- Page 1 Keysight E4416A and E4417A EPM-P Series Peak and Average Power Meters Installation Guide...
- Page 4 Keysight Technologies further Keysight Technologies shall not be liable for errors certifies that its calibration measurements are contained herein or for incidental or consequential...
-
Page 5: Safety Symbols
Safety Symbols Safety Symbols The following symbols on the instrument and in the documentation indicate precautions which must be taken to maintain safe operation of the instrument. The Instruction Documentation Symbol. The product is marked with this symbol when it is necessary for the user to refer to the instructions in the supplied documentation. -
Page 6: General Safety Information
REMOVE POWER and do not use the product until safe operation can be verified by service-trained personnel. If necessary, return the product to a Keysight Sales and Service Office for service and repair to ensure the safety features are maintained. - Page 7 DO NOT substitute parts or modify equipment: Because of the danger of introducing additional hazards, do not install substitute parts or perform any unauthorized modification to the product. Return the product to a Keysight Sales and Service Office for service and repair to ensure the safety features are maintained.
- Page 8 Safety Symbols EPM-P Installation Guide...
-
Page 9: Table Of Contents
Keysight Sales and Service Offices........ - Page 10 Contents EPM-P Installation Guide...
-
Page 11: Getting Started
Getting Started... -
Page 12: Welcome
If there is mechanical damage, notify the nearest Keysight Technologies office. Keep the damaged shipping materials (if any) for inspection by the carrier and a Keysight representative. If required, you can find a list of Keysight Sales and Service Offices on page Before continuing, please ensure you have read and understood the preceding safety information. -
Page 13: Documentation Information
This guide is only part of the information supplied. The documentation consists • The installation guide (this book) - Shows you how to check your power meter, switch it on and connect it to a Keysight power sensor. This information is presented in English, French, German, Italian, Japanese, and Spanish languages. -
Page 14: What You'll Find In This Guide
According to ISO 7779 (Type Test). on page 40 • Responsibilities of the Customer on page 43 • Keysight Sales and Service Offices on page 44 For more detailed operating information, refer to the EPM-P Series power meters user’s guide and programming guide. EPM-P Installation Guide... - Page 15 What You’ll Find in this Guide Getting Started Conventions Used in this Guide The following conventions are used to show the difference between a front panel key and a softkey. This is used to represent a labeled key on the power meter Zero front panel.
-
Page 16: Power Meter And Sensor Capability
• Peak Power • Rising Edge Trigger • Falling Edge Trigger Not applicable for N8480 Series power sensors with Option CFT Specifications The specifications for the power meter are listed in the E4416A and E4417A user’s guide. EPM-P Installation Guide... -
Page 17: Adjusting The Carrying Handle
Adjusting the Carrying Handle Getting Started Adjusting the Carrying Handle Adjust the carrying handle to carry the meter or view the display. The carrying handle can be locked into three different positions. Pull the handle outwards, rotate it to the required position and release it into one of the three locks. -
Page 18: Turning The Power Meter On
Getting Started Turning the Power Meter On Turning the Power Meter On You can turn the power meter on without connecting a power sensor or power- sensor cable. C AU T I O N The instrument has an autoranging power supply. Ensure the supply voltage is within the range 85 to 264 V and 47 - 440Hz. - Page 19 Turning the Power Meter On Getting Started 3. Turn the meter on and confirm the green LED is lit. POWER 4. The meter automatically steps through a self test routine..and is now ready for use. N O T E If the meter has been stored in extremely cold conditions, beyond its normal operating range, the display may require a few minutes to warm up and operate normally.
- Page 20 Check that power is supplied to the meter. Check the power meter fuse. (see Step 5) Fails self test(s) If there are any self-test failures the meter is defective. Contact your nearest Keysight Service Center (Refer to Keysight Sales and Service Offices on page 44).
-
Page 21: Front Panel Keys And Connections
Front Panel Keys and Connections Getting Started Front Panel Keys and Connections This section briefly describes the functions of the front panel keys and connectors. The user’s guide shows you how to use them in more detail. These keys are located to the left of the display. Function Press this key to switch the meter between on and standby. - Page 22 Getting Started Front Panel Keys and Connections These keys are located along the lower edge of the display. Function Press this key to access general configuration menus, such System as GPIB address. You can also access some measurement configuration menus. The measurement screen remains visible.
- Page 23 Front Panel Keys and Connections Getting Started These keys are all associated with the menu labels and data entry. They are located to the right of the display. Function Press this key to access the next pages of a menu. For More example, displayed beside the...
- Page 24 Option 003, the connector is fitted to the rear panel. The green LED beside the connector is lit when the calibrator is turned on. The sensor input connectors (Keysight E4417A shown, the CHANNEL E4416A has one input). If the meter is configured with Option 002 or Option 003, the connectors are fitted to the rear panel.
-
Page 25: Connecting A Power Sensor
Connecting a Power Sensor Using the correct cable, any Keysight diode based power sensor can be connected to the E4416A or E4417A power meters. (The E9288 Series cables are color coded to help distinguish them from the 11730 Series.) Power Sensor... - Page 26 Getting Started Connecting a Power Sensor 2. Connect the other end of the E9288 Series cable to the CHANNEL A (or CHANNEL B) input connector. 3. Confirm the message pop-up appears briefly. Reading Sensor Message does not appear when connecting an 8480 Series power sensor.
- Page 27 Connecting a Power Sensor Getting Started 5. Connect the sensor to the POWER REF connector. 6. When the sensor is connected to the POWER REF, you can zero and Zero calibrate the measurement path quickly by pressing Zero and Cal On dual channel meters, press Zero + Cal A Zero + Cal B...
