  • Page 1 OWNER’S MANUAL Revision: Rev00, Jun 21...
  • Page 2 CUSTOMER ASSISTANCE You can also approach nearest TATA MOTORS EV dealer. In our constant endeavour to provide assistance and complete service backup, TATA MOTORS has established an all India A separate Dealer network address booklet is provided with the cus-tomer assistance centre.
  • Page 3 Always carry out prescribed service / maintenance work as well as any required repairs at an authorized TATA MOTORS EV Dealers or Authorized EV Service Centre’s (TASCs). Use only genuine parts for continued reliability, safety and performance of your vehicle.
  • Page 4 Do not carry out any modification including fitment of non-genuine accessories on your vehicle. Safety, handling, performance and durability, may otherwise be adversely affected and may violate government regulations. TATA MOTORS has no liabili ty for damage resulting from the modifications or use of non-genuine accessories.

  • Page 5: Table Of Contents

    CONTENTS Supplementary Restraint System (SRS) 01. INTRODUCTION TO EV (Airbags) Introduction Child Lock (if applicable) Anti-theft Device-immobilizer / PEPS (if applica- 02. BATTERY INFORMATION ble) High Voltage Battery System Anti-lock Braking System (ABS) Electronic Brake Force Distribution (EBD) (if 03. CHARGING available) Safety Information Types Of Charging...
  • Page 6 CONTENTS Connected Vehicle Program (CVP) 06. DASHBOARD AND FEATURES Cockpit 07. STOWAGE AREAS Instrument Cluster Storage Compartment Warning Lamps Card Holder (if available) Audio Reminders (as available) Hooks (if available) Combi Switch (RH Stalk) (if available) Combi Switch (LH Stalk) (if available) 08.
  • Page 7 CONTENTS Seat Adjustments 11. MAINTENANCE AND SERVICES Rear View Mirrors Maintenance and Services ORVM Folding (as applicable) Monthly And Yearly Checks Sun Visors Radiator Maintenance Steering Wheel Adjustment Motor Compartment Steering Lock Cum Ignition Switch Tyres Electrical Power Assisted Steering (EPAS) Smart Key Battery Replacement (For PEPS Variant) Gear Modes...
  • Page 8 CONTENTS 13. CAR CARE Car Care Fastag Extended Warranty Value Added Services Vehicle Exterior Enrichment Vehicle Interior Enrichment 14. WARRANTY - TERMS AND CONDITIONS Warranty – Terms And Conditions 15. ENVIRONMENT SAFETY Environmental Safety 16. CHARGING DO’S AND DON’TS Charging Do’s And Don’ts viii...

  • Page 9: Introduction To Ev

    INTRODUCTION TO EV INTRODUCTION audio system, supplemental restraint sys- terms of air pollution. tems, headlights and windshield wipers. An electric vehicle is powered by a battery The high voltage battery also charges the - Edrive and it does not need any type of 12-volt battery.
  • Page 10 INTRODUCTION TO EV Main Components Important Information Electric Motor On-board Charger (OBC) A device that converts electrical energy In this Owner’s Manual, you will find the into rotational mechanical energy which is text under the heading “WARNING”, A device that charges the high voltage bat- then transferred as rotational torque to the “CAUTION”...
  • Page 11 Tata Motors EV service center for injury/casualty and there is also a risk • If work is not carried out properly, there any necessary maintenance.
  • Page 12 INTRODUCTION TO EV LED – Light Emitting Diode High-voltage System: Contact with Common Terminologies used in this Water Manual and their Abbreviations DRL – Daytime Running Lamp ORVM- Outer Rear View Mirror The high-voltage system is typically safe EV – Electric Vehicle even in the following example situations: IRVM –...

  • Page 13: Battery Information

    In a situation where the vehicle has under- gone complete discharge, please contact The Tigor EV is powered by a lithium ion the TATA MOTORS Authorized EV Service battery pack and it is managed by a highly Centre for further assistance.
  • Page 14 BATTERY INFORMATION Since the battery pack is not user service- for regular charging. capacity decreases, this will result in able, we urge you to visit the nearest TATA a decrease from the vehicle’s initial • If over time the maximum charge MOTORS authorized EV service centre to mileage range.
  • Page 15 Energy Recovery System down and TATA MOTORS EV Service out request from control panel which The Tigor EV features energy regenera- may generate noise from operation of Centre must be contacted for rectification.
  • Page 16 Slow Charging and full charging is the best out by TATA MOTORS after sales service form optimally for a prolonged time way to charge your vehicle to maintain the at the end of the battery life time or if the health of the high voltage battery.
  • Page 17 BATTERY INFORMATION Extreme Temperatures Extreme tempera- tures impact upon how well a battery can maintain its level charge. Avoid charging high voltage battery when it is hot and vehicle is driven for long distances especially in summers. Allow vehicle temperature to cool down before charging.

  • Page 19: Charging

    CHARGING SAFETY INFORMATION Charging Box Socket Carefully read these instructions and the charging instructions before charging your electric vehicle. The Slow Charging gun is located inside the boot of the vehicle. As shown in the image, the parts for Slow Charging system are: Home Charging box socket Plug...
  • Page 20 There are no user serviceable parts in- plantable cardiac pacemaker in a side the charging gun. Contact author- person. When a person has an implant ized TATA MOTORS EV Service NOTE like the one mentioned above, make Centre should you experience any...

  • Page 21: Types Of Charging

    CHARGING TYPES OF CHARGING NOTE cables are free of moisture before using There are two types of charging provided the charging gun. Never connect the Charging should be done in Ignition in your Tigor EV – Slow and Fast charging charging gun to the mains with wet or OFF state.
  • Page 22 CHARGING type of charging is called Slow charg- does not happen as frequently, please achieved by using Fast/DC charging ing / AC charging. charge the vehicles to 100% at least stations; they convert the AC power once a week. from the grid to DC power and can di- •...
  • Page 23 CHARGING charging only when necessary, i.e. when on long trips, away from home charging facilities etc. • If fast or opportunity charging is used, it is recommended to slow charge the vehicle from <20% charge to 100% after maximum 4 fast or opportunity charging sessions.
  • Page 24 CHARGING Here are the Details of the Different Types of Charging Mechanisms: Types Of Charging Specifications Charge Port Charge Gun Power Source Charging • Nominal voltage: 230 V ac RMS Sin- gle phase, 50Hz supply • Voltage range Slow/AC Charg- Minimum voltage = 190V ac RMS Maximum voltage = 250V ac RMS •...
  • Page 25 CHARGING Slow / AC Charging dust, water or snow while connecting Precaution for Slow Charging the charging gun; if not proper cleaning It takes about 8.5 hours at room tempera- Proper maintenance of earthing pit is method must be used to remove dust, ture and normal operating conditions (refer must.

  • Page 26: Home Charging Box For Slow Charging Of Your Ev

    In order to provide customer a seamless assistance. charging experience at home, Tata motors Warranty Period provides a complementary Home charging 3 Years Warranty for below components of...
  • Page 27 CHARGING DO NOT plug into a power strip. Pull the ‘Charging-inlet Flap Open Lever’ to open the charging inlet flap. Open the Protective cap on charging gun.
  • Page 28 Open the protective cap on charging If the actuator is engaged and the gun inlet. is not getting inserted properly, contact Tata Motors EV service center. Remove any dust on the Charging Gun and Charging Inlet. Connect the charging gun to vehicle AC Charging Inlet.
  • Page 29 CHARGING In case the park brake is not engaged or partially engaged the charging won’t start and ‘Engage Park Brake to start charging’ message will be displayed on instrument cluster. Put on the protective caps on both To stop the charging, switch off the AC NOTE Charging Gun and Vehicle Inlet.
  • Page 30 CHARGING NOTE In emergency charging shutdown con- ditions, Gun won’t be unlocked. Contact authorized TATA Service Centre. NOTE In unforeseeable circumstances if the charging gun is stuck to the socket after charging is done, user has to contact the service personnel. No mechanical override to remove the charging gun is available for user.
  • Page 31 CHARGING Slow Charging Control Box Indica- tions Home Control box Vehicle Fault Slow charging control box...
  • Page 32 CHARGING Control Working State Home Vehicle Fault Example Description Self-inspection Blink Blink Blink Blink Self-inspection for system state No fault Check for engagement of park brake Standby state Blink Plug temperature is high No fault Charging state Blink Blink Plug temperature is high No fault Charging stopped Blink...
  • Page 33 CHARGING Troubleshooting Guide for Slow Charging Refer the below table if charging is not starting or if it stops abruptly. The below symbols of ‘House’, ‘Control Box’, ‘Vehicle’ and ‘Fault’ can be seen on the control box beside the respective LEDs. Fault Cate- Control Indication...
  • Page 34 Fault Cate- Control Indication Home Vehicle Fault Recommended Action gory Blink Control Contact TATA Motors EV Service fault engineer Blink Blink Blink Go to nearest TATA Motors EV Vehicle box Service Centre Blink Blink Legend -Blink - Off - On...
  • Page 35 Wait for 5 minutes. drain system. If water is stagnant in Do not use charging gun if it is wet in charging port area call TATA MOTORS • Restart the charging. (Refer charging interface area. Allow it to dry before procedure).

