COLD CUT SAW
1280W
INSTRUCTION MANUAL
SPECIFICATIONS
Rated Voltage:
230 – 240V ~ 50Hz
Rated Power:
1280W
No Load Speed:
3800rpm
Supplied Blade:
Ø180mm (7") x Ø20mm x 1.9 (36T)
Cutting Blade Max.:
Ø185mm (7-1/4")
Cutting Angle Capacity:
0 – 45°
Max Cutting Capacity
Round & Square Tube:
50mm - 6 mm Section
Rectangular Profile:
75mm x 45mm - 6mm Section
Round & Square Bar:
20mm Mild Steel
Net Weight:
7.7kg
ozito.com.au
WHAT'S IN THE BOX
Cold Cut Saw
5mm & 6mm
Hex key
Carbon Brush Set
CCS-1200
Advertisement
Table of Contents
Related Manuals for Ozito CCS-1200
Summary of Contents for Ozito CCS-1200
-
Page 1: Instruction Manual
Cutting Angle Capacity: 0 – 45° Max Cutting Capacity Round & Square Tube: 50mm - 6 mm Section Carbon Brush Set Rectangular Profile: 75mm x 45mm - 6mm Section Round & Square Bar: 20mm Mild Steel Net Weight: 7.7kg ozito.com.au CCS-1200... -
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION COLD CUT SAW 1. ADJUSTMENTS 1 Carry handle 11 Rear spark shield 2 Upper blade guard 12 Vice handle Locking & releasing 3 Lock off button 13 Rubber foot the lock pin 4 Blade bolt cover 14 Vice lock The cold cut saw is boxed in 5 Retractable blade guard... -
Page 3: Adjusting The Cutting Angle
Adjusting the depth stop Adjusting the cutting angle Note. The angle guide allows cutting angles from 0° to 45°. Ensure that the depth stop is adjusted to the correct height before commencing operation. The adjustable depth stop is threaded into the pivot mount at the rear of the base. -
Page 4: Operation
OPERATION 2. MAXIMUM CUTTING CAPACITIES 3. TURNING ON AND OFF 1. Depress and hold the lock-off The cut off saw is recommended for cutting mild steel such as pipe, box button then pull the trigger section, rectangular, angle iron and mild steel bars. switch to start the tool. -
Page 5: Maintenance
MAINTENANCE 4. OPERATION REPLACING A BLADE When all the necessary adjustments have been made including IMPORTANT! BEFORE CLEANING YOUR COLD CUT SAW adjusting the vice, cutting angle and depth stop (see Adjustments OR CARRYING OUT ANY MAINTENANCE PROCEDURE, section), the operation of the cold cut saw can commence. MAKE SURE THAT THE MOTOR IS OFF AND THE TOOL DISCONNECTED FROM THE POWER SUPPLY TO 1. -
Page 6: General Inspection
Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the saw by an unauthorised person or by mishandling of the saw. -
Page 7: Description Of Symbols
Spare parts can be ordered from the Special Orders Desk at your local Bunnings Warehouse. For further information, or any parts not listed here, visit www.ozito.com.au or contact Ozito customer service Australia 1800 069 486 New Zealand 0508 069 486... - Page 8 Tool: SPARE PARTS Model No. 76 41 52 28 20 21 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Carbon Brush Holder (Pair)
-
Page 9: Electrical Safety
Replace the extension lead if damaged Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and or defective. - Page 10 Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1013...
