DT-4572 X-Band Down Converter
Serial Interface Operation
8.7.2.15

VFD (VFD Brightness)

Use VFD to set or return the front panel brightness from 0% to 100% in 25%
steps. The default VFD brightness is 100.
Description
Set VFD:
Confirmation:
Return VFD:
Confirmation:
8.7.2.16

SRO (Set Reference Oscillator Tuning)

Use SRO to set or return the reference oscillator tuning. The default value is 087.
Description
Set Oscillator:
Confirmation:
Return Tuning:
Confirmation:
8.7.2.17

SSA (Converter Slope Adjustment)

Use SSA to set or return the slope adjustment value. The default value is 0.3.
Description
Set Slope Adjust:
Confirmation:
Return Slope Adjust:
Confirmation:
Details
<DEV/VFD_xxx{cr} where:
xx = 000 to 100 (in 025 steps)
>DEV/VFD_xxx{cr}{lf}]
<DEV/LCD_{cr}
>DEV/VFD_xxx{cr}{lf}]
Details
<DEV/SRO_xxx{cr} where:
xxx = 0 to 255
>DEV/SRO_xxx{cr}{lf}]
<DEV/SRO_{cr}
>DEV/SRO_xxx{cr}{lf}]
Details
<DEV/SSA_xxx{cr} where:
xxx = 0.0 to 1.0
>DEV/SSA_xxx{cr}{lf}]
<DEV/SSA_{cr}
>DEV/SSA_xxx{cr}{lf}]
8–16
MN/DT4572.IOM
Revision 1