  • Page 36: Fast Charging Procedure

    CHARGING FAST CHARGING PROCEDURE Gun and Charging Inlet. Connect the charging gun to vehicle Engage the parking brake. (Charging AC and DC Charging Inlet. won’t start without engaging the parking brake). You hear a “click”, when the Gun is connected correctly. NOTE Switch on the DC charging station sup- Ensure vehicle is in OFF / Ign ON con-...
  • Page 37 In emergency charging shutdown con- Indication Priority Table on the ditions, Gun won’t be unlocked. Contact charging station. Infotainment and cabin cooling can be authorized Tata Motors EV service used during charging of the vehicle by center. NOTE putting the vehicle in Ignition.

  • Page 38: State Of Charge (Soc) Gauge For High Voltage Battery

    CHARGING STATE of CHARGE (SoC) GAUGE reaches 0%. Charge the vehicle imme- diately. FOR HIGH VOLTAGE BATTERY Provided in the instrument cluster as a tell- tale. It shows the charging status of the high voltage battery. Low charge or minimum position on the in- dicator indicates that there is not enough energy in the high voltage battery.

  • Page 39: Safety

    SAFETY IMPORTANT INFORMATION Safety Tips Driving in Adverse Condition • Always take into account the road con- Safe Driving Driving Through Water ditions, weather conditions, vehicle Safety consciousness not only ensures Do not drive through flooded areas. Judge speed in order to prevent accidents. your safety and the safety of other road the depth of water before driving through •...
  • Page 40 Contact a near- surface and the vehicle’s tires due to a • Drive more slowly at night than in the est TATA MOTORS Authorized EV water film forming between them. Steering daytime, as the visual range is re- Service Centre.

  • Page 41: Seat Belts

    SAFETY the parking brake and depress the accel- SEAT BELTS your foot off the accelerator pedal. This erator pedal to start off. This section of user manual gives the in- allows you to take advantage of regen- On climbing sharp gradients, never hold formation about your vehicle seat belt, erative braking effect and helps avoid the vehicle at a stop using only the accel-...
  • Page 42 SAFETY across your thighs, below your ab- Seat Belt Height Adjustments (if domen. To remove slack, pull up a bit equipped) on the shoulder seat belt. To loosen If the height adjustment is provided in the the lap portion seat belt if it is too tight, seat belt, occupant can adjust it to their tilt the tongue and pull on the lap seat comfort.
  • Page 43 If the seat belt webbing or hardware is damaged, get it replaced immedi- In a collision, the pre-tensioner seat belt ately at TATA MOTORS Authorized assembly mechanisms become hot dur- EV service centre. ing activation. Do not touch the pre-ten- sioner seat belt assemblies for several •...
  • Page 44 Au- abdomen. That way the strong duration until the driver’s seat belt is thorized TATA MOTORS EV Service fastened. bones of the hips will take the force Centre.

  • Page 45: Child Restraint System (Crs)

    ISOFIX only (if equipped) sensor. TATA motors does not recom- or ISOFIX with Top Tether (if equipped). mended any non-validated seat covers The harness system of CRS holds the on seats.
  • Page 46 SAFETY NOTE The above images are for reference purpose only.
  • Page 47 SAFETY Recommended CRS Position asper Front Mass Rear Out- Rear Out- Rear the Vehicle Matrix Group Age Group Passen- Group board Lh board Rh Center The suitability of seat position for carriage of children and recommended category of Upto to 10 Up to 9 months CRS is shown in the table below as per the child...
  • Page 48 (as may be applicable) inves- stall a rear facing CRS in the front pas- tigated at TATA MOTORS Authorized EV • Do not install a booster seat or a senger seat. If the PAB inflates, a child service centre.
  • Page 49 SAFETY Each CRS should be used for one child only. If the airbag SRS warning indicator in the instrument cluster illuminates continu- ously, it means that there is malfunction in the system. Remove the CRS from front passenger seat and contact your TATA MOTORS authorized EV service centre.

  • Page 50: Supplementary Restraint System (Srs) (Airbags)

    SAFETY SUPPLEMENTARY RESTRAINT that you may not even realize that it has deployed. If you are involved in another activated. The air bag will neither hinder collision, the airbags will not be in place to SYSTEM (SRS) (Airbags) your view nor make it harder to exit the ve- protect you.
  • Page 51 SAFETY WARNING • If an occupant is out of position dur- NOTE ing collision, then quickly deploys air • Open your windows and doors as • Even in vehicles with airbags, pas- bag may hit the occupant causing soon as possible after collision to re- sengers must always put on the serious or fatal injuries.
  • Page 52 SAFETY...
  • Page 53 TATA MOTORS Authorized EV • ALWAYS contact your TATA MO- Service Centre for necessary guid- •...
  • Page 54 We recommend the customer to imme- Please refer CRS section for recom- diately visit TATA MOTORS Authorized mended seating position for children. EV Service Centre and get the SRS system inspected if any of the above...
  • Page 55 SAFETY belts provide highly effective occupant pro- Why front airbags do not deploy, even Airbags Deployment Conditions tection during rollover collision. Front with exterior visible vehicle damage to When the front airbags should not de- airbags are not designed to deploy in a the car? ploy? rollover as frontal airbags cannot offer any...

  • Page 56: Child Lock (If Applicable)

    SAFETY CHILD LOCK (if applicable) NOTE • Lift the lock lever upward to deacti- vate the childproof lock when not re- quired. • Child safety lever is used for safety of child. When child seat in the pas- senger seat, child lock prevent the child to open the rear door.

  • Page 57: Anti-Theft Device-Immobilizer / Peps (If Applicable)

    - Problem with key (Wrong key used to start vehicle) Ignition ON Locked - Problem with Immobilizer system. Contact the TATA MO- TORS Authorized EV Service Centre Contact the TATA MOTORS Authorized EV Service Centre Ignition ON Blinking Unlocked immediately...

  • Page 58: Anti-Lock Braking System (Abs)

    SAFETY ANTI-LOCK BRAKING SYSTEM While Braking directional control. (ABS) • In an emergency situation take your • However, remember that ABS will foot off the accelerator and press the regulates brake not compensate for bad road or brake pedal fully. This allows the ABS pressure in such a way weather conditions or poor driver to regulate braking for you and have...

  • Page 59: Electronic Brake Force Distribution (Ebd) (If Available)

    SAFETY ELECTRONIC BRAKE FORCE DIS- Centre as soon as possible. TRIBUTION (EBD) (if available) EBD monitors and controls the brake pressure on the rear wheels to improve driv- ing stability while braking. EBD provides optimal braking pressure distribution between front and rear wheels to optimize braking distance and to ensure vehicle stability by means of lowering braking pressure increase at rear wheels.

  • Page 61: Opening And Closing Keys

    Loss of Keys cranking. If you cannot the find the key, contact the nearest TATA MOTORS Authorized EV Service Centre immediately.
  • Page 62 OPENING AND CLOSING Keys (as available) Sr. No. Name Remote Key Description Locking all doors Mechanical key Unlocking all doors Unlocking all doors Approach light Flip key with remote Locking all doors Folding key blade in/out Locking all doors Approach light Smart Key (PEPS) Tail gate opening Unlocking all doors...

  • Page 63: Flip Key

    OPENING AND CLOSING FLIP KEY Folding Key Blade in / out Approach Light / Follow Me Press button (4) to flip out the key blade. Press approach light button (2) once, low For folding, press the button (4) and fold beam, park and roof lamp will turn ‘ON’...

  • Page 64: Smart Key (If Applicable)

    OPENING AND CLOSING SMART KEY (if applicable) flashes of turn signal indicators. Manual Operation of Central Door Locking / Unlocking Approach Light All doors can be locked / unlocked operat- This feature helps to find and reach the ing driver door using either key blade from parked vehicle.

