determining which information in those publications applies to your product. Brocade products with no IBM equivalents are not listed in the table. Note that the IBM products can be ordered with additional features, while Brocade products with those additional features may be offered as separate models.

  • Page 25: Getting Help

    For the latest version of your product documentation, visit the web at www.elink.ibmlink.ibm.com/public/applications/publications/cgibin/pbi.cgi. Search by form number or title. For more information about this and other IBM products, visit the IBM web site: www.ibm.com/ For support information for this product and other IBM products, see the following Web site: www.ibm.com/systems/support/.

  • Page 26: How To Send Your Comments

    Department GZW 9000 South Rita Road Tucson, Arizona 85744-0001 U.S.A. When you send information to IBM, you grant IBM a nonexclusive right to use or distribute the information in any way it believes appropriate without incurring any obligation to you.

  • Page 27: Chapter 1. About This Guide

    Chapter 1. About This Guide This guide includes procedures for installing the hardware and configuring essential parameters such as permanent passwords and IP addresses for the IBM Ethernet Switch B08S and B16S products. The basic software configuration procedures show how to perform tasks using the CLI. This guide also includes instructions for managing and maintaining the hardware.
  • Page 28 Ethernet Switch s-series Installation and User Guide...

  • Page 29: Chapter 2. Product Overview

    2-port 10-GbE ports or 8-port GbE fiber and copper ports. v The management modules are interchangeable between the IBM Ethernet Switch s-series models. However, you cannot mix IPv4 and IPv6 modules together in the same chassis. v Optional dual management modules provide 100% redundancy.

  • Page 30: Poe Port Density

    Layer 3 multiprotocol routing through the purchase of an upgrade feature, at which time they are considered to be premium devices. The IBM Ethernet Switch s-series can be configured with either all IPv4 management and IPv4 interface modules, or all IPv6 management and IPv6 interface modules.

  • Page 31: Power Over Ethernet (Poe) Applications

    The modules must be of like-kind. Hardware features The s-series switches include the following major hardware components: v Chassis v Management module with optional support for dual management modules that provide 100% redundancy...

  • Page 32: B08S

    The slot panel ensures proper airflow within the chassis. v One AC System power supply (SYS) v A fan tray assembly which contains the cooling system for the chassis Ethernet Switch s-series Installation and User Guide...

  • Page 33: B16S

    For safety reasons, the ESD wrist strap should contain a series 1 meg ohm resistor. B16S The IBM B16S is a 14 rack unit and consists of the following: v Two half slots for the management modules v Two half slots for the switch fabric modules v Sixteen half slots for the interface modules v Eight slots for power supplies along the bottom of the card shelf.
  • Page 34 Figure 4 on page 9 shows the chassis slots into which you can install the various modules and power supplies. It also shows an electrostatic discharge (ESD) connector, into which you can plug an ESD wrist strap to ground yourself while handling and installing modules. Ethernet Switch s-series Installation and User Guide...

  • Page 35: Management Modules

    CAUTION: For safety reasons, the ESD wrist strap should contain a series 1 meg ohm resistor. Switch Fabric Mgmt Slot 1 Slot 9 Interface Interface Interface Interface Interface Interface Interface Interface Slot 1 Slot 3 Slot 5 Slot 7 Slot 11 Slot 13 Slot 15 Slot 17...

  • Page 36: B08S And B16S Management Modules

    Standard management modules provide Layer 2 and base Layer 3 functionality only. Note: Premium management modules support full Layer 3 functionality. v The IBM Ethernet Switch B08S and B16S management modules are interchangeable with each other, and are only supported on these chassis models.

  • Page 37: 10/100/1000 Gbe Copper Port On The B08S And B16S Management Modules

    10/100/1000 Console Active Ethernet Figure 5. B08S and B16S management module with no ports Figure 6 shows the front panel of the IPv4 management modules with two 10-GbE ports. 10/100/1000 Console Link Link Active Ethernet Figure 6. B08S and B16S management module with two 10-GbE ports The front panel on the management modules include the following control features: v A console port and 10/100/1000 RJ-45 copper port allow you to access the system’s CLI directly from a PC or terminal or via a Telnet connection to the PC...

  • Page 38: Console Port

    The switch fabric modules in the B08S and B16S are separate from the management modules and are physically located next to the management modules. Figure 7 on page 13 shows the B08S and B16S switch fabric module. Ethernet Switch s-series Installation and User Guide...

  • Page 39: Leds On The Switch Fabric Module

    Active Figure 7. B08S and B16S switch fabric module LEDs on the switch fabric module The front panel provides status information using the LEDs listed in Table 6. Table 6. Front panel switch fabric LED status Description and Position State Meaning Top-most LED On (Green)

  • Page 40: 24-Port 10/100/1000 Mbps Ethernet Rj45 Copper Interface Module

    24 LEDs (on bottom) that indicate the status of POE. Note: The POE LEDs work only when POE is enabled on your device. The copper ports also provide status information using the LEDs. Ethernet Switch s-series Installation and User Guide...

  • Page 41: 24-Port 100/1000 Mbps Ethernet Hybrid Fiber (Sfp) Interface Module

    Table 8. LEDs for 10/100/1000 copper ports Position State Meaning Link/Activity Square LED located on upper On (Green) A link is established with the remote left corner of upper copper port. connector for upper copper connector Blinking The port is transmitting and receiving traffic.

