- Page 1 Yealink Network Technology CO., LTD Yealink VC120 Video Conferencing System Quick Start Guide Applies to firmware version 40.21.0.15 or later V21.15...
-
Page 3: Table Of Contents
Table of Contents Packaging Contents VC120 Connections Remote Control and Cable Ties Installation Bracket and Camera Installation Main Screen Network Deployment Troubleshooting... -
Page 4: Packaging Contents
Microphone Array Package Please use the Yealink-customized DVI cable We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in reduced performance. VC120 video conferencing system can work with the video conferencing phone or video conferencing microphone... -
Page 5: Vc120 Connections
VC120 Connections The video conferencing phone is used to be the audio input/output device: Display HDMI to VGA Cable HDMI Cable 2m Ethernet Cable Power Adapter 7.5m Ethernet Cable DVI Cable Camera CPE80 CPE80 Video Conferencing Phone... - Page 6 VCM30 Camera Please connect to the Display1 port if you only have one display device The system should be used with Yealink original power adapter (19V/3.42A) only. The use of the third-party power adaptermay cause the damage to the system...
-
Page 7: Remote Control And Cable Ties Installation
Remote Control and Cable Ties Installation Install batteries Fasten the cables with the cable tie... -
Page 8: Bracket And Camera Installation
Bracket and Camera Installation Hanging Mode Please chose the following installation mode when the thickness of the TV is between 35-120mm Steps: Lock the camera to the L-bracket. Remove the protection of the Velcro. Put the L-bracket on the top of the TV. Make sure the back of the TV is clean, and then adjust the bracket to ensure close adhesion to the back of the TV with Velcro. - Page 9 Wall Mount Method Screw specification: M3 8 100mm Hole depth: 30mm Screw specification: T4 30 Hole diameter: 6mm Steps： Punch holes & Insert expansion bolts Drive screws Adjust the screws position and manually lock them Insert screws to lock the bracket to the wall Connect DVI cable Lock the camera The recommended height for camera positioning is 1.5m-1.8m above the ground...
-
Page 10: Main Screen
Main Screen System IP address and Time and date Site name Status icon account information... -
Page 11: Network Deployment
Network Deployment To ensure that the VC120 works correctly, please configure it according to the conference role that it plays. If it is in the head office, please make sure that it can be reached from the public network. If it is in a branch office, please use an intelligent firewall to deploy it, or just follow the same steps as for the head office. - Page 12 Turn off the【DHCP】 Enter the IP address, subnet mask, gateway and DNS information in corresponding fields. . Press 【Save】to save the configuration, then the screen prompts【Reboot now】. Press【OK】 to reboot the system. Configure Port Mapping If the VC120 is deployed in an Intranet, you need to finish the following port mapping on the firewall: Function Port Protocol Type...
- Page 13 Branch Office If you are in a branch office, following two options are suggested: Option1: Deploy the VC120 following the same steps as for the head office. In this way, both inbound and outbound calls are available. Option2: Deploy the VC120 using an intelligent firewall, which means that plug and play is possible without any further firewall configuration, but only outbound calls are available.
-
Page 14: Troubleshooting
Assume that you are A in head office. Using the configuration method explained in "Head Office" chapter on page 8, you find that you can call B in branch office or Yealink Demo, but that they cannot call you. The most likely reason is that the firewall or gateway in the environment does not support the H.323 ALG feature. - Page 15 . Select 【Auto】 from the 【Type】 pull-down list, the system will obtain public IP address automatically. . If the system does not obtain a public IP address automatically, select【Manual Settings】from the 【Type】 pull-down list, and then enter the public IP address in the 【Public IP Address】field. Yealink Test Room IP: 117.28.251.50、117.28.251.51...
- Page 16 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. Web: www.yealink.com Addr: 309, 3th Floor, No.16, Yun Ding North Road, Huli District, Xiamen City, Fujian, P.R. China Copyright©2016Yealink Inc.All right reserved.