  • Page 65: Smart Key Features

    OPENING AND CLOSING SMART KEY FEATURES power is in OFF mode and vehicle all NOTE doors in locked condition. After doing other Vehicle Search than driver door transition (open a closed) If smart key battery is low/drained or ve- If lock button on smart key is pressed then vehicle all door will get unlocked and hicle battery is low/drained, user can when the vehicle is locked, the turn indica-...
  • Page 66 OPENING AND CLOSING Smart Key Precautions the push button of remote. If smart key is close to radio transmit- Force Panic Operation ter, it may interfere with the operation of the smart key. Force Panic ON Operation If the smart key is near a mobile two When the vehicle is in off condition and the way radio system or a cellular phone, lock and unlock buttons are pressed at the...
  • Page 67 OPENING AND CLOSING Two Smart Keys Scenarios Sr No Scenarios Precondition Action Peps Behaviour One smart key is inside the Lock the vehicle with vehicle (away from Immobi- outside smart key (pas- Vehicle is in OFF lizer antenna) and other sive lock / RKE lock) and When user tries to start the vehicle with in- mode and all door...
  • Page 68 OPENING AND CLOSING Sr No Scenarios Precondition Action Peps Behaviour One smart key is inside the Vehicle is in OFF Lock the vehicle with When user tries to start the vehicle with in- vehicle (away from Immobi- mode and all door outside smart key (pas- side smart key, vehicle doesn’t start.

  • Page 69: Doors

    OPENING AND CLOSING DOORS the door handle switch (DHS) provided on Locking without a Key from Inside the driver door to lock/unlock all the four Door Lock and Unlock with Key (if doors excluding Tail gate. available) The front doors can be locked or unlocked from outside using the key blade.

  • Page 70: Windows

    OPENING AND CLOSING Opening the Doors from Inside WINDOWS NOTE Power Window (if available) Power windows can be operated for 30 seconds in ‘IGN OFF’ and ‘KEY OUT’ positions, provided the doors are closed. Express Down (if applicable) Window glasses can be opened by a sin- gle long press of the switch.
  • Page 71 OPENING AND CLOSING cannot be operated. However, it can be Individual Switches WARNING operated from the switches on driver’s arm Individual window winding switches have rest. While raising the glass, take care to been provided on the front passenger and avoid fingers/hands getting trapped be- Inhibit Switch OFF rear doors.

  • Page 72: Bonnet

    OPENING AND CLOSING BONNET cated under the bonnet centre to the left side. Opening NOTE WARNING Make sure that the wiper arms are not Always switch off the ignition before raised before you lift up the bonnet to opening the bonnet. avoid damaging the wiper arms and the bonnet.

  • Page 73: Tailgate Opening

    OPENING AND CLOSING TAILGATE OPENING Option 2 WARNING NOTE Make sure that the bonnet is locked properly before driving or it can fly up Some variants may have multiple op- unexpectedly during driving. tions. Option 1 Use a key to open the Tailgate. Insert the key and turn clockwise to open the tail- gate.

  • Page 74: Opening Charging Port Flap

    TATA MOTORS NOTE Remove the Rubber Cap for charging be- Authorized EV Service Centre.

  • Page 75: Dashboard And Features

    DASHBOARD AND FEATURES COCKPIT A.C. Air vent (Middle) Hazard Warning Switch Combi-Switch Steering Wheel Instrument Cluster Horn pad / Air Bag (DAB) Driver side pocket Bonnet switch Accelerator Pedal Brake Pedal Foot Rest Start stop switch - if fitted Parking Brake Lever Cup Holder Gear Selection Knob USB/AUX Port - if fitted...

  • Page 76: Instrument Cluster

    DASHBOARD AND FEATURES INSTRUMENT CLUSTER NOTE: All indicators show may not be applicable to your vehicle.
  • Page 77 DASHBOARD AND FEATURES State Of Charge (SoC) Speedometer indicates the vehicle speed EV Mode Gauge in km/h. This function provides instantaneous power consumption mode of vehicle dur- NOTE ing driving and displayed in the instrument At every key in and Ignition ON, cluster.
  • Page 78 DASHBOARD AND FEATURES Power Mode Power mode, Power band will fill as per power con- sume in Power drive by taking instanta- neous power con- sumption input. Regeneration Mode In regeneration mode, Regeneration band will fill as per energy recu- peration while driving by taking instantaneous...
  • Page 79 DASHBOARD AND FEATURES Driver Information System Driver Information System Image Description Indicates total distance travelled by a vehicle. Odometer The Odometer reading does not return to “0” when it reaches maximum value, the display will freeze to maximum value and not resettable.
  • Page 80 NOTE: If RANGE is displayed as ‘—-‘, take your vehicle to Distance to empty authorized TATA MOTORS EV Service station. The distance to empty value is an estimate of the available driving distance. In event of drive with higher power consump- tion / harsh drive, actual initial RANGE shown and kilometer driven will vary than display.
  • Page 81 DASHBOARD AND FEATURES Driver Information System Image Description section in owner’s manual for extensive information on serv- ice schedules. When the ignition switch is in the “ON” position, it shows the time. NOTE: You can change the clock time using SET and MODE Clock buttons.
  • Page 82 DASHBOARD AND FEATURES Driver Information System Image Description All four doors and tail gate are indicated independently when respective door or tail gate is open. NOTE: If any other door is open roof lamp will be ‘ON’ pro- vided that roof lamp switch is in position Door ajar (if applicable) This warning will be indicated when driver door is open.
  • Page 83 DASHBOARD AND FEATURES Driver Information System Image Description Indicates the outside ambient temperature of FATC System from ‘LO’ to ‘HI’. Displays outside ambient temperature in units °C. and Resolution is 1°C. NOTE: The temperature sensor is in the front bumper of the vehi- cle, therefore the temperature reading can get affected by Outside ambient tempera- heat reflection from the road surface, Power electronics...
  • Page 84 DASHBOARD AND FEATURES Driver Information System Image Description “SERVICE DUE” text warning comes ‘ON’ for 4 seconds when Service due service is overdue. “OVER SPEED” text warning comes ‘ON’ for 4 seconds when Over speed dis-play speed crosses 120 Km/Hr. “TAKE A BREAK”...
  • Page 85 DASHBOARD AND FEATURES Driver Information System Image Description “HV CRITICAL ALERT” text warning comes ‘ON’ for 4 sec- HV critical alert onds when there is critical alert in HV System. “LIMITED PERFORMANCE” text warning comes ‘ON’ for 4 Limited performance seconds when Limited Performance Mode Activated.
  • Page 86 DASHBOARD AND FEATURES Driver Information System Image Description “FASTEN CO-DRIVER SEAT BELT” text warning comes ‘ON’ Fasten co-driver seat belt for 4 seconds when Co-Driver seat belt is not fasten and Vehi- cle speed is above 15 Kmph. AUX BATTERY LOW text warning comes ‘ON’ for 4 seconds AUX battery low when Auxiliary battery is low.
  • Page 87 DASHBOARD AND FEATURES Driver Information System Image Description CHARGE NOT FULL BAT SOC XX PERNT text warning Charge not full bat SoC XX comes ‘ON’ for 4 seconds when Vehicle Charger is Removed Pernt & Battery is not Fully Charge. CHARGE FULL text warning comes ‘ON’...
  • Page 88 DASHBOARD AND FEATURES Driver Information System Image Description “LOW SOC S MODE DEACTIVATED” text warning comes Low SoC S mode deacti- ‘ON’ for 4 seconds when S Drive Mode is selected with Vehi- vated cle Battery Low Condition.
  • Page 89 Lamp ‘ON’ and then Press the ‘SET’ knob If RANGE is displayed as ‘—-‘, then on Instrument Cluster. take your vehicle to TATA MOTORS Au- Press ‘SET’ knob to change the illumina- thorized EV Service Centre. tion intensity level in 5 steps. A delayed press on the ‘SET’...
  • Page 90 DASHBOARD AND FEATURES Driver Information Settings Screen flow of Instrument cluster...
  • Page 91 DASHBOARD AND FEATURES Clock Setting...

