DT-4572 X-Band Down Converter
Serial Interface Operation
8.7.5.6

TSC (Terminal Status Change)

Use the TSC query to determine if the status of the terminal has changed since it
was last polled. If any of the parameters listed in the RCS or RUS queries have
changed as a result of user front panel operations or remote operations, or if any
new fault conditions occur, the TSC command returns YES. The TSC query then
continues to return YES until any of the following queries are received: RCS, RUS,
RAS, PACRCS, PACRUS, or PACRAS.
Description
Configuration Status:
Confirmation:
8.7.5.7

PACRCS (Packed Configuration Status)

Description
Configuration Status:
Confirmation:
Details
<DEV/TSC_{cr}
>DEV/TSC_nnn{cr}{lf}] where:
nnn=YES/NO
Details
<DEV/PACRCS_{cr}
>DEV/PACRCS_aaaaaaabbbcdeffgghijkl{cr}{lf}] where:
aaaaa or aaaaaa = # of steps above base frequency
bbb = # of 0.25 dB steps above 0.00 dB
c = 1 if Transmitter ON, 0 if OFF, 2 if Cold
d = 1 if unit ONLINE, 0 if OFFLINE
e = 1 if Redundancy ON, else 0
ff = converter # (01-12, BU or 00 if e = 0)
gg = 00 if 'ff' is 00 (redundancy OFF)
g = chain length (01-12) if 'ff' is BU
gg = XX if 'ff' = 01 - 12
h = A if Auto Mode, M if Manual
I = 1 if Cold Start Enabled, else 0
j = 1 if Auto recovery enabled, else 0
k = 1 if an Ext. Ref is present, else 0
l = 1 if Remote Mode, 0 if Local Mode
8–29
MN/DT4572.IOM
1
2
3
Revision 1
