Danfoss TRONE-RF Installation Manual page 9

Display
Info & Settings
Button
Lock
Battery
Low
Heat
Calling
NOTE:
TPOne monitors several conditions and will provide warning or
information messages when necessary. Details on these can be
found on pages 24 - 26.
Danfoss Heating
16:35 Mon
21
Status Icons
Indicates that Button Lock has been activated to
avoid unintentional setting changes. To activate
buttons while button lock is active press the OK
button for 5 seconds. The Button Lock setting is
found in the Installer Menu.
The battery low icon indicates when the TPOne
batteries should be changed. To avoid loss of
heating or damage to your thermostat replace
batteries when this icon is displayed.
When the current room temperature is below the
required room set temperature the TPOne will call
for heating from the connected heat source. This is
indicated by the Heat Calling icon.
The TPOne-RF is connected by radio signal to a
receiver. The Radio Frequency icon will be displayed
to confirm that this connection is active and that the
TPOne-RF is controlling the heating.
If connection is lost the icon will go off and a warning
will be shown at the top of the display.
Important Note: Ensure that there are no large metal
objects, such as boiler cases, other large appliances
or mirrors in line of sight between the transmitter
and receiver as these will prevent communication
between the TPOne-RF and receiver.
°
.5
Warnings
Dates &
9