  • Page 92: Warning Lamps

    System & lights up when the ‘IGN’ is turned ‘ON’ for 4 Sec & goes LV Battery Charging OFF after Power electronics and Drive unit start. It will continuously illuminate when there is malfunction of charging system. Contact a TATA MOTORS Authorized EV Service Centre. Illuminates momentarily when ignition is switched ‘ON’. EPAS Amber Illuminates when there is a fault in the EPAS.
  • Page 93 Seatbelt reminder remains OFF when reverse gear is engaged. Illuminates when ignition is switched ‘ON’ and goes ‘OFF’ in ap- Airbag status prox. 4seconds. If it continuously illuminates or blinks then contact the TATA MOTORS Authorized EV Service Centre immediately.
  • Page 94 DASHBOARD AND FEATURES Warnings Lamps Color Indicator Remarks This features provides HV battery charging status to user. When- ever the IGN is ON, this telltale glows for a few seconds and goes off. The telltale shall remain ON irrespective of the Input state dur- Charging indicator Green ing these few seconds.
  • Page 95 DASHBOARD AND FEATURES Warnings Lamps Color Indicator Remarks If the seatbelt remains unbuckled and vehicle goes 15 Kmph then final warning audio chime will start and continue for 90 seconds. Note: Once the seatbelt is fastened the buzzer and warning lamp goes OFF.
  • Page 96 DASHBOARD AND FEATURES Warnings Lamps Color Indicator Remarks Speed Limit warning indicator comes ‘ON’ for a few moments, when ignition is turned ‘ON’. When Vehicle Speed cross 80 kmph then Speed Limit Warning Indicator will turn ON along with audio warning every two minutes.
  • Page 97 This symbol shall continue to remain ‘ON’ if there is a problem in the ABS system. If the warning is continuously ON Take your Car to TATA MOTORS Authorized EV Service Centre. This features provides High Voltage battery status to user. When- ever the IGN is ON, this telltale glows for a few seconds and goes off.
  • Page 98 This tell-tale shall be controlled turned ON/OFF by receiving the input HV battery high tempera- ture input signal , whenever battery temperature is high it will indi- cate the user EV system battery high temperature and to visit TATA MOTORS Authorized EV Service Centre.

  • Page 99: Audio Reminders (As Available)

    DASHBOARD AND FEATURES AUDIO REMINDERS (as available) more than 90 seconds. Seat belt telltale NOTE light will remain continuously ON when Key in Reminder/audio Warning audio alarm is active. Do not forget to turn OFF your park If you forget the key inside the vehicle lamp as it may drain the vehicle’s bat- NOTE when you leave the ignition in ‘OFF’...
  • Page 100 DASHBOARD AND FEATURES contact service center. user to contact service center. TT and user. buzzer will be in sync continuously till the TT and buzzer will be in sync continuously Gear Indication state remains TRUE. till the state remains TRUE. If gear changes, buzzer shall sound for Gear Shift Denied Chime High Temperature Alert for Motor...

  • Page 101: Combi Switch (Rh Stalk) (If Available)

    DASHBOARD AND FEATURES COMBI SWITCH (RH STALK) (if High Beam Lane Change Signal available) Move the lever forward to select the high To change a lane, move the lever slightly beam function. up or down to the point where the turn sig- nal light begins to flash for six times, but Pull the lever back to normal for low beam.

  • Page 102: Combi Switch (Lh Stalk) (If Available)

    DASHBOARD AND FEATURES Head Lamp Levelling Rotary Switch COMBI SWITCH (LH STALK) (if for single wipe. available) Slow Wipe Push the stalk towards position (2) for con- tinuous slow wipe. Fast Wipe Push the stalk towards position (3) for con- tinuous fast wipe.
  • Page 103 DASHBOARD AND FEATURES Rear Wipe NOTE NOTE Turn the rotary knob counter When you crank the vehicle, the supply When you reverse the car with front clockwise such that it aligns to washer motor is momentarily cut off. wipers in ‘ON’ condition, the rear wiper its positions with arrow mark will also be ‘ON’...

  • Page 104: Dashboard Controls

    DASHBOARD AND FEATURES DASHBOARD CONTROLS Option 2 Option 3 Option 1 Centre door lock-unlock Charger gun lock unlock Charger gun lock unlock Tail Gate Opening Tail gate opening Centre door lock-unlock To unlatch the tail gate, press the switch located on Charger gun lock unlock fascia switch.

  • Page 105: Steering Mounted Controls (Lhs) (If Available)

    DASHBOARD AND FEATURES Charger Gun Lock Unlock STEERING MOUNTED CONTROLS (LHS) (if available) Charging socket inlet is lo- cated at Rear LH side of ve- hicle in fuel flop. It is mandatory that the charging gun should be locked with CCS 2 inlet during the charging process.

  • Page 106: Mic (If Available)

    DASHBOARD AND FEATURES Volume droid Auto, Apple CarPlay is connected. MIC (if available) Press above switch to in- NOTE crease or decrease vol- The system will start recognizing your ume of music system / radio. voice command only after the beep. So, Mute / Phone Reject speak your command only after you hear the voice activation beep.

  • Page 107: Infotainment System Display (If Available)

    DASHBOARD AND FEATURES INFOTAINMENT SYSTEM DISPLAY Option 2 Force/master Reset System (if available) Option 1 If your infotainment system touch screen NOTE becomes unresponsive or shows some • For more information, refer infotain- unusual behavior, then you can restart it to ment manual.

  • Page 108: Usb Port (If Available)

    DASHBOARD AND FEATURES The step above will trigger the infotain- USB PORT (if available) POWER SOCKET ment system restart procedure. Wait until the system restarts. When you hold the Steering wheel Mute button for more than 15 sec, system aborts restart process and dis- play turns ON.

  • Page 109: Antenna

    DASHBOARD AND FEATURES ANTENNA Option II Option I Power Socket Rear (if available) The power socket will work when the igni- Antenna is located on the roof. Turn the tion switch is in the “ACC” or “ON” position. antenna anticlockwise to remove it from This socket can be used to provide 12V Shark FIN antenna is provided on the roof the vehicle, if required.

  • Page 110: Roof Grab Handle

    DASHBOARD AND FEATURES ROOF GRAB HANDLE TAG HOLDER ROOF LAMP Interior roof lighting lamp is provided on the roof within built switch. Grab handles are installed on the roof for Tag holder is provided near the front wind- all seats except for the driver’s seat. These shield for ease of displaying toll, parking help the passengers to position them- tickets, ID’s, passes, labels etc.

  • Page 111: High Mounted Stop Lamp

    DASHBOARD AND FEATURES the last door is closed, the lamp will turn HIGH MOUNTED STOP LAMP HEAD LAMP ‘OFF’ with dimming. This helps settling in the seat and inserting the key in the ignition switch. When the key is turned to the ‘IGN’ position, the lamp goes ‘OFF’...

  • Page 112: Tail Lamp

    & records the data from various vehicle The Data collected through Connected systems like Traction Motor, Battery & Car module is used by Tata Motors other electrical systems. This data is then Limited for various pur processed & used for providing the con- but not limited to, nected Car features (For details &...
  • Page 113 After obtaining a written consent from the Car Owner. • Upon request from Law enforcing agencies and regulatory bodies. • Used for research purpose without the Personal Verifiable information (anonymized). • Used as defence of Tata Motors in a Law-suit.

  • Page 115: Stowage Areas

    STOWAGE AREAS STORAGE COMPARTMENT &hTab Glove box Center console Utility pockets on front door Stowage for rear passenger Utility pockets on rear door Foldable arm rest Driver side pocket Tailgate compartment...
  • Page 116 STOWAGE AREAS Glove Box Cooling Facility (if available) Stowage Details (if available) On selected models glove box is provided Opening and Closing Following items can be stowage in glove with a cooling facility. It cools the glove box box. To open - Press the knob and open the only when the front A/C is ON.
  • Page 117 STOWAGE AREAS Driver Side Coin Box Utility Pockets on Front Doors Utility Pockets on Rear Doors Stowage is provided on RH side of steer- Utility pockets are provided on front doors Utility pockets are available on rear doors ing wheel for Coin, mobile and wallet. and it can be used to keep following items.
  • Page 118 STOWAGE AREAS Center Console Foldable Arm Rest Stowage for Rear Passenger (if avail- able) Stowage compartment A foldable arm rest has been provided in the rear seat. It also has two cup holders, Stowage for the rear passenger is avail- Stowage compartment provided for keep- which can be accessed by opening the able on rear side of floor console between...

  • Page 119: Card Holder (If Available)

    STOWAGE AREAS CARD HOLDER (if available) Tail Gate Compartment • Position heavy loads towards rear seat and low down in the trunk as possible. Store the luggage in tailgate compartment. A pocket is provided on the back of the driver side sun visor to keep cards, pa- WARNING pers, etc.