  • Page 42: Support For 100Base-Fx On The 100/1000 Interface Module

    2-port 10-Gigabit Ethernet interface modules The 2-port 10-Gigabit Ethernet modules contain two physical ports, through which you can connect the IBM device to other network devices at a speed of 10 Gigabits per second. Only supported Brocade-branded fiber-optic transceivers can be used in this product.

  • Page 43: Leds For 2-Port 10-Gigabit Ethernet Module

    The IPv6 version has an identical appearance, except for the label on the left side, which reads 62XG. LEDs for 2-port 10-Gigabit Ethernet module The 10 Gbps ports provide status information using the LEDs . This chapter highlights the meanings and appearance of the LED on the 2-port 10-Gigabit Ethernet module.

  • Page 44: Power Supplies

    “About replacement power supplies” on page 21. Note: Manufacturing part numbers are inscribed on the labels on the top of the power supply. The following power supplies can be installed in the devices: Ethernet Switch s-series Installation and User Guide...
  • Page 45 POE port supports a maximum of 15.4 watts of power per POE power-consuming device. for example, if each POE power-consuming device attached to the IBM device consumes 15.4 watts of power, one 48-volt supply will power up to 70 POE ports. You can install a second 48-volt supply for additional POE power.

  • Page 46: Power Supply Placement In The B08S

    CAUTION: The power supplies are hot swappable, which means they can be removed and replaced while the chassis is powered on and running. However, IBM recommends that you disconnect the power supply from the wall outlet before removing and replacing the supply. The device can be running while a power supply is being installed or removed, but the power supply itself should not be connected to a power source.

  • Page 47: About Replacement Power Supplies

    About replacement power supplies Replacement power supplies for the 90-240 VAC SYS and 90-240 VAC POE, are functionally equivalent to the original power supplies, and can be used in combination with the original power supplies in the same chassis. Although the model numbers for both the newer and older versions of the power supplies are identical, the front of the power supplies are visually different and the manufacturing part numbers are different.

  • Page 48: Power Supply Leds

    No alarms present Amber There is an alarm present and the power and the power supply is supply is in normal malfunctioning. operating condition. Verify the AC input voltage. Ethernet Switch s-series Installation and User Guide...

  • Page 49: About Redundant Power Supplies And Power Supply Failure

    About redundant power supplies and power supply failure A chassis with redundant power supplies can maintain full operation when one or more power supplies fail. Power supply failure can be a failure of the supply itself or the office power grid connected to the power supply. A chassis can be either 1 + 1 redundant or N + 1 redundant.

  • Page 50: Cooling System

    The chassis ships with all fan components fully installed in the fan tray. To read additional information about replacing the fan tray, see one of the following sections: v “Replacing the B08S fan tray” on page 116 v “Replacing the B16S fan assemblies” on page 117 Ethernet Switch s-series Installation and User Guide...

  • Page 51: Built-In Mounting Brackets

    Built-in mounting brackets The front of each B08S has built-in, fixed mounting brackets that enable you to front-mount the chassis in a standard 19-inch (EIA310-D) rack. for instructions about using the adjustable mounting brackets to mount the device in a rack, see “Installing a chassis in a rack”...
  • Page 52 Ethernet Switch s-series Installation and User Guide...

  • Page 53: Chapter 3. Installing The Chassis

    Install the chassis in a rack. “Installing a chassis in a rack” on page 30 Because of the weight of a fully loaded chassis (97 lbs minimum), IBM recommends mounting a chassis in a rack before installing the modules and power supplies.

  • Page 54: Unpacking A System

    If you do not install a module in a slot, you must keep the slot panel in place. If you run the chassis with an uncovered slot, the system will overheat. Attention: Never leave tools inside the chassis. Ethernet Switch s-series Installation and User Guide...

  • Page 55: Power Precautions And Warnings

    CAUTION: The power supplies are ″hot swappable″, which means they can be removed and replaced while the chassis is powered on and running. However, IBM recommends that you disconnect the power supply from the wall outlet before removing and replacing the supply. The device can be running while a power supply is being installed or removed, but the power supply itself should not be connected to a power source.

  • Page 56: Installing A Chassis In A Rack

    Figure 16. Removing the extra screws used for shipment Installing a chassis in a rack Because of the weight of a fully loaded chassis (97 lbs minimum), IBM recommends mounting a chassis in a rack before installing the modules and power supplies.
  • Page 57 Select holes in rack that match the keyholes in mounting brackets (in this case, the top for the left-hand bracket and the bottom for the right-hand bracket) Figure 17. Positioning two of four mounting screws in a rack. 3. Mount the chassis that goes in the lowest position in the rack, as shown in Figure 18.

  • Page 58: Installing Mounting Brackets On The B16S

    1. Loosen the screws on either end of the slot panel with a #2 Phillips-head or flathead screwdriver. 2. Pull the slot panel out of the chassis, and store it in a safe place for future use. Ethernet Switch s-series Installation and User Guide...

  • Page 59: Installing The Management And Interface Modules

    Notes: 1. The interface modules are interchangeable among the s-series products. However, if you try to install them in chassis other than those documented here, the chassis and interface modules will not function properly.

