5 Powering the device

• Yellow: Operator desktop microphone
• Green: Operator monitor headset, headphones
• Pink: Operator monitor headset, boom microphone
• Gray: Operator monitor speaker
A. SF (AC), right and left
B. AC
C. BC
D. CD/Tape
Caution
•
comply with the same safety standards as MADSEN Itera II can lead to a general reduction in the system's safety level.
5 Powering the device
Switching MADSEN Itera II on and off
6
When you connect other electrical equipment to MADSEN Itera II, remember that equipment that does not
E. External microphone/Monitor
headset
Monitor
F.
G. Talk back
1. Plug the power cord into the power socket of MADSEN Itera II.
Installation ► 5
See
2. Plug the other end of the power cord directly into an AC mains power
outlet with a three-wire protective ground.
A. The on/off switch is located on the right side of MADSEN Itera II.
H. Digital aux.
Patient response
I.
J. DC power out
K. RS232 interface
.
Otometrics - MADSEN Itera II