  • Page 120: Hooks (If Available)

    STOWAGE AREAS HOOKS (if available) Collapsible Hook Collapsible hook is provided for hanging small carry bags etc. NOTE Do not use these hooks for securing luggage like using nets etc. in the boot.

  • Page 121: Climate Control

    CLIMATE CONTROL AIR DISTRIBUTION The HVAC is operational when car is running and blower is ‘ON’. The Climate control regulates the temperature in the car interior and filters dust particles. You can manually set the desired temperature. The air is distributed through the vents in the passenger compartment as shown below: NOTE If your car battery is discharge below 10%, your vehicle AC &...

  • Page 122: Air Vents

    CLIMATE CONTROL AIR VENTS NOTE tain optimum performance. Air vents are available on the dashboard. • To get faster heating, it is recom- The AC can be switched ‘ON’ only if the The direction of air flow can be adjusted mended to set 4- 5°C higher set blower is ‘ON’...

  • Page 123: Fully Automatic Temperature Control (Fatc)

    CLIMATE CONTROL FULLY AUTOMATIC TEMPERA- Fresh Air / Recirculation button managing the climate control. TURE CONTROL (FATC) Air Distribution (mode) button Also, when the display is not in climate mode then climate information will be dis- General Description OFF button played on the all-time display provide on Auto ON selection button FATC system controls the in-cabin temper-...
  • Page 124 CLIMATE CONTROL ECON FATC Controls NOTE AC ON / OFF Button For your safety make sure you have a clear view through all the windows be- fore driving. Rear Window Demister Button During ECON AC operation, the system This button turns the rear automatically cuts off compressor at a window demister ON or OFF.
  • Page 125 CLIMATE CONTROL Directs air through the cen- Auto ON Selection Button screen. Keep this area clear from ter, side and foot well vents leaves and other debris. Directs air through the foot The system should be used with recircula- air vents tion air mode for faster heat up and cool Directs air through the de- down, however keeping the system in re-...
  • Page 126 CLIMATE CONTROL clockwise increases the temperature of NOTE the air. The desired temperature will be in- In ‘AUTO’ mode, the FATC system will creased by steps of 0.5ºC. User can select regulate the blower speed automati- temperature range from 18ºC to 30ºC. cally.
  • Page 127 CLIMATE CONTROL When the interior has cooled down to NOTE CAUTION a comfortable level, close the win dows To control the battery temperature of and set the required temperature, with • It is important that the correct type the high voltage battery the air condi- recirculation ON.
  • Page 128 CLIMATE CONTROL Functions and Settings Control Knob Position Button Position Functions Normal Desired Desired Temp Heating Speed Quick To the extreme Max. speed Heating right Normal Desired speed Desired Temp Optional Cooling Quick Cool- To the extreme Max speed Optional left Demisting To the right up...
  • Page 129 CLIMATE CONTROL CAUTION It is important that the correct type and amount of oil and refrigerant used, otherwise damage to the vehicle and injury may occur. To prevent damage, the air conditioning system in your vehicle should only be serviced by trained and certified technician. We rec- ommend that you contact authorized TATA EV dealer for more details.

  • Page 131: Starting And Driving

    To lighten your load by removing any • All the mirrors properly adjusted. carpet near pedal region. unnecessary cargo. Weekly Check • TATA Motors does not recommend • Windows are fully raised. use of any floor mats below driver • Coolant level •...

  • Page 132: Tips To Get Maximum Range While Driving

    STARTING AND DRIVING TIPS TO GET MAXIMUM RANGE • Gradually press and release the accel- • Do not mount parts on the exterior of erator pedal when accelerating or de- the car as it might increase drag. WHILE DRIVING celerating. •...
  • Page 133 STARTING AND DRIVING • The electric motor when decelerating • Less deceleration is provided by the and braking transforms kinetic energy regenerative brake system when the to electrical energy in order to charge High voltage battery is fully charged. the high voltage battery. (Torque is ap- Regenerative brake is automatically plied in the opposite direction when de- reduced when the high voltage battery...

  • Page 134: Limp Home Condition Of Ev

    Home Intervention along with the IPC HV Critical Fault message. Blinking Contact TATA MOTORS EV Sports mode cannot be selected if the Service Station. vehicle SoC is below 25% or the vehicle is in limp home mode. If the vehicle is...
  • Page 135 STARTING AND DRIVING Limp Home Strategy Level 0 Intervention Zone IPC message and state Max speed Acceleration Gradability Cabin cooling If the vehicle is in Sport mode, it will automatically shift to Drive SoC <=25% No change No change No change mode which will be shown on clus- Then SoC Gauge 1 Bar ON with...
  • Page 136 STARTING AND DRIVING Tyre Equipment Driving on Snow or Ice while on the ice, and avoid any sud- Summer tires have a tread designed to den steering maneuvers. WARNING provide superior performance on dry pave- • Do not use cruise control on slippery ment.

  • Page 137: Before You Start Ev

    STARTING AND DRIVING Carry Emergency Equipment BEFORE YOU START EV Check Battery and Cables Depending on the severity of the weather, • Make sure that the area around the ve- Winter puts additional burden on the bat- you should carry appropriate emergency hicle is clear.
  • Page 138 STARTING AND DRIVING Procedure to Start EV Procedure to Stop EV With the smart key sit in the driver’s Hold down the brake pedal while the seat/Engage the key in the lock set. vehicle is parked. Fasten the seat belt before you start While pressing the brake pedal, shift the vehicle.
  • Page 139 STARTING AND DRIVING ter, computed basis a predictive model Tips to Maximize Range gaging the park brake. that analyzes the current and historical Regenerative Braking drive segments of the vehicle. The model When the ‘Ready’ message is ON and if attaches suitable weightages to the en- Regenerative braking the gear knob is in a position other than N...
  • Page 140 STARTING AND DRIVING recommended to set the air conditioning in Driving Style Tyre Pressure Auto mode with Econ activated. Also the Driving behavior has Maintaining specified set temperature should be set between a significant influence Tyre pressure only 24-26 deg C. Tigor EV is equipped with on the driving range ensures comfortable Remote Air conditioning.
  • Page 141 STARTING AND DRIVING Vehicle Maintenance Dead Weight Different Modes in EV Vehicle to be serv- There are three different modes that tell Dead weight like iced regularly as per you the vehicle’s energy consumption rate bags, boxes etc. service schedule in along with the charge / discharge status of which is not required authorized...

  • Page 142: Cold Weather Driving

    STARTING AND DRIVING COLD WEATHER DRIVING anti-icing agent through the key hole. DRIVING TIPS Some examples of anti-icing agents are The battery life, vehicle range, brakes and CAUTION sodium chloride, potassium chloride, glyc- tyre wear are mainly affected by below fac- erol, and urea.

  • Page 143: Important Tips

    (>15 days). After this time period the ten the seat belt while driving. There is repaired at only Tata Motors authorized vehicle must be charged to 100% a risk of an accident. EV workshop.
  • Page 144 LEDs start blinking on the Charging tage of an EV. The calibration on the should be minimized in order to help gun, please contact TATA MOTORS regen is done in such a way that most prolong high voltage battery life.

  • Page 145: Seat Adjustments

    STARTING AND DRIVING peratures to a comfortable 24°C, and SEAT ADJUSTMENTS WARNING see the comfort as well as the range Front Seat Adjustments go up significantly. Do not adjust the driver’s seat while Following seat adjustments can be carried driving. Adjusting the seat while driving Travel Light –...
  • Page 146 STARTING AND DRIVING Adjustable Head Restraint in a collision. equipped) Seat Height Adjustment (if equipped) To raise the seat, pull and continue pump- ing the lever (2) in the upward direction until the seat is at the desired height. To lower the seat, pump the lever down- ward until the seat is at desired height.

  • Page 147: Rear View Mirrors

    STARTING AND DRIVING REAR VIEW MIRRORS Occupant Detection System (ODS) NOTE Inside Rear View Mirror (IRVM) Use of aftermarket cover over the seats Objects visible in mirror are actually may impact the performance of ODS in To adjust the mirror move the mirror up, closer than they appear.

  • Page 148: Orvm Folding (As Applicable)

    STARTING AND DRIVING To Adjust the Mirrors ORVM FOLDING (as applicable) ing/Un-folding will stop functioning and will be re-activated after delay of 2 min. During Move the selector switch to the left (L) Option 1: Manual Folding that period avoid repeated pressing of or right (R) to select the mirror you ORVMs can be folded or unfolded manu- Switch.