  • Page 60: Installing A Management Module In The B08S

    Figure 20 shows the installation of a management module in the B08S. Figure 20. Installing a management module in the B08S Figure 21 on page 35 shows the installation of a management module in the B16S. Ethernet Switch s-series Installation and User Guide...

  • Page 61: Installing A Management Module In The B16S Chassis

    Figure 21. Installing a management module in the B16S chassis Figure 22 on page 36 shows the installation of an interface module in the B08S Chapter 3. Installing the Chassis...

  • Page 62: Installing An Interface Module In The B08S

    Figure 22. Installing an interface module in the B08S Figure 23 shows the installation of an interface module in the B16S Figure 23. Installing an interface module in the B16S Ethernet Switch s-series Installation and User Guide...

  • Page 63: Attaching A Management Station

    PC or terminal. You can order the serial cable separately from IBM or build your own cable. If you prefer to build your own, see the pinout information in “Serial (console) port pinouts” on page 125.

  • Page 64: Attaching A Switch To An Ethernet Port

    2. Lift the cord-retainer and connect the AC power cord to the power supply. 3. Snap the cord-retainer over the power plug to hold it in place, as illustrated below. Ethernet Switch s-series Installation and User Guide...

  • Page 65: Connecting Ac Power To A B08S

    Figure 24. Connecting AC power to a B08S Chapter 3. Installing the Chassis...

  • Page 66: Verifying Proper Operation

    Observing the LEDs After the chassis powers on, you can observe its LEDs to verify that it initialized successfully. If a problem persists after taking action described in this table, contact IBM Support. Ethernet Switch s-series Installation and User Guide...

  • Page 67: Desired And Possible Abnormal Led States After System Power-On

    Table 15. Desired and possible abnormal LED states after system power-on Abnormal Desired State Meaning State Meaning/Action Management module Active The module is functioning Neither of the management as the active module(s) is managing the switch management module. fabric and interface modules. A problem could have occurred during initialization.

  • Page 68: Displaying The Module Status

    Displaying the module status After you have attached a PC or terminal to the management module’s console port or Ethernet port and the IBM device has initialized successfully, press Enter to display the following CLI prompt in the terminal emulation window: FastIron>...
  • Page 69 F2: SX-FISF Switch Fabric active S1: SX-F424C 24-port Gig Copper OK 24 00e0.beef.0000 S2: SX-F424C 24-port Gig Copper OK 24 00e0.beef.0000 S3: SX-F42XGW 2-port 10G LAN/WAN OK 2 00e0.beef.0030 S4: SX-F424C 24-port Gig Copper OK 24 00e0.beef.0048 S5: SX-F42XGW 2-port 10G LAN/WAN OK 2 00e0.beef.0060 S6: SX-F424C 24-port Gig Copper OK 24 00e0.beef.0078 S7: SX-F424C 24-port Gig Copper OK 24 00e0.beef.0090 S8: SX-F424F 24-port Gig Fiber OK 24 00e0.beef.00a8...
  • Page 70 Ethernet Switch s-series Installation and User Guide...

  • Page 71: Chapter 4. Connecting Network Devices And Checking Connectivity

    “Troubleshooting network connections” on page 56 Assigning permanent passwords By default, the CLI is not protected by passwords. To secure CLI access, IBM strongly recommends assigning passwords. Note: You cannot assign a password using the Web management interface. You can assign passwords using IronView Network Manager if an enable password for a Super User has been configured on the device.

  • Page 72: Configuring Ip Addresses

    You must configure at least one IP address using the serial connection to the CLI before you can manage the system using the other management interfaces. In addition, IBM Ethernet routers require an IP subnet address for the subnet in which you plan to place them in your network.

  • Page 73: Ipv4 Devices Running Layer 2 Software

    The following procedure shows how to add an IPv4 address and mask to a router port. 1. At the opening CLI prompt, enter enable. FastIron> enable 2. Enter the following command at the CLI Privileged EXEC level prompt, then press Enter. This command erases the factory test configuration if still present: FastIron# erase startup-config Attention: Use the erase startup-config command only for new systems.

  • Page 74: Ipv6 Devices

    3. Access the configuration level of the CLI by entering the following command: Privileged EXEC Level: FastIron# configure terminal Global CONFIG Level: Ethernet Switch s-series Installation and User Guide...

  • Page 75: Ipv6 Devices Running Layer 2 Software

    FastIron(config)# 4. Configure the IPv6 address and mask address for the interface: FastIron(config)# int e 1/5 FastIron(config-if-e1000-1/5)# ipv6 address 2001:200:12D:1300:240:D0FF:FE48:4672:/64 These commands configure the global prefix 2001:200:12d:1300::/64 and the interface ID ::240:D0FF:FE48:4672, and enable IPv6 on interface e 1/5. Note: The above procedure shows how to configure an IPv6 address with a manually configured Interface ID as the address for the interface.

  • Page 76: Connecting Network Devices

    For copper connections to Ethernet hubs, a 10/100Base-TX or 1000Base-T switch, or another IBM device, a crossover cable is required. If the hub is equipped with an uplink port, it will require a straight-through cable instead of a crossover cable.

