DT-4572 X-Band Down Converter
Serial Interface Operation
8.7.5

Status Queries

Status queries retrieve configuration, maintenance and alarm status in summary
form.
8.7.5.1

RCS (Configuration Status)

Description
Configuration Status:
Confirmation:
If Redundancy=OFF, then xx_yy_z = OFF; otherwise, if Redundancy=ON
and you select a converter as a backup controller: xx_yy_z = BU_yy,
where yy is the number of converters in the chain (i.e. 01 to 12).
Alternately, if Redundancy=ON and you select a converter as a chain
unit, where xx is the converter number (01 to 12), and z = A (if Auto
Mode) or M (if Manual Mode).
8.7.5.2

RMS (Maintenance Status)

Description Details
Maintenance Status: <DEV/RMS_{cr}
Confirmation: >DEV/RMS_{cr}
P15_xx.x{cr}
P14_xx.x{cr}
VCC_x.x{cr}
5VD_x.x{cr}
TEM_xx{cr}
IFL_xx.x{cr}
SUM_xx.x{cr}
COR_xx.x{cr}
FIN_xx.x{cr}{lf}]
Details
<DEV/RCS_{cr}
>DEV/RCS_{cr}
FRE_xxxxx.xxx{cr}
ATT_yy.yy{cr}
TX_nnn{cr}
ONL_nnn{cr}
RED_xx_yy_z{cr}
CLD_nnn{cr}
AFR_nnn{cr}
EXT_xxx{cr}{lf}]
15V DC Supply
14V DC Supply
VCC Supply
Display 5V DC
Temperature
IFLO Tuning
Sum Loop Tuning
Coarse Loop Tune
Fine Loop Tuning
8–27
Frequency from 7250 to 7750 MHz (RF
RF ), in 1 kHz steps
HIGH
Attenuation
Transmitter: ON/OFF/COLD
Online: ON/OFF
See Note
Cold Start: ON/OFF
Auto Flt Recovery: ON/OFF
Ext. Ref.: YES/NO
MN/DT4572.IOM
Revision 1
to
LOW