  • Page 149: Sun Visors

    STARTING AND DRIVING Option 4: Rear View Mirror with Joy- SUN VISORS STEERING WHEEL ADJUSTMENT stick Knob The sun visors can be pulled down to You can adjust the steering wheel position You can adjust the outer rear view mirror block glare coming through the windshield.
  • Page 150 STARTING AND DRIVING Pull release lever up completely to lock tance and slow down gradually. the brakes are less effective than normal, the steering column. dry them by repeatedly applying the WARNING brakes while driving slowly until the brakes Make sure that steering wheel is cor- have regained their normal effectiveness.

  • Page 151: Steering Lock Cum Ignition Switch

    STARTING AND DRIVING STEERING LOCK CUM IGNITION ACC - Accessories such as the infotain- ELECTRICAL POWER ASSISTED ment system can be operated, but the ve- SWITCH STEERING (EPAS) hicle remains ‘OFF’. Steering gets Your vehicle is equipped with electric unlocked. power assisted steering system.

  • Page 152: Gear Modes

    STARTING AND DRIVING GEAR MODES tion key turned ‘ON’ or motor NOTE start/stop button pressed. If this The following symptoms may occur dur- happens, turn the steering wheel to ing normal vehicle operation: the right or left slightly to unlock the •...

  • Page 153: Starting And Driving (Peps)

    LED blinks Reverse gear can be engaged only when more than 10 seconds, then contact vehicle is stationary and brake pedal authorized TATA MOTORS EV pressed. An audio signal indicates when dealer. reverse gear is engaged. ‘R’ will be indi- •...
  • Page 154 STARTING AND DRIVING Immobilizer antenna (in center console). • Customer presses driver door handle switch along with valid Smart key within authentication range approx. 1.2 Tailgate handle NOTE Emergency Start Press the tail gate button on smart key NOTE and press the tail gate door handle UID (Smart Key) switch within 30 seconds to open it.
  • Page 155 STARTING AND DRIVING switch along with valid Smart key Parking Brake Mechanical parking brake acting only on within authentication range of 1.2m. the rear wheels is provided on the vehicle. To apply the parking brake, pull the lever • Vehicle gets locked. up fully.
  • Page 156 STARTING AND DRIVING NOTE While parking on uphill or downhill gra- dients, place the gear lever in the ‘N’ po- sition and engage parking brake. WARNING Never leave children unsupervised in the parked vehicle. They could also op- erate the vehicle’s equipment. There is a risk of an accident and injury.

  • Page 157: Reverse Park Assist With Sensor (If Equipped)

    After these two seconds, normal functioning of the sys- tem will continue. If no audio buzzer is heard for first two seconds, it mean that RPAS system is faulty. Please take the vehicle to a TATA MOTORS Authorized EV Service Cen- tre.
  • Page 158 STARTING AND DRIVING Park Assist Indications vehicle. Reverse Park Assist Limitations • If height of the bumper is changed due If Reverse park assist system malfunc- Reverse Park Assist system is not a colli- to alteration to the suspension or other tions, the following fault messages will ap- sion avoiding system.
  • Page 159 STARTING AND DRIVING causes wrong visual information on Reverse Park Assist System Preven- WARNING display. In case of dam-age make sure tive Maintenance Due to any reason, if the sensor gets that Reverse Park Assist sensors are Regularly clean the Sensors/camera* misaligned or loses its intended fitment fitted properly at the intended location.

  • Page 160: Rear View Camera

    STARTING AND DRIVING REAR VIEW CAMERA Activation Reverse Mode This system will activate, if reverse gear is engaged, or reverse park assist button (if equipped) is pressed. Display screen Rear View Camera is a visual reverse guiding system. When reversing or park- ing, make sure that there are no persons, animals or objects in the area which you are reversing.
  • Page 161 STARTING AND DRIVING mation may not be the actual rear view Understanding Guidelines Indication Cleaning Camera of the vehicle & system will warn with Due to environmental reasons, dust, message ‘Tail Gate Open, Please mud or fog may accumulate on the close’.
  • Page 162 STARTING AND DRIVING WARNING camera’s field of view. The area dis- depend on rear view camera park played on the screen may vary ac- aid. • The camera uses fish eye lens. So cording to vehicle orientation or the size of the objects or in the dis- •...
  • Page 163 STARTING AND DRIVING When the ground behind the vehicle Rear View Camera System Precau- slopes up sharply tions Area displayed on screen The rear view camera system displays an image of the view from the bumper of the rear area of the vehicle. •...
  • Page 164 STARTING AND DRIVING tance. When any part of the vehicle sags Because of this, objects will appear to be farther away than they actually are. In the same way, there will be a margin of error between the guidelines and the ac- tual distance/course on the road.
  • Page 165 STARTING AND DRIVING When approaching three dimensional b. Vehicle width guidelines objects The distance guidelines are displayed ac- cording to flat surfaced objects (such as the road). It is not possible to determine the position of three-dimensional objects (such as vehicles) using the distance guidelines.
  • Page 166 STARTING AND DRIVING below, the truck appears to be outside of the vehicle width guidelines and the vehi- cle does not look as if it hits the truck. However, the rear body of the truck may actually cross over the vehicle width guidelines.

  • Page 167: Emergency And Breakdown Assistance

    EMERGENCY AND BREAKDOWN ASSISTANCE EMERGENCY EQUIPMENT Tool Kit, Tow Hook, Jack and Spare Jack Wheel You should be familiar with the location of the emergency equipment provided in the vehicle and how to use it. Do a check of this equipment periodically and make sure that they are in proper working condition and stowed at their lo- cations.
  • Page 168 EMERGENCY AND BREAKDOWN ASSISTANCE Advance Warning Triangle NOTE An advance warning triangle is kept in the After using the warning triangle tie it luggage compartment. firmly and keep it inside the bag to avoid rattling noise. your vehicle could become a potential traf- fic hazard.

  • Page 169: Spare Wheel Removal Process

    EMERGENCY AND BREAKDOWN ASSISTANCE SPARE WHEEL REMOVAL Hazard Warning Switch PROCESS • To access the spare wheel, open the tail gate and remove the cover pro- vided on the spare wheel. Press the hazard warning switch to acti- vate the hazard warning. All the turn signal lamps will flash simultaneously.

  • Page 170: In Case Of Flat Tyre

    EMERGENCY AND BREAKDOWN ASSISTANCE IN CASE OF FLAT TYRE Changing Flat Tyre WARNING • Reduce vehicle speed gradually, Avoid Loosen the nuts (as indicated) on the If you drive with a flat tyre, there is a risk sudden steering movement or braking. wheel in diagonal sequence.
  • Page 171 EMERGENCY AND BREAKDOWN ASSISTANCE jack sits completely on the specified point • Use the jack on level, hard ground. and the base of the jack lies evenly on the Avoid changing the wheel on uphill ground. and downhill slopes. Chock the wheels, if the deflated wheel needs to be changed on slope / ghat area.
  • Page 172 EMERGENCY AND BREAKDOWN ASSISTANCE wheel nuts one by one using wheel span- WARNING ner. If you do not position the jack correctly Press fit the wheel cover back (if fitted). at the appropriate jacking point of the Restore all the tools and jack at their re- vehicle, the jack could tip over with the spective locations.

  • Page 173: Towing

    (for-ward or help of a TATA MOTORS Authorized EV backward), as this may cause seri- Service Centre or a commercial tow-truck ous damage to the E-Drive.
  • Page 174 • Open the tailgate and remove tow • Do not get under your vehicle after contact the nearest Tata Motors authorised hook from the tool kit. it has been lifted by a tow truck. EV dealer or EV service centre.