  • Page 77: Connecting To Workstations, Servers, Or Routers

    Cat-5 crossover cable 1000BaseT net48bg028 Figure 26. UTP crossover cable Figure 27 shows a cat-5 crossover cable for 1000Base-T. Cat-5 Crossover Cable 1000BaseT Figure 27. Cat-5 crossover cable for 1000Base-T Note: The 802.3ab standard calls for automatic negotiation of the connection between two 1000Base-T ports.

  • Page 78: Connecting A Network Device To A Fiber Port On The Device

    Note: All physical IP interfaces on the Layer 3 devices share the same MAC address. For this reason, if more than one connection is made between two devices, one of which is an s-series Layer 3 device, IBM recommends the use of virtual interfaces. It is not recommended to connect two or more physical IP interfaces between two routers.

  • Page 79: Cleaning Fiber Optic Modules

    Cleaning fiber optic modules To avoid problems with the connection between the fiber optic module (SFP or XFP) and the fiber cable connectors, IBM strongly recommends cleaning both connectors each time you disconnect and reconnect them. See “Cleaning the fiber optic connectors”...

  • Page 80: Testing Network Connectivity

    LEDs related to the network connections, the desired state of each LED, possible abnormal states of each LED, and what to do if an LED indicates an abnormal state. Note: Some modules use combined link and activity LEDs. Ethernet Switch s-series Installation and User Guide...

  • Page 81: Tracing A Route

    Web management interface or IronView Network Manager. If a problem persists after taking these actions, contact IBM Support. Tracing a route To determine the path through which a device can reach another device, enter a command such as the following at any level of the CLI on the device: FastIron>...

  • Page 82: Troubleshooting Network Connections

    For the indicated port, verify that both ends of the cabling (at the device and the connected device) are snug. v Verify that the IBM device and the connected device are both powered on and operating correctly. v Verify that the port has not been disabled through a configuration change. You can use the CLI.

  • Page 83: Chapter 5. Managing The Chassis And Modules

    Slot 2 Temperature: 34.5 deg-C Slot 3 Temperature: empty Slot 4 Temperature: 39.5 deg-C Slot 5 Temperature: empty Slot 6 Temperature: empty Slot 7 Temperature: empty Slot 8 Temperature: empty Slot 9 Temperature: 39.0 deg-C © Copyright IBM Corp. 2009...
  • Page 84 Slot 16 Temperature: 40.0 deg-C Slot 17 Temperature: 45.0 deg-C Slot 18 Temperature: 41.5 deg-C SF 1 Temperature: 40.5 deg-C SF 2 Temperature: empty Boot Prom MAC: 0012.f287.c900 The show chassis command display shows the following information: Ethernet Switch s-series Installation and User Guide...
  • Page 85 Table 18. Chassis status and temperature Information This Field... Displays... Chassis Type This field displays the chassis type. for example: B08S B16S v -PREM indicates that the device is a premium device (supports full Layer 2 switching and full Layer 3 multiprotocol routing). Power Power Supply Indicates whether a power supply is installed in the specified power supply slot and...
  • Page 86 Slot <number> Temperature The temperature of each module. On the B08S and B16S, the management modules reside in slots 9 and 10 and the switch fabric modules are SF 1 and SF 2. Miscellaneous Information Ethernet Switch s-series Installation and User Guide...

  • Page 87: Managing The Cooling System

    Table 18. Chassis status and temperature Information (continued) This Field... Displays... Boot PROM MAC The MAC address of the chassis. Managing the cooling system This section provides configuration, management, and monitoring information for the cooling system. Configuring the cooling system The device provides default settings for all cooling system parameters.

  • Page 88: Changing Temperature Thresholds For Thermal Planes And Fan Speeds On The On The B16S

    In general, each fan speed, except for low, has a low and high temperature threshold associated with it as shown in Figure 30 on page 63. The low fan speed has a high temperature threshold only. Ethernet Switch s-series Installation and User Guide...

  • Page 89: Fan Speeds And Temperature Thresholds On The B16S

    High temperature threshold Low temperature threshold HIGH High temperature threshold Low temperature threshold MEDIUM-HIGH High temperature threshold Low temperature threshold MEDIUM High temperature threshold Low temperature threshold MEDIUM-LOW High temperature threshold Figure 30. Fan speeds and temperature thresholds on the B16S The low and high temperature thresholds enable the device to determine at which speed the fans should operate.

  • Page 90: Changing Temperature Thresholds For Thermal Planes And Fan Speeds On The B08S

    In general, each fan speed, except for low, has a low and high temperature threshold associated with it as shown in Figure 30 on page 63. The low fan speed has a high temperature threshold only. Ethernet Switch s-series Installation and User Guide...

  • Page 91: Fan Speeds And Temperature Thresholds On The B08S

    High temperature threshold (shutdown temperature) Low temperature threshold HIGH High temperature threshold Low temperature threshold MEDIUM High temperature threshold Low temperature threshold MEDIUM-LOW High temperature threshold Figure 31. Fan speeds and temperature thresholds on the B08S The low and high temperature thresholds enable the device to determine at which speed the fans should operate.

  • Page 92: Acceptable Settings For Low Temperature Thresholds And Fan Speed

    (72° C) for the medium-high speed. Table 21. Acceptable settings for low temperature thresholds and fan speed Fan Speed Low Temperature Threshold High Temperature Threshold High 67° C 82° C Medium-high 57° C 72° C Ethernet Switch s-series Installation and User Guide...

