Wiring
RX1-S Receiver
Remote sensor inputs
S1 S2
Remote room or limit sensor
NOTE:
Remote Sensor to be wired with 1mm 2 core double insulated cable
only. Cable length should not exceed 10 metres. Sensor cable should
NOT be run parallel to mains cable.
Danfoss Heating
RX1-S Receiver
N
L
1
N
L
230Vac
3
2
COM ON OFF
S1 S2
Window switch contact
4
5