  • Page 175: Fuses

    Make sure that all other fuses are Cabin compartment LV fuse box pressed firmly in position. • If a newly installed fuse also blows, have the cause traced and rectified at • Remove the blown fuse by “fuse nearest TATA MOTORS Authorized EV...
  • Page 176 EMERGENCY AND BREAKDOWN ASSISTANCE Service Centre immediately. Battery Mounted LV Fuse Box WARNING WARNING If you manipulate or bridge a faulty fuse or if you replace it with a fuse with If you manipulate or bridge a defective higher amperage, the electric cables fuse or if you replace it with a fuse with could be overloaded.
  • Page 177 Components. fuse box. the cause traced and rectified at nearest • The 10A fuse labelled in yellow color TATA MOTORS Authorized EV Service as shown in image. Centre immediately. Accident disconnect fuse In case of an accident, to disconnect the...
  • Page 178 EMERGENCY AND BREAKDOWN ASSISTANCE NOTE The fuse box layout is for reference pur- pose only. Please refer the sticker pro- vided inside the fuse box cover. WARNING If Fuse box cover is removed for any reason, it should be refitted properly at its original position.
  • Page 179 EMERGENCY AND BREAKDOWN ASSISTANCE Under The Bonnet Fuse Box...
  • Page 180 EMERGENCY AND BREAKDOWN ASSISTANCE Under Bonnet Fuse Box – Layout and details...
  • Page 181 EMERGENCY AND BREAKDOWN ASSISTANCE Fuse No. Value Type Description SLOW BLOW INTERIOR F/B 1 IGNITION SLOW BLOW SLOW BLOW VACUUM PUMP SLOW BLOW COOLING FAN SLOW BLOW EV POWERTRAIN SLOW BLOW SPARE SLOW BLOW INTERIOR F/B 2 BATTERY SLOW BLOW SPARE SLOW BLOW SPARE...
  • Page 182 EMERGENCY AND BREAKDOWN ASSISTANCE Fuse No. Value Type Description EF22 FAST BLOW HV BATT. COOLANT PUMP EF23 FAST BLOW CHILLAR SOLENIOD EF24 FAST BLOW E-DRIVE/HV BATT. RELAY COILS EF25 FAST BLOW E DRIVE BATT EF26 FAST BLOW EF27 FAST BLOW HV OBD BATT.
  • Page 183 EMERGENCY AND BREAKDOWN ASSISTANCE Under Bonnet Relay Details Fuse Value Type Description Fuse Value Type Description HEAD LAMP HIGH BEAM VACUUM PUMP RELAY MICRO NO HORN MICRO MINI IGNITION HV BATT KP ALIVE MICRO NO RELAY MICRO NO - NC FRONT WIPER SPEED MINI NO VECU - MAIN RELAY REVERSE LAMP...
  • Page 184 EMERGENCY AND BREAKDOWN ASSISTANCE Under Bonnet Low Voltage Service Dis- per below image. • After successfully completion of serv- connect ice, press the secondary lock inside and safety lock to its original position. WARNING • During any kind of servicing of the Without touching any other high voltage vehicle, the Technician/Service op- components, Disengage the Low voltage...
  • Page 185 EMERGENCY AND BREAKDOWN ASSISTANCE Re-fitment Procedure Cabin Compartment LV Fuse Box Align and engage the top and bottom Cabin Removal Procedure mounting lugs with respective slots on Fuse box is located in the cover below dash board and press the cover firmly. steering column.
  • Page 186 EMERGENCY AND BREAKDOWN ASSISTANCE Fuses - Cabin Compartment Fuse Box Details Fuse Fuse Type Description Rating Fuse Fuse Type Description Rating FAST BLOW CDL FAST BLOW PDC/TELEMATICS IGN RESTRAINT CONTROL FAST BLOW MODULE KEY IN(XE+ & XM) / PEPS 5A/10A FAST BLOW (XZ+) FAST BLOW ACC CONN.
  • Page 187 EMERGENCY AND BREAKDOWN ASSISTANCE Cabin Compartment Fuse Box Relay Details Relay Rating Relay Type Description Relay Rating Relay Type Description MICRO MICRO MINI NO ACC, RELAY MINI NO BLOWER RELAY MINI BUZZER BUZZER MICRO HEATED REAR WINDOW MICRO NO (XZ+) MICRO NO- CDL LOCK MICRO (XM &...

  • Page 188: 24 X 7 Road Assistance

    120 minutes +/- other places the probability of a breakdown happening within hailing distance of a TATA MOTORS ** (The response time will depend on the Authorized EV Workshop is very low. location, terrain, traffic density and the...
  • Page 189 EMERGENCY AND BREAKDOWN ASSISTANCE and available in select cities policy, post warranty is upto maximum Exclusions presently Delhi, Mumbai, Ben- instance of assistance in one year 24 X 7 On Road Assistance Program galuru, Pune and Hyderabad. If the for both the plans- Basic and Premium. does not apply to service is expanded to other cities, In the premium plan, this includes 2 in-...
  • Page 190 • In case vehicle cannot be repaired on- TATA MOTORS shall not be liable for calamities, road blocks due to acci- site, customers are advised to use the any damages / claims as a result of the dents, general strife and law &...
  • Page 191 If the ‘Ready’ vehicle will not start, contact an author- message does not come in the instru- ized Tata Motors EV dealer or seek ment cluster, do not try to switch ON other qualified assistance. the supply by pressing the Start/Stop button.
  • Page 192 • Inform the Tata Motors On-Road- gency services immediately. Never is involved. Assistance immediately. touch the fluid leaked inside or out- side the vehicle.
  • Page 193 Even if the gear knob is in Drive mode, the system may shutoff sud- denly. In this case, contact the nearest Tata Motors authorized EV dealer to rectify the issue.

  • Page 195: Maintenance And Services

    Periodic maintenance is essential for en- Refer “Opening and Closing” section for suring long trouble free performance. front bonnet opening. Have your vehicle serviced regularly from TATA MOTORS Authorized EV Service WARNING Centre. • Keep all open flames and other...

  • Page 196: Monthly And Yearly Checks

    • Do a check of the air conditioning sys- TATA MOTORS authorized EV Service At least twice a year tem. Centre to replace any electrical compo- • Examine the heater and air condition- •...

  • Page 197: Radiator Maintenance

    MAINTENANCE AND SERVICES RADIATOR MAINTENANCE tremely important to your radiator parts • In case of dust/mud/snow accumula- maintenance and to keep it good and tion in charging port, it can be cleaned Maintaining radiator and fan motor shroud running. by blowing air into the charging port. (FMS) is important for keeping your EV in Never use any water or liquid for clean- •...

  • Page 198: Motor Compartment

    MAINTENANCE AND SERVICES MOTOR COMPARTMENT High voltage components Coolant tank Low voltage battery Motor compartment fuse box Brake fluid reservoir Windshield Washer reservoir...
  • Page 199 MAINTENANCE AND SERVICES Brake Fluid Level Windshield Washer Fluid Level • Do not operate washer motor with no fluid in washer tank, washer motor will be damaged Auxiliary Battery (12V) The level of the brake fluid should be be- tween the ‘MIN’ and ‘MAX’ marks on the Measure the washer fluid in the tank.
  • Page 200 • Use only ATF recommended by • Always disconnect the negative (-ve) smoking materials away from the TATA MOTORS. Do not mix with cable first and reconnect it last. battery. other fluids. • Clean the battery terminals with a ter- •...

  • Page 201: Tyres

    MAINTENANCE AND SERVICES TYRES High-pressure Washing Inflation High pressure washing is not allowed in Do a check for inflation and condition of the motor bay and on the battery connec- your vehicle tyres periodically. tors. Examine the pressure in the tyres when •...
  • Page 202 MAINTENANCE AND SERVICES sure. Over-inflation, in particular, may Recommended Tyre Pressures • Do a check of the tyre pressures in cause puncture or bursting of tyre. the regular and spare tyres for one Tyre Wheel Tyre Pressure time in a month. Size NOTE Front...
  • Page 203 MAINTENANCE AND SERVICES Tyre Rotation Wheel Balancing Wheel Covers (if available) To help increase tyre life and distribute Wheels of your vehicle are balanced for For Regular Steel Rim wear more evenly you should have tyres better ride comfort and longer tyre life. Bal- rotated at specified intervals or earlier de- ancing needs to be done whenever tyre is pending on the operation of vehicle.
  • Page 204 MAINTENANCE AND SERVICES Insert the tool as shown in above Removal Precautions NOTE image. Insert the tool on mark shown in below Do not use any sharp tools (such as Make a gap around the cover by tool & image. screw driver etc.) to remove the wheel then removed by hand.

  • Page 205: Smart Key Battery Replacement (For Peps Variant)

    It is recommended to replace bat- tery at a TATA MOTORS Authorized EV Service Centre. You should, however, proceed as follows if you wish to replace the discharged bat- tery yourself: Open the key blade.
  • Page 206 MAINTENANCE AND SERVICES Ensure that the “+” symbol on the bat- tery is facing upwards. The correct po- larity is shown on the battery cover. Position the battery cover on the key and press on it until it is heard to lock in place.

