MENU SYSTEM
ADVANCED SUB MENU
color management
The color temperature and color coordinates can be calibrated as desired.
mode
Select not corrected, temperature or custom color. The not corrected setting displays
the native color temeperature of the projector.
temperature
Select color temperature in steps of 100 Kelvin from 3200 – 9200 K along the 'black
body curve' of the CIE color chart.
custom color
Allows user control of the color temperature by way of either adjustments in the RGB
domain or x,y space.
RGB
Allows correction of R, G and B gain individually.
coordinate (x,y)
Set x and y color space coordinates directly. You may also reset to standard D65
coordinates.
source correction
This function allows correction of the incoming signal in the RGB space. Some
sources may output R, G and B signals that need correction of gain (contrast) and/or
offset (brightness). You may adjust gain (contrast) and offset (brightness) for R, G
and B individually.
video format
Select between manual or auto detection of TV standard.
video type
Select between video types; DVD and VCR. The DVD setting is
normally used and will yield well defined video images.
2
COLOR MANAGEMENT AND SOURCE CORRECTION
mode
red gain
green gain
blue gain
red offset
red gain
green offset
green gain
blue offset
blue gain
