Summary of Contents for Horizon Hobby timber
- Page 1 Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni ® SAFE Select Technology, Optional Flight Envelope Protection...
-
Page 2: Safety Precautions And Warnings
Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warn- ings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. -
Page 3: Table Of Contents
Box Contents Quick Start Information Transmitter Set up your transmitter using the Setup transmitter setup chart Hi Rate Low Rate 33mm 25mm 33mm 25mm Dual Rates 22mm 16mm 30mm 20mm Full Half Flaps =35mm =20mm Center of 60mm +/- 5mm back from leading edge of wing at the fuselage. -
Page 4: Select Technology
3. Set AICRAFT TYPE: WING: 1 AIL 1 FLAP 4. Go to the FUNCTION LIST 5. Set FLAP SYSTEM: SELECT SWITCH D: DX10t POS 0: -100% FLAP DX18 POS 1: 0% FLAP 9% ELEVATOR POS 2: 60% FLAP 13% ELEVATOR SPEED 2.0 Timber... -
Page 5: Model Assembly
Model Assembly Landing Gear Installation 1. Turn the fuselage so the bottom side is facing up. 2. Slide the strut assembly (A) into the strut pocket on the side of the fuselage. 3. Secure the the strut assembly into place with two included screws (B). 4. -
Page 6: Model Assembly Continued
If adjustment is required, turn the clevis on the linkage to change the length of the linkage between the servo arm and the control horn. After binding a transmitter to the aircraft receiver, set the trims and sub-trims to 0, then adjust the clevises to center the control surfaces. Timber... -
Page 7: Wing Assembly
Model Assembly Continued Wing Assembly Required Adhesives: Medium CA Slat Installation (Optional) 1. Carefully remove all the foam slat pocket covers (A) from the wing. 2. When the pocket is exposed, carefully apply medium CA to each slat pocket. 3. Carefully mount the slat onto the wing with the rounded edge facing forward. - Page 8 3. Secure the front section of the fl oats using the two included screws (H) to secure the front support members to the bottom of the fuselage. 4. Attach the included wire from each fl oat rudder (I) to the pull–pull horn (J) using the two included pins (K). Disassemble in reverse order. Timber...
-
Page 9: Transmitter And Receiver Binding / Switching On And Off Safe Select
Transmitter and Receiver Binding / Switching ON and OFF SAFE Select ™ ® ® This product requires an approved Spektrum DSM2 /DSMX compatible Bind Plug Installation transmitter. Visit www.bindnfl y.com for a complete list of approved transmitters. The aircraft has an optional SAFE Select technology, which can be switched ON or OFF easily by binding in a specifi... -
Page 10: Select Switch Designation
Refer to the Spektrum AR636 manual for Elevator adjustment of gain values. After fl ying, you may choose to adjust the linkage positions for the desired control response. See the table to the right. Rudder More control throw Less control throw Timber... -
Page 11: Battery Installation And Esc Arming
Battery Installation and ESC Arming Battery Selection We recommend the E-fl ite ® 2200mAh 11.1V 3S 30C Li-Po battery (EFLB22003S30). Refer to the Optional Parts List for other recommended batteries. If using a battery other than those listed, the battery should be within the range of capacity, dimensions and weight of the E-fl... -
Page 12: Center Of Gravity (Cg)
If the control surfaces do not respond as shown, do not fl y the aircraft. Refer to the receiver manual for more information. Once the AS3X system is active, control surfaces may move rapidly. This is normal. AS3X remains active until the battery is disconnected. Timber... -
Page 13: In Flight Trimming
In Flight Trimming During your fi rst fl ight, trim the aircraft for level fl ight at 3/4 throttle with fl aps and gear up. Make small trim adjustments with your transmitter’s trim 3 Seconds switches to straighten the aircraft’s fl ight path. After adjusting trim, do not touch the control sticks for 3 seconds. -
Page 14: Pnp Receiver Selection And Installation
SAFE Select Flying SAFE Select will automatically compensate for pitch up with throttle the elevator stick is returned to center, the Timber will automatically resume application and fl aps deployed. level fl ight. If not doing a short takeoff, apply throttle and let the tail come up and then gently apply up elevator and allow the plane to fl... -
Page 15: Post Flight
Post Flight Disconnect the fl ight battery from the ESC (Required for Safety Repair or replace all damaged parts. and battery life). Store the fl ight battery apart from the aircraft and monitor the Power OFF the transmitter. battery charge. Remove the fl... -
Page 16: Troubleshooting Guide
Recharge fl ight battery or replace battery that is no longer performing Motor power pulses Weather conditions might be too cold Postpone flight until weather is warmer then motor loses Battery is old, worn out, or damaged Replace battery power Battery C rating might be too small Use recommended battery Timber... -
Page 17: Ama National Model Aircraft Safety Code
AMA National Model Aircraft Safety Code Effective January 1, 2014 A. GENERAL B. RADIO CONTROL A model aircraft is a non-human-carrying aircraft capable of sustained fl ight 1. All pilots shall avoid fl ying directly over unprotected people, vessels, in the atmosphere. It may not exceed limitations of this code and is intended vehicles or structures and shall avoid endangerment of life and property exclusively for sport, recreation, education and/or competition. -
Page 18: Limited Warranty
Product, (iv) attempted service by problem. A copy of your original sales receipt must be included for warranty anyone other than a Horizon Hobby authorized service center, (v) Product not consideration. Be sure your name, address, and RMA number are clearly purchased from an authorized Horizon dealer, or (vi) Product not compliant written on the outside of the shipping carton. -
Page 19: Contact Information
Compliance Information for the European Union EFL Timber BNF Basic (EFL5250) EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the R&TTE and EMC Directive. EFL Timber PNP (EFL5275) EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the EMC Directive. -
Page 20: Replacement Parts
Timber - Planche de décoration Foglio decorazioni adesive: Timber EFL5267 Landing Gear Retainer: Timber Timber: Fahrwerkshalter Timber - Bague de train d’atterrissage Fermo carrello d’atterraggio: Timber EFLP1240UE Propeller: 12 x 4 Propeller 12 x4 Hélice 12x4 Elica: 12 x 4... - Page 21 E-fl ite, AS3X, DSM, DSM2, DSMX, the DSMX logo, Bind-N-Fly, SAFE, the SAFE logo, Z-Foam, ModelMatch, Dynamite, EC3, Prophet and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
