Unpacking; Installation - otometrics madsen itera ii User Manual

Note Indicates that you should take special notice.
•
3

Unpacking

1. Unpack the device carefully.
When you unpack the device and accessories, it is a good idea to keep the packing material in which they were
delivered. If you need to send the device in for service, the original packing material will protect against damage dur-
ing transport, etc.
2. Visually inspect the equipment for possible damage.
If damage has occurred, do not put the device into operation. Contact your local distributor for assistance.
3. Check with the packing list to make sure that you have received all necessary parts and accessories. If your package is
incomplete, contact your local distributor.
4. Check the Test Report (Calibration Certificate), make sure that the transducers (headphones and bone oscillator) are
the correct ones, and that they comply with the ordered calibration standards.
4

Installation

Install OTOsuite on the PC before you connect to MADSEN Itera II from the PC.
For instructions on installing OTOsuite, see the OTOsuite Installation Guide, which you can find on the OTOsuite install-
ation medium (disk or memory stick).
MADSEN Itera II is fully assembled on delivery, and you simply have to connect cables.
Caution
•
(approx. 10 feet).
Installation sequence
1. Install OTOsuite on your PC.
2. Assemble and set up MADSEN Itera II.
– See
3. Switch on MADSEN Itera II.
4. Run the Configuration Wizard in OTOsuite to connect to and set up communication with MADSEN Itera II.
– See
Connection panel - MADSEN Itera II
For a detailed description of the connection panel, see the MADSEN Itera II Reference Manual.
The connections are located at the back of MADSEN Itera II.
All four cables for connecting accessories are joined in a bundle and color-coded for easy connection:
Otometrics - MADSEN Itera II
To connect MADSEN Itera II to the PC, use the supplied USB cable. The cable length must not exceed 3 m
Powering the device ► 6
Connecting MADSEN Itera II to OTOsuite ► 7 .
3 Unpacking
5
