USER GUIDE USER GUIDE

EXPLORER 110 WEB MMI cont.

1.
Simply enter the WorldPro1010's default IP address
192.168.0.1
into your Web browsers address line and
the Status Summary page will be shown:
2.
Enter the SIM PIN code and press the Enter Pin
button.
More information about the WEB MMI is found
on the EXPLORER_110_Ethernet_user_Guide.
EXPLORER 100/110
3.
Select Data Connections menu item on the web
MMI page. You may store three different data connec-
tion confi gurations: Normal, Alternative1 and Alterna-
tive2. For most cases only one confi guration (Normal)
should be suffi cient.
The different data connection settings are explained
below:
- Standard background: Varying bit rate dependent on available resources. Tariff based
on data volume.
- Streaming 32kbps Guaranteed bit rate. Time based tariff.
- Streaming 64kbps Guaranteed bit rate. Time based tariff.
OPERATION '
CONT D
51 51