-
Page 28: Rear Panel Connections
Getting Started Rear Panel Connections Rear Panel Connections The following connections are available on the rear panel. To setup the remote interfaces, refer to Remote Interface Configurations on page 1. GPIB 2. RS232 and RS422 1 2 3 4 5 RS232 RS422 6 7 8 9... - Page 29 Rear Panel Connections Getting Started 3. RJ11 1 2 3 4 5 6 7 8 Pin Connection none Ground TTL Output 1 TTL Output 2 TTL Input 1 TTL Input 2 Ground Ground 4. Recorder output (two outputs are fitted to dual channel meters) and Trigger Input and Output connections are made via BNC connectors.
-
Page 30: Remote Interface Configurations
Getting Started Remote Interface Configurations Remote Interface Configurations The power meter is equipped with GPIB (IEEE488), RS232, and RS422 remote programming interfaces. This section shows you how to change the interface settings. GPIB The power meter is shipped from the factory with GPIB as the selected interface and the address set to 13. -
Page 31: Rs232/Rs422
Remote Interface Configurations Getting Started RS232/RS422 System To check the settings for the RS232 or RS422 interfaces press . The settings are displayed Remote Interface Configure Interface Serial below the respective softkey labels. Press to access the next menu page. More To change any setting: System... -
Page 32: Rack Mounting The Power Meter
Getting Started Rack Mounting the Power Meter Rack Mounting the Power Meter Rack Mounting One Meter (Using the Option 908 rack mount kit) 1. Remove the carrying handle. 2. Remove the front and rear rubber bumpers. EPM-P Installation Guide... - Page 33 Rack Mounting the Power Meter Getting Started 3. Fit the rack mount flanges. (Parts available separately: 5063-9240). Ready for installation. EPM-P Installation Guide...
-
Page 34: Rack Mounting Two Meters Together (Using The Option 909 Rack Mount Kit)
Getting Started Rack Mounting the Power Meter Rack Mounting Two Meters Together (Using the Option 909 rack mount kit) 1. Remove the carrying handle. 2. Remove the front and rear rubber bumpers. Hardware required to link meters together. EPM-P Installation Guide... - Page 35 Rack Mounting the Power Meter Getting Started 4. Fit one small rack mounting flange to opposite sides of each power meter. (Parts available separately: 5061-9694 and 5063-9212). 5. Fit two front linking plates to each power meter. 6. Engage the linking plates at the front of the power meters. EPM-P Installation Guide...
- Page 36 Getting Started Rack Mounting the Power Meter 7. Attach the rear linking brackets. Ready for installation EPM-P Installation Guide...
-
Page 37: Regulatory Information
Regulatory Information... -
Page 38: General Specifications
For continued protection against fire hazard, replace the line fuse only with the same type and line rating (250V, F3.15A, 20mm fast blow fuse with high breaking capacity, Keysight part number 2110-0957). The use of other fuses or materials is prohibited. - Page 39 General Specifications Regulatory Information WARNING No operator serviceable parts inside. Refer servicing to qualified personnel. To prevent electrical shock do not remove covers. WARNING If this instrument is not used as specified, the protection provided by the equipment could be impaired. This instrument must be used in a normal condition only (in which all means for protection are intact).
-
Page 40: Compliance And Markings
Regulatory Information Compliance and Markings Compliance and Markings IEC 61010-1 Compliance This instrument has been designed and tested in accordance with publication EN61010-1(1993) / IEC 61010-1(1990) +A1(1992) +A2(1995) / CSA C22.2 No. 1010.1(1993) Safety Requirements for Electrical Equipment for Measurement, Control and Laboratory Use, and has been supplied in a safe condition. -
Page 41: Markings
Compliance and Markings Regulatory Information Markings The following markings can be found on the rear panel. The CE mark shows that the product complies with all the relevant European legal Directives. The CSA mark is a registered trademark of the Canadian Standards Association and indicates compliance with the standards set out by them. -
Page 42: Regulatory Information
Regulatory Information Regulatory Information Regulatory Information Sound Emission Herstellerbescheinigung Diese Information steht im Zusammenhang mit den Anforderungen der Maschinenlarminformationsverordnung vom 18 Januar 1991. • Sound Pressure LpA < 70 dB. • Am Arbeitsplatz. • Normaler Betrieb. • Nach DIN 45635 T. 19 (Typprufung). Manufacturers Declaration This statement is provided to comply with the requirements of the German Sound DIN 45635 T. -
Page 43: Declaration Of Conformity
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC, and carries the CE-marking accordingly. South Queensferry, Scotland 17 October 2000 R.M. Evans / Quality Manager For further information, please contact your local Keysight Technologies sales office, agent, or distributor. EPM-P Installation Guide... - Page 44 The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC, and carries the CE-marking accordingly. South Queensferry, Scotland 17 October 2000 R.M. Evans / Quality Manager For further information, please contact your local Keysight Technologies sales office, agent, or distributor. EPM-P Installation Guide...
-
Page 45: Responsibilities Of The Customer
• Access to and use of all information and facilities determined necessary by Keysight to service and/or maintain the products. (Insofar as these items may contain proprietary or classified information, the customer shall assume full responsibility for safeguarding and protection from wrongful use.) •... -
Page 46: Keysight Sales And Service Offices
Keysight Sales and Service Offices In any correspondence or telephone conversations, refer to the power meter by its model number and full serial number. With this information, the Keysight representative can quickly determine whether your unit is still within its warranty period. - Page 47 This information is subject to change without notice. © Keysight Technologies 2000 - 2014 Edition 2, August 2014 *E4416-90002* E4416-90002 www.keysight.com...