  • Page 93: Shutdown Warning Messages

    However, the device will not accept the following values because the low temperature threshold for the high speed (73° C) is higher than the high temperature threshold (72° C) for the medium-high speed. Table 22. Unacceptable settings for low temperature thresholds and high fan speed Fan Speed Low Temperature Threshold High Temperature Threshold...

  • Page 94: Changing The Temperature Polling Interval

    The show chassis command displays the temperature reading of each thermal plane, as shown in the following examples. The following shows an example output on the B08S. The output is similar on the B16S. Ethernet Switch s-series Installation and User Guide...

  • Page 95: Displaying Fan Status And Speed

    FastIron# show chassis Fan controlled temperature: Rule 1/3 (MGMT CARDS THERMAL PLANE): 55.5 deg-C... Rule 2/3 (LINE CARDS THERMAL PLANE): 59.6 deg-C... Rule 3/3 (SWITCH FABRIC CARDS THERMAL PLANE): 78.7 deg-C... Syntax: show chassis Displaying fan status and speed The show chassis command displays the status and speed of the fans in the chassis.

  • Page 96: Displaying The Syslog Configuration And Static And Dynamic Buffers

    Dynamic - logs all other message types In the static log, new messages replace older ones, so only the most recent message is displayed. For example, only the most recent temperature warning Ethernet Switch s-series Installation and User Guide...

  • Page 97: Syslog Messages For Pci (Hardware) Errors

    message will be present in the log. If multiple temperature warning messages were sent to the log, the latest one will replace the previous one. The static buffer is not configurable. The message types that appear in the static buffer do not appear in the dynamic buffer.

  • Page 98: Displaying Management Module Cpu Usage

    Ethernet port. for the <slot> parameter, enter the number of the chassis slot in which the Ethernet interface module is installed. for the <port> parameter, enter the Ethernet port whose MAC address you want to remove. Ethernet Switch s-series Installation and User Guide...
  • Page 99 Use the vlan <number> parameter to remove all MAC addresses for a specified VLAN. Chapter 5. Managing the Chassis and Modules...
  • Page 100 Ethernet Switch s-series Installation and User Guide...

  • Page 101: Chapter 6. Using A Redundant Management Module

    During a switchover, the standby management module takes over the active role and re-initializes all the interface modules in the system that are not CLI-disabled by the administrator. This may cause a brief interruption of the traffic forwarding. © Copyright IBM Corp. 2009...

  • Page 102: Management Module Switchover

    If you remove the active management module, the standby module automatically assumes the role of the active module. After you insert a replacement module in the slot from which the original active module was removed, the replacement module Ethernet Switch s-series Installation and User Guide...

  • Page 103: Removal And Replacement Of A Standby Management Module

    The active management module boots from the active management module’s flash memory. Note: Before removing the active management module, IBM recommends that you first issue the command switch-over-active-role. For details, see “Manually switching over to the standby management module” on page 80.

  • Page 104: Syslog And Snmp Traps

    The B08S and B16S support the following management tasks related to management module redundancy: v Perform immediate synchronization of files v Perform a manual switchover to the standby module v Reboot the standby module Ethernet Switch s-series Installation and User Guide...

  • Page 105: File Synchronization Between The Active And Standby Management Modules

    File synchronization between the active and standby management modules Each active and standby management module contains the following files that can be synchronized between the two modules: v Flash code - The flash code can include the following files: – Primary - Contains the management module’s primary IronWare image. –...

  • Page 106: Manually Switching Over To The Standby Management Module

    You can cause the system to switch over to the standby module (and thus make it the active module). To do so, enter the following command: # switch-over-active-role Once you enter this command, the system will prompt you as follows: Ethernet Switch s-series Installation and User Guide...

  • Page 107: Rebooting The Active And Standby Management Modules

    Are you sure? (enter 'y' or 'n'): y Running Config data has been changed. Do you want to continue the switch-over without saving the running config? (enter 'y' or 'n'): n Please save the running config and try switch-over again Syntax: switch-over-active role Rebooting the active and standby management modules You can use the boot system or reload commands to reboot the management...

  • Page 108: How A Hitless Os Upgrade And Hitless Switchover Impacts System Functions

    Note: All traffic going through Ethernet interfaces (if present) on the management modules will be interrupted during a hitless OS upgrade. This is because Ethernet Switch s-series Installation and User Guide...

  • Page 109: Syslog Message For Hitless Os Upgrade And Hitless Switchover

    both management modules must be reloaded with the new image. This applies to hitless OS upgrade only. It does not apply to hitless switchover, which does not interrupt traffic going through Ethernet interfaces on the management modules. Note: Static and dynamic multi-slot trunks will flap during a hitless switchover if any of the trunk port members are on the management module.

  • Page 110: Layer 2 Hitless Os Upgrade

    MAC learning disable Management VLAN MLD v1/v2 snooping PIM v1/v2 snooping Port-based VLANs Port flap dampening (including with UDLD) Port mirroring Port security Private VLANs Protocol VLANs PVST, PVRST Rapid spanning tree Rate limiting Ethernet Switch s-series Installation and User Guide...

  • Page 111: Configuration Considerations

    Table 26. Information regarding Layer 2 hitless OS upgrades (continued) Rate shaping Remote Fault Notification (RFN) Root guard Single instance LACP Spanning tree Static MAC and multi-port static MAC Static trunks Subnet VLANs Super Aggregated VLANs (SAV) System-max parameters Topology groups Traffic policies UDLD VLAN groups...

