  • Page 1 Fixed Speed Split Room Air Conditioner Installation Manual KSE26CRC, KSE26HRC, KSE35CRC, KSE35HRC, KSE53HRC, KSE62HRC, KSE70CRC, KSE70HRC, KSE88CRC KSE88HRC Refrigerant R410A...
  • Page 2: Table Of Contents

    • Staff kitchen areas in shops, offices and other working environments • Farm houses • By clients in hotels, motels, and other residential type environments • Bed and breakfast type environments 2 Contents Kelvinator Air Conditioning...
  • Page 3: Safety Precautions

    This symbol indicates never to do this warning Before obtaining access to terminals, all supply circuits must This symbol indicates always do this be disconnected. Kelvinator Air Conditioning Important safety instructions/Notice for installation 3...
  • Page 4 The height difference between indoor and outdoor units 1. Water pipe complies with the table on page 8. 2. Gas pipe Select a place where it is out of reach of children. 3. Contamination pipe 4 Notice for installation Kelvinator Air Conditioning...
  • Page 5: Installation Drawing

    If these dimensions are not adhered to the air conditioner will not perform to specification, may not be able to be serviced and the warranty may be voided. the installation must allow for reasonable access This image is for reference only. Kelvinator Air Conditioning installation drawing 5...
  • Page 6: Installation Of Indoor Unit

    Do not put the outlet in the water. the outdoor side. bulge distortion Piping hole Units 2.6 kW, 3.5 kW ( 55) 5.3kW, 6.2 kW, 7.0 kW and 8.8 kW ( 70) Flooded 6 Installation instructions Kelvinator Air Conditioning...
  • Page 7 Cut off the tailings 1 when routing the wiring only; 7.0 kW Cooling only, 7.0 kW & 8.8 kW Reverse cycle 50g/m b. Cut off the tailings 1 and tailings 2 when routing both the wiring and piping. Kelvinator Air Conditioning Installation instructions 7...
  • Page 8: Refrigerant Pipe Connection

    Improper flaring • Carry out flaring work using flaring tool as shown below. • Firmly hold copper pipe in a die according to the dimension shown in the table below. Even length all round 8 installation instructions Kelvinator Air Conditioning...
  • Page 9: Installation Of Outdoor Unit

    Bottom frame indoor unit connection Drain plug 2.6kW,3.5kW Cool and Heat type Drain connecter N(1) Hose (available commercially, yellow- violet orange blue black white blue brown inner diameter 16mm) green indoor unit connection Kelvinator Air Conditioning installation instructions 9...
  • Page 10: Check After Installation And Operation Test

    Press MODE button to select the COOL, HEAT (Not available with Cooling Only models), FAN to check The general service life for the HEPA filter is about one year whether the operation is normal or not. under normal conditions. 10 Kelvinator Air Conditioning installation instructions...
  • Page 11: Warranty

    PLEASE CALL 13 13 50 ELECTROLUX HOME PRODUCTS For the cost of a local call (Australia only) www.electrolux.com.au For the cost of a local call (Australia only) FOR SERVICE SERVICE NEW ZEALAND FOR SPARE PARTS or to find the address of your nearest or to find the address of your nearest authorised service centre in New Zealand state spare parts centre in New Zealand FREE CALL 0800 10 66 10 FREE CALL 0800 10 66 20 ELECTROLUX HOME PRODUCTS www.electrolux.co.nz (New Zealand only) (New Zealand only) KSSAC_Warr_Apr11 Kelvinator Air Conditioning warranty 11...
  • Page 12 1300 363 640 fax: 1800 350 067 email: customercare@electrolux.com.au web: www.kelvinator.com.au Kelvinator. We are part of the Electrolux family. Share more of our thinking at www.electrolux.com.au 66129909283 © 2011 Electrolux Home Products Pty Ltd ABN 51 004 762 341 Print code: Airwave_IM_Jul11...
