Gamma Progression STII Owner's Manual page 13

MAINTENANCE & ADJUSTMENTS
Adjusting the Tensioner Brake
After stringing many racquets, the brake of
A
the tensioner may need to be adjusted.
With the brake lever engaged, loosen the
lock bolt located on the back side of the
tensioner frame with the 4mm hex wrench.
Note: The lock bolt should only be loosened
enough to be turned by hand and must not
be removed completely.
A - Lock Bolt
Adjusting the Tensioner Brake
With the lock bolt loosened and the brake
lever engaged in the latch, insert the 6 mm
B
hex wrench through the hole in the tensioner
cover and into the (B) brake lever adjusting
bolt.
B - Brake Lever Adjustment Bolt
Adjusting the Tensioner Brake
To tighten the braking mechanism, turn the
brake lever adjusting bolt counter clockwise
about 1/8 turn. Retighten the lock bolt on the
back side of the tensioner frame and check
for brake tightness. The tensioner should
move freely along the track with the brake
lever engaged and should hold tension with
the brake lever released. If more adjustment
is needed, repeat steps above until properly
adjusted.
Note: Cover removed for clarity
12
