Reference

Trouble shooting

Symptom Cause
No display Handset not switched on
Battery empty
No allocation of The telephone connection
the switched line cable is not correctly put
The power connection
cable is not correctly put
The switched line is occupied
by another handset
No radio communication Handset not registered
to the base unit or the bell at Base-station
of the handset is not ringing
The power connection
cable is not correctly put
into base
Handset is not ringing Ringing volume is too low
the bell
When dialling, the switched Lock mode enable
line disconnected
48
Remedy
Switches handset on
Put handset on the base
unit for charging batteries
Plug in the telephone line
cable into the base unit
and also check the wall
socket connection
Plug in the power ADAPTOR
into the base unit
Wait until the switched line
is free
Handset need to be
registered at base unit
Plug in the power ADAPTOR
into the base unit
Set the ringing volume high
on the handset
Check lock mode, and
disable lock mode

Technical specifications

Base station and handset
Standard DECT/GAP
Number of channels 120 duplex channels
Channel spacing 1.728 MHz
Bit rate 1152 kbit / sec
Duplex procedure TDMA (time division multiple access procedure)
Voice coding ADPCM (32 kbit/s)
Modulation GFSK
Radio frequency range 1.880 GHz to 1.900 GHz
Average transmission power Approx. 10 mW (per channel)
Range Up to 250 m outdoors
Up to 40 m indoors
Power supply
Base station Input: 230 V, 50 Hz
Output: AC 9 V, 300 mA
Handset Rechargeable Ni-MH 1.2V, 600 mAh, AAA(x 3)
Handset operating time with full battery Talk time: up to 10 hours
Standby time: up to 100 hours
Permissible ambient temperature 0 °C to 40 °C
Permissible storage temperature – 20 °C to 60 °C
Dimensions (length x width x height)
Handset (D) 28.0 x (W) 46.5 x (H) 115.0 mm
Base station (D) 133.0 x (W) 81.5 x (H) 52.5 mm
Weight 111 g (Battery included)
Handset 148 g
Base station
Dialling procedure DTMF and Pulse
Recall key function Flash
Line cord 2 Meter Tel-line cord
49
