MAINTENANCE
5. Ensure that the "+" symbol on the
battery is facing upwards. The cor-
rect polarity is shown on the battery
cover.
6. Position the battery cover on the key
and press on it until it is heard to lock
in place.
NOTE
Use CR 2032 battery only.
116
On Board Diagnostic (OBD II)
System
On board Diagnostics or OBD is an auto-
motive term referring to a vehicle's self-
diagnostic and reporting capability. The
OBD system allows continuous diagno-
sis of the components of the vehicle cor-
related with emissions. This system
warns the driver, by turning "ON" the
Malfunction Indication lamp (MIL) on the
instrument cluster, when a fault causes
emission levels to increase.
The OBD system also has a diagnostic
connector that can be interfaced with
appropriate diagnostic tools, which
makes it possible to read the fault codes
stored in the Electronic Control Unit, to-
gether with a series of specific parame-
ters for Engine operation and Diagnosis.
This check can also be carried out by the
traffic police.
To access the diagnostic connector,
open the fuse box cover which is located
on RH side below the steering wheel. Re-
fer 'Emergency and Breakdown Assis-
tance' section for removal of cover.
