Portable Gas Barbecue
Operating and Assembly Instructions
FOR YOUR SAFETY.
IF YOU SMELL GAS:
1. Shut off gas to the
appliance, if possible.
2. Extinguish any open flame.
3. Open hood.
4. If odour continues,
immediately call your gas
supplier or fire department.
FOR YOUR SAFETY.
1. Do not store or use
petrol or other flammable
vapours and liquids in the
vicinity of this or any other
appliance.
2. A gas cylinder not
connected for use must not
be stored in the vicinity of
this or any other appliance.
These instructions are a
guide to assembling and
using the Premium 6X
barbecue.
Please read carefully, and
retain for future reference.
Only to be used outdoors.
Illustration may vary from barbecue
contained in carton.
Advertisement
Table of Contents
Related Manuals for Grandhall Portable Gas Barbecue
Summary of Contents for Grandhall Portable Gas Barbecue
- Page 1 Portable Gas Barbecue Operating and Assembly Instructions These instructions are a FOR YOUR SAFETY. FOR YOUR SAFETY. guide to assembling and using the Premium 6X IF YOU SMELL GAS: 1. Do not store or use barbecue. petrol or other flammable 1.
-
Page 2: Table Of Contents
G E N E R A L I N F O R M A T TABLE OF CONTENTS GAS INSTALLATION CODES This appliance is certified to AS 4557 by the Australian Gas Association. General Information Refer data label on the barbecue for certificate number. Safety Barbecues must be used in accordance with the installation Outdoor Areas... -
Page 3: Safety
CHECKING FOR GAS LEAKS READ CAREFULLY BEFORE ASSEMBLING AND OPERATING NEVER TEST FOR LEAKS WITH A FLAME. YOUR BARBECUE. Prior to first use, and at the beginning of each new season (or, if using bottled gas, whenever gas cylinder is changed), you must check FOR YOUR SAFETY: for gas leaks. - Page 4 ALWAYS CHECK FOR GAS LEAKS EACH TIME YOU USE YOUR BARBECUE. You should follow this procedure after any of the following: • Not having used the barbecue for an extended period of time • Initial assembly of barbecue • Any disconnection and reconnection of hose assembly •...
-
Page 5: Outdoor Areas
THIS APPLIANCE SHALL ONLY BE USED IN AN ABOVE GROUND OPEN AIR SITUATION WITH NATURAL VENTILATION, WITHOUT STAGNANT AREAS, WHERE GAS LEAKAGE AND PRODUCTS OF COMBUSTION ARE RAPIDLY DISPERSED BY WIND AND NATURAL CONVECTION. ANY ENCLOSURE IN WHICH THE APPLIANCE IS USED SHALL COMPLY WITH ONE OF THE FOLLOWING: •... -
Page 6: Pre-Assembly
GENERAL CARTON CONTENTS While it is possible for one person to assemble the barbecue, Description we recommend asking for the assistance of another person when Side panel – right manoeuvring some of the larger or heavier pieces. Side panel – left Bottom shelf ASSEMBLY TIPS Castor seat... -
Page 7: Assembly
A S S E M B L Y Attach castor seats to side panels. NOTE: Castor seats are labelled for correct location Phillips-head screw " x " Qty: 8 Countersunk flat-head screw " x " LF / RR Qty: 8 Door magnets Attach side panels to bottom shelf. - Page 8 A S S E M B L Y Attach the trolley bracket front Trolley bracket front and rear panel. Rear panel Phillips-head screw " x " Qty: 8 Flange nut " Qty: 8 Attach body support brackets and gas cylinder housing, facing wing bolt to rear.
-
Page 9: Tool Hooks
G E N E R A L Attach barbecue body to trolley. NOTE: Cut cable tie from underneath the barbecue head to release the gas regulator before assembling onto trolley. Phillips-head screw " x 1 " Qty: 4 Washer " Qty: 4 Slide tool hook onto the tool holder and attach to the side shelf. - Page 10 A S S E M B L Y • Attach side shelf NOTE: Hardware for one side shown. NOTE: Do not tighten until all screws and bolts have been assembled. • Partially install two of the hex-head flanged bolts front and rear, into the side of the barbecue body as shown ‘1st’...
- Page 11 A S S E M B L Y CONNECTING TO, AND DISCONNECTING CONNECTING THE SIDE BURNER HOSE FROM GAS SOURCE CAUTION: Fully handtighten hose nut prior to using spanner to ensure threads are TEST FOR LEAKS WITH A not ‘cross-threaded’. SOAP SOLUTION, NEVER WITH AN OPEN FLAME (Refer pages 3 and 4).
