COMPOUND
MITRE SAW
210mm (8
")
1/4
INSTRUCTION MANUAL
SPECIFICATIONS
Motor:
S1:1200W, S6 25%:1500W
Input:
230-240V ~ 50Hz
No Load Speed:
5,000/min
Blade:
Ø210mm x Ø16 x 48T
Mitre Angle:
0-45° left & right
Bevel Angle:
0-45° left
Max. Cutting Capacity:
Mitre 0° x Bevel 0°:
120x60mm wood
Mitre 45°x Bevel 0°:
80x60mm wood
Mitre 0°x Bevel 45°:
120x35mm wood
Mitre 45°x Bevel 45°:
80x35mm wood
ozito.com.au
WHAT'S IN THE BOX
Compound Mitre Saw
Dust Bag
Material & Rear
Support Bars
Hex Key
CMS-210
Advertisement
Table of Contents
Related Manuals for Ozito CMS-210
Summary of Contents for Ozito CMS-210
-
Page 1: Instruction Manual
Bevel Angle: 0-45° left Material & Rear Max. Cutting Capacity: Support Bars Mitre 0° x Bevel 0°: 120x60mm wood Mitre 45°x Bevel 0°: 80x60mm wood Mitre 0°x Bevel 45°: 120x35mm wood Mitre 45°x Bevel 45°: 80x35mm wood ozito.com.au Hex Key CMS-210... -
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION MITRE SAW 1 Dust bag 11 On/Off switch 1. ASSEMBLING THE SAW 2 Cutting head 12 Carry handle 3 Blade 13 Spindle lock button WARNING! ENSURE THE SAW IS SWITCHED OFF AND 4 Rear fence 14 Head locking pin DISCONNECTED FROM THE POWER SUPPLY BEFORE 5 Side support bars... - Page 3 2. ADJUSTING THE MITRE SAW Rear Support Bar Mitre Angle Adjustment The rear support bar provides additional stability for the mitre saw base. 1 Loosen the mitre table lock knob by rotating anti- clockwise. 1 Loosen the phillips head screws on the base of the mitre saw.
- Page 4 3. STRAIGHT AND ANGLE CUTTING Bevel Angle Adjustment A straight cut is made by cutting the 0º grain of the workpiece. A 90° straight 1 Loosen the bevel lock knob by cut is made with the mitre scale set in rotating anti-clockwise.
-
Page 5: Operation
When cutting long 5 Once the cut has been made, pieces of timber, release the on/off switch. support the opposite When the blade has stopped end of the timber with you can then raise the cutting the material support head. bars. CMS-210... -
Page 6: Maintenance
SAW. THIS WILL NOT BE COVERED UNDER WARRANTY. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the mitre saw by an unauthorised person or by mishandling of the mitre saw. -
Page 7: Troubleshooting
Check with your local council authority For further information, or any parts not listed here, visit for recycling advice. www.ozito.com.au or contact Ozito Customer Service: Recycling packaging reduces the need for landfill and raw materials. Australia 1800 069 486 Reuse of recycled material decreases pollution in the environment. - Page 8 Tool: 210mm Compound Mitre Saw SPARE PARTS Model No. CMS-210 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Fence SPCMS210-041...
-
Page 9: Electrical Safety
Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. -
Page 10: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1114...