  • Page 207: Service Instructions

    MAINTENANCE AND SERVICES SERVICE INSTRUCTIONS Servicing of the vehicle can be done at any TATA MOTORS Au- thorised EV Dealer Workshop or TATA MOTORS Authorised EV The TATA TIGOR EV has been manufactured to give you eco- Service Centre (TASC).

  • Page 208: Service Schedule

    MAINTENANCE AND SERVICES SERVICE SCHEDULE Kms → Operation Months → Frequency In ‘000 Kms / Months Wash the vehicle & Clean Ra- Every ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●...
  • Page 209 MAINTENANCE AND SERVICES Kms → Operation Months → Frequency In ‘000 Kms / Months Change coolant (Battery cool- ing system (BCS) and Trac- ● ● 60K/36M tion cooling system (TCS)) Check and Capture all DTC’s Every Clear all faults and Erase the ●...
  • Page 210 MAINTENANCE AND SERVICES Kms → Operation Months → Frequency In ‘000 Kms / Months For severe usage, above checks to be done at every 5,000 km or after every se- vere usage event. Check All door latch & striker operations , Adjust and apply 15K/12M ●...
  • Page 211 MAINTENANCE AND SERVICES Kms → Operation Months → Frequency In ‘000 Kms / Months BRAKES Check front brake pads & rear 15K / brake linings. Replace if nec- ● ● ● ● ● ● ● ● ● ● essary Replace brake fluid , Check # 45K / brake system components for ●...
  • Page 212 MAINTENANCE AND SERVICES Kms → Operation Months → Frequency In ‘000 Kms / Months TRANSAXLE Oil change interval (First at ● ● ● ● ● ● 7.5K / 6M) 30K/24M ELECTRICAL Check specific gravity of bat- 7.5K / tery electrolyte for 12V Aux. ●...

  • Page 213: Vehicle Parking For Long Duration

    MAINTENANCE AND SERVICES VEHICLE PARKING FOR LONG DU- Inflate the tyres to 0.5 bar above the normal specified pressure and check it RATION at regular intervals. If the vehIcle need to be park for long du- Check the HV battery charge every six ration, following care to be taken: weeks.

  • Page 215: Technical Information

    Company Brand Quantity Sunstar CCI Battery cooling system - Coolant Class II/JIS K2234 (Pre-mixed) (Antifreeze agent + Anchemco TATA MOTORS original coolants 6 Litres TATA SS7700S1 Soft water 40:60 ratio) Castrol Sunstar CCI Traction cooling system - Class II/JIS K2234...

  • Page 216: Technical Specifications

    TECHNICAL INFORMATION TECHNICAL SPECIFICATIONS Parameter Motor Type 345 V, Permanent magnet, synchronous motor Installation Transverse Electric power train FWD Max. Power 55 kW Max. Torque 170 Nm Transaxle Model Single speed, Automatic No. of gears 1-Forward, 1-Reverse Steering Type Electrical Power assist Steering, Rack & Pinion Gear, collapsible Steering Column Brakes Brakes Front (Disc);...
  • Page 217 TECHNICAL INFORMATION Parameter 5.5J X 14” Hyper style Steel wheel Cab / body Type Semi-mono volume, 4 doors sedan, steel monocoque body Electrical system HV Battery Lithium-ion 75 Ah (26 kWh) Drivetrain 345V Auxiliary battery 12V, 47Ah Main Chassis dimension (in mm) Wheel base 2450 Track front...
  • Page 218 TECHNICAL INFORMATION Parameter Weight (in kg) 1594 (XM) Gross vehicle weight 1590 (XE+) 1610 (XZ+) 1219 (XM) Kerb weight (Unladen) 1215 (XE+) 1235 (XZ+)

  • Page 219: Vehicle Dimensions

    TECHNICAL INFORMATION VEHICLE DIMENSIONS...

  • Page 220: Aggregate Identification Numbers

    TECHNICAL INFORMATION AGGREGATE IDENTIFICATION NUMBERS VIN plate near front passenger seat Chassis number punching near driver seat...

  • Page 221: Car Care

    CAR CARE CAR CARE cleaners like ‘Stain remover’ which are WARNING safe for paint surfaces. Your vehicle is subjected to many external Do not wash the vehicle with high pres- Avoid substances like petrol, diesel, influences such as climate, road condi- sure washer fluid/ water jets (Pressure kerosene, benzene, thinner, acids or tions, industrial pollution and proximity to...
  • Page 222 CAR CARE If the stain has dried, then gently brush Polishing NOTE off the material and then press with Polishes and cleaners can restore shine to Avoid wiping of painted surface in dry damp cloth or sponge till it disappears. the painted surface that has oxidized and condition as it may leave scratches on Do not use household detergents to...

  • Page 223: Fastag

    CAR CARE • It is driven in coastal areas. FASTAG Proper Parking • Do not direct high pressure washer FAST TAG is pasted on front windshield • Always park your vehicle in shade to fluid/water jets (Pressure above 0.5 from the inside. It enables Electronic toll protect it from harsh sunlight or in a bar) at electrical devices and con- collection.

  • Page 224: Extended Warranty

    Extended Warranty Booklet & Cover Note The Extended Warranty booklet and cover note is the basis of the contract between TATA MOTORS LIMITED and the Owner of the vehicle shown on the Extended Warranty booklet. The Customer is to retain this booklet and the same to be pro- duced to the dealer while claiming benefit s under Extended Warranty.
  • Page 225 Mechanical / Electrical break down as defined in this warranty and confirmed by the dealer within the stipulated terms and condi- tions. • TATA MOTORS EV dealer shall either rep air or replace any part found to be defective with a new p art or an equivalent at no cost to the owner for p arts or labour. •...

  • Page 226: Value Added Services

    CAR CARE VALUE ADDED SERVICES Why are Corrosion Protection Waxes necessary? Corrosion is Caused by: Water / salt water acid rain & atmospheric fallouts. Critical Areas are: Cavities: joints, crevices, spot welds, underbody • Corrosion is the most important factor when we talk about the vehicle life.
  • Page 227 CAR CARE TATA MOTORS has tied up with M/s Wurth, M/s Autokrom, M/s 3M India Lt d & M/s Bardahl for these world class treatment at af- fordable prices. These treatments are available in all authorized workshops. The Dealer Service Marketing Executive will explain to you the benefits and terms and conditions of this treatment.

  • Page 228: Vehicle Exterior Enrichment

    Cleaning & dressing of tyres, Bumpers and all exterior plastic moldings/trims. TATA MOTORS has tied up with M/s Autokrom, M/s 3M & M/s Wurth for this world class treatment at affordable prices. This treatment is available in all authorized workshops. The Dealer Service Marketing Executive will explain to you the benefits and...

  • Page 229: Vehicle Interior Enrichment

    Specialized protection for seat fabric from liquid spills. TATA MOTORS has tied up with M/s Wurth and M/s Autokrom for this world class treatment at affordable prices. This treatment is available in all authorized workshops. The Dealer Service Marketing Executive will explain to you the benefits and terms and conditions of this treatment.

  • Page 231: Warranty - Terms And Conditions

    WARRANTY - TERMS AND CONDITIONS WARRANTY – TERMS AND CONDI- Any part which is found to be defective loading in excess of such carrying ca- and is replaced by us under the war- pacity as certified by us, or such serv- TIONS ranty shall be our property.
  • Page 232 WARRANTY - TERMS AND CONDITIONS This warranty shall not apply to any The buyer shall have no other rights sory at any time without incurring any damage or deterioration caused by en- except those set out above and have, obligation to incorporate the same in vironmental pollution or bird droppings.

  • Page 233: Environment Safety

    ENVIRONMENT SAFETY ENVIRONMENTAL SAFETY TATA MOTORS LTD. is committed to produce vehicles using en vironmentally sustainable technology. TATA MOTORS passenger vehicles have been designed to ensure environmental compati- bility throughout the life cycle of the vehicle. We would also like to inform you that your vehicle is a zero emission and environ- mental friendly vehicle.

  • Page 235: Charging Do's And Don'ts

    CHARGING DO’S AND DON’TS CHARGING DO’S AND DON’TS ground and your hands are dry as well • Once charging is complete and gun is while using the high voltage charging removed from the charging port, it is • The charging gun provided for home equipment.
  • Page 236 CHARGING DO’S AND DON’TS...

This manual is also suitable for:

Tigor.ev 2023

Table of Contents

Save PDF
