Note: Not suitable for use with
Discharge lighting.
• Certain washing machines require the power to
be permanently connected so they cannot be
controlled by the TS800N. This is also true of
tumble dryers with push button start.
Diagram A
3
Time
indicator
Self-
cancelling
override
switch
24hr programme ring
(inner holes = ON
outer holes = OFF)
Setting
pins
Protective
lobes
Tough flame
retardant casing