  • Page 112: Configuration Steps

    OS upgrade using the hitless-reload command. for example: #hitless-reload primary Syntax: hitless-reload primary | secondary The primary parameter specifies that the management module will be reloaded with the primary image. Ethernet Switch s-series Installation and User Guide...

  • Page 113: Verifying The New Software Image

    The secondary parameter specifies that the management module will be reloaded with the secondary image. Verifying the new software image Enter the show version command at any CLI level to verify that all management and interface modules are running the new software image version. Monitoring management module redundancy You can monitor the following aspects of management module redundancy: v The status of the management modules (if a module is the active or standby...

  • Page 114: Displaying Temperature Information

    0d14h43m23s:N:System: Fan speed changed automatically to 3 0d14h43m23s:N:System: Fan speed changed automatically to 3 0d14h43m23s:N:System: Fan speed changed automatically to 3 0d14h43m23s:N:System: Fan speed changed automatically to 3 0d14h43m23s:N:System: Fan speed changed automatically to 3 Ethernet Switch s-series Installation and User Guide...
  • Page 115 0d14h43m23s:N:System: Fan speed changed automatically to 3 0d14h43m20s:I:System: Interface ethernet 5/2, state up 0d14h43m19s:I:System: Interface ethernet 3/2, state up 0d14h43m19s:I:System: Interface ethernet mgmt1, state up 0d14h43m19s:I:System: Interface ethernet 6/13, state up 0d14h43m18s:I:System: Interface ethernet 4/1, state up 0d14h43m18s:I:System: Interface ethernet 2/13, state up 0d14h43m18s:N:System: Fan speed changed automatically to 2 0d14h43m18s:N:System: Fan speed changed automatically to 2 0d14h43m18s:N:System: Fan speed changed automatically to 2...
  • Page 116 Ethernet Switch s-series Installation and User Guide...

  • Page 117: Chapter 7. Maintaining The Hardware

    To clean the fiber cable connectors, IBM recommends using the fiber-optic reel-type cleaner that shipped with your chassis. When not using an SFP or XFP connector, make sure to keep the protective covering on it.

  • Page 118: Removing A Management Module

    An ESD wrist strap with a plug for connection to the ESD connector on the chassis. CAUTION: For safety reasons, the ESD wrist strap should contain a series 1 meg ohm resistor. v A #2 Phillips-head or flathead screwdriver. Ethernet Switch s-series Installation and User Guide...

  • Page 119: Installing A Management Module In The B08S

    Note: You cannot mix IPv4 and IPv6 modules together in the same chassis. A chassis must either contain all IPv4 management modules and IPv4 interface modules or all IPv6 management modules and IPv6 interface modules. To install a new management module in the chassis, do the following: 1.

  • Page 120: Replacing A Switch Fabric Module

    For safety reasons, the ESD wrist strap should contain a series 1 meg ohm resistor. v A #2 Phillips-head or flathead screwdriver. To remove a switch fabric module from the chassis, do the following: Ethernet Switch s-series Installation and User Guide...

  • Page 121: Installing A New Switch Fabric Module

    1. Put on the ESD wrist strap and ground yourself by inserting the plug into the ESD connector located in the lower right corner of the chassis front. 2. Use a #2 Phillips-head or flathead screwdriver to loosen and remove the two screws on the ends of the module.

  • Page 122: Installing A Switch Fabric Module In The B08S

    Figure 35. Installing a switch fabric module in the B08S Figure 36 shows the installation of a switch fabric module in the B16S Figure 36. Installing a switch fabric module in the B16S Ethernet Switch s-series Installation and User Guide...

  • Page 123: Replacing An Interface Module

    Replacing an interface module You can remove an interface module and replace it with a new one while the B08S and B16S is powered on and running. This section provides information about the following tasks: v General precautions v Removing an interface module v Installing a new interface module Precautions Note the following when removing and replacing interface modules:...

  • Page 124: Removing An Interface Module

    Before installing one of these modules into the chassis, have the following on hand: v A new interface module v An ESD wrist strap with a plug for connection to the ESD connector on the chassis. Ethernet Switch s-series Installation and User Guide...
  • Page 125 CAUTION: For safety reasons, the ESD wrist strap should contain a series 1 meg ohm resistor. v A #2 Phillips-head or flathead screwdriver. To install a new interface module in the chassis, do the following: Note: You cannot mix IPv4 and IPv6 modules together in the same chassis. A chassis must either contain all IPv4 management modules and IPv4 interface modules or all IPv6 management modules and IPv6 interface modules.

  • Page 126: Installing An Interface Module In The B08S

    Figure 37. Installing an interface module in the B08S Figure 38. Installing an interface module in the B16S Ethernet Switch s-series Installation and User Guide...

  • Page 127: Configuring A Lan/Wan Phy Interface Module

    Configuring a LAN/WAN PHY interface module WAN PHY enables a 10 Gbps Ethernet port to use SONET/SDH for Layer 1 transport, thus allowing for the extension of Ethernet links across a WAN transport backbone. The following sections contain instructions for configuring the LAN/WAN PHY module.

