Note: The docking station lets you connect two 4K displays, or a single 5K display.
Video adapters sometimes limit the maximum available resolution. Check the
documentation of the video adapter to determine its maximum supported resolution.
Connect multiple Thunderbolt 3 displays in a daisy chain
You can also set up dual displays using multiple Thunderbolt 3 displays in a daisy-chain
configuration.
Example: You can connect a Thunderbolt 3 display to the Thunderbolt 3 USB-C port
port on the docking station. You can then connect another Thunderbolt 3 device, such
as a second Thunderbolt 3 display, through the first Thunderbolt 3 display.
Supported video resolutions
Thunderbolt technology supports both video and data throughput. However, it
prioritizes video bandwidth to help ensure seamless display performance. The
performance of the remaining dock functions depends entirely on the display
configuration you used.
The docking station supports the follow maximum resolutions:
Number of
Displays
1
1
2
• Depending on the configuration and the supported resolutions of your connected
monitor(s), the docking station can support video resolutions lower than specified
above.
• In a multi-display configuration, set the refresh rates on each of your connected
monitors to the same values, otherwise your monitors might not properly display.
• Video output capabilities are dependent on the video card and hardware
specifications of your connected host laptop.
Instruction manual
for a range of USB-C video adapters and cables.
Ports
DisplayPort port
Thunderbolt 3 USB-C
port
DisplayPort port and
Thunderbolt 3 USB-C
port
Maximum Resolution
4096 x 2160p (60Hz)
5120p x 2880p (60Hz)
4096 x 2160p (60Hz) and 4096 x
8
2160p (60Hz)
