DXi6700, DXi6701, and
DXi6702 Site Planning Guide
Product Overview
The DXi6700 family of disk backup and replication appliances use
Quantum's data deduplication technology to expand the amount of
backup data users can retain on fast-recovery RAID systems by 10 to 50
times. The result is a cost-effective way for IT departments to store backup
data on disk for months instead of days, providing high speed, reliable
restores, increasing available data recovery points, and reducing media
management.
For disaster recovery in distributed environments, the DXi6700 systems
make automated WAN replication practical by dramatically reducing the
bandwidth required to move backup data securely between sites.
DXi6700 solutions are integrated systems that are easy to install and use
with all leading backup applications. They provide best-in-class
performance with flexible, easy-to-use interface options including NAS,
OST, virtual library, or mixed presentations, as well as Ethernet and Fibre
Channel connectivity. DXi6700 appliances are part of a comprehensive set
of backup solutions, serviced and supported by Quantum, the leading
global specialist in backup, recovery, and archive.
Note: This
Site Planning Guide
DXi6700 Node
DXi6700 Expansion
Module
is for DXi6700 with DXi 2.0.1 Software.
DXi6700/DXi6701/DXi6702
Contents
Product Overview................................... 1
and DXi6702........................................... 2
Licenses .............................................. 2
Installation ............................................. 3
Rack Compatibility ............................. 3
Network Configuration...................... 4
About Network Segmentation........... 5
General Recommendations................ 6
DXi6700 Segmentation Options ........ 6
Requirements ..................................... 9
Service .................................................. 10
DXi6700 Warranty............................ 10
Service Package Upgrades ............... 10
Email Home ...................................... 11
StorageCare™ Guardian................... 11
DXi Advanced Reporting.................. 11
Configurations ..................................... 12
Shipping Information........................... 14
Specifications ....................................... 14
Physical Characteristics.................... 16
Environmental Specifications .......... 21
www.quantum.com
Advertisement
Table of Contents
Related Manuals for Quantum DXi6700
Summary of Contents for Quantum DXi6700
-
Page 1: Table Of Contents
WAN replication practical by dramatically reducing the bandwidth required to move backup data securely between sites. DXi6700 solutions are integrated systems that are easy to install and use with all leading backup applications. They provide best-in-class performance with flexible, easy-to-use interface options including NAS, OST, virtual library, or mixed presentations, as well as Ethernet and Fibre Channel connectivity. -
Page 2: Included With Your Dxi6700, Dxi6701, And Dxi6702
The following licenses are included with the DXi6700, DXi6701, and DXi6702. Some licenses are pre-installed and some are included on License Certificates, as noted below. • NAS - Enables the NAS interface to hosts. (License key is pre-installed on all DXi6700 models.) •... -
Page 3: Installation
DXi6700/DXi6701/DXi6702 To use DXi Accent, you must install the Quantum OST Client Plug-in on the media server. Symantec For information about installing the OST Plug-in and using DXi Accent, see the NetBackup OST Configuration Guide Installation Rack Compatibility Nearly all standard four-post 19” server racks meeting EIA-310 specifications are compatible with the DXi6700 rack mount kits. -
Page 4: Network Configuration
The DXi6700 allows you to perform the following types of network configuration: • Basic - The Basic network option allows you to configure the DXi6700 with a single bonded interface. All physical Ethernet ports are bonded together to act as a single interface (logical port). -
Page 5: About Network Segmentation
(A network switch is not supplied with the DXi6700.) The DXi6700 bonding settings must match the switch settings. If the switch settings and the DXi6700 settings do not match, your system may become inaccessible through the switch. About Network... -
Page 6: General Recommendations
Advanced Network Recommendations on page 8. DXi6700 (2 x 1 GbE Ports) and DXi6701 (6 x 1 GbE Ports) If less than 1 Gb per second (~450 GB/hr) of performance is required, follow these steps. Otherwise proceed to the Intermediate Network Recommendations on page 7. - Page 7 Advanced Network Recommendations on page 8. DXi6700 (2 x 1 GbE Ports) and DXi6701 (6 x 1 GbE Ports) If multiple 1 Gb port connectivity is required, follow these steps: 1 For Segmentation, select BOND ALL (Not segmented).
- Page 8 (Management/Data), replication traffic will exclusively traverse port ETH0, and Management and Data traffic will exclusively traverse ETH1. DXi6700 (2 x 1 GbE Ports) and DXi6701 (6 x 1 GbE Ports) For advanced network configuration, follow these steps: 1 For Segmentation, select the appropriate configuration option to isolate traffic as necessary.