  • Page 128: Installing Or Replacing A Poe Daughter Card

    2. Remove the 24-port Gigabit Ethernet module from the chassis as follows: v Put on the ESD wrist strap and ground yourself by inserting the plug into the ESD connector located on the chassis front. Ethernet Switch s-series Installation and User Guide...

  • Page 129: Connector Slots For Poe Daughter Card

    v Use the #2 Phillips-head or flathead screwdriver to loosen and remove the two screws on the left and right ends of the 24-port module. v Pull the card ejectors on the 24-port module toward you and away from the module front panel.

  • Page 130: Poe Daughter Card Key Detail

    Info: PoE module detected in slot 1. Initializing..9. Issue the show module command. The output should show the following description for the 24-port module on which the POE daughter card is installed: 24-port Gig Copper + PoE Ethernet Switch s-series Installation and User Guide...

  • Page 131: Replacing A Copper Or Fiber Optic Module

    10. Enable POE and configure POE parameters. See the Configuration Guide for information. Replacing a copper or fiber optic module You can remove an SFP or XFP from a port and replace it with a new one while the chassis is powered on and running. This section provides information about the following tasks: v Removing a copper or fiber optic module v Installing a new copper or fiber optic module...

  • Page 132: Installing A New Copper Or Fiber Optic Module

    1. Remove the protective covering from the fiber-optic port connectors and store the covering for future use. 2. Before cabling a fiber optic module, IBM strongly recommends cleaning the cable connectors and the port connectors. For more information, see “Cleaning the fiber optic connectors”...

  • Page 133: Installing Or Replacing A Power Supply

    Installing or replacing a power supply Attention: Before beginning the installation, see the “Safety notices” on page xiii. This section provides information about the following topics: v Determining which power supply has failed v Replacing an AC power supply v Connecting power to the chassis v Verifying proper operation Determining which power supply failed To determine which power supply has failed, enter the following command at any...

  • Page 134: Removing An Ac Power Supply

    CAUTION: The power supplies are hot swappable, which means they can be removed and replaced while the chassis is powered on and running. However, IBM recommends that you disconnect the power supply from the wall outlet before removing and replacing the supply. The chassis can be running while a power supply is being removed and replaced, but the power supply itself should not be connected to a power source.

  • Page 135: Removing An Original Power Supply

    2. Disconnect the power cord from the chassis rear panel. 3. Use a Phillips-head or flathead screwdriver to loosen the latch retaining screw in the front upper right corner of the power supply. Once the screw is loosened, the latch will spring gently forward and down. 4.

  • Page 136: Installing A New Power Supply

    Figure 50 on page 111. 2. When the power supply is fully seated, tighten the retaining screw as shown in Figure 50 on page 111. Ethernet Switch s-series Installation and User Guide...

  • Page 137: Installing An Original Power Supply

    3. Connect power to the chassis. See “Connecting AC power to the chassis” on page 112. 1.Slide the power supply Into the chassis 2.Push latch up until it locks into place 3.Tighten the retaining screw net08bs057 Figure 50. Installing a replacement power supply Installing an original power supply This section describes how to install an original power supply.

  • Page 138: Connecting Ac Power To The Chassis

    2. Lift the cord-retainer and connect the AC power cord to the power supply. 3. Snap the cord-retainer over the power plug to hold it in place, as illustrated below. Ethernet Switch s-series Installation and User Guide...
  • Page 139 Figure 52. Location of AC power connection on B08S Chapter 7. Maintaining the hardware...

  • Page 140: Verifying Proper Operation Of The Power Supply

    LEDs on the power supply. Table 27 on page 115 outlines the LEDs, the desired state of each LED, possible abnormal states of each LED, and what to do if an LED indicates an abnormal state. Ethernet Switch s-series Installation and User Guide...

  • Page 141: Displaying The Status Of The Power Supplies

    Table 27. Power supply LED operating status Desired State Abnormal Abnormal State Desired State Meaning State Meaning/Action AC OK ON - Green The power The power supply is (steady) supply is not receiving power receiving AC from an AC power power from an source.

  • Page 142: Replacing The B08S Fan Tray

    Figure 55 on page 117. While pressing the latch inward, gently pull on the handle until the fan connector unfastens from the chassis connector. Once unfastened, pull the fan tray out of the chassis. Ethernet Switch s-series Installation and User Guide...

  • Page 143: Replacing The B16S Fan Assemblies

    CAUTION: Be careful not to accidentally insert your fingers into the fan tray while removing it from the chassis. The fans may still be spinning at a high speed. FanTray Latch FanTray Figure 55. Removing the fan tray 6. Insert the new fan tray into the fan slot and push on the latch until the face plate is flush with the chassis.
  • Page 144 5. Secure the fan to the chassis by tightening the four captive screws. 6. Access the CLI, and enter the show chassis command to verify that both fans are operating normally. Ethernet Switch s-series Installation and User Guide...

  • Page 145: Upgrading The Device To Run Layer 3 Software

    Upgrading the device to run Layer 3 software You can upgrade the device to run Layer 3 code with the purchase of an additional feature. Chapter 7. Maintaining the hardware...
  • Page 146 Ethernet Switch s-series Installation and User Guide...

  • Page 147: Chapter 8. Hardware Specifications

    17.2 in (43.7 cm) behind the mounting brackets Environmental considerations For optimal performance, operate or store your IBM device in compliance with the following environmental conditions. Table 29. Environmental Conditions for the Chassis Description Range Operating Environment Operating temperature 32°...

