- Page 1 A Wilson Electronics Brand WILSON PRO 4000R In-Building Multi-Antenna Signal Booster With Extended Dynamic Range User Manual wilsonpro.com 866.294.1660 NEED HELP?
-
Page 2: Table Of Contents
_____ Index Package Content About The WilsonPro 4000R Key Features Competitive Advantages Post Install Setup Status Screen Port/Band Status Screens Enable/Disable Ports Safety Guidelines Warranty... -
Page 3: Package Content
________ Package Content Kit 460231 WilsonPro Wide Band Directional 4 Qty. Dome 4000R Antenna + 75’ Antenna + 4 Qty. 100’ Wilson 400 Cable Wilson 400 Cable 2’ Wilson Lightning Surge Protector WILSON PRO 4000R IN-BUILDING MULTI-ANTENNA SIGNAL BOOSTER... - Page 4 Color LCD For Easier Access Unlike other boosters, the WilsonPro 4000R has a color LCD screen with four-way navigation, allowing integrators to have easy and effective control of the product. WILSON PRO 4000R...
- Page 5 Designed to provide enhanced in-building cellular coverage for commercial and large residential spaces, the WilsonPro 4000R amplifies weak cell signals to provide reliable voice and data coverage – including 4G – to inside spaces where signals may not penetrate.
-
Page 6: Key Features
Extended Dynamic Range (XDR) for continuous connectivity: Gives the 4000R much greater tolerance than any competing booster for a strong incoming signal from the tower. XDR lets the 4000R system work with an incoming signal stronger than any competing booster and never shuts down. -
Page 7: Competitive Advantages
Lower Overload and Shutdown Threshold: No matter how strong the outside signal, the WilsonPro 4000R never shuts down. This is a huge benefit in strong signal environments like cities and locations close to a carrier tower. - Page 8 __________ Installation Diagram Outside Directional Antenna Inside Panel Antenna(s) WILSON PRO 4000R IN-BUILDING MULTI-ANTENNA SIGNAL BOOSTER...
-
Page 9: Post Install Setup
Post Install Setup The WilsonPRO 4000R is designed with advanced internal programming, which allows it to automatically adjust for a variety of conditions, while still boosting weak signals. Once the AC power cable and antenna cables are connected, turn the unit on by toggling the power switch located near the AC power receptacle, located at the rear of the unit. -
Page 10: Status Screen
____________ Status Screen The 4000R takes about 20 seconds to boot up. Once boot up is complete, the status screen will appear, showing the amplification and status of each port and band. System Status Screen Splash Screen Lights Description A solid green light indicates that a band/port is operating correctly with maximum allowable gain. - Page 11 Reposition antennas (more separation between indoor and outdoor antennas, and pointed in opposite directions) and then reboot (power cycle) the 4000R to reactivate the band/port and maximize performance. When adequate separation is achieved, the red light(s) will return to green upon reboot.
-
Page 12: Port/Band Status Screens
D-Pad with Enter button Status Screen Close-up This screen provides specific band and port information. Including the strength of the received uplink and downlink signal, status details, and the amplifier gain. Band Details Screen WILSON PRO 4000R IN-BUILDING MULTI-ANTENNA SIGNAL BOOSTER... - Page 13 ___________ (PORT/BAND STATUS SCREENS - GREEN LIGHT cont.) In the presence of a strong outdoor cell tower signal, the 4000R will reduce it’s “boost” (Gain) using internal Automatic Gain Control (AGC). This gain reduction is necessary to stay within FCC requirements. When this occurs, the 4000R has reached the ‘speed limit’...
-
Page 14: Enable/Disable Ports
Unused indoor antenna ports should be enabled/disabled by pressing enter on the applicable port, from the status screen. D-Pad with Enter button Status Screen Close-up ‘Disabled’ will be displayed on the applicable port, as shown. Status Screen WILSON PRO 4000R IN-BUILDING MULTI-ANTENNA SIGNAL BOOSTER... -
Page 15: Safety Guidelines
To uphold compliance with network protection standards, all active cellular devices must maintain at least 6 feet of separation distance from Panel and Dome antennas. Use only the power supply provided in this package. Use of a non-Wilson Electronics product may damage your equipment. - Page 16 _________________ Antenna Kit Options The following accessories are certified by the FCC to be used with the Wilson PRO 4000R. Kit 314411-5825 Inside Antenna Expansion Kit Kit 301111-11140 50 Ohm Wide Band Directional Yagi Directional Antenna Kit 309900-50N40090 25’ RG58 Cable 140’...
-
Page 17: Specifications
This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. WILSON PRO 4000R IN-BUILDING MULTI-ANTENNA SIGNAL BOOSTER... - Page 18 ____________ Notes WILSON PRO 4000R IN-BUILDING MULTI-ANTENNA SIGNAL BOOSTER...
-
Page 19: Warranty
However, no responsibility is assumed by WilsonPro for any business or personal losses arising from its use, or for any infringements of patents or other rights of third parties that may result from its use. support.wilsonpro.com 866.294.1660 NEED HELP? WILSON PRO 4000R IN-BUILDING MULTI-ANTENNA SIGNAL BOOSTER... - Page 20 A Wilson Electronics Brand 3301 East Deseret Drive, St. George, UT www.wilsonpro.com | support.wilsonpro.com Copyright © 2016 Wilson Electronics. All rights reserved. Wilson Electronics products covered by U.S. patent(s) and pending application(s) For patents go to: weboost.com/us/patents NOT AFFILIATED WITH WILSON ANTENNA 111857_Rev02_09.28.16...