- Page 12 IGNITION BATTERY BURNER OPERATION AND IGNITION SYSTEM CHECK Piezo igniter Electronic igniter Gas collector / electrode Screw battery Igniter Gas valve assembly Orifice Burner tube Contact Spring With burner controls in ‘OFF’ position, open the gas cylinder valve or connect to gas supply. BACK BURNER SPARK ELECTRODE TEST Upon first assembly the gas lines and burners will be full of AND ADJUSTMENT –...
-
Page 13: Inspection
I N S P E C T I O N WITH THE ASSISTANCE OF ANOTHER SIDE BURNER ELECTRODE CHECK PERSON, PERFORM THIS ELECTRODE CHECK BEFORE PROCEEDING. • Open side burner lid. Remove plastic shipping band from burner and pot support. This test will ensure that the spark electrode tips are properly •... -
Page 14: Assembly - General
A S S E M B L Y – G E N E R A L INSTALL GREASE DRAINING TRAY FLAME TAMERS AND GREASE RECEPTACLE The flame tamer plate is designed to reduce flaring. The plates fit onto the ledge at the front and rear of the barbecue body. Position with the slots to the front as shown below. -
Page 15: Operation
Once the burner is ignited, the adjacent burner can be lit by TEMPERATURE GAUGE simply turning its control knob to ‘HI’. The temperature gauge is used as a Adjust burner control knobs to your desired cooking guide to cooking temperatures temperature. - Page 16 OPERATING PROCEDURE • THE SIDE BURNER IS DESIGNED FOR USE WITH A WOK UP TO 360 mm DIAMETER AND COOKING POTS UP TO BURN-OFF 200 mm DIAMETER Before cooking on your barbecue for the first time, burn-off any • USE OF VERY LARGE POTS MAY residual oils or foreign matter from the cooking plates.
- Page 17 • The easiest foods to balance are those of uniform shape ROTISSERIE and texture. To test if the food is balanced correctly when secured, place the ends of the rotisserie skewer loosely Rotisserie is available as an optional extra from your place of in the palm of your hands.
-
Page 18: Fault Finding
IF THE BARBECUE FAILS TO LIGHT SHOULD A FLASHBACK FIRE OCCUR IN OR AROUND THE BURNER TUBES, FOLLOW THE INSTRUCTIONS BELOW. Turn gas off at source and turn burner control knobs to FAILURE TO COMPLY WITH THESE ‘OFF’. Wait at least five (5) minutes for gas to clear, then retry. INSTRUCTIONS COULD RESULT IN A FIRE OR EXPLOSION THAT COULD If your barbecue still fails to light, check gas supply and... -
Page 19: Maintenance
DO NOT USE OVEN CLEANER TO CLEAN CLEANING THE FLAME TAMERS THE BARBECUE. SOME PROPRIETORY BARBECUE Periodically you should wash the flame tamer in a soap and warm CLEANERS MAY AFFECT / DAMAGE water solution. Use a vegetable brush to remove stubborn burnt-on SOME OF THE SURFACE COATINGS cooking residue. - Page 20 • BEWARE OF SPIDERS. STORAGE BURNER TUBES SHOULD BE INSPECTED AND CLEANED We recommend that you minimise the barbecue’s exposure to PERIODICALLY the elements. High moisture content in the air (rain, mist, salt spray etc.) can affect metal components and lead to material •...
- Page 21 METHOD 3: Use an air hose to force air through each burner tube. CLEANING THE BURNER TUBES The forced air should pass debris or obstructions through the AND BURNER PORTS burner and out the ports. To reduce the chance of FLASHBACK FIRE you must clean the Regardless of which burner cleaning procedure you use, we burner tubes as follows at least once a month in summer and fall recommend you also complete the following steps to help prolong...
-
Page 22: Parts Diagram / List
This diagram is provided to assist you identify parts if replacement is necessary. Contact your place of purchase or the manufacturer to enquire about parts, availability and or service. Items included in your barbecue specification may differ from the parts list, depending on region or specific dealer specification. - Page 23 Description Part # Hood P00148034B Hood hinge P05501018A Protective pad P05518002I Temperature gauge P00601011B Hood handle P00205068M Name plate P00407006S Grill plate P01615028C Hot plate P01702008H Burner P02008015A Flame tamer P01705011E Body wind shield – back burner P06905028A Rear wind shield P0075101IB Burner bracket P0220606ED...
- Page 24 Privacy Act 1988 (Cth). Importantly, individual consumers generally have a right to access information held about them. Manufactured by Grand Hall Enterprise Co Ltd Focus Lifestyle Products Pty Ltd ABN 93 160 136 977 223 - 225 Governor Road, Braeside, Victoria, Australia 3195 P.O.