  • Page 148: Cooling

    Total air flow: 127 CFM * 6 (qty) = 762 CFM v Fan operating noise: maximum 67.0 dB Cool air enters on left Hot air exits onright net08bs061 Figure 57. Internal Airflow in the B08S Ethernet Switch s-series Installation and User Guide...

  • Page 149: Cooling System On The B16S

    Cooling system on the B16S Note: This section describes the cooling system in the B16S. The fan trays in the B16S are located in the top rear of the chassis. The fans cool the CPU, main memory, and voltage regulators. The fans move the air from the front of the device to the rear of the device, as shown in Figure 58 on page 124.

  • Page 150: Maximum Power Consumption

    Hardware Component Consumption (Watts) B08S B16S Management module B08S and B16S management module with 2 10-GbE ports B08S and B16S management module with no ports B08S and B16S management module with 8 ports Ethernet Switch s-series Installation and User Guide...

  • Page 151: Power Source Interruptions

    Table 31. Maximum power consumption for devices (continued) Maximum Power Hardware Component Consumption (Watts) B08S B16S Switch Fabric module in the B08S Switch Fabric module in the B16S 2-port 10-GbE interface module, including fiber optics 24-port GbE copper interface module 24-port GbE fiber interface module, including fiber optics...

  • Page 152: 10/100 And Gigabit Port Pinouts

    Figure 60. Console Port Pin Assignments Showing Cable Connection Options to a Terminal or PC 10/100 and Gigabit port pinouts Figure 61 on page 127 lists the pin assignments and signalling for 1000Base-T ports. Ethernet Switch s-series Installation and User Guide...

  • Page 153: Cable Specifications

    Note: Cable installation and network configuration will affect overall transmission capability. The numbers provided below represent the accepted recommendations of the various standards. For network-specific recommendations, consult your local IBM representative or system engineer. Table 33. Cable length summary table Cable Type: (SMF...

  • Page 154: Power Cords

    XFP module 10GBase-ZRD LC connector for 1530.33 - 1561.42 up to 80000 (80 XFP module Power cords All of the devices ship with US-compatible power cords unless otherwise specified at the time of order. Ethernet Switch s-series Installation and User Guide...

  • Page 155: Power Supply Specifications

    Power supply specifications This section contains the following information for the power supplies that ship with the chassis. v “Physical dimensions and weight of power supplies” v “Configuring a LAN/WAN PHY interface module” on page 101) v “Electrical specifications” on page 130 v “Input connector and plug”...

  • Page 156: Electrical Specifications

    1250 watts of 4265 POE with VAC, 50 - 60 100 VAC maximum total output manufacturing power 8 amps at part number 200 VAC 1080 watts of 32016- xxx total POE output power Ethernet Switch s-series Installation and User Guide...

  • Page 157: Input Connector And Plug

    Table 36. Electrical specifications for power supplies (continued) Maximum Power Input voltage Inrush Maximum BTUs per Supply range Input current current Output hour 90-240 VAC 100 - 240 13.9 amps at 30 amps peak 1250 watts of 4265 POE with VAC, 50 - 60 100 VAC maximum...
  • Page 158 Figure 63. AC power cable plug and input connector - male and female Ethernet Switch s-series Installation and User Guide...

  • Page 159: Notices

    The materials at those web sites are not part of the materials for this IBM product and use of those web sites is at your own risk.

  • Page 160: Trademarks

    IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business Machines Corporation in the United States, other countries, or both. A complete and current list of other IBM trademarks is available on the Web at http://www.ibm.com/legal/copytrade.shtml Linux is a registered trademark of Linus Torvalds in the United States, other countries, or both.

  • Page 161: Electronic Emission Notices

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment.

  • Page 162: Germany Electromagnetic Compatibility Directive

    EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse A ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung der IBM verändert bzw.

  • Page 163: People's Republic Of China Class A Electronic Emission Statement

    People’s Republic of China Class A electronic emission statement Taiwan Class A warning statement Japan VCCI Class A ITE electronic emission statement Korea Class A electronic emission statement Electronic emission notices...
  • Page 164 Ethernet Switch s-series Installation and User Guide...

  • Page 165: Index

    46 examples xv CIDR notation 46 default gateway 47 Default gateway 49 documents Brocade xxii labels, safety xviii product xxii LEDs redundant management module 87 license, patents 133 licensing electrical specifications 130 address 133 © Copyright IBM Corp. 2009...
  • Page 166 79 status 87 safety xiii labels xiii, xviii examples xviii notices xiii rack xx Ethernet Switch s-series Installation and User Guide...
  • Page 167 When you send comments to IBM, you grant IBM a nonexclusive right to use or distribute your comments in any way it believes appropriate without incurring any obligation to you. IBM or any other organizations will only use the personal information that you supply to contact you about the issues that you state on this form.
  • Page 168 Readers’ Comments — We’d Like to Hear from You Cut or Fold Along Line GC27-2243-00 Fold and Tape Please do not staple Fold and Tape _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ NO POSTAGE NECESSARY IF MAILED IN THE...
  • Page 170 Part Number: 45W3125 Printed in USA GC27-2243-00 80214- 001...

Table of Contents
