4. Operation

• Decide what times you would like the time switch
to switch ON and OFF.
• Insert a pin in the Inner Circle for an ON period.
• Insert a pin in the Outer Circle for an OFF period.
Important: The pins should be pushed fully
home or they will catch on the underside of
the protective lobes on the bottom of the
front socket face (See diagram "A").
4
• The minimum switching interval is 30 minutes,
and this can be increased in 15 minute steps.
• Set the correct time of day by rotating the dial
clockwise, until the correct time is indicated by
the Time indicator located on the left centre of
the time switch (See diagram "A").
• Plug the time controller into a socket and switch
socket ON if necessary.
• Plug your appliance into the time controller
and switch the appliance ON.
