Reflector Housing Assembly

6
Reference
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
R e m o v i n g r e f l e c t o r
Tools Required:
•
W A R N I N G :
Step 1:
Reflector Housing Assembly
8
10
3
5
(4 required)
Part Description
Number
7060A3054 Housing, reflector casting, painted black
7060A3006 Clip, reflector retainer
7060A4010 Bushing, gate
7060A3016 Plate, clutch
7060A3019 Spring, reflector support
7060A4015 Reflector, molded glass, coated
7060A3058 Bracket, yoke, painted
HW8144 Handle, yoke knob, 5/16 - 18
HW753 Rivet, machine, 3/16 x.720, flat head, black zinc
HW5126 Washer, flat, 5/16, black zinc
HW5193 Bolt 5/16-18 x 3/4, black zinc
HW5125 Bolt, carriage, 5/16-18 x.75, black zinc
HW752 Rivet machine, 3/16 x 5/16, black zinc
7060A4088 Label, S4 750w UL
Minimally padded work surface (cardboard, carpet, or rubber mat recommended)
This procedure may crack or break the reflector. Always wear gloves, safety
glasses, and a dust mask when performing this procedure.
Place the reflector housing face down on your work surface so that the concave
reflector surface points downward.
7
14
12
4
9
(2 required)
2
(4 required)
13
(4 required)
1
8
10
11
Figure 9
Quantity
Required
1
4
4
1
1
1
1
2
2
4
2
2
4
1
