5109212/03
OWNER GUIDE
Equinox
INSET LIVE FUEL EFFECT GAS FIRE
Model 754
(GC No. 32-032-59)
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE).
This guide is intended to help you care for your gas fire. Please read thoroughly before
using and keep for future reference.
Manufactured exclusively for British Gas & Scottish Gas by Valor Heating,
Wood Lane, Erdington, Birmingham B24 9QP
For Service Phone 0845 950 0400
This guide to be left with the owner
© Valor Heating

Advertisement

loading

Related Manuals for Valor equinox 754

Summary of Contents for Valor equinox 754

  • Page 1 This guide is intended to help you care for your gas fire. Please read thoroughly before using and keep for future reference. Manufactured exclusively for British Gas & Scottish Gas by Valor Heating, Wood Lane, Erdington, Birmingham B24 9QP For Service Phone 0845 950 0400 This guide to be left with the owner ©...
  • Page 2 CORGI Registered Installer in accordance with our Installer Guide and should not be fitted directly on to a carpet. Valor Heating, Erdington, Birmingham B24 9QP www.valor.co.uk Because our policy is one of constant development and improvement, details may vary slightly from those...

  • Page 3: Table Of Contents

    OWNER GUIDE LIST OF CONTENTS Heading Page SAFETY APPLIANCE DIMENSIONS GAS CONSUMPTION OPERATING YOUR FIRE The Oxysafe flame sensing & flue blockage safety system. To light the fire CLEANING Metal Parts Lighting with a taper To turn off Burner Pebbles and Pebble base FUEL BED REFITTING MAINTENANCE USEFUL TELEPHONE NUMBERS...

  • Page 4: Safety

    OWNER GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE - SEE YOUR LOCAL TELEPHONE DIRECTORY Do have the fire installed by a competent person.
  • Page 5 OWNER GUIDE Do provide a suitable guard that complies with BS 8423 for the protection of young children, the elderly and the infirm. Such a guard is also recommended for the protection of pet animals. (Although this fire conforms to all the applicable standards, it is a heating appliance and certain parts of its surface will become hot).

  • Page 6: Appliance Dimensions

    OWNER GUIDE APPLIANCE DIMENSIONS Figure 1. Appliance dimensions GAS CONSUMPTION Model 754 Has a maximum natural gas input of 5.1kW (Gross) Has a maximum natural gas output of 2.6kW (Gross) Has a minimum natural gas input of 3.0kW (Gross) Has a minimum natural gas output of 1.5kW (Gross) Page 6...

  • Page 7: Operating Your Fire

    OWNER GUIDE OPERATING YOUR FIRE PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after a few hours use.
  • Page 8 OWNER GUIDE the flame sensing device from shutting off the gas while its probe warms up as explained previously. If the pilot does not ignite quickly repeat the procedure. If after 10 seconds pilot ignition has not occurred, turn the control knob back to the “Off”...

  • Page 9: Cleaning

    OWNER GUIDE long spill. Insert the taper or spill into the gap underneath the pebble at the extreme left hand side of the fuel bed. Depress the control knob, turn it to PILOT/IGN To turn off  To turn the main burner off but leave the pilot alight, partially depress the knob and turn to PILOT/IGN.

  • Page 10: Burner

    OWNER GUIDE Pebbles and Pebble base This product uses fuel effect pieces containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres. Excessive exposure to this material may cause irritation to eyes, skin and respiratory tract. Consequently, it is important to take care when handling these articles to ensure that the release of dust is kept to a minimum.

  • Page 11: Fuel Bed Refitting

    OWNER GUIDE FUEL BED REFITTING 1. The front base pebble has the letters ‘MF’ on the underside. Locate the front base pebble in front of the burner (See figure 5) 2. The rear base pebble has the letters ‘MB’ on the underside. Locate the rear base pebble behind the burner (See figure 6) Figure 5.
  • Page 12 OWNER GUIDE 4. There are two pebbles numbered‘5’. They have a central location peg on the underside. Locate the first pebble ‘5’ centrally between the left hand ceramic support rods (See figure 8). Locate the second pebble ‘5’ centrally between the right hand ceramic support rods (See figure 8).
  • Page 13 OWNER GUIDE 7. There are four pebbles numbered ‘1’ on the underside. Locate these onto the pebble base at the ends of the outer left and right hand ceramic support rods (See figure 11). Leave a gap between pebble ‘3’ and the pebble ‘1’ as shown in figure 11.

  • Page 14: Maintenance

    OWNER GUIDE MAINTENANCE Regular maintenance In order to achieve and maintain high levels of personal safety and performance efficiency, it is essential that the opening at the back of the fire and the flue are kept clear of any form of obstruction. It is possible that deposits of mortar or soot could fall and accumulate causing the flue to be blocked or restricted and so preventing proper clearance of dangerous exhaust fumes.
