Original BMW Accessories.

Installation Instructions.

Basic Bluetooth Hands-Free Kit Retrofit
Basic Bluetooth hands-free kit with USB/audio interface retrofit
BMW 3 Series (E90, E91) built after 09/2010
BMW 3 Series (E92, E93) built after 03/2010
Installation instructions only valid for cars with SA 606 (Business navigation system) without SA 6FL
or SA 609 (Professional navigation system) without SA 6FL
Retrofit kit number
84 64 0 441 949
65 41 2 152 528
Installation time
The installation time for the basic Bluetooth hands-free kit is approx. 1.5 hours.
The installation time for the basic Bluetooth hands-free kit with USB/audio interface is approx. 2.0 hours.
This may vary depending on the condition of the car and the equipment in it. On cars without the the fibre-optic
cable distributor station, the installation time will increase by approx. 0.5 hours.
The installation time specified does not include the time spent on programming/coding.
The calculation of the total costs for the programming time must be factored into the calculation of retrofitting costs
(no invoicing via warranty).
Important information
These installation instructions are primarily designed for use within the BMW dealership organisation and by
authorised BMW service companies.
In any event, the target group for these installation instructions is specialist personnel trained on BMW cars with
the appropriate specialist knowledge.
All work must be completed using the latest BMW repair manuals, wiring diagrams, servicing manuals and work
instructions, in a rational order, using the prescribed tools (special tools) and observing current health and safety
regulations.
In the event of any installation or functional problems, restrict the troubleshooting session to about
0.5 hours for mechanical work or 1 hour for electrical work.
To avoid unnecessary extra work and/or costs, an inquiry is to be sent straight away to the technical parts support
via the After Sales Assistance Portal (ASAP).
Quote the following information:
- Chassis number,
- retrofit kit part number,
- a detailed description of the problem,
- any work already carried out.
Do not archive the hard copy of these installation instructions since daily updates are made via ASAP!
© BMW AG, Munich
© BMW AG, Munich
Basic Bluetooth Hands-Free Kit
Basic Bluetooth hands-free kit with USB/audio interface
01 29 2 210 822
01 29 2 210 822
4/2011
4/2011
(Z/Z)
(Z/Z)
1

Advertisement

Table of Contents
loading

Related Manuals for BMW 84 64 0 441 949

Summary of Contents for BMW 84 64 0 441 949

  • Page 1: Installation Instructions

    These installation instructions are primarily designed for use within the BMW dealership organisation and by authorised BMW service companies. In any event, the target group for these installation instructions is specialist personnel trained on BMW cars with the appropriate specialist knowledge.
  • Page 2 Ensure that the cables and/or lines are not kinked or damaged as you install them in the car. Costs arising from this will not be reimbursed by BMW AG. Additional cables/lines that you install must be secured with cable ties.

  • Page 3: Table Of Contents

    Pairing the mobile phone with the car ............22 © BMW AG, Munich...

  • Page 4: Parts List

    Installation frame (E90, E91, E92 cars only) Steering column shroud (E93 cars only, not supplied with the retrofit kit) Cover cap 26-pin socket casing USB cable (to be given to the customer) © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)
  • Page 5 USB/AUX-IN jack (only included in the basic Bluetooth hands-free kit with USB/audio interface retrofit kit) BL 54-pin socket casing (only included in the basic Bluetooth hands-free kit with USB/audio interface retrofit kit, not required) © BMW AG, Munich 01 29 2 210 822 4/2011...

  • Page 6: Preparatory Work

    E90, E91, E92 cars only A pillar trim on the right 51 43 148 Roof function centre/front interior light 61 31 043 E93 cars only Steering column shroud 32 31 003 © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 7: Connection Diagram

    Fakra socket casing, GN BT aer On Bluetooth aerial B X14080 Adapter cable E93 cars only SW 3-pin pin housing On hands-free microphone O SW 3-pin pin housing On branch A8 X3564 © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 8: Usb Wiring Harness Connection Diagram

    In socket casing T PIN 24 0.35 mm Socket contact AUX_NF_L In socket casing T PIN 23 0.35 mm SW 4-pin HSD socket casing On combox D X34135 USB wiring harness © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 9: Installation And Cabling Diagram

    USB wiring harness (only when installing the basic Bluetooth hands-free kit with USB/audio interface retrofit kit) USB/AUX-IN jack (only when installing the basic Bluetooth hands-free kit with USB/audio interface retrofit kit) Radio connectors X13812 and X13815 © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 10: Wiring Harness On The Radio Receiver

    Unlock the fibre-optic cable connector (1) on branch A5 and connect the disconnected fibre optic cable (2). Connect plug X13812 (SW 16-pin) to the radio receiver. X13812 087 0654 Z © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)
  • Page 11 The 26-pin connection (1) must point in the direction shown.  Secure combox D using hexagon screws H, hexagon nuts I and two cable ties L to combox mount E. 090 1575 Z © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 12: With Usb/Audio Interface Retrofit Kit)

    - Branch A6 (SW 2-pin fibre optic cable casing) - Branch S (GN 26-pin socket casing) Branch U7 (SW 4-pin HSD socket casing, only when installing the basic Bluetooth hands-free kit with USB/audio interface retrofit kit). © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)
  • Page 13 (1). Loosely fasten combox holder E to the two drill holes (1) made previously using oval-headed screws G. Separate the rib (1) from the glove compartment (2). 090 1314 Z © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 14: Installing And Connecting The Usb/Aux-In Jack (Only When Installing The Basic Bluetooth Hands-Free Kit With Usb/Audio Interface Retrofit Kit)

    USB/AUX-IN jack V. 090 1406 Z Connect branches U1 and U2 to USB/AUX-IN jack V. Clip USB/AUX-IN jack V into the centre console. 090 1400 Z © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 15: Installing And Connecting The Bluetooth Aerial

    (2) and connect branch N2 of Bluetooth aerial connecting cable N to combox D. 090 1308 Z Tighten oval-headed screws G. Install the glove compartment (1) as per ISTA. 090 1307 Z © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 16: Installing And Connecting The Hands-Free Microphone (E90, E91, E92 Cars Only)

    Cut out the marked area on template M and place it on the interior light (1). Mark the contours of the cut-out (2) for the hands-free microphone and cut out the headlining (3). 082 0095 Z © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)
  • Page 17  Guide branch A8 through the installation frame Q and connect to hands-free microphone C. Clip hands-free microphone finisher F into installation frame G. 090 1304 Z © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 18: Installing And Connecting The Hands-Free Microphone (E93 Cars Only)

    Route branch A8 (SW 3-pin socket casing) on the right- hand side of the steering column and connect it to branch P2 (SW 3-pin pin housing). Install the steering column shroud (not shown). 093 0161 Z © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)

  • Page 19: Concluding Work And Coding

    - Pair the mobile phone with the car (see section 15 or 16) - Carry out a functional test of the basic Bluetooth hands-free kit - Re-fit the car components as required © BMW AG, Munich 01 29 2 210 822 4/2011...

  • Page 20: Wiring Diagram

    /A3* X13812 X14118/U2* X17183/U1* RT/GN X1716 X13016 090 1549 Z Cable colours Blue Grey Bordeaux (Burgundy) L-GN Light green Black Brown Natural Transparent Yellow Orange Violet Green Pink White © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)
  • Page 21 X13016 Earth support point X13815 SW 2-pin fibre-optic cable socket casing All the designations marked with an asterisk (*) apply only to these installation instructions or this wiring diagram. © BMW AG, Munich 01 29 2 210 822 4/2011 (Z/Z)
