- Page 1 Fixed Speed Split-type Room Air Conditioner Installation Manual KSE26CRB, KSE26HRB, KSE35CRB, KSE35HRB,KSE53HRB, KSE62HRB, KSE70CRB,KSE70HRB, KSE88CRB AND KSE88HRB Refrigerant R410A...
-
Page 2: Important Safety Instructions
Indoor Outdoor type environments • Bed and breakfast type environments Max. Min. Max. Min. 30°C 17°C 24°C -5°C Note: Optimum performance will be achieved within these operating temperatures. 2 Contents Kelvinator Air Conditioning Kelvinator Air Conditioning Important safety instructions 3... -
Page 3: Before Installation
This illustration is for explanation purposes only. • Two of the A, B and C directions should be free from obstructions. • Copper lines must be insulated independently. 4 before installation Kelvinator Air Conditioning Kelvinator Air Conditioning typical installation 5... -
Page 4: Installation Instructions
If an awning is built over the outdoor unit to prevent direct sunlight or rain exposure, make sure that heat radiation from the condenser is not restricted. 6 Installation instructions Kelvinator Air Conditioning Kelvinator Air Conditioning piping length elevation 7... -
Page 5: Flaring Work And Connection Of Piping
Always use wall hole conduit when drilling metal grid, required). For some models this is not needed. metal plate or the like. • Replace the tubing retainer in its original position. 8 installation Kelvinator Air Conditioning Kelvinator Air Conditioning flaring work and connection 9... - Page 6 Make a small loop with the cable for easy connection later. 3/4" 19.0mm • Tighten the flare nut with a wrench, in accordance with the following table. Indoor unit tubing Flare nut Pipings 10 flaring work and connection Kelvinator Air Conditioning Kelvinator Air Conditioning flaring work and connection 11...
- Page 7 • F or your safety and protection, this unit is earthed through the power cord plug when plugged into a 2.6kW and 3.5 kW Cooling only models. matching wall receptacle. 12 flaring work and connection Kelvinator Air Conditioning Kelvinator Air Conditioning flaring work and connection 13...
- Page 8 Specification of power source. To outdoor unit Confirm that electrical capacity of the installation To indoor unit To power supply is sufficient. 14 flaring work and connection Kelvinator Air Conditioning Kelvinator Air Conditioning flaring work and connection 15...
-
Page 9: Air Purging
Usually, the cylinder is used in a vertical standing position. • Do a leak test of all joints of the tubing (both indoor and outdoor) and both gas and liquid side service valves. 16 air purging Kelvinator Air Conditioning Kelvinator Air Conditioning air purging 17... -
Page 10: Test Running
The air conditioner is now ready for use. have leakage. Man ua l c ontrol AUTO/COOL Leak detector button Use the leak detector to check for leakage. 18 test running Kelvinator Air Conditioning Kelvinator Air Conditioning test running 19... - Page 11 Notes Notes 20 notes Kelvinator Air care Kelvinator Air care notes 21...
- Page 12 Warranty FOR SALES IN AUSTRALIA AND NEW ZEALAND Notes APPLIANCE: KELvINATOR SPLIT SYSTEM AIR CONDITIONER This document sets out the terms and conditions of the product In all instances, unless the Appliance is transported by Electrolux or an warranties for Electrolux Appliances. It is an important document.
- Page 13 1800 350 067 email: customercare@electrolux.com.au web: www.kelvinator.com.au Kelvinator. We are part of the Electrolux family. Share more of our thinking at www.electrolux.com.au P/No. 1452635 © 2011 Electrolux Home Products Pty Ltd ABN 51 004 762 341 Print code: KFixIMUM_Jul11...