-
Page 9: Replication Firewall Port Requirements
• Port 80 • Port 1062 Installation and Installation and integration of the DXi6700 systems by Quantum is not required since Integration Services the DXi6700 are customer installable. Quantum recommends that system installation be performed only by qualified network or system administrators who have a working knowledge of ISV setup and configuration. -
Page 10: Service
A variety of support options are available to you via Quantum’s tiered hardware support plans to meet a range of budget and availability requirements. Quantum’s Support Plans include Next Business Day Gold (Next Business Day Onsite, 7x24 Phone Support), Gold (7x24x4 Hr on-site, 7x24 phone support), and a customized Platinum offering. -
Page 11: Email Home
StorageCare™ Guardian StorageCare Guardian is a remote monitoring and diagnostic solution that enables Quantum to proactively monitor the health of Quantum systems over the Internet and use intelligent diagnostics data to remotely service the equipment if issues arise. StorageCare Guardian delivers more reliable backups and faster resolution time for customers at no additional cost for supported products under warranty or service contract. -
Page 12: Dxi6700, Dxi6701, And Dxi6702 Configurations
– 56 TB * To upgrade the capacity of a DXi6700 to 64 TB or greater, the DXi must be converted to a DXi6701 or DXi6702 first. For more Quantum DXi6700 to DXi6701/DXi6702 and DXi6701 to DXi6702 Conversion information about model conversion, see the Instructions (6-67195). - Page 13 ** Any combination of expansion modules (with 1 TB drives or 2 TB drives) may be ordered or used for field capacity upgrades as long as the total capacity does not exceed 80 TB. The table does not list all possible combinations. DXi6700, DXi6701, and DXi6702 Configurations...
-
Page 14: Dxi6700, Dxi6701, And Dxi6702 Shipping Information
3). Each node and expansion module ships in its own box. Each node shipping box weighs approximately 125 lbs. (56.7 kg). Each expansion module shipping box weighs approximately 75 lbs. (34.0 kg). All boxes for each DXi6700, DXi6701, or DXi6702 configuration are shipped on a single pallet. - Page 15 Approximately 810 lbs. (367.4 kg) Length: 42 in. (106.7 cm) Height: 56 in. (91.4 cm) Width: 52 in. (132.1 cm) Approximately 885 lbs. (401.4 kg) Length: 42 in. (106.7 cm) Height: 56 in. (116.8 cm) DXi6700, DXi6701, and DXi6702 Shipping Information...
-
Page 16: Physical Characteristics
DXi6700, DXi6701, and DXi6702 Site Planning Guide DXi6700, DXi6701, and DXi6702 Specifications This section lists characteristics and specifications the DXi6700, DXi6701, and DXi6702. These characteristics and specifications are categorized as follows: • Physical Characteristics • Environmental Specifications Note: For hard drive specifications see the appropriate hard drive product manual. - Page 17 DXi6700, DXi6701, and DXi6702 Cable Drops Ethernet Cable Drops DXi6700 (2 x 1 GbE ports) - 1 to 2 1 GbE Ethernet connections for NAS or OST connectivity, replication, and remote management DXi6701 (6 x 1 GbE ports) - 1 to 6 1 GbE Ethernet connections for NAS or...
- Page 18 DXi6700, DXi6701, and DXi6702 Site Planning Guide Hardware / Interfaces DXi6700 2 ports 100/1000BASE-T Ethernet (RJ45 connector) and 4 ports 8 Gb Fibre Channel (LC connector) DXi6701 6 ports 100/1000BASE-T Ethernet (RJ45 connector) and 4 ports 8 Gb Fibre Channel (LC connector)
- Page 19 DXi6700/DXi6701/DXi6702 Table 8 Power Requirements DXi6700, DXi6701, and DXi6702 Power Requirements Power Supplies and Cords Node Two (2) hot-swappable redundant power supplies Two (2) USA type 3-prong power cords with IEC320 C13 to Nema 5-15 connectors: Two (2) C13 to C14 type 3-prong power cords with...
- Page 20 420 Watts, 1.75A @ 240 VAC Caution: To safeguard backups and to avoid potential data loss in the event of a power outage, Quantum recommends that you connect the DXi6700, DXi6701, or DXi6702 to an uninterruptable power supply (UPS) with a minimum UPS capacity rating that meets the power requirements stated above.
-
Page 21: Environmental Specifications
DXi6700/DXi6701/DXi6702 Environmental Table 9 provides various DXi6700, DXi6701, and DXi6702 environmental specifications. Specifications Table 9 Environmental Specifications Climatic Environment Temperature Operating 10° to 35°C (50° to 95°F) up to 3048m (10,000 ft) Shipping and storage –20° to 60°C (–4° to 140°F) up 12,000m (39,370 ft) - Page 22 EN 61000-4-8 - Power frequency magnetic field immunity test EN 61000-4-11 - Voltage dips, short interruptions and voltage variations immunity test Caution: The DXi6700, DXi6701, and DXi6702 systems are designed to be installed in a rack enclosure. Ensure that the operating temperature inside the rack enclosure does not exceed the maximum rated ambient temperature.
